Aaeon PFM-800P Manual de usuario
PC/104 CPU Module PFM-800P
PFM-800P
Intel®Ultra Low Voltage Celeron®M
Processor
24/48-bit Dual-Channel LVDS
2 COM/ 2 USB2.0
CompactFlash/ PCI-104 Interface
PFM-800P Manual Rev.A 2nd Ed.
Mar. 2010
PC/104 CPU Module PFM-800P
i
Copyright Notice
This document is copyrighted, 2010. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, or for
any infringements upon the rights of third parties that may result
from its use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its
accuracy, AAEON assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information
contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.
PC/104 CPU Module PFM-800P
ii
Acknowledgments
All other products’ name or trademarks are properties of their
respective owners.
Award is a trademark of Award Software International, Inc.
CompactFlash™ is a trademark of the Compact Flash
Association.
Intel®, Celeron®M are trademarks of Intel®Corporation.
Microsoft Windows®is a registered trademark of Microsoft Corp.
ITE is a trademark of Integrated Technology Express, Inc.
IBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
SoundBlaster is a trademark of Creative Labs, Inc.
All other product names or trademarks are properties of their
respective owners.
PC/104 CPU Module PFM-800P
iii
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
9681800P00 (TF) Cable Kit
1701440500 44-pin IDE Cable x 1
1700060152 Keyboard & Mouse Cable x 1
1701160201 VGA Cable x 1
Quick Installation Guide
Utility CD
PFM-800P
If any of these items should be missing or damaged, please
contact your distributor or sales representative immediately.
PC/104 CPU Module PFM-800P
iv
Contents
Chapter 1 General Information
1.1 Introduction................................................................1-2
1.2 Features....................................................................1-3
1.3 Specifications............................................................1-4
Chapter 2 Quick Installation Guide
2.1 Safety Precautions....................................................2-2
2.2 Location of Connectors and Jumpers .......................2-3
2.3 Mechanical Drawing..................................................2-5
2.4 List of Jumpers..........................................................2-7
2.5 List of Connectors .....................................................2-8
2.6 Setting Jumpers ........................................................2-9
2.7 LCD Voltage Selection (JP1) ....................................2-10
2.8 Clear CMOS (JP3) ....................................................2-10
2.9 PCI-104 I/O Voltage Selection..................................2-10
2.10 COM2 Ring/+5V Selection (JP5) ............................2-10
2.11 LVDS Connector (CN1)...........................................2-10
2.12 PS2 Keyboard/ Mouse Connector (CN3)................2-11
2.13 Mini 4P Power Connector (CN5).............................2-12
2.14 Fan Connector (CN6)..............................................2-12
2.15 Mini 4P Connector (CN7)........................................2-12
2.16 Front Panel Connector (CN8) .................................2-12
2.17 LAN LED Connector (CN9).....................................2-13
PC/104 CPU Module PFM-800P
v
2.18 VGA Display Connector (VGA1).............................2-13
2.19 10/100Base-TX Ethernet Connector (LAN1) ..........2-14
2.20 USB Connector (USB1) ..........................................2-14
2.21 EIDE Connector (IDE1)...........................................2-14
2.22 RS-232 Serial Port Connector (COM1)...................2-15
2.23 RS-232/422/485 Serial Port Connector (COM2).....2-16
Chapter 3 Award BIOS Setup
3.1 System Test and Initialization. ..................................3-2
3.2 Award BIOS Setup....................................................3-3
Chapter 4 Driver Installation
4.1 Installation.................................................................4-3
Appendix A Programming The Watchdog Timer
A.1 Programming .........................................................A-2
A.2 IT8712F-A Watchdog Timer Initial Program..........A-5
Appendix B I/O Information
B.1 I/O Address Map....................................................B-2
B.2 Memory Address Map............................................B-3
B.3 IRQ Mapping Chart................................................B-3
B.4 DMA Channel Assignments...................................B-4
Appendix C Mating Connector
C.1 List of Mating Connectors and Cables.................. C-2
PC/104 CPU Module PFM-800P
Chapter 1 General Information 1- 1
General
Chapter
1
Information
PC/104 CPU Module PFM-800P
Chapter 1 General Information 1- 2
1.1 Introduction
AAEON announces the latest PC/104 CPU Module--PFM-800P.
This model adopts onboard Intel®Ultra Low Voltage Celeron®
M Processor up to 1GHz and the 200-pin DDR 266 SODIMM up
to 1GB. It definitely is a power consumption and cost effective
solution for your applications.
The PFM-800P adopts the chipset of Intel®852GM and Intel
82801DB (ICH4) and one 10/100Base-TX Ethernet port for
network connection. This model features the PC/104 form
factor and deploys PCI-104 expansion interface for fulfilling
different demands from customers.
In this compact size PC/104 CPU module, the PFM-800P
supports 24/48-bit dual-channel LVDS TFT LCD and CRT/LCD
simultaneous display. In addition, the PFM-800P supports
ATA33 and Type I CompactFlashTM for the storage function.
Moreover, it possesses two USB2.0 ports, one RS-232 port,
and one RS-232/422/485 port for a better expansion.
The debut of the PFM-800P is not only to complete the product
line of PC/104 CPU module, but also provide a compact,
flexible solution to customers.
PC/104 CPU Module PFM-800P
Chapter 1 General Information 1 - 3
1.2 Features
Onboard Intel®ULV Celeron®M 600MHz/ 1GHz
Intel®852GM +ICH4
DDR 266 SODIMM Memory Up to 1GB
24/48-bit Dual-channel LVDS TFT LCD (Emulated)
10/100Base-TX Ethernet x 1
EIDE x 1, CompactFlashTM x 1
USB2.0 x 2, COM x 2
PCI-104 Socket
PC/104 CPU Module PFM-800P
Chapter 1 General Information 1- 4
1.3 Specifications
System
Processor Onboard Intel®Ultra Low Voltage
Celeron®M 600MHz/ 1GHz
Processor
System Memory 200-Pin DDR 266 SODIMM x 1, Max.
1GB
Chipset Intel®852GM +Intel®82801DB
(ICH4)
Ethernet Intel®82562ET, 10/100Base-TX
BIOS Award 1 MB FLASH ROM
Watchdog Timer Generates a time-out system reset
H/W status monitoring Supports power supply voltages and
temperature monitoring
Expansion Interface PCI-104 Interface
Battery Lithium battery
Power Requirement +5V, +12V/AT
Power Consumption
(Typical) Intel®Celeron®M 1.0GHz, DDR266
1GB
0.27A @ +12V, 3.02A @ +5V
Operating
Temperature 32oF~140oF (0oC~60oC)
Storage Temperature -40oF~176oF (-40oC~80oC)
Operating Humidity 0%~90% relative humidity,
non-condensing
