Contents

Aspire Notebook Series

Quick Guide

Model number: __________________________________

Serial number: ___________________________________

Date of purchase: ________________________________

Place of purchase: ________________________________

Aspire Notebook Series Quick Guide

Original Issue: 07/2010

Aspire Notebook Series

First things first

We would like to thank you for making an Acer notebook your choice for

meeting your mobile computing needs.

Your guides

To help you use your Acer notebook, we have designed a set of guides:

First off, the setup poster helps you get started with setting up your computer.

The Aspire Series Generic User Guide contains useful information applying to all

models in the Aspire product series. It covers basic topics such as using the

keyboard and audio, etc. Please understand that due to its nature, the Generic

User Guide as well as the AcerSystem User Guide mentioned below will

occasionally refer to functions or features which are only contained in certain

models of the series, but not necessarily in the model you purchased. Such

instances are marked in the text with language such as "only for certain

models".

The Quick Guide introduces you to the basic features and functions of your new

computer. For more on how your computer can help you to be more productive,

please refer to the AcerSystem User Guide. This guide contains detailed

information on such subjects as system utilities, data recovery, expansion

options and troubleshooting. In addition it contains warranty information and

the general regulations and safety notices for your notebook. It is available in

Portable Document Format (PDF) and comes preloaded on your notebook.

Follow these steps to access it:

1 Click on Start > All Programs > AcerSystem.

2 Click on AcerSystem User Guide.

Note: Viewing the file requires Adobe Reader. If Adobe Reader is not

installed on your computer, clicking on AcerSystem User Guide will run the

Adobe Reader setup program first. Follow the instructions on the screen to

complete the installation. For instructions on how to use Adobe Reader,

access the Help and Support menu.

English

Your Acer notebook tour

After setting up your computer as illustrated in the setup poster, let us show

you around your new Acer notebook.

Top view

#Icon Item Description

1Acer Crystal Eye

webcam

Web camera for video communication

(only for certain models).

English

2Display screen Also called Liquid-Crystal Display (LCD),

displays computer output (configuration

may vary by model).

3Power button Turns the computer on and off.

4Keyboard For entering data into your computer.

5Touchpad Touch-sensitive pointing device which

functions like a computer mouse.

6Click buttons (left

and right)

The left and right buttons function like

the left and right mouse buttons.

7Microphone Internal microphone for sound recording.

8Power indicator Indicates the computer's power status.

Battery indicator Indicates the computer's battery status.

1. Charging: The light shows amber when

the battery is charging.

2. Fully charged: The light shows blue

when in AC mode.

HDD indicator Indicates when the hard disk drive is

active.

Communication

indicator

Indicates the computer’s wireless

connectivity device status.

9Palmrest Comfortable support area for your hands

when you use the computer.

10 Speaker Delivers audio output.

#Icon Item Description

English

Hotkeys

The computer employs hotkeys or key combinations to access most of the

computer's controls like screen brightness and volume output.

To activate hotkeys, press and hold the <Fn> key before pressing the other key

in the hotkey combination.

Hotkey Icon Function Description

<Fn> + <F3> Communication Enables/disables the computer’s

communication devices.

(Communication devices may vary by

configuration.)

<Fn> + <F4> Sleep Puts the computer in Sleep mode.

<Fn> + <F5> Display toggle Switches display output between the

display screen, external monitor (if

connected) and both.

<Fn> + <F6> Display off Turns the display screen backlight off

to save power. Press any key to

return.

<Fn> + <F7> Touchpad

toggle Turns the internal touchpad on and

off.

<Fn> + <F8> Speaker toggle Turns the speakers on and off.

<Fn> + < >Brightness up Increases the screen brightness.

<Fn> + < >Brightness

down Decreases the screen brightness.

<Fn> + < >Volume up Increases the sound volume.

<Fn> + < >Volume down Decreases the sound volume.

<Fn> +

<Home>Play/Pause Play or pause a selected media file.

<Fn> +

<Pg Up> Stop Stop playing the selected media file.

<Fn> +

<Pg Dn> Previous Return to the previous media file.

<Fn> +

<End> Next Jump to the next media file.

English

Closed front view

#Icon Item Description

1Microphone jack Accepts inputs from external

microphones.

Headphone/speaker/

line-out jack

Connects to audio line-out devices

(e.g., speakers, headphones).

22-in-1 card reader Accepts Secure Digital (SD),

MultiMediaCard (MMC).

Note: Push to remove/install the card.

Only one card can operate at any given

time.

Rear view

#Icon Item Description

1Battery bay Houses the computer's battery pack.

English

Left view

#Icon Item Description

1Kensington lock slot Connects to a Kensington-compatible

computer security lock.

Note: Wrap the computer security lock

cable around an immovable object such as

a table or handle of a locked drawer. Insert

the lock into the notch and turn the key to

secure the lock. Some keyless models are

also available.

2DC-in jack Connects to an AC adapter.

3Ventilation slots Enable the computer to stay cool, even

after prolonged use.

4External display

(VGA) port

Connects to a display device (e.g.,

external monitor, LCD projector).

5Ethernet (RJ-45) port Connects to an Ethernet 10/100/1000-

based network.

6HDMI port Supports high-definition digital video

connections.

7USB 2.0 port Connects to USB 2.0 devices (e.g., USB

mouse, USB camera).

2134567
