Abus Secvest IP Manual de usuario

FUAA10011

Secvest IP

wireless alarm centre

Installation and operating instructions (UK)

02032012

1 Contents

1. Contents

1.Contents 1

2.Preface 2

3.Conformity 2

4.Meaning of the symbols 3

5.Important safety information 3

6.Scope of delivery 7

7.Compatibility with ABUS products 8

8.Installation 9

9.Installation of the backup battery (backup power supply) 10

10.Display and setting elements 11

11.Labelling the Secvest IP 16

12.Putting into operation 16

13.Enclosed software 17

14.Configuration of the web server 18

15.Teaching the wireless components 66

16.Alarm types and notification 74

17.Resetting an alarm 75

18.Maximum system extension 75

19.Firmware display of wireless PCB 77

20.Information on additional ABUS products 77

21.Notes on maintenance 77

22.Technical data 78

23.Customer service and support 79

24.Explanation of terms 80

2 Preface

2. Preface

Dear customer,

Many thanks for your purchase of this Secvest IP wireless alarm centre. This product

is built according to state-of-the-art technology. It complies with current domestic and

European regulations. Conformity has been proven, and all related certifications are

available from the manufacturer on request (www.abus-sc.com). To ensure safe

operation, it is your obligation to observe these instructions! If you have any

questions, please contact your local specialist dealer. No part of the product may be

changed or modified in any way.

These instructions contain important installation and operation information. Store

these instructions in a safe place for future reference. These instructions are part of

the product. Bear this in mind if you pass the product on to others.

Disclaimer:

These operating instructions have been produced with the greatest care. Should you

discover any missing information or inaccuracies, please contact us under the

address shown.

ABUS Security-Center GmbH does not accept any liability for technical and

typographical errors, and reserves the right to make changes to the product and

operating instructions at any time and without prior warning.

We reserve the right to make changes to these instructions without prior notice. No

forms of guarantee are accepted for the contents of this document.

3. Conformity

The declaration of conformity can be ordered from:

ABUS Security-Center GmbH & Co. KG

Linker Kreuthweg 5

86444 Affing

GERMANY

www.abus-sc.com

[email protected]

4 Meaning of the symbols

4. Meaning of the symbols

Disposal as per directive WEEE 2002/96 EC

At the end of its useful life, dispose of the product according to the

applicable legal requirements. Within the EU, the product and its

accessories must be collected and disposed of separately.

Devices displaying this symbol may not be disposed of as

domestic waste. Please contact your dealer or dispose of the

products at the local collection point for electronic waste.

This symbol indicates important notes in these operating

instructions, which must be observed.

This symbol indicates special tips and notes on the operation of

the unit.

5. Important safety information

5.1 Intended use

Only use the device for the purpose which it was designed and built for. Any other

use is considered inappropriate.

This device may only be used for the following purpose(s):

•This three-zone IP wireless alarm centre is used in combination with connected

wireless detectors, signallers, actuators and operating units for object

surveillance.

5.2 General

Before using the device for the first time, read the following instructions carefully and

pay attention to all warnings, even if you are already familiar with electronic devices.

5 Important safety information

Warning

All guarantee claims become invalid for damage caused by non-

compliance with these operating instructions.

We cannot be held liable for resulting damages.

Warning

We cannot be held liable in the event of material or personal damage

caused by improper operation or non-compliance with the safety

information.

All guarantee claims are invalid in such cases.

Keep this manual in a safe place for future reference.

If you pass on or sell the device, you must also include this user manual. This device

has been manufactured in accordance with international safety standards. Inspect

the device before putting it into operation. If the device shows signs of damage, do

not put it into operation.

5.3 Power supply

•Only operate this device through a power source which supplies the mains power

specified on the type plate of the power supply unit.

•If you are unsure of the power supply at the installation location, contact your

power supply company.

•Only operate this device with the device-specific power supply unit.

•This device uses Safety Extra Low Voltage (SELV). The circuits of the switch

outputs and the 13.8 V power supply also fall into this voltage range. SELV is a

low electrical current that offers special protection against electric shocks based

on its low level and insulation compared to higher voltage circuits.

Warning

The installation of additional equipment or modification of the device

invalidates your guarantee if not carried out by trained personnel.

Your guarantee is invalidated in the event of improper installation o

additional equipment or modifications.

5.4 Overloading/overvoltage

•Avoid overloading of mains sockets, extension cables and adapters as this can

result in fires or electric shocks.

•Use overvoltage protection to prevent damage caused by overvoltage (e.g.

electrical storms).

5 Important safety information

5.5 Cables

•Always hold cables by the connector, and do not pull the cable itself.

