9110 USER GUIDE

9110 2 EF.book Page 0 Monday, March 29, 2004 3:51 PM

Table of Contents

Introduction.................................................................................................. 2

Emergency service Feature........................................................................ 2

Unpacking your phone ................................................................................ 2

Key Descriptions ......................................................................................... 3

Basic Installation.......................................................................................... 5

Making and Answering Calls ...................................................................... 8

Making a call............................................................................................... 8

Answering a Call ......................................................................................... 8

Using the Hold Key...................................................................................... 8

Making a Handsfree call.............................................................................. 8

Muting a Handsfree call ..............................................................................9

Using the Redial .........................................................................................9

Adjusting the Handset and Speaker volume............................................... 9

Adjusting the Ringer volume ....................................................................... 9

Set Indicator light ........................................................................................9

Memory keys .............................................................................................. 10

Saving numbers into memory keys........................................................... 10

Labeling the memory keys........................................................................ 10

Making calls from memory keys ...............................................................11

Deleting memory keys............................................................................... 11

Saving features in memory keys............................................................... 11

Using features keys................................................................................... 12

Using the Dataport.................................................................................... 12

Troubleshooting......................................................................................... 12

9110 2 EF.book Page i Monday, March 29, 2004 3:51 PM

Introduction

Congratulations....

. on the purchase of your 9110 telephone.

This guide contains operating information for your 9110.

Emergency Service Feature

The Model 9110 will continue to provide basic telephone service during

a power failure.

Unpacking your phone

Along with this user guide, the following items are included

with your telephone.

The 9110 is an advanced single-line telephone, that offers the following features:

• Handsfree (speakerphone) with mute

capabilities

• 7 speed dial positions for frequently called

numbers or feature access codes

• Last number redial

• Loop powered

Telephone Memory key card

and plastic lens

Handset

Telephone line cord

Handset cord

Telephone stand

Regulatory sheet

Number card

and plastic lens

9110 2 EF.book Page 2 Monday, March 29, 2004 3:51 PM

Introduction

Key Descriptions

Redial

Save

Flash

Mute

Handset

Ringer Switch

Data Jack

Set Indicator

Light

Volume Bar

Dial Pad

Handsfree/Mute

7 Memory Keys

9110 2 EF.book Page 3 Monday, March 29, 2004 3:51 PM

Introduction

Keys Key Description

Set Indicator

Light

Flashes when the telephone rings, or when a call is on hold; lights

up when a message is waiting. See

Set indicator light

on page 9

for more information.

7 Programmable

Keys

Stores a number or feature for easy access.

Ends an active call. It will not hang up a call that is on hold.

Places calls on or off hold. See

Using the Hold Key

on page 8

for more information.

Sets the handset and speaker volume while on call.

Activates the speaker and microphone so you can listen and talk

without using the handset; also mutes the microphone so that

your caller cannot hear you (the light indicator will ßash when

the microphone is muted).

Use with network features such as Call Waiting and Three Way

Calling (ßash is also referred to as link).

Dials the last number dialed out on the telephone. See

Using

Redial

on page 9 for more information.

Use to store numbers in memory keys.

Memory keys store numbers. See

Memory keys

on page 10.

9110 2 EF.book Page 4 Monday, March 29, 2004 3:51 PM

Basic Installation

1. Connect the Handset Cord 2.Connect the Line Cord

Attach one end of the coiled handset

cord to the handset and the other end to

the handset port on the back of

the telephone.

Route the handset cord along the groove

leading off the side of the telephone as

shown in the illustration.

Plug one end of the telephone cord into

on the back of the telephone and the

other end to the phone jack.

3. Attach the Stand for Desk Use

If you plan to mount the telephone on the wall, you do not need to attach the stand.

Lower the stand as shown below into the

slots on the back of the telephone.

Slide the stand in the direction shown

below until it clicks into the locked position.

