ABB CP405 Manual de usuario
—
QUICK START GUIDE
Control Panels CP405
Control Panels CP408
Quickstart 1 CP405, CP408
Content
Introduction ...............................................................................................................2
Before You Start........................................................................................................2
2.1 Hardware Connection ........................................................................................................2
2.2 Software Installation ..........................................................................................................4
3Application Examples - Data Display ......................................................................6
Revision History......................................................................................................13
Quickstart 2 CP405, CP408
Introduction
This documentation describes the steps to create a simple CP400PB (Panel Builder 400) project. The
description includes hardware, configuration and programming of CP405/CP408 and AC500-eCo in
order to communicate with each other.
Before You Start
2.1 Hardware Connection
Before you start, following equipments should be prepared:
1. Personal Computer
2. 24V DC power supply
3. AC500-eCo PM554
4. TA562-RS(-RTC) (RS485 serial adapter for
COM2 interface)
5. CP405/CP408 control panel
6. TK504 (PLC programming cable for COM2)
7. USB programming cable type A to type B
(Between CP405/CP408 and PC)
8. TK407 communication cable
(Between AC500-eCo and CP405/CP408)
9. PS501 Control Builder Plus installation
(TK504 driver included)
10. CP400PB (Panel Builder400) installation
(USB programming cable type A to type B
driver included)
Make sure all above listed items are available, then follow the steps below.
1
2
7
3
56
8
4
Quickstart 3 CP405, CP408
1. Connect CP405/CP408 (5) with AC500-eCo (3). Pinning of TK407 (8) is shown below.
COM1 of AC500-eCo COM1 of CP405/CP408
2. Connect CP405/CP408 (5) with PC (1).
3. Connect AC500-eCo (3) with PC (1) with TK504 (6).
4. Connect 24VDC power supply (2) to CP405/CP408 (5) and AC500-eCo (3).
3
5
8
1
3
6
2
5
3
7
5
1
Quickstart 4 CP405, CP408
NOTE
System requirements for using CP400PB (Panel Builder 400):
Driver will be installed automatically for:
Windows 2000TM SP4
Windows XPTM SP2
Windows Server 2003TM
Windows VistaTM
Driver needs to be installed manually, see Chapter 2.2:
Windows 7TM
2.2 Software Installation
Install the driver for panel in Windows 7 system as below.
1. Install CP400PB (Panel Builder 400) and CBP (Control Builder Plus) software. For further details,
please see AC500-eCo Starter Kits: 2CBA125031M0201
2. After USB programming cable is plugged in PC for the first time, Windows will detect it automatically.
Right click ABB CP40x HMI to update the software.
Quickstart 5 CP405, CP408
3. Browse the driver software.
4. Finish the installation.
5. Check if driver is installed correctly in Device Manager.
1
Choose whether
Win32bit or Win64bit,
depending on your
computer system
2
4
3
Quickstart 6 CP405, CP408
3Application Examples - Data Display
Open Panel Builder software to configure the setting on CP400PB.
1. Open CP405/CP408 configuration environment and creat a new project.
2. Input project name and location. Then click Next.
3. Choose corresponding CP405/CP408 type. Then click Next.
4. Set ABB Modbus RTU as communication service. Then click Next.
Quickstart 7 CP405, CP408
5. Configure the Link parameter of CP405/CP408, which shall be consistent with the used parameter
settings in AC500-eCo.
Parameter setting for
control panel on
CP400PB
Parameter settings
for AC500-eCo on
CBP
Quickstart 8 CP405, CP408
6. Draw a text label and edit the current text.
7. Draw a numeric display label to display the data received from AC500-eCo.Choose the data type
(Monitored variable type), display type and monitor address.
1. Choose Text
3. Input the text
and check Shape
2. Double click the label
1. Choose
Numeric Display
2. Double click
the label
3. Input Monitor
Address
Quickstart 9 CP405, CP408
8. Draw and specify a numeric display label to display the data sent to AC500-eCo.
9. Draw and specify a numeric display label to display the error record (how many times data received
from AC500-eCo is not equal to data send to AC500-eCo).
