Hardware Specifications and Configurations 1-5

Hardware Specifications and Configurations

Features 0

The following is a brief summary of the computer’s many features:

Operating System 0

 Genuine Windows®7 Home Premium 64bit

Platform 0

 AMD Zacate E-Series dual-core processor (1 MB L2 cache, 1.6 GHz, DDR3 1066MHZ,

18W)

 AMD Hudson-M1

System Memory 0

 Dual-channel DDR3 SDRAM support:

 Up to 4 GB of DDR3 system memory, upgradable to 8 GB using two soDIMM

modules

Display 0

 17.3" HD+ 1600 x 900 resolution, high-brightness (220-nit) Acer CineCrystal™

LED-backlit TFT LCD

 16:9 aspect ratio

Graphics 0

ATI Radeon™ HD 6310 Graphics with 256 MB of dedicated system memory, supporting

Unified Video Decoder 3 (UVD3), OpenCL™ 1.1, OpenGL® 3.1, OpenEXR High

Dynamic-Range (HDR) technology, Shader Model 5.0, Microsoft® DirectX® 11

Dual independent display support

16.7 million colors

External resolution / refresh rates:6

 •VGA port up to 2560 x 1600: 60 Hz

 •HDMI® port up to 1920 x 1080: 60 Hz

MPEG-2/DVD decoding

VC-1 and H.264 (AVC) decoding

MPEG-4 Part 2 DivX® and Xvid decoding

1-6 Hardware Specifications and Configurations

Storage Subsystem 0

Hard disk drive 0

 320/500/640/750 GB or larger

2-in-1 card reader(Realtek-RTS5209-GR), supporting: 0

 Secure Digital™ (SD™) Card, MultiMediaCard™ (MMC)

Audio Subsystem 0

 Realtek ALC271X-VB3-GR

 High-definition audio support

 Two built-in stereo speaker

 MS-Sound compatible

 Built-in microphone

Optical Media Drive 0

 8X DVD Super-Multi double-layer drive:

 Read: 24X CD-ROM, 24X CD-R, 24X CD-RW, 8X DVD-ROM, 8X DVD-R, 8X

DVD+R, 8X DVD-ROM DL, 8X DVD-R DL, 8X DVD+R DL, 8X DVD-RW, 8X

DVD+RW, 5X DVD-RAM

 Write: 24X CD-R, 24X CD-RW, 8X DVD-R, 8X DVD+R, 6X DVD-R DL, 6X DVD+R

DL, 6X DVD-RW, 8X DVD+RW, 5X DVD-RAM

Communication 0

Webcam 0

 0.3M pixels UVC CAM

 1.3M pixels UVC CAM

 Acer Video Conference, featuring:

Acer Crystal Eye webcam with 640 x 480 resolution

Wireless and networking 0

 WLAN:

 Acer InviLink™ Nplify™ 802.11b/g/n Wi-Fi CERTIFIED™

 Supporting Acer signalUp™ wireless technology

 LAN:

 Atheros/ AR8151 PCI-E Fast Ethernet, Wake-on-LAN ready

Hardware Specifications and Configurations 1-7

Privacy Control 0

 BIOS user, supervisor, HDD passwords

 Kensington lock slot

Dimensions and Weight 0

Dimensions 0

 414.75 (W) x 275(D) x 34.3(H) mm (16.3 x 10.8 x 1.35 inches)

Weight 0

 2.7 kg (5.95 lbs.) with 6-cell battery pack

Power Adapter and Battery 0

ACPI 3.0 CPU power management standard: supports Standby and Hibernation

power-saving modes

Power adapter 0

 3-pin 65W AC Adapter

95 (W) x 50 (D) x 25.4 (H) mm (3.74 x 1.96 x 1 inches)

216 g (0.47 lbs) with 180 cm DC cable

Battery 0

 48Wh 4400 mAh 6-cell Li-ion standard battery pack

 Battery life: 4 hours

 ENERGY STAR®

Special Keys and Controls 0

Keyboard 0

 103-/104-/107-key Acer Finetip keyboard with independent standard numeric keypad,

international language support

Touchpad 0

 Multi-gesture function, supporting two-finger scroll, pinch, rotate, flip

Media keys 0

 Media control keys (printed on keyboard): play/pause, stop, previous, next, volume up,

volume down

I/O Ports 0

 2-in-1 card reader (SD™, MMC)

1-8 Hardware Specifications and Configurations

 Three USB 2.0 ports

 HDMI®port with HDCP support

 External display (VGA) port

 Headphone/speaker

 Microphone-in jack

 Ethernet (RJ-45) port

 DC-in jack for AC adapter

Hardware Specifications and Configurations 1-9

Optional Items 0

 1/2/4 GB DDR3 1066MHz soDIMM module

 6 cell Li-ion battery pack

 3-pin 65 W AC adapter

Software 0

Productivity 0

 Acer Backup Manager (V3.0.0)