9110 2 EF.book Page 5 Monday, March 29, 2004 3:51 PM

Basic Installation

4. Attach the line cord to the telephone stand 5.Wall mounting installation

Route the line cord along the groove

on the telephone stand as shown in

the illustration.

It is recommended that you use a

wall-mounting plate which is available

through your telephone company

or a local retailer. You will Þnd it easier

to wall-mount the telephone if you

purchase a short telephone cord and use

it in place of the long telephone cord.

Coil the telephone cord into the space

provided on the back of the telephone.

Line up the keys on the wall mounting

plate with the key holes on the back of

the telephone.

Place the telephone onto the wall

mounting plate, and then push down

to secure the telephone into place.

6.Wall mounting installation with stand

The telephone can be wall mounted at an angle (tipped back slightly) by using the

stand. Screw the stand to the wall using the two round holes in the stand (wedge

part down, holes up). Connect line cord to the telephone. Attach the telephone stand.

9110 2 EF.book Page 6 Monday, March 29, 2004 3:51 PM

Basic Installation

7. Insert the number card on

your telephone

8. Insert the Memory key card on your telephone

Write your telephone number

on the number card.

Place the number card into the

slot underneath the handset

cradle on the on the telephone.

Gently bend the clear plastic lens

and place it on top of the number

card in the slot.

This card contains the feature names for the

dedicated keys and label identiÞcation spaces for

the seven programmable memory keys.

Place the card into the memory key card slot

on the telephone.

Gently bend the clear plastic lens and place it on

top of the memory key card in the slot.

For information on programming memory keys,

refer to

Memory keys

on page 10

Avoid potential electrical shock hazard and damage to the

telephone, by using the manufacturer-supplied parts. SpeciÞcally,

only use a two conductor modular line cord.

Substitution of non-approved parts will void the Aastra Telecom

Inc., warranty. If you have a question about your installation

or safety concerns, please call 1-800-574-1611 to speak with our

representative.

Redial

Save

Flash

Mute

9110 2 EF.book Page 7 Monday, March 29, 2004 3:51 PM

Making and Answering Calls

Making a call

With your telephone you can make and answer calls using your handset or c

for speakerphone capabilities.

Answering a Call

Using the Hold Key

Note:

The 9110 automatically releases a call on hold when a person on an

extension telephone on the same line picks up the call. If you don’t hang up

the handset after you have put a call on hold and that call is picked up by

someone at another extension, the call is taken off hold but remains connected

to your telephone. If this happens, any background noise from your area will

be heard by the caller and the person at the other extension.

Making a Handsfree call

You don’t have to use the handset to use your telephone. Instead, you can use Handsfree

mode to place a call, or you can switch to Handsfree mode while a call is in progress.

Note:

After ending a handsfree call, you may Þnd you must wait for at least

2 seconds prior to pressing c

to obtain dial tone and initiating your next

call. This time is required to allow the network to completely disconnect

your last call.

To make a regular call:

1. Lift the handset or press c

2. Enter the number using the dial pad.

To answer a call:

1. Lift the handset or press c

To put a call on hold and take a call off hold:

1. Make or answer a call.

2. Press O

The set indicator light will ßash quickly to indicate there is a call on hold.

3. To retrieve the call, press O

or c

. If you don’t retrieve the call within

15 minutes, the call is automatically dropped.

To dial without picking up the handset: To switch to a Handsfree call:

1. Press c

. 1. Lift the handset.

2. Dial a number using the dial pad. 2. Dial a number using the dial pad.

3. When the call is over, press N

. 3. To switch to handsfree,

press c

4. Hang up the handset.

5. When the call is over, press N

9110 2 EF.book Page 8 Monday, March 29, 2004 3:51 PM

Making and Answering Calls

Muting a handsfree call

You can turn off the microphone so that the caller can’t hear you but you can still hear

the caller. Muting a call only works when you are in Handsfree mode.

Using Redial

Pressing Redial dials the last number dialed.