•Never touch the mains cable with wet hands, as this can lead to a short circuit or

electric shock.

•Never position the device, furniture or other heavy items on the cable. Ensure

that the cable does not become kinked, especially on the connector and sockets.

•Never knot the cable, and do not tie it to other cables.

•All cables should be laid so that they cannot be stepped on or cause an

obstruction.

•A damaged mains cable or power supply unit can cause a fire or electric shock.

Check the mains cable from time to time.

•Do not modify or manipulate the mains cable or plug.

•Do not use plug adapters or extension cables that do not conform to the

applicable safety standards, and do not make alterations to power supply cables

or mains cables.

5.6 Installation location/operating environment

•Install the device on the wall and do not place any objects in front of it.

•The device is not designed for operation in rooms subject to high temperatures

or moisture (e.g. bathrooms), or in excessively dusty rooms.

•Operating temperature and ambient humidity:

-10°C to +55°C, maximum 75% relative humidity. The device may only be

operated in moderate climate conditions.

Ensure the following:

•Sufficient ventilation must always be guaranteed – leave a gap of at least 10 cm

from all sides.

•The device must not be exposed to direct heat sources (e.g. heaters).

•The device must not be exposed to direct sunlight or strong artificial light.

•The device must not be placed in close proximity to magnetic fields

(e.g. loudspeakers).

•Naked flames (e.g. candles) must not be placed on or near the device.

•Contact with spraying or dripping water and aggressive liquids must be avoided.

•The device must not be operated in close proximity to water, and must not be

submerged under any circumstances (do not place objects containing water on

or near the device, such as vases or drinks).

•Foreign objects must not penetrate the device.

5 Important safety information

•The device must not be exposed to strong variations in temperature, as this can

lead to condensation and electrical short circuits.

•The device must not be exposed to excessive jolts or vibrations.

5.7 Care and maintenance

Maintenance is necessary if the device has been damaged. This includes damage to

the plug, mains cable and housing, penetration of the interior by liquids or foreign

objects, exposure to rain or moisture or when the device does not work properly or

has fallen.

•Disconnect the device from the mains power supply before maintenance (e.g.

cleaning).

•If smoke develops or unusual noises or odours are detected, then pull the mains

plug from the socket immediately and remove the backup battery. In such cases,

the device should not be used until it has been inspected by a qualified

technician.

•Clean the device housing with a damp cloth.

•Do not use solvents, white spirit or thinners as these can damage the surface of

the device.

•Do not use any of the following substances:

Salt water, insecticides, solvents containing chlorine or acids (ammonium

chloride) or scouring powder.

•Gently rub the surface with a cotton cloth until it is completely dry.

5.8 Accessories

•Only connect devices that are suitable for the intended purpose. Otherwise,

hazardous situations or damage to the device can occur.

5.9 Putting into operation

•Observe all safety and operating instructions before putting the device into

operation for the first time.

•Only open the housing during installation and when training the wireless

components.

Warning

If in doubt, have a specialist technician carry out assembly, installation

and connection of the device.

Improper or unprofessional work on the mains power supply puts both

you and other persons at risk.

6 Scope of delivery

5.10 Children and the device

•Do not allow children access to electrical devices. Never allow children to use

electrical devices without supervision. Children may not be able to accurately

detect possible risks. Small parts can be life-threatening if swallowed.

•Keep batteries away from small children. Call for medical assistance immediately

if a battery is swallowed.

•Keep packaging materials away from children (danger of suffocation).

•This device should not be used by children.

6. Scope of delivery

Individual alarm centre:

1 x Secvest IP wireless alarm centre

1 x power supply unit

1 x backup battery

1 x 1 metre network cable

1 x Quick guide

1 x CD-ROM (installation and operating instructions, Secvest IP Finder, labelling

templates)

1 x installation material (4 x wall plugs, 4 x screws)

1 x battery cable

2 x cable clips

7 Compatibility with ABUS products

7. Compatibility with ABUS products

Compatible

CASA10010 IP alarm module

FU59xx Secvest Key 2WAY wireless cylinder

FU8100 Secvest 2WAY wireless remote control

(integrated panic function not usable)

FU8130 Secvest 2WAY wireless additional lock (7010E)

FU8140 Secvest 2WAY wireless additional lock (7025E)

FU8150 Secvest wireless remote control

(integrated panic function not usable)

FU8200 Secvest 2WAY wireless info module

(No display of: status ready / internally active / entry-

and exit delay time)

FU8210 / FU8211 Secvest 2WAY wireless universal module

(only repeater function)

FU8220 / FU8222 Secvest 2WAY wireless outdoor siren

(Beep acknowledgement as of FU8222)

