NPM301 Serial Server Module
Hardware Manual
Document Version: 03
Publication Date: 2019-09-12
Industrial Ethernet communication solutions experts 3onedata Co., Ltd.
Copyright © 2019 3onedata Co., Ltd. All rights are reserved.
No company or individual is allowed to duplicate or transmit this manual in any forms without written
permission issued by 3onedata Co., Ltd.
Trademark statement
, and are the registered trademark owned by
3onedata Co., Ltd. And other trademarks mentioned in this manual belong to their corresponding
companies.
Notes
Purchased product, service or features should be constrained by 3ondedata commercial contracts and
clauses. The whole or part product, service or features described in this document may beyond
purchasing or using range. 3onedata won't make any statement or warranty for this document content
unless any other appointment exists.
Due to product version upgrading or other reason, this document content will be upgraded periodically.
Unless other appointment exists, this document only for application guide, all statement, information and
suggestion in this document won't constitute any warranty.
3onedata Co., Ltd.
Headquarter address:
3/B, Zone 1, Baiwangxin High Technology Industrial Park, Song Bai Road,
Nanshan District, Shenzhen, 518108, China
Technology support:
tech-support@3onedata.com
Service hotline:
+86-400-880-4496
E-mail:
sale@3onedata.com
Fax:
+86-0755-26703485
Website:
http://www.3onedata.com
Quick Installation Guide Of NPM301 Serial Server Module
3onedata proprietary and confidential 1
Copyright © 3onedata., Ltd.
Preface
The quick installation guide of NPM301 serial server module introduces:
Product features
Hardware description
Readers
This manual mainly suits for the engineers as follows:
Network administrator responsible for network configuration and maintenance
On-site technical support and maintenance staff
Hardware engineer
Text Format Convention
Format
Description
" "
Words with " " represent interface word. e.g.: "Port number".
>
Multi-level path is separated by ">".Such as open the local
connection path description: Open "Control Panel > Network
Connection > Local Connection".
Light blue font
It represents the words clicked to achieve hyperlink. Font
color as: "Light blue".
About this chapter
The "About This Chapter" section provides links to each
section and corresponding principles/operating chapters in
this chapter.
Icon Convention
Format
Description
Remind the announcements in the operation, improper
operation may result in data loss or equipment damage.
Pay attention to the notes on the mark, improper operation
may cause personal injury.
Quick Installation Guide of NPM301 Serial Server Module
3onedata proprietary and confidential 2
Copyright © 3onedata., Ltd.
Format
Description
Conduct a necessary supplements and explanations for the
description of operation content.
Configuration, operation or tips for device usage.
Pay attention to the operation or information for ensuring
success device configuration or normal working.
Revision History
Version NO.
Revision Date
Revision Description
01
7/22/2013
Product release
02
10/1/2013
Document upgrade
03
9/12/2019
Document upgrade
Quick Installation Guide of NPM301 Serial Server Module
3onedata proprietary and confidential
Copyright © 3onedata Co., Ltd. I
Contents
PREFACE.........................................................................................................................................................1
CONTENTS.......................................................................................................................................................I
1PRODUCT OVERVIEW..................................................................................................................................... 1
1.1 PRODUCT INTRODUCTION............................................................................................................. 1
1.2 PRODUCT FUNCTION..................................................................................................................... 1
2PRODUCT FEATURES....................................................................................................................................... 3
3HARDWARE DESCRIPTION.................................................................................................................... 5
3.1 PIN DISTRIBUTION......................................................................................................................... 5
3.2 ETHERNET PORT DESCRIPTION....................................................................................................8
3.3 POWER SUPPLY PORT DESCRIPTION...........................................................................................8
3.4 SERIAL PORT AND I/O PORT DESCRIPTION................................................................................. 8
3.5 PIN DESCRIPTION OF LED INDICATION........................................................................................ 9
3.6 OTHER PIN DESCRIPTION............................................................................................................. 9
4MECHANICAL DIMENSIONAL DRAWING..........................................................................................11
5PERFORMANCE AND PARAMETER................................................................................................... 12
Quick Installation Guide of NPM301 Serial Server Module
3onedata proprietary and confidential
Copyright © 3onedata Co., Ltd. 1
1Product Overview
1.1 Product Introduction
NPM301 is a high-performance embedded serial to Ethernet module. It can
implement self-adaptive 10Base-T/100Base-TX Ethernet port. Its serial port has
communication rate of 300 bps-115200bps and multiple operating modes like TCP
Server, TCP Client, TCP Auto, UDP and Real COM. It supports up to 4 connections
and other functions such as domain name visiting.
