A.C.Ryan Veolo acr-ve91200 Manual de usuario

ACR-VE91200

SMART ANDROID HUB

QUICK GUIDE

SMART ANDROID HUB

AC RYAN VEOLO

QUICK START GUIDE

TABLE OF CONTENT AVAILABLE LANGUAGES

English 03

Deutsch 12

Nederlands 22

Svenska 32

Norsk 42

Français 52

Español 62

Türkçe 72

Русский

 82

Ελληνικά

 92

BahasaIndonesia 102

ภาษาไทย

112

תירבע

122

ENGLISHTHIS IS A QUICK INSTALLATION GUIDE TO

GET YOU STARTED WITH YOUR NEW

AC RYAN VEOLO

ThankyouforpurchasingourproductandwelcometotheVEOLOcommunity!Thisisa

QuickStartGuidetogetyoustartedwithyournewACRyanVEOLO(ACR-VE91200).

Wehopeyouenjoythisproduct.

Included in this VEOLO box:

 1xVEOLOSmartAndroidHub

 1xVEOLO3-in-1RemoteControl

 2xBatteries

 1xHDMIcable

 1xPoweradapter

 1xQuickStartGuide

Theillustratedpluginthispicturemaydi󱐯erpercountryorregion.

›

ENGLISH KNOWING YOUR VEOLO

TheSD/SDHCcardreadersupportsupto32GB.

›

Minimum requirements:

 ATVwithatleast1availableHDMIinputconnection

 Anactiveinternetconnectionisrequiredforonlineservices,highlyrecommended

 forthebestexperience

VEOLO Back and Side view:

›

DC 5V

Power Analog

Audio Out

HDMI Out

Gigabit LAN

10/100/1000Mbps

S/PDIF Optical

Audio Out

USB Host

USB Host SD/SDHC

Cardreader

Power

ENGLISHKNOWING YOUR VEOLO

VEOLO 3-in-1 Remote Control:

PressthePointerbuttononcetodisplaytheon-screenpointer,presstwicetoturno󱐯thisfunction.

Toconservebatterylife,thepointerisautomaticallybeingturnedo󱐯whentheVEOLOisleftidlefor30secs.

PressthePointerON/OFFbuttonagaintoturnontheVEOLO.

Thebuilt-insensorcancelsoutaccidentalpressesontheremotesidewhentheQWERTYkeyboardisinuse.

ComfortabledistancebetweenVEOLOandVEOLO3-in-1RemoteControl:2m–3m.

›

Power/Standby

Return

PointerON/OFF

Select/Swipe

Navigation

Enter

Home

Volume+/- PressALTtoactivatethenumbersandsymbols

indicatedonthebuttonsinred.PressALTagainto

de-activate.

FRONT

BACK (QWERTY)

ENGLISH GETTING STARTED

Connecting VEOLO to your TV set:

1. ConnecttheincludedHDMIcable,oneendtotheHDMIoutputonyourVEOLO,

andtheotherendtotheHDMIinputonyourTV.



2. ConnectthepoweradaptertotheDC5VinputjackofyourVEOLO,andtheother

endtothepowersocket.



3. PoweronyourVEOLOandshortlyyouwillseethebootsequenceonyourTV

screen.

Note:IfyouseenothingonyourTVscreen,pleasecheckifyourHDMIsourceiscorrect.

ENGLISHGETTING STARTED

Initial Setup

1. Language setting

Selectyourdesiredmenulanguage.

2. Date and time setting

 Selecttimezone,dateandtimeformat.Thesystemdateandtimewill

automaticallybeobtainedwhenthereisanactiveinternetconnection.

3. Video

 ThissetstheTVresolution,aspectratioandscreenpositionadjustment.



4. Wireless and LAN Network

 ConnectstoyourlocalnetworkusingthewiredorwirelessLANconnection.

ENGLISH

YouwillseetheVEOLOhomescreenafterinitialsetupiscompleted.

1. Notication bar:

 Thisiswhereyouwillreceivenoticationsorupdatesfromtheappsthatyouhave

installed.



2. Date/Time:

 Thesystemdateandtimewillautomaticallybeobtainedwhenthereisanactive

internetconnection.



3. Un-mount:

 Thisisaquickshortcuttoun-mountyourstoragedevicesforremoval.



4. Home screen:

 Thereare5pagesavailabletoplaceyourapps,shortcutsorwidgetsinstalledin

yoursystem.

HOME SCREEN

21 3

4 5

ENGLISHHOME SCREEN

UsingtheVEOLO3-in-1remotecontrol,youcandragthescreenleft/rightbyholdingontotheSELECT

buttonandswipinginaleft/rightmotion.

Youcanalsojumptoscreensbyclickingonthebottomdots,orbypressingtheHOMEbuttontodisplayall

5screensforselection.

PressandholdtheSELECTbuttononanyemptyspotofyourhomescreenpagetoseeamenuselectionfor

placingwidgets,changingwallpaper,etc.

PressandholdanyiconsinsidetheMyAppsmenutoplacethemonanyemptyslotofthecurrenthome

screenpage,dragtheicontotheleft/rightmarginsofthepageifyouwanttoplaceitinadi󱐯erenthome

screenpage.

Whenyouplaceawidgetonyourhomescreen,youcancustomisethenumberofrowsandcolumnsthis

widgetwilltakeup,ifthedefaultvaluedoesnotdisplaythewidgetcorrectly.

PressandholdanyiconinsidetheMyAppsmenutoplaceonanyemptyslotoftheAppsdock.Iftheslotis

alreadyoccupieditwillbereplacedbythenewicon.

PressandholdanyiconsontheAppsdocktoremovethem.Pleasetakenotethatthisremovestheshortcut

andnottheappitself.

›

5. Apps dock:

 Youcanplaceyourfavouriteappsinthedockingbarforquickaccess.Thedefault

selection,WebBrowser,MyAppsandSettingscannotberemovedfromthisbar.
