Acer Digital camera 6.36 Mega pixels Manual de usuario

EN-1

Contents

3 INTRODUCTION

4 Package Contents

5 GETTING TO KNOW YOUR CAMERA

5 Front View

6 Rear View

7 Mode Dial

8 LCD Monitor Information

10 PREPARING THE CAMERA

10 Installing the Batteries

11 Using the AC Adapter (Optional Accessory)

12 Inserting and Removing an SD Memory Card (Optional Accessory)

13 GETTING STARTED

13 Turning the Power On/Off

13 Choosing the Screen Language

14 Setting the Date and Time

15 Formatting an SD Memory Card or Internal Memory

16 Using the LCD Monitor

17 PHOTOGRAPHY MODE

17 Shooting Images

18 Setting Image Resolution and Quality

19 Using the Zoom Function

20 Using the Flash

21 Setting Focus

22 Capture Mode

22 Burst

23 Self-Timer

24 Adjusting the Exposure (EV Compensation)

25 Setting White Balance

26 USING THE MODE DIAL

27 PLAYBACK MODE - THE BASICS

27 Viewing Images

28 Magnifying Images

29 Thumbnail Display

EN-2

30 MOVIE MODE

30 Recording Movie Clips

31 Playing Back Movie Clips

32 PLAYBACK MODE - ADVANCED FEATURES

32 Playing Back Still Images/Movie Clips on TV

33 Deleting Images/Movie Clips

34 Connecting to a PictBridge-Compatible Printer

38 TRANSFERRING FILES FROM YOUR DIGITAL CAMERA TO COMPUTER

38 Step 1: Install the USB driver

39 Step 2: Connect the digital camera to your computer

40 Step 3: Download images or movie clips

41 EDITING SOFTWARE INSTALLATION

41 Installing NTI Photo Suite (Optional)

42 USING THE DIGITAL CAMERA AS A PC CAMERA

42 Step 1: Install the PC camera driver

43 Step 2: Connect the digital camera to your computer

43 Step 3: Run your application software (i.e. Windows NetMeeting)

44 MENU OPTIONS

44 Camera Menu

49 Movie Menu

50 Playback Menu

53 Setup Menu

57 SPECIFICATIONS

EN-3

INTRODUCTION

Thank you for purchasing the new digital still camera!

Equipped with a 6.36 Mega pixels CCD sensor, your camera delivers high quality,

2816 x 2112 resolution images. Other features provided by the camera include the

following:

6.36 Mega pixels

A high-resolution CCD sensor provides 6.36 mega pixels for high quality of

images.

Auto flash

An auto flash sensor automatically detects the shooting (lighting) conditions and

determines whether the flash should be used.

2.36” TFT color image LCD monitor

Optical zoom: 1x~3x

Digital zoom: 1x~4x

Approx. 8MB internal (built-in) memory

Images can be captured without using an SD memory card.

Support for SD memory card for memory expansion

You may wish to expand the memory capacity (up to 1GB capacity) by using an

additional SD memory card.

USB connection

Still images or movie clips that you have recorded can be downloaded to your

computer using the USB cable (A USB driver is required for Win 98 and

Win98SE).

DPOF functionality

DPOF can be used to print your images on a DPOF compatible printer by simply

inserting the SD memory card.

PictBridge support

You can connect the camera directly to a printer that supports PictBridge and

perform image selection and printing using the camera monitor screen and

controls.

Provided editing software: NTI Photo Suite

You can enhance and retouch your images on your computer by using the

provided editing software.

EN-4

Package Contents

Carefully unpack your kit box and ensure that you have the following items. In the

event that any item is missing or if you find any mismatch or damage, promptly

contact your dealer.

Common Product Components:

Digital camera

User’s manual

Camera strap

USB cable

2 AA batteries(Alkaline or Ni-MH recommended)

Warranty card

Common (Optional) Accessories:

SD memory card

Battery charger

AC power adapter

Software CD-ROM

Camera pouch

AV cable

Accessories and components may vary by retailer.

