ZRGP PowerBase X1 Manual de usuario
Residential Energy Storage Unit
PowerBase X1
Reference Manual
Rev 1.58
11/20/2021
About this manual
l This manual introduces how to install the energy storage system battery pack.
Please read this manual before trying to install the product Installation process. If
you are not sure about any requirements, suggest
l The information contained in this manual is accurate in publication. The specifications of
this product are more than subject to notice. In addition, the illustrations in this manual are
intended to help explain the system configuration concepts and installation instructions.
The project may be in a project that is in a different location.
Introduction
l All information in this document is the property of the equipment manufacturer. No
part of this document may be reproduced in any commercial manner. Allow internal
use.
l The equipment manufacturer makes no express or implied warranty or guarantee
for this document or any equipment and / or software that may be described in this
document.
l This includes, but is not limited to, any implied warranties of practicality,
commerciality, or fitness for any particular purpose. Expressly disclaim all such
representations or guarantee under no circumstances shall the equipment
manufacturer or its distributors or distributors be liable for indirect, incidental, or
indirect losses.
l Under certain regulations, the exclusion of implied warranties may not apply, so the
above exclusion may not apply.
l The specifications in this document are subject to change without notice. We have
made every effort to make this document complete, accurate and up to date.
l In some cases, the supplier may need to make some improvements without notice.
The equipment manufacturer shall not be liable for any loss caused by this document
l Any liability, including but not limited to omissions, typographical errors, arithmetic
errors, or listed errors in this document.
Table of Contents
1. Safety Precautions ................................................................................................................ 3
1.1 LABEL ICONS EXPLANATION ............................................................................................... 3
1.2 GENERAL WARNING .............................................................................................................. 4
1.3 CHARGE AND DISCHARGE WARNINGS ............................................................................. 6
1.4 TRANSPORTATION WARNINGS ......................................................................................... 6
1.5 DISPOSAL OF LITHIUM BATTERIES ................................................................................... 7
1.6 BEFORE CONNECTION .......................................................................................................... 7
1.7 WHEN IN USE .......................................................................................................................... 8
2. STORAGE, TRANSPORTATION, AND EMERGENCY SITUATIONS ................................ 9
2.1 STORAGE .................................................................................................................................. 9
2.2 TRANSPORTATION ............................................................................................................... 9
2.3 EMERGENCY SITUATIONS ................................................................................................... 9
3. Product Introduction ........................................................................................................... 11
3.1 Introduction ........................................................................................................................... 11
3.2 Lithium Iron Phosphate Battery ....................................................................................... 11
3.3 Power Base X1 FEATURES ................................................................................................. 11
4. Product Description ............................................................................................................. 13
4.1 Product Description .............................................................................................................. 13
4.2 Battery Indicator Description ............................................................................................ 16
4.3 SLEEP AND WAKE UP ........................................................................................................ 18
5. Installation ............................................................................................................................ 20
5.1 The package includes: ......................................................................................................... 20
5.2 Installation location ............................................................................................................. 20
5.3 Tools ....................................................................................................................................... 22
5.4 Safety gear ........................................................................................................................... 22
5.5 Making network cable ........................................................................................................ 22
5.6 Installation clearance ......................................................................................................... 24
5.7 Cable connections ................................................................................................................ 24
6. Trouble Shooting ................................................................................................................. 27
6.1. Determine the problem based on whether the battery can be turned on or not: .. 27
6.2. Preliminary determination steps .................................................................................... 27
7. Battery Indicator Description ............................................................................................ 30
3
1. Safety Precautions
1.1 LABEL ICONS EXPLANATION
Risk of electric shock!
Risk of fire!
Corrosive materials!
Risk of explosion!
Hot surface. Do not touch.
Read the instructions and keep them for future reference.
Wear protective eyeglasses and clothing.
Keep the battery away from open flame or ignition sources.
NOTE:
It is very important and necessary to read the user manual carefully (in the
accessories) before installing or using battery. Failure to do so or to follow any of the
instructions or warnings in this document can result in electrical shock, serious injury,
or death, or can damage battery, potentially rendering it inoperable.