 Acer ePower Management

 Acer eRecovery Management

 Adobe®Reader®v9.1

 Adobe®Flash®Player

 AUPEO! (US only)

 Bing™ Bar

 newsXpresso™

 Kobo™ (Canada only)

 Microsoft®Office 2010 preloaded (purchase a product key to activate)

 Microsoft®Office Starter 2010

 New York Times Reader (US only)

 NOOK for PC (US only)

 Norton™ Online Backup

Security 0

 MyWinLocker®(except China, Hong Kong)

 McAfee®Internet Security Suite Trial

Multimedia 0

 Acer clear fi

 NTI Media Maker™

Gaming 0

 Oberon Game Zone (except US, Canada, Hong Kong, Korea)

 Wild Tangent®(US, Canada only)

Communication and ISP 0

 Acer Crystal Eye

1-10 Hardware Specifications and Configurations

 Microsoft®Silverlight™

 Skype™

 Windows Live™ Essentials 2011

Web links and utilities 0

 Acer Accessory Store (Belgium, France, Germany, Italy, Netherlands, Spain, Sweden,

UK only)

 Acer Identity Card

 Acer Registration

 Acer Updater

 Netflix Shortcut (US only)

 eBay®shortcut 2009 (Canada, France, Germany, Italy, Mexico, Spain, UK, US only)

Environment 0

 Temperature:

 Operating: 0 °C to 40 °C

 Non-operating: -20 °C to 60°C

 Humidity (non-condensing):

 Operating: 20% to 80%

 Non-operating: 20% to 80%

Hardware Specifications and Configurations 1-11

Notebook Tour 0

This section provides an overview of the features and functions of the notebook.

Top View 0

Figure 1-1. Top View

Table 1-1. Top View

No Icon Item Description

1 Microphone Internal microphone for sound recording.

2 Display screen Also called Liquid-Crystal Display (LCD),

displays computer output(congiguration may

vary by model).

3 Speakers Deliver stereo audio output.

4 Power button Turns the computer on ad off.

5 Keyboard For entering data into your computer

6 Touchpad Touch-sensitive pointing device which functions

like a computer mouse.

1-12 Hardware Specifications and Configurations

7 Power indicator Indicates the computer’s power status.

Power on: Blue

Standby: Breeze mode Blue(1sec on/3 sec off)

Entering Hibernation: Blinking mode Blue(1 sec

on/1 sec off)

Hibernation/Power off: N/A

Battery Indicator INdicates the computer’s battery status.

1. Charge: The light shows amber when the

battery is charging.

2. Fully charged: The light shows blue when in

AC mode.

Full Charged: Blue

Under Charging: Orange

Battery low: Breeze mode Orange(1 sec on/3

sec off)

Battery situation: Blinking mode Orange(1 sec

on/1 sec off)

Using battery or not connected to AC

power:N/A.

8 Click buttons (left, and

right)

The left and right buttons function like the left

and right mouse buttons.

9 Integrated webcam Web camera for video communication.

Table 1-1. Top View (Continued)

No Icon Item Description

Hardware Specifications and Configurations 1-13

Left View 0

Figure 1-2. Left View

Table 1-2. Left View

No Icon Item Description

1 Kensington lock slot Connects to a Kensington-compatible computer

security lock.

NOTE:

Wrap the computer security lock cable around

an immovable object such as a table or handle

of a locked drawer. Insert the lock into the

notch and turn the key to secure the lock.

Some keyless models are also available.

2 External display (VGA)

port

Connects to a display device (e.g. external

monitor, LCD projector).

3 Ethernet (RJ-45) port Connects to an Ethernet 10/100/1000-based

network.

4 HDMI port Supports high-definition digital video connections.

5 USB 2.0 port Connects to USB 2.0 devices (e.g., USB mouse,

USB camera).

6 2-in-1 card reader Accepts Secure Digital (SD 3.0), MultiMediaCard

(MMC).

NOTE:

Push to remove/install the card. Only one card

can operate at any given time.

1-14 Hardware Specifications and Configurations

Right View 0

Figure 1-3. Right View

Table 1-3. Right View

No Icon Item Description

1 Microphone Jack Accepts inputs from external microphones.

Headphone/speaker

Jack

Connects to audio devices(eg., speakers,

headphones).

2 USB 2.0 port Connects to USB 2.0 devices (e.g., USB mouse, USB

camera).

3 Optical drive Internal optical drive; accepts CDs or DVDs.

4 Optical disk access

indicator

Lights up when the optical drive is active.

5 Optical disk eject

button

Eject the otical disk from the drive.

6 Emergency eject hole Eject the optical drive tray when the computer is

turned off.

NOTE:

Insert a paper clip to the emergency eject hole to

eject the optical drive tray when the computer is

off.

7 DC-In Jack Connects to AC adapter.