All settings of NPM301 module can be achieved through serial port and network. The
module can be used as a communication processor between serial device and PC, or
remote communication between multiple serial devices. It can be widely used in PLC
control and management, building automation, medical care automation system,
measuring instrument, and environment power monitoring system.
1.2 Product Function
Adopt 32-bit ARM processor
Support self-adaptive 10/100M Ethernet interface
Support AUTO MDI/MDIX, using crossed or cut-through network cable for
connection
Support 300bps-115200bps wire speed non-blocking communication
Support low power consumption mode and high performance mode.
Support multiple operating modes like TCP Server, TCP Client, TCP Auto, UDP
and Real COM driver. Operating port, destination IP address and port are all
configurable
Quick Installation Guide of NPM301 Serial Server Module
3onedata proprietary and confidential
Copyright © 3onedata Co., Ltd. 2
Support WEB server management, which is convenient for client to configure
webpage
Support AT command, convenient for user’s secondary development
Support DNS, can meet the requirement of achieving communication via domain
name
Support virtual serial port drive access mode and automatic recovery and
reconnection from network interrupt
Flexible serial port data framing setting, can meet user’s various requirements for
data partition
Support SOCKET operating modes (TCP Server, TCP Client, UDP etc.)
Flexible serial port data framing setting, can meet user’s various requirements for
data partition
TCP supports multi-connection, enable up to 4 users to manage the device with
embedded module simultaneously
In UDP mode, it supports stand-alone and multi-computer communication,
enable multiple users to manage the device with embedded module
simultaneously
Support multiple configurations like SOCKET, serial port and WEB
Support both local and remote system firmware upgrade
-40～75℃operating temperature
Quick Installation Guide of NPM301 Serial Server Module
3onedata proprietary and confidential
Copyright © 3onedata Co., Ltd. 3
2Product Features
TCP/UDP Direct Programmatic Access
NPM301 module supports TCP/UDP Ethernet direct access mode of standard API
interface form such as WINSOCK. It can implement all control and transmission
process through easy programming. In most cases, direct programmatic access,
which could achieve error-free connection, is the best solution.
Virtual Serial Port Access
For most serial devices based on serial port programmatic access, reprogramming is
not always the best choice. NPM301 module provides a virtual serial port access
mode. User only needs to install the driver that comes with the product, and then
multiple virtual serial ports would be created on PC. User software can transparently
access remote serial port device by opening the serial port virtualized by software and
need no complicate Ethernet access process. And all Ethernet control and
transmission process related to NPM301 module could be operated on the driver.
Interconnection of Two Serial Device Networking Servers
Sometimes user can extend serial port distance via Ethernet only. NPM301 module
supports this application, which is to implement point-to-point interconnection of two
devices through easy settings and no need of programming and drivers.
Multiple Hosts Sharing One Serial Device Networking Server
In many cases, multiple users need to share data resources from one serial port;
therefore, it needs multiple hosts to access one serial device networking server.
Quick Installation Guide of NPM301 Serial Server Module
3onedata proprietary and confidential
Copyright © 3onedata Co., Ltd. 4
NPM301 module could operate in this mode according to user’s requirements,
allowing multiple hosts to access one serial port at different times.
One Host Accessing Multiple Serial Device Networking Servers
Because of the scattered distribution of collecting devices, it usually needs one host to
access multiple serial device networking servers in data collecting system. NPM301
module provides two modes to support this situation: one is establishing multiple
virtual serial ports for accessing different serial device networking servers respectively;
the other is using one virtual port to access all serial device networking servers. User
could reasonably choose those two modes according to their own features.
Support Cross-router Transmission
Routers are needed for connecting devices of both ends in many projects. NPM301
module could cross router to connect opposite device easily. The setup process is
quite easy as well.