CAUTION！
It is required to read the user manual carefully before installing or using the battery.
Failure to do so or to follow any of the instructions or warnings in this document can
result in electrical shock, serious injury, or death, or can damage the battery,
potentially making it inoperable.
4
1.2 GENERAL WARNING
• WARNING! The voltage of this battery is strong enough to cause electric shock.
• Use the battery only as intended. The system must only be used to store electrical
power.
• Work on a lithium battery should be carried out by qualified personnel only.
• Use insulated tools. Do not wear any metallic items such as watches, bracelets, etc.
• Terminals of the lithium battery are always alive. Therefore, do not place items or
tools on the lithium battery.
• Do not allow the battery connectors to touch conductive objects such as wires.
• Avoid short circuits, too deep discharges and too high charge currents.
• Any uncovered battery material such as electrolyte or powder on the skin or in the
eyes must be flushed with plenty of clean water immediately. Then seek medical
assistance. Stains on clothing should be rinsed out with water.
• If the battery casing is damaged, do not touch the exposed electrolyte or powder
because it is corrosive.
• The battery is intended for indoor use only. Do not expose the cables outdoor.
• Do not open, dismantle, or repair the battery. Electrolyte is very corrosive. In normal
working conditions, contact with the electrolyte is impossible.
CAUTION！
The product must be installed by a qualified electrician only and must be accompanied
by a document confirming this. Do- it-yourself installation will void the warranty and
may damage the battery resulting in electric shock, fire, or loss of life.
5
• Lithium batteries are heavy. If involved in an accident, they can become a projectile!
Ensure adequate mounting, secure it, always use suitable handling equipment for
transportation.
• Handle with care. A lithium battery is sensitive to mechanical shock.
• Do not touch the battery with wet hands.
• Keep out of the reach of children and pets.
• Do not expose the battery to flammable or harsh chemicals or vapors.
• Do not paint any part of the battery, including any internal or external components.
The battery may explode. Do not drop, deform, impact, cut, crush or puncture it.
• Do not drag or step on the battery. Do not subject it to any strong force.
• Do not expose the battery to heat, fire, direct sunlight, liquids and moisture.
• Do not use a damaged battery.
• Contact the supplier within 24 hours if you observe abnormal operation.
• It is prohibited to insert any foreign object into any part of the battery.
• Servicing must be performed by qualified personnel only. All the battery terminals
must be disconnected for maintenance.
• Do not use cleaning solvents to clean the battery.
• In case of fire, you must use a type D, foam or CO2 fire extinguisher.
• The warranty claims are excluded for direct or indirect damage due to items above.
The manufacturer does not undertake any consequences or related responsibility which
results from violation of safety operation or violating of design, production and
equipment safety standards.
At the end of its useful life, do not dispose of the device with your normal household
waste. For proper treatment, recovery and recycling, take this product to a designated
collection point.
6
1.3 CHARGE AND DISCHARGE WARNINGS
• If the battery is stored for a long time, it is required to charge it every 6 months, and
the SOC should be at least 90%.
• After full discharge, the battery needs to be recharged within 12 hours.
• Do not connect the battery to PV solar wiring directly.
• Use only with an approved BMS.
• If the lithium battery is charged after being discharged below the "Discharge Cut-off
Voltage", or when the lithium battery is damaged or overcharged, it can release a harmful
mixture of gases such as phosphate.
• The temperature range within which the battery can be charged is 0 °C to 55 °C.
Charging the battery at temperatures outside this range may cause severe damage to
the battery and/or reduce battery life expectancy.
• The temperature range within which the battery can be discharged is -20 °C to 55 °C .
Discharging the battery at temperatures outside this range may cause severe damage
to the battery and/or reduce battery life expectancy.
1.4 TRANSPORTATION WARNINGS
• The battery must be transported in its original or equivalent package and in an
upright position. If the battery is in its package, use soft slings to avoid damage.
