User Manual
WalkThrough Metal Detector: ZK-D4330
Version: 1.0
Date: June. 2017
Contents I
Contents
Notes..........................................................................................................................................................1
Product Specification......................................................................................................................2
Installation Environment...............................................................................................................3
Performance and Features...........................................................................................................5
Parts.............................................................................................................................................................7
Installation..............................................................................................................................................8
Panel Description.............................................................................................................................10
Remote ControlDescription....................................................................................................11
Detection Zones...............................................................................................................................12
Operation..............................................................................................................................................13
DetectionAdjustment..................................................................................................................20
Brief Maintenance...........................................................................................................................22
Technical Parameters.....................................................................................................................23
Factory Settings................................................................................................................................24
Packing List..........................................................................................................................................25
Warranty Card.....................................................................................................................................26
Notes 1
Notes
PLEASE READTHE FOLLOWING INSTRUCTION CAREFULLYBEFORE
OPERATION:
1. -term outdoor work, please
use canopy to protect it against rain.
2. Install the device steadily on a smooth ground without vibration.
Violent shaking may cause false alarms.
3. Passengers should pass the device one byoneafter the preset
standby duration or alarm duration elapses.Crowding around the
device will interfere withthe infrared induction.
4. Choose to install in areas away from high frequency devices and
large mobile metals to avoid interference.
5. Pay attention to bolts and screws of the connecting parts of the
door body to ensure that the door body is firmly installed without
shaking.
6. Each device has awarranty card,with which users can have their
devices maintained or repaired free of charge within the warranty
period.
2ZK-D4330 User Manual
Product Specification
WalkThrough Metal Detector is mainly used to check the metal items
hidden in the body.When the passengers pass through the device, if
they carried metals morethan preset parameters value, the device
would immediately alarm and display alarm location for security guards
to identify people with the prohibited metal articles timely.
Installation Environment 3
Installation Environment
1. Stationary Metallic Items
When installing walk through metal detector, it should stay away from
the stationaryor fixed bulk metal items 30cm; otherwise it will affect the
sensitivity, causing false alarm. Metal items such as: aluminum alloy/
stainless steel doors and windows etc.
2. Movable Metallic Items
The big metal items that can be moved should stay away from the
device about 50cm to avoid false alarm.
3. FloorVibration
The floor shouldbe flat and fixed to avoid false alarms triggered by the
movement (walking or moving) of people and shaking of metal objects.
4. Electromagnetic RadiationAnd Electromagnetic Interference
Because the device uses bilateral transceiver technology, therefore, any
electromagnetic interference source and electromagnetic radiation
source is not allowed to close the device.The recommended distance is
50cm and above.The parameters of the distance depend on the
installation environment, anddifferent installation environments with
different parameters.
4ZK-D4330 User Manual
The electromagnetic interference sources and electromagnetic radiation
sources are as follows:
Electrical Control Box, Radio Equipment, Interphone, High Power Motor,
High PowerTransformer,AC Power Line,Thyristor Control Circuit(High
Power Switching Power Supply, InverterWelder), Engine, Motor, etc.
5. Side-By-Side Use
When installing the devices side by side,the distance between two walk
through metal detectors cannot be less than 30cm and the device work
frequency must be different. Specific distance parameters according to
the actual environment and the selection of the work frequency to
adjust.
Performance and Features 5
Performance and Features
Accurate Positioning:The device supports single zone, six zones,
11 zones, and 33 zones overlapping network detection modes,
bilateral transmit and receive,can be accurately positioned to detect
objects, intuitive display of the target location.
Micro ProcessorTechnology: the scanning electromagnetic wave
generated by the microcomputer control circuit, the scanning rate
can be precisely controlled.
SensitivityAdjustable: each detection zone has 300 sensitivity
levels (0 ~ 299). Preset metal size, you can exclude the coins, keys,
jewelry, belt buckle etc.
Visual SensitivityAdjustment: test and adjust the sensitivity
according to the alarm status of LED lights.
Digital PulseTechnology: digital signal processing and filtering
system, has excellent anti-interference ability.
Password Protection: only the correct password can change the
sensitivity and other parameters. Password with six digital, can be
set by the user.
Count Statistics: precision passenger counting and alarm counting,
maximum supports 100,000 counts.
6ZK-D4330 User Manual
Harmless to human body: harmless to heart pacemaker, pregnant
women, magnetic floppy disk, recording tapes etc.
Alarm Records: supports 10 million alarm record queries.
Advantage structure: adapts beam structure, modular design, and
hidden wiring design.This design not only is moreconvenient for
installation, maintenance and logistics, but also enables higher
security level.
Waterproof Foot Cover: The waterproof foot cover can not only fix
the device but also protect the device against water.
Waterproof:The device uses PVC synthetic materials and special
technologies and is waterproof, fireproof, and shockproof.
Easy to install:The system uses the integrated design, and it takes
you just 15 minutes to complete the installation oruninstallation.
Linkage:Asignal cable connector is delivered with the device.You
can connect the signal cable connector to implement linkage
between the turnstile and the walk through metal detector.
Optional items: waterproof cover and Universal wheel, the
waterproof cover can keep the device away from rain and dust, and
the pulley makes the equipment move more easily.
