ZORA MASTER Manual de usuario
ELECTRIC CARGO BIKE
ZORA MASTER
Thank you for purchasing a Zora Master electric bike！
We take pride in bringing you a quality product that will offer years of enjoyment.
We are here to help you!
Support link: https://zorabike.com/pages/contact
Phone: +1 802-456-0820
Website: zorabike.com
CATALOG
USING THIS MANUAI
GENERAL SAFETY
RECOMMEND TIGHTENING TORQUE
PRODUCT STRUCTURE
GETTING STARTED
What’s In TheBox
Pre-ride Safety Checklist
Start-up Procedure
Display Features
BIKE STORAGE
BASIC BATTERY CHARGING TIPS
BIKE CARE
WARRANTY INFO
20
25
24
21
ERROR CODE TABLE
19
2
3
6
7
8
8
11
13
14
1
NOTICE:
Please read and understand this manual fully before assembling and riding your bike. If
you have questions after reading this manual please contact us by email or phone.
Your serial number is located near the front fork of the bike. You need it for warranty request.
You may also need to provide this number to law enforcement if your bicycle is stolen.
umberNSerial
This manual contains details of the product equipmentand information on operation, maintenance, and other helpful
tips for owners. Read it carefully and familiarize yourself with the ebike before using it to ensuresafe use and pre-
vent accidents.This manual contains many warnings and cautions concerning the safe operatiorand consequences if
proper setup, operation, and maintenance are not performed. All information in this manual should be carefully reviewed
and if you have any auestions you should contact Zora immediately.
The notes, warnings, and cautions contained within the manual and paragraphs are marked by the triangular Caution
Symbol at the left side should be given special care. User should also pay special attention to information marked
in this manual beginning with
NOTICE.
Keep this manual along with any other documents that were included with your bike, for future reference, however
all content in this manual is subject to change or withdrawal without notice. Vist zorabike.com to view and dowload
the latest version. Zora makes every effort to ensure the accuracy of its documentation and assumes no responsibility
or liability if any errors or inaccuracies appear whithin.
Because it is impossible to anticipate every situation or condition that will occur while riding, this manual makes no
representations about the safe use of bikes under all conditions. There are risks associated with the use of any bike
that cannot be predicted or avoided and are the sole responsibility of the rider.
USING THIS MANUAI
2
GENERAL SAFETY
Read all the instructions before using the product.
To reduce the risk of injury, close supervision is necessary when the product is used near children.
Do not put fingers or hands into the product.
Do not use this product if the flexible power cord or output cable is frayed, has broken insulation,
or any other signs of damage.
IMPORTANT SAFETY INSTRUCTIONS WARNING!
NOTICE:
When using this product, basic precautions should always be followed, including the following:
3
When riding a bike, always wear a properly fitted helmet that covers the forehead. Many locations require specific
safety devices. It is your responsibility to familiarize yourself with the local laws, rules, and regulations where you
ride and to comply with all applicable laws, including equipping yourself and your bike as thelaw requires.
OBSERVE ALL LOCAL BICYCLE TRAC LAWSAND REGULATIONS.
Before you ride your bike, always check to make sure everything is working properly and correctly aligned.
Be familiar with the controls of your bicycle, such as brakes,pedals and shifting, etc..
Keep all body parts or any obtrusive objects away from the sharp chainrings when pedaling.Failure to wear
proper attire could lead to injuries.
While riding, remember you are sharing the road or pathwith others. i.e. motorists, pedestrians, and the cyclists.
Always be a defensive rider. Always assume that others do not see you.
Always be aware of your surroundings. Be alert and responsive to:
1.Motor vehicles of all types and in all directions.
2.Unexpected movement of obstacles.
3.Nearby pedestrians.
4.Children or animals in the area.
5.Imperfections of bike paths or paved roads including potholes, uneven surfaces, loose gravel construction,
and debris.
6.Warning, hazard, and yield signs.
Observe regulations about bicycle lighting, licensing riding on pavements/sidewalks, bike path and trail use, helmet
laws, child laws relating to cycling, and special bicycletrac laws, it is your responsibility
local laws.
to know and obey your
4
Riding in Wet Conditions
Use caution when riding in wet conditions as it will take longer to brake and to stop. Your tires may slipwhen turning.
Risk of a crash is dramatically increased in wet conditions.
Your electric bicycle can withstand light rain and small splashes, but it is not designed to be subjected to inclem ent
weather, extremely heavy showers, or submersion in water.
Ride in designated bike lanes when available and always ride in the direction of trac.
Acknowledge and stop at ALL stop signs and trac lights.
When coming to a complete stop, look both ways at street intersections before continuing onward.
Use ocial hand signals for turning and stopping.
Do not ride with headphones.
Never hold onto another vehicle.
Do not weave through trac or make unexpected moves or turns.
Rules that govern the right-of-way for motorists apply to cyclists. A bicyclist should always be prepared to yield.
Do not ride while under the influence of alcohol or drugs.
Avoid riding in bad weather when visibility is obscured, for example, dawn, dusk, or in the dark such
increase the risk of accidents.
conditions
5
RECOMMEND TIGHTENING TORQUE
6
PRODUCT STRUCTURE
1
3
2
14 4
5
6
7
8
9
10
15
18
18
19
17
13
16
11
1
2
3
4
5
6
7
8
10
Handle
On/Off
Throttle
Rear Rack
9Saddle
Frame
Shimano Shifter
Brake Lever
LED Rear Light
11 Stem
12 Chain
13 Battery
14 USB
15 Front Fork
16 Front Brake
17 Tire
18 Pedal
19 Controller
19
7
