Acer Aspire E700 Manual de usuario

Acer

Aspire E700

Service Guide

PRINTED IN TAIWAN

Service guide files and updates are

available on the ACER/CSD web. For

more information, please refer to http:/

/csd.acer.com.tw

Revision History

Please refer to the table below for the updates of Desktop Aspire E700 service guide.

Date Chapter Updates

September 8, 2006 first release

III

reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any

language or computer language, in any form or by any means, electronic, mechanical, magnetic,

optical, chemical, manual or otherwise, without the prior written permission of Acer

Incorporated.

Disclaimer

The information in this guide is subject to change without notice.

Acer Incorporated makes no representations or warranties, either expressed or implied, with

respect to the contents hereof and specifically disclaims any warranties of merchantability or

fitness for any particular purpose. Any Acer Incorporated software described in this manual is

sold or licensed “as is”. Should the programs prove defective following their purchase, the buyer

(and not Acer Incorporated, its distributor, or its dealer) assumes the entire cost of all necessary

servicing, repair, and any incidental or consequential damages resulting from any defect in the

software.

Acer is a registered trademark of Acer Incorporated.

Other brand and product names are trademarks and/or registered trademarks of their respective

holders.

Conventions

The following conventions are used in this manual:

SCREEN MESSAGES Denotes actual messages that appear on screen.

NOTE Gives bits and pieces of additional information

related to the current topic.

WARNING Alerts you to any damage that might result from

doing or not doing specific actions.

CAUTION Gives precautionary measures to avoid possible

hardware or software problems.

IMPORTANT Reminds you to do specific actions relevant to the

accomplishment of procedures.

Preface

Before using this information and the product it supports, please read the following general

information.

1. This Service Guide provides you with all technical information relating to the BASIC CONFIGURATION

decided for Acer's “global” product offering. To better fit local market requirements and enhance

product competitiveness, your regional office MAY have decided to extend the functionality of a

machine (e.g. add-on card, modem, or extra memory capability). These LOCALIZED FEATURES will NOT

be covered in this generic service guide. In such cases, please contact your regional offices or the

responsible personnel/channel to provide you with further technical details.

2. Please note WHEN ORDERING FRU PARTS, you should check the most up-to-date information available

on your regional web or channel. For whatever reason, if a part number change is made, it will not be

noted in the printed Service Guide. For ACER-AUTHORIZED SERVICE PROVIDERS, your Acer office may

have a DIFFERENT part number code to those given in the FRU list of this printed Service Guide. You

MUST use the list provided by your regional Acer office to order FRU parts for repair and service of

customer machines.

TOC VII

Table of Contents

Chapter 1 System Specification 1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Main Board . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Special Design Specification . . . . . . . . . . . . . 3

Wake-Up Event Specification . . . . . . . . . . . . . 4

Block Diagram . . . . . . . . . . . . . . . . . . . . . . . 5

Main Board Placement . . . . . . . . . . . . . . . . 6

Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Acer Empowering Technology . . . . . . . . . 11

Empowering Technology password . . . . . . 11

Acer eRecovery Management . . . . . . . . . . . 12

Acer eDataSecurity Management . . . . . . . 13

Acer ePerformance Management . . . . . . . 15

Acer eRecovery . . . . . . . . . . . . . . . . . . . . . . 16

Create Backup . . . . . . . . . . . . . . . . . . . . . . . . 16

Restore from Backup . . . . . . . . . . . . . . . . . . 16

Create Factory Default Image CD . . . . . . . . 16

Re-install Bundled Software without CD . . 17

Change Password . . . . . . . . . . . . . . . . . . . . . 17

Acer Disc-to-Disc Recovery . . . . . . . . . . . . . 18

Restore without a Recovery CD . . . . . . . . . . 18

Multilingual Operating System Installation 18

Hardware Specification and Configuration

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Power Management Function . . . . . . . . . . 25

Device Standby Mode . . . . . . . . . . . . . . . . . 25

Global Standby Mode . . . . . . . . . . . . . . . . . 25

Suspend Mode . . . . . . . . . . . . . . . . . . . . . . . 25

ACPI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Chapter 2 Setup Utility 26

