Acer Aspire 5538 Series Manual de usuario

Aspire 5538 Series

Quick Guide

Changes may be made periodically to the information in this publication without obligation

to notify any person of such revisions or changes. Such changes will be incorporated in new

editions of this manual or supplementary documents and publications.

Record the model number, serial number, purchase date and place of purchase information in

the space provided below. The serial number and model number are recorded on the label

affixed to your computer. All correspondence concerning your unit should include the serial

number, model number and purchase information.

This booklet has been reviewed for accuracy. Although Acer makes all reasonable attempts for

this booklet to be printed in an accurate manner, Acer takes no responsibility for any

inadvertent errors or misprints. Acer's liability with respect to this booklet is subject to any

limitation of liability set out in the applicable product warranty.

No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in

any form or by any means, electronically, mechanically, by photocopy, recording or

otherwise,without the prior written permission of Acer Incorporated.

Model number: __________________________________

Serial number: ___________________________________

Date of purchase: ________________________________

Place of purchase: ________________________________

Aspire 5538 Series Quick Guide

Original Issue: 06/2009

Aspire 5538 Series Notebook PC

Acer and the Acer logo are registered trademarks of Acer Incorporated. Other companies'

product names or trademarks are used herein for identification purposes only and belong to

their respective companies.

First things first

We would like to thank you for making an Acer notebook your choice for

meeting your mobile computing needs.

Your guides

To help you use your Acer notebook, we have designed a set of guides:

First off, the Just for Starters... poster helps you get started with setting up your

computer.

The Aspire Series Generic User Guide contains useful information applying to all

models in the Aspire product series. It covers basic topics such as using the

keyboard and audio, etc. Please understand that due to its nature, the Generic

User Guide as well as the AcerSystem User Guide mentioned below will

occasionally refer to functions or features which are only contained in certain

models of the series, but not necessarily in the model you purchased. Such

instances are marked in the text with language such as "only for certain

models".

The Quick Guide introduces you to the basic features and functions of your new

computer. For more on how your computer can help you to be more productive,

please refer to the AcerSystem User Guide. This guide contains detailed

information on such subjects as system utilities, data recovery, expansion

options and troubleshooting. In addition it contains warranty information and

the general regulations and safety notices for your notebook. It is available in

Portable Document Format (PDF) and comes preloaded on your notebook.

Follow these steps to access it:

1 Click on Start, All Programs, AcerSystem.

2 Click on AcerSystem User Guide.

Note: Viewing the file requires Adobe Reader. If Adobe Reader is not

installed on your computer, clicking on AcerSystem User Guide will run the

Adobe Reader setup program first. Follow the instructions on the screen to

complete the installation. For instructions on how to use Adobe Reader,

access the Help and Support menu.

English

Your Acer notebook tour

After setting up your computer as illustrated in the Just for Starters... poster,

let us show you around your new Acer notebook.

Top view

#Icon Item Description

1 Acer Crystal Eye

webcam

Web camera for video communication.

2 Microphone Internal microphone for sound recording.

English

Hotkeys

The computer employs hotkeys or key combinations to access most of the

computer's controls like screen brightness and volume output.

To activate hotkeys, press and hold the <Fn> key before pressing the other key

in the hotkey combination.

3 Display screen Also called Liquid-Crystal Display (LCD),

displays computer output

(Configuration may vary by models).

4 Power button /

indicator

Turns the computer on and off. /

Indicates the computer's power status.

5 Keyboard For entering data into your computer.

6 Touchpad Touch-sensitive pointing device which

functions like a computer mouse.

7 Click buttons (left

and right)

The left and right buttons function like

the left and right mouse buttons.

8 Palmrest Comfortable support area for your hands

when you use the computer.

9 Touchpad toggle Turns the internal touchpad on and off.

10 Communication

key

Enables / disables the WLAN function.

Backup key Launches Acer Backup Management for

three-step data backup.

HDD Indicates when the hard disk drive is

active.

11 Eject button Presses to eject the optical disk from the

drive.

12 Speakers Left and right speakers deliver stereo

audio output.

Hotkey Icon Function Description

<Fn> + <F2> System

property

Starts System Property for displaying

system information.

<Fn> + <F3> Bluetooth Enables/disables the Bluetooth

function. (only for certain models)

<Fn> + <F4> Sleep Puts the computer in Sleep mode.

#Icon Item Description

English

<Fn> + <F5> Display

toggle

Switches display output between the

display screen, external monitor (if

connected) and both.

<Fn> + <F6> Screen

blank

Turns the display screen backlight off

to save power.

Press any key to return.

<Fn> + <F8> Speaker

toggle

Turns the speakers on and off.

<Fn> + < > Brightness

Increases the screen brightness.

<Fn> + < > Brightness

down

Decreases the screen brightness.

<Fn> + < > Volume up Increases the sound volume.

<Fn> + < > Volume

down

Decreases the sound volume.

Hotkey Icon Function Description

English

Closed front view

Rear view

#Icon Item Description

1Battery Indicates the computer's battery status.

1. Charging: The light shows amber

when the battery is charging.

2. Fully charged: The light shows blue

when in AC mode.

2 5-in-1 card reader Accepts Secure Digital (SD),

MultiMediaCard (MMC), Memory Stick

(MS), Memory Stick PRO (MS PRO), xD-

Picture Card (xD).

Note: Push to remove/install the card.

Only one card can operate at any given

time.

#Icon Item Description

1 Battery bay Houses the computer's battery

pack.

English

Left view

#Icon Item Description

1 Kensington lock slot Connects to a Kensington-compatible

computer security lock.

Note: Wrap the computer security lock

cable around an immovable object such

as a table or handle of a locked drawer.

Insert the lock into the notch and turn

the key to secure the lock. Some keyless

models are also available.

2 Ventilation slots Enable the computer to stay cool, even

after prolonged use.

3 External display

(VGA) port

Connects to a display device (e.g.,

external monitor, LCD projector).

4 HDMI HDMI port Supports high definition digital video

connections.

5 USB 2.0 port Connect to USB 2.0 devices (e.g., USB

mouse, USB camera).

6Microphone-in jack Accepts inputs from external

microphones.

Headphones/speaker/

line-out jack with

S/PDIF support

Connects to audio line-out devices

(e.g., speakers, headphones).

English

Right view

#Icon Item Description

1 Optical drive Internal optical drive; accepts CDs or

DVDs.

2 Optical disk access

indicator

Lights up when the optical drive is

active.

3 Emergency eject

hole

Ejects the optical drive tray when the

computer is turned off.

Note: Insert a paper clip to the

emergency eject hole to eject the

optical drive tray when the computer

is off.

4 USB 2.0 port Connects to USB 2.0 devices

(e.g., USB mouse, USB camera).

5 Ethernet (RJ-45)

port

Connects to an Ethernet 10/100/1000-

based network.

6 DC-in jack Connects to an AC adapter.

English

Base view

#Icon Item Description

1 Battery bay Houses the computer's battery pack.

2 Battery lock Locks the battery in position.

3 Memory compartment Houses the computer's main memory.

4 Hard disk bay Houses the computer's hard disk

(secured with screws).

5 Ventilation slots and

cooling fan

Enable the computer to stay cool, even

after prolonged use.

Note: Do not cover or obstruct the

opening of the fan.

6 Battery release latch Releases the battery for removal.