EN-5

GETTING TO KNOW YOUR CAMERA

Front View

1. Shutter release button

2. Mode dial

3. Power switch

4. Flash

5. Self-timer LED

6. PC / AV terminal

7. DC input terminal

8. Lens

9. Microphone

EN-6

Rear View

1. LED indicator

2. / Zoom in (telephoto)

button

/ Zoom out (wide-angle)

button

3. Playback button

4. Menu button

5. Delete button

6. Self-timer button

7. Focus button

8. Strap holder

9. Exposure compensation

button

10. Flash button

11. button

Display button

12.Battery / card cover

13.Tripod socket

14. LCD monitor

EN-7

Mode Dial

You can select from seven shooting modes and setup mode according to shooting

conditions to achieve the desired effect.

Mode Description

1. Program Select this mode to permit the shutter speed and

aperture to be set manually.

2. Portrait Select this mode to make people stand out with the

background out-of-focus.

3. Landscape Select this mode to take phototgraphs of distant scenery

or landscapes.

4. Sports Select this mode to shoot fast moving objects.

5. Night Select this mode to take phototgraphs of people against

a dusk or night-time background.

6. Setup Select this mode to adjust the camera settings.

7. Video Select this mode to record video clips.

8. Auto Select this mode to adjust point-and-shoot action.

EN-8

LCD Monitor Information

+0.3

2.2X

5321 4

Camera Mode

1. Mode indication

[ ] Program Mode

[]PortraitMode

[ ] Landscape Mode

[ ] Sports Mode

[ ] Night Mode

[]SetupMode

[ ] Movie Mode

[ ] Auto Mode

2. Flash mode

[]Auto

[]Redeye

[ ] Flash on

[ ] Flash off

3. Capture mode

[]Single

[]Burst

[ ] AEB

[ ] 2 sec. Self-timer

[ ] 10 sec. self-timer

[ ] 10+2 sec. Self-timer

4. Focus mode

[ ] Standard

[]Macro

[ ] Infinity

5. Possible number of shots

6. Memory status

: Built-in memory

(without card)

: SD memory card

7. Battery and AC adapter

[ ] Full battery power

[ ] Medium battery power

[ ] Low battery power

[ ] No battery power

[ ] AC adapter

8. Recorded pixels

[ ] 2816 x 2112

[ ] 2272 x 1704

[ ] 1600 x 1200

[ ] 640 x 480

9. Image quality

[]Fine

[]Normal

[ ] Economy

10. White balance

Auto

[ ] Daylight

[ ] Cloudy

[ ] Tungsten

[]Fluorescent

11. ISO sensitivity

[ ] Auto

[]64

[]100

[]200

12. EV compensation

13. Zoom bar

14. Focus area

EN-9

Movie Mode

1. Movie mode

2. Flash mode

3. Recordable movie time available

4. Memory status

5. Battery power and AC adapter

indicator

6. Focus area

7. Zoom bar

Image Playback

1. Playback mode

2. Number of image

3. Memory status

4. Battery power and AC adapter

indicator

5. Index number of total number

6. DPOF indicator

7. Protect indicator

8. Date

9. Time

10.EV compensation

11.ISO sensitivity

12. White balance

13. Image quality

14. Recorded pixels

Movie Playback

1. Playback mode

2. Movie mode

3. Number of movie

4. Memory status

5. Battery power and AC adapter

indicator

6. Index number of total number

7. Elapsed time

8. Date

9. Time

10. Play/Pause indicator

00:49

321

12:00

12:00+0.3

+0.3

ISO 100

ISO 100 01/01/2006

01/01/2006

1/7

100-0001

12:01

01/01/2006

1/7

100-0001

00:05

31 2

EN-10

PREPARING THE CAMERA

Installing the Batteries

You can use 2 AA size batteries (alkaline or Ni-MH rechargeable) to power the

camera. Make sure that the power of the digital camera is off before inserting or

removing the batteries.

1. Make sure the camera is turned off.

2. Open the battery cover.

3. Insert the batteries in the correct

orientation as shown in the illustration.

4. Close the battery cover.

To remove the batteries, turn the

camera off before removing batteries

and hold the camera with the battery

cover facing upward, then open the

battery cover.

Be careful not to drop the batteries when opening or closing the battery cover.

Due to the characteristics of AA alkaline battery, camera performance may deteriorate. AA

alkaline battery is not recommended except in emergencies and checking the camera's

functionality.