About the Setup Utility . . . . . . . . . . . . . . . 26

Control Keys . . . . . . . . . . . . . . . . . . . . . . . . . 26

VIII TOC

Entering the Setup Utility . . . . . . . . . . . . . 27

Product Information . . . . . . . . . . . . . . . . . 28

Standard CMOS Features . . . . . . . . . . . . . . 29

Advanced BIOS Features . . . . . . . . . . . . . . 30

Advanced Chipset Features . . . . . . . . . . . . 34

Integrated Peripherals . . . . . . . . . . . . . . . . 35

Power Management Setup . . . . . . . . . . . . 40

PnP/PCI Configurations . . . . . . . . . . . . . . . 42

PC Health Status . . . . . . . . . . . . . . . . . . . . . 43

Frequency Control . . . . . . . . . . . . . . . . . . . 44

Load Default Settings . . . . . . . . . . . . . . . . . . 45

Set Supervisor/User Password . . . . . . . . . . . 45

Save and Exit Setup . . . . . . . . . . . . . . . . . . . 45

Exit without Saving . . . . . . . . . . . . . . . . . . . 45

Chapter 3 Machine Disassembly and Replacement 46

General Information . . . . . . . . . . . . . . . . . 46

Before You Begin . . . . . . . . . . . . . . . . . . . . . 46

Aspire E700 Disassembly Procedure . . . . . 47

Chapter 4 Troubleshooting 53

Chapter 5 Jumper and Connector Location 54

Main Board Placement . . . . . . . . . . . . . . . 54

Introduction of Connectors and Headers . 56

System Board Jumper Setting . . . . . . . . . . . 56

System Board Header Setting . . . . . . . . . . . 56

Chapter 6 FRU (Field Replaceable Unit) List 62

Exploded Diagram . . . . . . . . . . . . . . . . . . . 63

Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Chapter 1 1

Overview

Main Board

Description

Size Max. 244 mm x 244 mm, MicroATX

Processor • Socket type: Intel socket T LGA775 pin

• Socket quantity: one

• Intel Prescott 775 / Smithfield / Cedar Mill / Presler / Conroe, core speed

533/800/1066MHz

System Chipset • GMCH: Intel G965

• ICH: Intel ICH8DH

• Super I/O: ITE8718

Memory • Four DDR2 connectors

• Capacity:

• 256MB to 1GB DDR2 800/667/533 unbuffered SDRAM module support

• Feature support 2GB DDR2 800/667/533 unbuffered SDRAM module

when memory sample passes validation

• Max. 256MB to 4GB memory support

• Feature support to 8GB max. memory support when memory sample

passes validation.

• Dual-channel function enabled when plugging in two same memory

size DDR2 memory modules

Onboard Graphic

Solution

• Intel G965 on-die graphic (Intel GMA X3000) solution

• DVMT 4.0 technology support

• Enhanced 3D and clear video technology support

• Dual view function supported by Intel ADD2/ADD2+

• One D-sub VGA port on the rear side

PCI Express / PCI

Slots

• One PCI Express x16 slot

• One PCI Express x1 slot

• Two PCI 2.3 slots

FDD • One slot for FDD

• 1.44MB / 3 mode 3.5” devices support

SATA • Six SATA slots

• Storage type support:

• HDD / CD-ROM / CD-RW / DVD-ROM / DVD-RW / DVD+RW / DVD Dual /

DVD SuperMultiPlus / Blue-Ray ODD

System Specification

Chapter 1

2Chapter 1

Audio • Chip: HD audio codec ALC888 HD codec 7.1 with S/PDIF out

• Connectors support (at least):

• Rear six jacks that follow HD audio definition

• Front microphone in

• Front headphone out

• S/PDIF out header (1*4)

• AUX-in

• Front panel audio header (2*5) support

• HD de-pop CKT added

• S/N ration: 90 dB at rear output jack

LAN • Controller: Intel ICH8DH

USB • Controller: ICH8DH

• Ten port quantity:

• Four back panel ports

• Four ports for front daughter board

• Two ports for card reader + IR

• Connector pin: standard Intel FPIO pin definition

• Date transfer rate support: USB 2.0/1.1

1394 • Controller: Ti TSB43AB23PDTG4

• One onboard header

• One six-pin 1394 port

Front Panel IO

Header

Hardware Monitor • Controller: Super I/O ITE8718

• Intel broadwater: ICH8 SST

• Voltage: Vcore / +12V / +5V / +3.3V / +12.5V / 5VSB

System LDE

Definition

• Power state LED:

• S0: blue steady

• S1/S3: blue blinking

• S4/S5: off

• Storage state LED:

• Active: blue blinking

• Idle: off

• LAN state LED:

• LAN active: blue blinking

• LAN idle: off

• Voltage bias: 5V

• Current: 10mA to 15 mA