FU8230 Secvest 2WAY wireless indoor siren

FU8240 Secvest wireless socket

FU8300 Secvest 2WAY wireless panic alarm

FU8305 Secvest 2WAY wireless panic transmitter

FU8310 Secvest 2WAY wireless fire alarm

FU8320W/B Secvest 2WAY wireless magnetic contact

FU8321W/B Secvest 2WAY wireless magnetic contact

FU8325W/B/S Secvest 2WAY mini wireless magnetic contact

FU8330 Secvest 2WAY wireless flood detector

FU8340 / FU8341 Secvest 2WAY wireless smoke detector

FU8350 Secvest 2WAY wireless motion detector

FU8360 Secvest 2WAY animal-immune wireless motion

detector

FU8370 Secvest 2WAY wireless glass breakage detector

FU8380 Secvest 2WAY wireless vibration detector

FU8390 Secvest 2WAY wireless emergency transmitter

FU841xW/B FTS 96 E wireless window lock

FU842x Secvest 2WAY wireless window bar lock (FOS550E)

FU8430W/B/S Secvest 2WAY wireless window handle (FG350E)

FU8435W/B/S Secvest 2WAY wireless window handle plus

TVIP41550 PIR network camera

Not compatible

FU8110 Secvest 2WAY wireless control unit

FU8165 Secvest 2WAY wireless key switch

8 Installation

8. Installation

Key:

A) Wall tamper switch

B) Housing screw

C) Fixing holes on base plate

D) Cable opening

E) Tension relief (bar for fastening cable to cable clip)

Installation procedure:

1. Loosen the housing screw on the bottom narrow side and open the housing.

2. Using the back of the housing as a template, mark the drill holes (C).

Drill the holes for the fixing screws.

3. Guide the connection cable through the appropriate opening (D).

4. Connect the power supply to the terminal block with the correct polarity

(grey dashed wire is positive).

5. Connect the LAN cable (see following diagram).

13.8 V DC

(power supply unit)

Power supply for

optional BT2020

backup battery

Tabla de contenidos

Otros manuales de Sistema de seguridad de Abus

Abus

Abus FUEM30000 Manual de usuario

Abus

Abus Secvest 2WAY Manual de usuario

Abus

Abus FG300A Manual de usuario

Abus

Abus DTS3218 Manual de usuario

Abus

Abus FUSG50010 Manual de usuario

Abus

Abus Bordo 6000 Alarm Manual de usuario

Abus

Abus FU8300 Manual de usuario

Abus

Abus CASA10010 Manual de usuario

Abus

Abus TVAC26030 Manual de usuario

Abus

Abus Security Center Eyseo TV7171 Manual de usuario

Abus

Abus 2510 Manual

Abus

Abus FUWM30000 Manual de usuario

Abus

Abus 56829 9 Manual de usuario

Abus

Abus Smartvest FUSG35000A Manual de usuario

Abus

Abus PPDF16000 Manual de usuario

Abus

Abus FUSG50000 Manual de usuario

Abus

Abus Smartvest FUMK35000 Manual de usuario

Abus

Abus TVAC18000A Manual de usuario

Abus

Abus FUBE35001A Manual de usuario

Abus

Abus TVAC15000 Manual de usuario

Abus

Abus Outdoor motion detector PIR Manual de usuario

Abus

Abus Secvest FU8006 Manual de usuario

Abus

Abus GWM100ME Manual de usuario

Abus

Abus TVAC14000A Manual de usuario

Manuales populares de Sistema de seguridad de otras marcas

Inner Range

Inner Range Concept 2000 Manual de usuario

Climax

Climax Mobile Lite R32 Instrucciones de montaje

CADDX

CADDX NX-6 Manual de usuario

FBII

FBII XL-31 Series Manual de usuario

Johnson Controls

Johnson Controls PENN Connected PC10 Manual de usuario

Aeotec

Aeotec Siren Gen5 Manual de usuario

Blaupunkt

Blaupunkt SA 2700 Manual de usuario

IDEAL

IDEAL Accenta Manual del propietario

AJAX

AJAX DoubleButton Manual de usuario

Swann

Swann SW-P-MC2 Manual de usuario

Ecolink

Ecolink Siren+Chime Manual de usuario

Digital Monitoring Products

Digital Monitoring Products XR150 Manual de usuario

EDM

EDM Solution 6+6 Wireless-AE Manual de usuario

Highway Safety Group

Highway Safety Group EA401 Manual de usuario

Siren

Siren LED GSM Manual de usuario

Detection Systems

Detection Systems 7090i Instrucciones de montaje

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manual de usuario

Siemens

Siemens FDM273 Manual de usuario
