A1TECH JAZZ Manual de usuario
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Caution : Any changes or modifications in construction of this device which
are not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
Two-Way Communication
Vehicle Security and Remote Convenience System
With Remote Engine Start and Paging System
OWNER’S GUIDE
OWNER’S GUIDE
A1Tech Inc.
Before Usage 3
System Components 4
Basic Function 7
Locking the Door / Arming the System
Unlocking the Door / Disarming the System
Trunk Release
Vehicle Locator
Emergency Panic Alarm
Vibrate Mode
Alarm Clock
Optional Feature Control
Button Lockout
Triggering the Alarm
Driver paging
Quick-service
Engine Start Features 13
Remote Engine Start
Programmable Timed Remote Engine Start
Remote Start for Manual Transmission Vehicles
Entering the Vehicle During Remote Engine Start
Cold Weather Start
Convenience Features 15
Automatic Door Lock / Unlock Controlled by lgnition
Hidden Alarm
Mute Chirp Sound
Turbo Funtion
--1--
Contents
Starter Interrupt
Dome Light Control
Use of One-way Remote Control
Setting Time 17
Setting the Clock Time
Setting Programmed Remote Start Time
Setting Alarm Clock Time
System 1 Programming 18
Chirp Sound Mute On/Off
Passive Arming On/Off
Passive Door Lock On/Off
Last Door Arming On/Off
Ignition Control Door On/Off
System 2 Programming 20
Alarm Sound Duration
Setting Remote Start Run Time
Setting TurboTime
Cold Weather Start Time
Technical Support 21
Manual Valet Mode
Valet Mode by Push Switch
Code Programming
System Intializing
System Shutoff
System Troubleshooting 24
--2--
Contents
--3--
You are mostly welcome to purchase JAZZ Vehicle Alarm & Starter System, World
wide Top Quality Product !
JAZZ will surely keep your vehicle
from theft and outside impact in
safety for 24 hours and provide you
with various convenience and
comfort.
You are kindly recommended to read
Owner’s Guide thoroughly and refer
to it whenever you encounter any
inquiry by keeping it always in the
vehicle.
Please contact the dealer nearby you
when you need a solution and
technical advice during usage.
Keep the Remote Control dry and do not drop and disassemble it.
When the Remote Control is lost, please contact the dealer nearby you and
delete the code number for the purpose of anti-theft. Then, purchase new
Remote Control and input new code number for usage.
Please make it sure never to use Remote Engine Start in the closed area.
Before Usage
JAZZ-II has no Remote engine start function(Remote engine start,
Programmable timed remote engine start, Cold weather start, Quick service).
Engine Start Module can be installed optionally for Remote engine start.
If you want to add this function, please discuss with the dealer nearby you.
--4--
With 3 buttons on the facade and 2 buttons on the side, it
contains color LCD screen, TX/RX electronic circuit,
highly efficient speaker for original sound and vibration
motor. User can discern easily the current status of the
vehicle and the system with each sound because it
makes different sounds according to each function,
reviving the natural sounds like various kinds of voices
and music melody and engine-starting sound (brrung).
Especially, E/L back light for illuminating a dark place
and clock function are built in as additional apparatuses.
Remote Control
Battery Replacement
Remote Control is operated by 1 x Alkaline
1.5V LR03 AAA. When icon on the
screen appears with beep sound, change the
battery. When the old battery is
replaced to new one, Remote Control
sounds melody, illuminates light on the
screen and vibrates. Then, the clock
returns to AM12:00 after displaying all
the icons one after another.
Please use JAZZ after setting the clock
to present time and checking the
current status by pressing I button.
System Components
III Button
II Button
I Button S Button
M Button
+
--5--
System Components
It transfers signal to/from Remote Control
and is plugged into the Control Module.
Knock Sensor and Warning LED are built-in.
By adjusting screw on the side part, you can
set the sensitivity of the Knock Sensor to
strong or week position properly, i.e.
sensitivity will be increased by turning screw
clockwise and decreased by turning it
counterclockwise.
Communication Module
Communication Range Check
By pressing button II, you can also check if your Remote
Control is within the range of transmission or not. If within the
range, the current status of system (Arm or Disarm) appears on
the LCD screen with melody sounding. If out of the range,
icon disappear with relevant melody sounding.
With communication by low-powered radio wave of JAZZ, the operating range
may be extremely shortened due to the existence of same frequency of wireless
radio nearby and electric wave disturbance.
Press II
--6--
System Components
Because of the two-way communication capability, sometimes it does not operate
immediately upon pressing the button. So, please operate again for it’s not
product’s defect. Press the button for one second if there is no other special
instruction.
To see if the area is available zone for communicating with the vehicle or not, press
II button. In case melody emits from the Remote Control, with the word “System is
Okay” communication is available for range.
How to Communicate (Operation method)
Sound
Vibrate mode
Digital clock
Alarm clock
Shock sensing
Mute chirp
RF range verification
Battery low warning
Door lock status
Engine running
Trunk open
Door open
System valet
Light flashing
Arming status
Programmable start
Optional function
Hood open
--7--
Basic Functions
Locking the Doors / Arming the System
If all doors are not closed when the system is armed, the alarm will sound.
If the system is in Valet mode, the doors will lock and unlock, but the alarm
function will remain inactive.
The alarm becomes fully armed 15 seconds after you press the I button.
Make sure that, before arming the vehicle, the switch of Dome Light is at the
position where the Dome Light is inter-locked to be turned on whenever the
doors are opened. Otherwise, all the alarm function shall not work correctly.
Unlocking the Doors / Disarming the System
If the chirp sounds 4 times when disarming(and/or light flash 4 times),
this indicates that the alarm sounded because door, hood, trunk was opened
in your absence.
If the chirp sounds 3 times when disarming(and/or light flash 3 times),
this indicates that the alarm sounded because the vehicle was bumped or hit
in your absence.
Press I Indicator locks
Plays lock melody
Press I Indicator unlocks
Plays unlock melody
Doors lock One chirp
System arming One flash
LED begins flashing
Doors unlock Two chirps
System disarming Two flashs
LED stops flashing
--8--
Basic Functions
Trunk Release
▶You must arm/lock again after closing the trunk
Vehicle Locator
A press on the remote control produces chirps, allowing you to locate your vehicle in
a crowded parking lot.
Emergency Panic Alarm
Press a button to set off the alarm and call people’s attention to your vehicle.
The panic alarm works even while driving or when the system is disarmed.
▶To turn off the Panic alarm sound, press button II.
Press S and then
Press I Indicator trunk
release
Press S and then
Press ⅡⅡ
Press I for 3 sec.
Trunk release
System disarming
Ten chirps
Ten flashes
Siren sounds continuously
Lights flash continuously
