ABB PSE18 Guía

Softstarters Type PSE18...PSE370

Installation and commissioning manual

PSE 18-600-70

2 Softstarters Type PSE18...PSE370 Installation and commissioning manual 1SFC132057M0201

This manual belongs to:

__________________________________________

Softstarters Type PSE18...PSE370 Installation and commissioning manual 1SFC132057M0201 3

Installation and Commissioning Manual

ABB Softstarters PSE18...PSE370

1 General

This is the Installation and Commissioning Manual for Softstarters Type PSE18…

PSE370 based on software version 01.01.02.

Document number: 1SFC132057M0201

Revision: E

Issue date: 2011-01-25

Data subject to change without notice.

We reserve all rights to this document, even in the event that a patent is issued

and a different commercial proprietary right is registered. Improper use, in particu-

lar reproduction and dissemination to third parties, is not permitted.

This document has been carefully checked. If the user nevertheless detects any

errors, he is kindly asked to notify us as soon as possible.

The data contained in this manual is intended solely for the product descrip-

tion and is not to be deemed to be a statement of guaranteed properties. In the

interests of our customers, we constantly seek to ensure that our products are

developed to the latest technological standards.

As a result, there may be some differences between the softstarter and the infor-

mation in this manual.

Author’s address:

ABB AB

Cewe-Control

SE-721 61 Västerås, Sweden

Telephone: +46 (0) 21 32 07 00

Telefax: +46 (0)21 12 60 01

http://www.abb.com/lowvoltage

notice.

4 Softstarters Type PSE18...PSE370 Installation and commissioning manual 1SFC132057M0201

2 Safety

This chapter describes warning and information signs used in this manual, which

the user should pay attention to.

The softstarter shall be installed by authorized personnel only.

This manual is a part of the PSE Softstarter and should always be accessible to

personnel working with this product.

The manual shall always be read through before performing any installation or

commissioning tasks.

2.1 Use of signs caution, warning and information

Caution!

Caution icon indicates the presence of a hazard which could result in per-

sonal injury.

Warning!

Warning icon indicates the presence of a hazard which could result in dam-

age to equipment or property.

Information

Information sign alerts the reader to pertinent facts and conditions.

Softstarters Type PSE18...PSE370 Installation and commissioning manual 1SFC132057M0201 5

Chapter

1 Introduction ............................................ 7

2 Quickstart ............................................... 11

3 Description ............................................. 15

4 Mounting ................................................ 27

5 Connection ............................................. 31

6 Human-Machine Interface (HMI).............. 45

7 Functions and conguration.................... 55

8 Fieldbus communication ......................... 79

9 Maintenance........................................... 81

10 Troubleshooting ...................................... 83

11 Wiring diagrams...................................... 95

12 Index ...................................................... 99

Customer feedback report............................... 102

6 Softstarters Type PSE18...PSE370 Installation and commissioning manual 1SFC132057M0201

Notes

Softstarters Type PSE18...PSE370 Installation and commissioning manual 1SFC132057M0201 7Chapter 1

Chapter 1 Introduction

Documentation for PSE18...PSE370 softstarter.......................................... 8

Installation and Commissioning................................................................... 8

Intended audience ................................................................................. 9

General ............................................................................................. 9

Requirements .................................................................................... 9

Revision notes and other documents ..................................................... 9

Acronyms and abbreviations .................................................................. 10

Explanation of concepts......................................................................... 10

Softstarters Type PSE18...PSE370 Installation and commissioning manual 1SFC132057M02018 Chapter 1

Chapter 1 Introduction

1.1 Documentation for PSE18...PSE370 soft-

starter

For the Softstarter Type PSE18...PSE370, the following manuals are available:

1SFC132059M9901 (User manual short form, printed)

1SFC132057M0201 (English version, PDF-le)

In the future, the following documents will be available as PDF-les:

1SFC132057M3401 (Swedish)

1SFC132057M0101 (German)

1SFC132057M0301 (French)

1SFC132057M0901 (Italian)

1SFC132057M0701 (Spanish)

1SFC132057M1601 (Portuguese)

1SFC132057M3101 (Dutch)

1SFC132057M4001 (Polish)

1SFC132057M1101 (Russian)

1SFC132057M1801 (Finnish)

1SFC132057M1901 (Turkish)

1SFC132057M1301 (Arabic)

1SFC132057M2001 (Chinese)

Please check:

www.abb.com/lowvoltage/.

On this site select the link Control

Products and then continue to Softstarters.

1.2 Installation and Commissioning

Manual

This manual contains instructions on how to install, commission and maintain the

softstarter. The manual covers procedures for mechanical and electrical installa-

tion, and installation of communication devices. It also covers energizing, setting,

and conguration and verifying settings.

For brief information see Softstarters Type PSE18...PSE370 User Manual short

form, containing the same languages as the Installation and Commissioning

Manual. Softstarters Type PSE18...PSE370 User Manual short form has docu-

ment ID 1SFC132059M9901.

For quickest possible start, read Chapter 2 Quickstart or go to the short form

manual (1SFC132059M9901).

A complete compilation of ABB’s softstarters can be found in Main catalogue

Softstarters, document ID 1SFC132005C0201.

Softstarters Type PSE18...PSE370 Installation and commissioning manual 1SFC132057M0201 9Chapter 1

1.2.1 Intended audience

1.2.1.1 General

The installation and commissioning manual is intended for the installation, com-

missioning, and maintenance personnel responsible for getting the softstarter into

normal service and out of service.

1.2.1.2 Requirements

The installation personnel must have a basic knowledge in handling electric equip-

ment. The commissioning and maintenance personnel must be well experienced

in using this kind of equipment.

1.2.2 Revision notes and other documents

For latest information on revisions and other documents related to the PSE

Softstarters, please check

www.abb.com/lowvoltage/.

On this site select the link

Control Products and then continue to Softstarters.

Softstarters Type PSE18...PSE370 Installation and commissioning manual 1SFC132057M020110 Chapter 1

1.2.3 Acronyms and abbreviations

The acronyms and abbreviations described in table 1.1 are used in this manual.

Table 1.1

Acronym/ abbre-

viation

Description

BP By-pass

DOL Direct-on-line

EOL Electronic overload protection for the Motor

FB Fieldbus

FBP FieldBusPlug

HMI Human-Machine Interface

IeRated operational current

IT Information Technology

LCD Liquid Crystal Display

LED Light Emitting Diode

PCB Printed Circuit Board

PLC Programmable Logic Controller

PTC Positive Temperature Coefcient

SC Short Circuit

SCR Silicon Controlled Rectier (thyristor)

TOR Top of Ramp (full voltage/Full-On)

UcRated control circuit voltage *

UeRated operational voltage *

UsRated control supply voltage *

*) For denition see IEC 60947-1 edition 5.0

1.2.4 Explanation of concepts

The setting of current Ieis the setting for the rated operational current (main cur-

rent) of the motor.

Ue= Rated operational voltage on the motor’s operational current (three phase

main voltage feeding the motor).

Us= Rated control supply voltage, feeding the electronics in the softstarter.

Uc= Rated control voltage, used for controlling the softstarter.
