IPCV10000 / IPCV10010 / IPCV10020

User manual

This user manual contains important information for installation and operation.

This should be also noted when this product is passed on to a third party.

Therefore look after these operating instructions for future reference!

Version 04/2019


2

D INHALT
Declaration of conformity............................................................................................ 3
GNU GPL License note.............................................................................................. 3
IPCV10000 –ABUS IP Camera Viewer (1-channel) .................................................. 4
Features.................................................................................................................. 4
Specification............................................................................................................ 4
LED Display............................................................................................................ 5
Connections............................................................................................................ 5
IPCV10010 –ABUS Quad View Addon for ABUS IP Camera Viewer........................ 6
Features.................................................................................................................. 6
IPCV10020 –ABUS Overlay Add-on für ABUS IP Camera Viewer............................ 6
Features.................................................................................................................. 6
How to install the ABUS IP Camera Viewer................................................................ 7
Configuration of the ABUS IP Camera Viewer the network........................................ 8
User interface............................................................................................................. 9
Password reset......................................................................................................... 11
Troubleshooting........................................................................................................ 11
Warning.................................................................................................................... 11




Declaration of conformity

ABUS Security-Center hereby declares that the enclosed product complies with the

requirements of the following directives concerning the product:

RED Directive (2014/53/EU)

EMC Directive (2014/30/EU)

Low Voltage Directive (2014/35/EU)

RoHS Directive (2011/65/EU)

The full EU declaration of conformity can be obtained from the following address:

ABUS Security-Center GmbH & Co. KG

Linker Kreuthweg 5

86444 Affing

GERMANY

www.abus.com/product/Itemnumber

(‘Item number’ in the link to be replaced with

the article number of the enclosed product)

GNU GPL License note

Note that this product includes open source software, licensed under the GNU

General Public License (GPL). The GPL license terms can be viewed online under

the following link:

https://www.abus.com/var/ImagesPIM/d110001/medias/docus/13/gpl-2.0_license.txt

IPCV10000 –ABUS IP Camera Viewer (1-channel)

Features

•Live image display of 2 MPx network cameras on one monitor

•Display expandable up to 4 cameras (IPCV10010)

•Practical solution for numerous customer needs

•Ideal for sales rooms, for example as a confrontation monitor

•Comfortable solution for private end customers, e.g. more security at the front

door

•Low installation costs

•Network integration via LAN or WiFi

•Monitor connection via HDMI

•Silent operation

•Without the use of an additional PC or recorder

Specification

Item #

IPCV10000

Dimensions

75 x 110 x 35 mm

Connections

1 x HDMI, 1x RJ45, 1x Micro-USB Typ B

Resolution

2 MPx

Resolution modes

1920 x 1080

Scope of delivery

1 x ABUS IP Camera Viewer (1-channel)

Max. operating temperature

50 °C

Min. operating temperature

0 °C

Net weight

0,12 kg

Network connector

RJ45

LAN network access

Gigabit Ethernet with max. 300 Mbit/s

Wi-Fi network access

2,4 GHz & 5 GHz WLAN IEEE 802.11 b/g/n/ac

Voltage supply

5 V DC

Power consumption

2500 mA

Technology

LED Display

LED

Color

Status

Description

PWR

Red

Off

No power supply connected

Power supply connected

Blink

Supply voltage below 4,63 Volt

ACT

Green

Off

No access to SD card

Accessing SD card (operating system) not possible

or no SD card available

Blink

Flashes every time accessing the SD card (read

and write access)

Connections

ACT-LED

PWR-LED

Micro-USB Typ B

Power supply

HDMI

Monitor connection

3,5 mm jack

Audio output

(not used)

RJ45

Network connection

IPCV10010 –ABUS Quad View Addon for ABUS IP Camera

Viewer

Features

•Extension from 1 to 4 channels for the ABUS IP Camera Viewer (1-channel)

IPCV10000

•Software extension via activation code

•No further installation or infrastructure needed

The ABUS Quad View Addon is the display expansion of your ABUS IP Viewer

IPCV10000 from one camera to four cameras. You will receive a sealed envelope

with activation code, which allows you to unlock three additional display channels

without any further installation effort.

