ZETR 12-FRE Manual de usuario
12 INSTALLATION MANUAL / 12-FRE / 210122
PH2
DRIVER
35MM
HOLE SAW
DRYWALL
SAW
TOOLS REQUIRED
COMPATIBLE PRODUCT INDEX
WARNING
DANGER
ATTENTION
SURFACE FIRE RATED ENCLOSURE
12 SURFACE FIRE RATED ENCLOSURE / 12-FRE
Remove the faceplate from the outlet/switch
grid and safely store until required.
Terminate wiring or desired service.
N.B. If installing a switchgrid, insert your
mechanisms prior to termination.
Screw the device to the bracket using the
N.B. A minimum of 4 x fixings for outlets and
2 x fixings for switch grids are required.
INSTALLATION GUIDE
4
7
8
9
Insert the fire rated enclosure into the hole
cut-out and lightly tap the staples into the wall
so the enclosure sits flush.
Snap fit the faceplate to the device.
Wipe the device with a soft damp cloth or
detergent-impregnated wipes to complete
installation.
B. Using a philips driver turn the screws in the
enclosure clockwise to fasten the arm to the
back of the fire rated substrate and set the
enclosure in place.
5
10
3
thread through the fire rated enclosure.
4
Align the centre of the template provided to the
centre of where you’d like to install your outlet/
switchgrid. Once aligned, mark both left and
right hole centres.
centre point.
Ensure these are tangential with the top and
bottom of these holes.
1
PLASTERBOARD
12.5mm
2
6
