Abocom P3102-4g Manual de usuario

P3102-4g Wireless Broaband

VoIP Gateway Router

Description:

P3102-4g Wireless Broadband VoIP Gateway Router integrates full-featured router/firewall with Analog Terminal

Adapter (ATA) into one small platform and enables server providers to create new toll-quality voice servers to

their customers.

P3102-4g Wireless Broadband VoIP Gateway Router integrates full-featured firewall, router, and VoIP Getaway

with standard-based QoS and traffic prioritization to provide multiple traffic priority queues, which ensure voice

communication and latency/bandwidth sensitive traffic. The priority queuing mechanism enables server providers

to create new services of data, voice, and video(Triple-Play). It’s built-in firewall,. NAT, and NAPT enable business

applications with enhanced network security.

P3102-4g Wireless Broadband VoIP Gateway Router’s industry standards based DSL Forum TR-069

implementation let service providers perform OA&M of router remotely.

Standard-Based Routing:

Comprehensive routing support on features including Network

Address Translation(NAT), Network Address Port Translation

(NAPT), Dynamic Domain Name Server (DDNS) relay, Dynamic

Host Configuration Protocol(DHCP), and Point-to –Point

Protocol over Ethernet (PPPoE).

Toll-Quality Voice; Enable Triple-play

Standard-based VoIP support with QoS and traffic prioritization

to ensure toll-quality voice experience for subscribers. Enable

service providers to provide new services of data, voice, and

video( Triple-play)

Standard-Based Network Management

Support industry standard DSL Forum TR-069 with SSL)Secure

Socket Layer) and enable service providers to perform router

management tasks remotely; these includes configuration

changes performance monitoring, and firmware upgrades.

Router Features:

Routing

zDHCP client for WAN

zStatic IP option

zDHCP server for WAN

zRFC 2516 Point-to-Point Protocol over Ethernet (PPPoE)

zDNS proxy relay ; support 2 DNS entries

zDynamic DNS support

zNetwork Address Translation (NAT)

zNetwork Address Port Translation (NAPT)

zRIP v1/v2 and static route support

zVPN pass through (IPSec-ESP Tunnel mode, L2TP,PPTP)

Management

zDSL Forum TR-069 CPE WAN Management

zDSL Forum TR-064 CPE LAN Management

zWed-based Graphical User Interface

zSNMP v1/v2 support

zUPnP support

zSystem Logging

Voice Features:

VoIP Protocol

zRFC3261 Session Initiation Protocol(SIP)

zRFC2327 Session Description Protocol(SDP)

zRFC2889 Real-Time Transport Protocol (RTP)

zITU-T T.38 Fax over IP

Telephone Interface

z2 RJ-11 FXS ports for analog phone connection

Codecs /Dialing /Tone/ QoS

zITU-T G.711, G.726, G.729 support

zVolume gan control

zStatic and dynamic jitter buffer

zG.168 echo cancellation

zVoice activity detection and comfort noise generation

zSilence Threshold

zConfigurable telephone hook flash timer

zIndependent dialing plan(E.164) support

zIn-band DTMF tone generation (G.711), and out-of-band DTMF(RFC2833)

zToS and Diffserv supprt

Wireless Features

zIEEE802.11b/g Wi-Fi

zSupports up to 54Mbps

zData encryption-64/128- bit WEP/TKIP/AES-CCM/AES-OCB/802.1x, and WPA

zRadio Frequency 2.4GHz band

zModulation Type

¾DSSS –BPSK, QPSK, CCK

¾OFDM -BPSK, QPSK, 16QAM, 64QAM

zTransmit Power-13 to 17 dBm

zReceiver Sensitivity- 68 to 90 dBm

Physical Features:

Physical Interface

zOne RJ-45 Ethernet port for WAN 10/100 Mbps connection

zFour RJ-45 Ethernet ports for LAN 10/100 Mbps connection

zThree RJ-11 FXS ports for phone/fax connection

zPower Jack

zReset button

zExternal antenna

LED Indicators

zPower

zWAN connectivity/activity

zLAN connectivity/activity

zInternet IP connection

zVoIP registration status

zVoice call status

Power

zExternal power supply, Input 120/240 VAC 60Hz 25W, Output 12VDC 1000Ma

Environment

zTemperature: IEC68-2-14

z0 to 40 degrees C (Standard Operating)

z-40 to 70 degrees C(Non-condecsing)

zVibration:IEC 68-2-36, IEC68-2-6

zShock:IEC68-2-29

zDrop: IEC68-2-32