• Do not stand below the battery when it is hoisted.
• Never lift the battery at the terminals or the BMS communication cables. Only lift the
battery at the handles.
7
For transport, the batteries fall within the category UN3480, Class 9, Packaging Group II
and must be transported according to this regulation. This means that for land and sea
transport (ADR, RID, I MDG), they must be packed according to the packaging instruction
P903 and for air transport (IATA) according to packaging instruction P965. The original
packaging complies with these instructions.
1.5 DISPOSAL OF LITHIUM BATTERIES
Batteries marked with the recycling symbol must be processed via a recognized
recycling agency. By agreement, they may be returned to the manufacturer.
Batteries must not be mixed with domestic or industrial waste.
Do not throw the battery into fire.
1.6 BEFORE CONNECTION
• After unpacking, check the product and the package content first. If the product is
damaged or its parts are missing, contact your local supplier.
• Before installation, be sure to cut off the grid power and make sure the battery is
turned off.
• Wiring must be correct. Do not switch the positive and negative cables.
NOTE：
Batteries are tested according to the UN Manual of Tests and Criteria, part III,
subsection 38.3 (ST/SG/AC.10/11/Rev.7).
8
• Do not short-circuit with the external device.
• It is prohibited to connect the battery and AC power directly.
• The embedded BMS in the battery is designed for 51.2 VDC. Do not connect the
battery in series circuit.
• The battery system must be well grounded, and the resistance must be less than
0.1Q.
• Before operating the battery, make sure the grounding connection is set correctly.
• Ensure that the electrical parameters of the battery system are compatible with the
related equipment.
• Do not install the battery in wet locations and in areas at risk of explosion.
1.7 WHEN IN USE
• If the battery system needs to be moved or repaired, the power must be cut off and
the battery completely shut down.
• It is prohibited to connect the battery with batteries of different types.
• It is prohibited to make the batteries work with faulty or incompatible inverter.
• It is prohibited to disassemble the battery (QC tab removed or damaged).
• In case of fire, only dry powder fire extinguishers can be used. Liquid fire
extinguishers are prohibited.
• Do not open, repair, or disassemble the battery. This can be done only by authorized
personnel.
9
2. STORAGE, TRANSPORTATION, AND EMERGENCY SITUATIONS
2.1 STORAGE
Recharge and maintain the battery every 3 months to ensure it is in the best condition.
The recommended storage temperature is from 15 ℃to 35 ℃.
2.2 TRANSPORTATION
The battery needs to be packed before it can be shipped. Protect it from severe impact,
compression, direct sunlight and rain during transportation.
2.3 EMERGENCY SITUATIONS
Leaking Batteries
If the battery leaks electrolyte, avoid contact with the leaking liquid or gas. If you are
exposed to the leaked substance, immediately perform actions described below.
Inhalation: Evacuate the contaminated area, and seek medical attention.
Contact with eyes: Rinse your eyes with running water for 15 minutes, and seek medical
attention.
Contact with skin: Wash the affected area thoroughly with soap and water, and seek
medical attention.
Fire
In case of fire, do not use water! Only dry powder fire extinguishers can be used. To
prevent the battery from catching fire, locate it in a fire-safe area.
WARNING
If the battery catches fire, it will produce noxious and poisonous gases. Do not
approach.
Only firefighters wearing proper protective clothing (including gloves, masks, and
breathing apparatus) may enter the room with the burning power storage system.
Otros manuales para PowerBase X1
2
Tabla de contenidos
Otros manuales de Almacenamiento de ZRGP
Manuales populares de Almacenamiento de otras marcas
Spectra Logic
Spectra Logic T-Series Spectra T50e Manual de usuario
Panasonic
Panasonic LKM-F931-1 Manual de usuario
Tabernus
Tabernus Enterprise Erase E2400 Manual de usuario
Rocstor
Rocstor COMMANDER 3F series Manual de usuario
HP
HP P9000 Manual de usuario
Western Digital
Western Digital Ultrastar Data60 Manual de usuario