Adjusting the Handset and Speaker volume

Press the left or right side of the volume bar R

to adjust the volume on

the handset or speaker. The handset volume resets to factory set volume level after

each call. The speaker volume remains at the level selected until the next time

you change it.

Adjusting the Ringer Volume

The ringer volume is controlled by a three position switch on the side of the Model

9110. The ringer volume can be set to low, medium, or high.

Set Indicator Light

The set indicator light, located on the top right hand corner of the Model 9110, ﬂashes

and illuminates to provide information as follows:

To mute a handsfree call:

1. Press c

2. Without lifting the handset, make a call.

3. To turn off the microphone, press c

. You can hear your caller but your

caller cannot hear you. The light next to the key will ﬂash to indicate the mute is

on.

4. To speak to your caller, press c

again. Each time you press c

, you

turn the microphone on or off.

5. When the call is over, press N

To make a call using Redial:

1. Lift the handset or press c

2. Press b

Set indicator light ﬂashes very quickly. Incoming call.

Set indicator light ﬂashes quickly.

(2 pulse/sec.)

Line is on HOLD.

Set indicator light ﬂashes slowly.

(1 pulse/sec.)

Message Waiting*.

9110 E2 UG.fm Page 9 Friday, May 21, 2004 9:39 AM

Otros manuales para 9110

Tabla de contenidos

Otros manuales de Teléfono de Aastra

Aastra

Aastra Aastra 610d Manual de instrucciones

Aastra

Aastra CM-16 Manual de usuario

Aastra

Aastra Venture 3-Line with Answering Manual de programación

Aastra

Aastra Venture Manual de usuario

Aastra

Aastra Venture 3-Line with Answering Manual de usuario

Aastra

Aastra 9417CW Manual de usuario

Aastra

Aastra dialog 4224 Operator Manual de usuario

Aastra

Aastra Office 60IP A150 Manual de usuario

Aastra

Aastra BluStar 8000i Manual de usuario

Aastra

Aastra 6737i Manual de usuario

Aastra

Aastra 9110 Manual de usuario

Aastra

Aastra MERIDIAN M5316 Manual de usuario

Aastra

Aastra Maestro 3500CW Manual de usuario

Aastra

Aastra 6730a Manual de usuario

Aastra

Aastra 480E Manual de usuario

Aastra

Aastra DIALOG 4223 PROFESSIONAL Manual de usuario

Aastra

Aastra 470 Manual de usuario

Aastra

Aastra IntelliGate 630d Manual de usuario

Aastra

Aastra 9143i Series Guía de instalación

Aastra

Aastra M325 Manual de usuario

Aastra

Aastra M350 Manual de usuario

Aastra

Aastra 9617 Manual técnico

Aastra

Aastra DIALOG 4223 PROFESSIONAL Manual de usuario

Aastra

Aastra Dialog 4223 Professiona Manual de usuario

Manuales populares de Teléfono de otras marcas

GE 2-9480 Manual de usuario

Geemarc

Geemarc PHOTOPHONE 155 Manual de usuario

D-Link

D-Link DWR-720/PW Manual de usuario

Interquartz

Interquartz Gemini IQ333 Manual de usuario

SSS Siedle

SSS Siedle HT 840-0 Manual de usuario

Motorola

Motorola TITANIUM Manual de usuario

Panasonic

Panasonic ICX Manual de usuario

LG H870DS Manual de usuario

Samsung

Samsung GT-I9500 Manual de usuario

AT&T

AT&T Trimline 205 Manual de usuario

Selta

Selta zenyth 600 Manual de usuario

Doro

Doro AFTI 20 Manual de usuario

UNIQCELL

UNIQCELL A1 Manual de usuario

Panasonic

Panasonic KX Series Manual de usuario

Jabra

Jabra SP5050 - Bluetooth hands-free Speakerphone Manual de usuario

BT Decor 425 Manual de usuario

NEC

NEC SV8500 Manual de usuario

Teledex

Teledex PEARL Manual de usuario