IPCV10020 –ABUS Overlay Add-on für ABUS IP Camera

Viewer

Features

•Software extension to display logo and text

•Video stream optimization for the POS and adaptation to the corporate design

•Integration of customized data for targeted customer information

•Software extension using activation code

•No further installation or infrastructure necessary

The Overlay add-on is an extension for the ABUS IP Viewer for displaying a logo and

text line. This function makes it possible to optimize the point of sale. The positions of

both elements are preconfigured.

How to install the ABUS IP Camera Viewer

•Connect the ABUS IP Camera Viewer with an HDMI cable to the monitor that

you want to use, to display the camera image.

•When operating via network cable, connect the cable now with the ABUS IP

Camera Viewer. If operating via WiFi, proceed directly with the next step.

•Connect the ABUS IP Camera Viewer to a USB power supply to turn on the

device and provide power.

•Select the appropriate HDMI input tob e displayed on the monitor.

•After the ABUS IP Camera Viewer has booted up, you will see the following

startup screen:

Please note that the ABUS Viewer must be connected to a network

that has access to the Internet for initial startup. This also applies to

commissioning after resetting the configuration settings to factory

default.

Example: Start display of the ABUS IP Camera Viewer on the monitor

Explanation of the IP addresses:

http://192.168.0.100 ABUS Viewer Address from the local connected network

via network cable.

http://192.168.4.1 ABUS Viewer address of its own WiFi hotspot

"ABUSVIEWER" (only for configuration access)

Configuration of the ABUS IP Camera Viewer the network

The ABUS Viewer has a web interface, which is used to configure the device. In

order to access the web interface, you must connect to the ABUS Viewer with your

PC or web-enabled terminal as follows.

Please note that the ABUS Viewer must be connected to a network that has access

to the Internet for initial startup.

An appropriate privacy policy is available at the beginning on the web interface of the

ABUS Viewer.

•Connection via ABUS IP Installer

If you are already using the ABUS IP Installer and have connected the ABUS

Viewer to the network, you can find the ABUS Viewer in the device list and access

the web interface of the ABUS Viewer.

•Connection via network.

If you have connected the ABUS Viewer to the network, you can access the web

interface of the ABUS Viewer directly via the web browser. The web interface can

be reached in the web browser via the IP address, which can be found on the

monitor's start display.

•Connection via WiFi

After booting, the ABUS Viewer provides a WiFi hotspot. On the start display of

the monitor, you can see the WiFi name (SSID) as well as the password to

connect to the ABUS Viewer with your mobile device. Now you can reach its web

interface in the web browser via the IP address, which can also be found on the

monitor's start display.

If the general conditions of use have been confirmed and you have an internet

connection, you can access the menu of the ABUS Viewer via the web interface.

First, the password must be changed.

Please note, if you need to reset the password in the future, you will

need the IP address of the ABUS Viewer to access the device. It is

therefore recommended to assign a fixed IP address during

configuration.

Please note that the device restarts after changing the network settings.

Now you can add IP cameras from the network as described in the section

"Cameras" of the following chapter.

User interface

Explanation of the user interface for making configuration settings on the ABUS IP

Camera Viewer.

Overview

The menu "Overview" provides information about currently displayed cameras.

Cameras

The menu "Cameras" is used for automatic or manual setup and adding of IP

cameras. Cameras are also edited or removed here.

Auto: Automatic search for IP cameras in the network

Manually: For the manual setup of a new IP camera, the following data must be

known and entered:

•Name

•IP address

•http Port

•RTSP Port

•RTSP Path Mainstream (optional)

•RTSP Path Substream (optional)

•User

•Password

View

Under the menu "View", the live image view is configured for the monitor.

•Setting the display mode, full screen or 2 x 2

•Selection of the camera which shall be used for live image view

•Selection of the camera stream which shall be displayed

System

Under the menu "System", the following system settings are made.

•Languages

➔Selection of the language for the user interface; DE, GB, NL, DK, ES,

FR, RU or IT.

•Addons

➔Activation of the ABUS Addon extension IPCV10010 and IPCV10020

by entering the activation code (AddOn Secure Code).

•Network

➔Configuration of the network settings for TCP/IP or WiFi

•Password

➔Password change for the ABUS Viewer

•Save and recovery

➔Backup configuration settings of the ABUS Viewers in a cfg file

➔Load backup of configuration settings from a cfg file

•Update

➔View the current software version and search automatically for updates

•Factory settings

➔Resetting the configuration settings of the ABUS Viewer to the factory

default. Optionally with or without network settings.

•Licenses

➔View the license terms
