Acer Aspire G600 Manual de usuario
Copyright Notice
©Acer Incorporated 2002. All rights reserved.
Acer Incorporated reserves the right to change product specifications and the
information contained in this user guide without notice.
No part of this document may be copied, reproduced, or transmitted by any
means, or for any purpose, without prior written permission from Acer
Incorporated.
Table
of Contents
Welcome 1
Major Benefits 2
Before You Start 2
Safety Instructions 2
Setting Up The System 3
Placement Tips 3
System Overview 4
Computer Front View 4
Computer Rear View 6
System Components 8
System Components 9
The Mouse 9
The Keyboard 12
The Speakers 15
The Monitor 16
Audio DJ 17
Cd Storage Unit 18
3-in-1 Flash Card Readers 19
TV Tuner (Optional) 21
Upgrading Your System 23
Opening The Case 23
Installing New Components 25
BIOS Settings 26
Questions & Troubleshooting 43
General System Problems 43
Cordless Keyboard/Mouse Problems 45
1
Welcome
Congratulations on purchasing your new Aspire
computer! You now have the convenience and
flexibility of a full-featured multimedia PC, offering
increased productivity combined with first class
digital entertainment. Incorporating the latest
Microsoft®Windows®XP operating system, your
Aspire offers a host of functions designed to improve
your computing experience.
Major Benefits
Your new Aspire computer enables you to do the
following:
•Use the latest productivity software to perform a
range of office tasks, such as word processing,
working with financial spreadsheets and creating
presentations.
•Maximize your use of the Internet by download-
ing and playing exciting new multimedia files.
•Enjoy your audio CDs, even when you are not
using your computer for other tasks.
•Delight in using a stylish new PC that offers con-
venient connections for the latest peripherals.
2
Before You Start
To ensure that you can use your computer safely and
correctly, please read this user guide carefully before
you start. For future reference, keep this user guide
handy at all times.
Safety Instructions
•Follow all warnings and instructions marked on
your computer.
•Do not attempt to service your computer your-
self. Refer servicing to qualified personnel.
•Unplug your computer and monitor from the
wall outlet before cleaning or before opening
the case.
•Clean your computer case and monitor with a
damp cloth. Do not use liquid or aerosol cleaners.
•Do not use your computer near water. Never spill
liquid of any kind on your computer.
•Do not place your computer on an unstable sur-
face.
•Do not expose your computer to a heat source or
leave it in direct sunlight for a prolonged period
of time.
•Do not cover or block any ventilation slots in the
case. Also, ensure the room has adequate ventila-
tion.
•Never push objects of any kind into your com-
puter.
•Do not allow anything to rest on the power cord.
Do not locate your computer where anyone will
walk on the power cord.
•Your computer should be operated from the type
of power indicated on the marking label. If you
are unsure of the type of power available, con-
sult your dealer or local power company.
•Your computer is designed for connection to a
grounded (earthed) outlet. Do not disable this
important safety feature.
•If a power strip is used, make sure that the total
ampere rating of the equipment does not exceed
the power strip ampere rating. Use a power strip
with surge protection.
3
•If your computer causes interference to radio or
television reception, try one or more of the fol-
lowing measures:
-Reorient or relocate the radio or television
antenna.
-Increase the distance between your computer
and the radio or television receiver.
-Connect your computer into an outlet on a
circuit different from that to which the radio
or television is connected.
-Consult your dealer or an experienced radio/
TV technician for more help.
Setting Up The System
It only takes a few minutes to set up your new Aspire
system. Start by preparing your workspace. Make
sure that the surface is stable, level and clean.
Open the box carefully, ensuring that you do not
damage the box or any of the other packing
materials. The box will be required if you ever have to
store or ship your computer. Unpack the box and set
out the contents on your work surface.
The package contains an Out Of Box Experience
(OOBE) poster. Refer to the OOBE poster for a step-
by-step guide to setting up your computer system.
Placement Tips
• For maximum viewing comfort, set up your mon-
itor at arm’s length from your seat, with the top
third of the screen at eye level. Tilt and swivel the
display to find the optimum position.
•Place your mouse and keyboard side by side in
front of the monitor. Check that you are able to
adopt a comfortable typing position.
•Choose a chair that can be adjusted for maximum
comfort.
•Make sure your work area is well lit.
4
System Overview
Take a few moments to study your new Aspire
computer system. Learn the locations of the buttons,
ports and other hardware features.
Computer Front View
* Only applies to Aspire G600.
No Description
1CD Storage Unit*
2Audio DJ
3Drive Door*
4CD-ROM/DVD/CD-RW Drive
5FDD Drive
6Front Port Bay Door*
7Front Port Bay
8Memory Stick Reader
9SD/MMC Reader*
10 Microphone-in Port
11 Speaker/ Headphone Port
12 USB Port
13 1394 Port (Optional)
14 Power Button
15 Wireless Connect Button*
5
Aspire G600
Aspire M500
6
Computer Rear View
No. Description
1Power Jack
2Voltage Selector Switch
3Fan
4PS/2 Keyboard Port
5PS/2 Mouse Port
6USB Port
7Lan Port
8Serial Port
9Ventilation slot
10 Parallel Port
11 VGA Port
12 Audio Ports
13 Game Port
14 PCI Card slots
7
Aspire G600
Aspire M500
8
System Components
•Monitor - refer to page 16
•Keyboard - refer to page 12
•Mouse - refer to page 9
•Speakers - refer to page 15
