Operating Manual

HBO 100

Microscope Illuminating

System

Microscope Illuminating System

HBO 100 Copyright Carl Zeiss

B 46-0063 e 03/06 1

Knowledge of this manual is required for the operation of the instruments. Would you therefore

please make yourself familiar with the contents of this manual and pay special attention to hints

concerning the safe operation of the instrument.

The specifications are subject to change.

communication of its contents are not permitted. Violations will entail an obligation to pay

compensation.

Published by: Carl Zeiss MicroImaging GmbH

P.O.B. 4041, 37030 Göttingen, Germany

Phone: +49 (0) 551 5060 660

Fax: +49 (0) 551 5060 464

E-mail: [email protected]

www.zeiss.de

Number of this manual: 46-0063 e

Date of issue: 03/01/2006

Microscope Illuminating System

Carl Zeiss Contents HBO 100

2 B 46-0063 e 03/06

Contents

1Notes on Safety ......................................................................................4

1.1 General ................................................................................................................4

1.2 Regulations concerning Instrument Safety and Electromagnetic Compatibility

(EMC) ...................................................................................................................4

1.3 Notes on Unpacking, Transport and Storage .........................................................5

1.4 Hints on Use .........................................................................................................5

1.5 Hints on Maintenance and Care............................................................................6

1.6 Advice on lamp breakage......................................................................................6

1.7 Hints on Disposal ..................................................................................................7

1.8 Hints on Warranty.................................................................................................7

2Instrument Description ..........................................................................8

2.1 Components of the Microscope Illuminating System ............................................ 8

2.2 Technical Data of the Microscope Illuminating Systems ......................................... 9

3Start-Up .................................................................................................11

3.1 Lamp Insertion and Change ................................................................................11

3.2 Start-Up of HBO 100 Microscope Illuminating System ......................................... 13

3.3 Focusing and Centering the HBO 100 Microscope Illuminator (423010) ...............14

3.4 Focusing and Centering the HBO 100 Microscope Illuminator, self-adjusting

(423011-9901) .....................................................................................................15

3.5 Setting Offset Values on HBO 100 Microscope Illuminator, self-adjusting

(423011-9901) ...................................................................................................16

3.6 Inserting the Collector Attachment .....................................................................17

Microscope Illuminating System

HBO 100 Illustrations Carl Zeiss

B 46-0063 e 03/06 3

Illustrations

Fig. 1 HBO 100 Microscope Illuminating System (manual adjustment) ............................ 8

Fig. 2 HBO 100 Microscope Illuminating System, self-adjusting...................................... 8

Fig. 3 Line spectrum of the HBO 100/103 mercury short-arc lamps............................... 10

Fig. 4 Inserting the HBO 103 lamp ............................................................................... 11

Fig. 5 Rear of transformer for HBO 100........................................................................ 13

Fig. 6 Front of transformer for HBO 100....................................................................... 13

Fig. 7 Lamp arc and mirror image................................................................................. 14

Fig. 8 Adjusting elements of HBO 100 for manual adjustment...................................... 14

Fig. 9 Adjustment of HBO 100, self-adjusting............................................................... 15

Fig. 10 Keys for setting offset values for the adjustment of lamp arc and mirror image... 16

Fig. 11 Inserting the collector attachment ...................................................................... 17

Safety Microscope Illuminating System

Carl Zeiss General, EMC HBO 100

4 B 46-0063 e 03/06

1 Notes on Safety

1.1 General

Please make yourself familiar with the contents

of these operating instructions before attaching

and starting up the HBO 100 Microscope

Illuminating System. Additional information is

available from our maintenance service or from

authorized agencies.

The HBO 100 Microscope Illuminating System

should be used with Zeiss microscopes

exclusively.

The HBO 100 Microscope Illuminating System

may only be handled by trained personnel.

To ensure that the illuminating system functions

properly with the microscope, the appropriate

microscope manual must be observed.

In addition, observe the manual

"HBO 100 – Electronic ballast“.

Special regard must be paid to the notes on

instrument safety included in this manual.

The data sheets from the lamp manufacturers

must be observed when the HBO 103 lamps are

operated.

To guarantee the safe operation and function

of the HBO 100 Microscope Illuminating

System, it is necessary under any circumstances

to take the precautions and observe the

warnings contained in the operating

instructions.

The following warning and information symbols

are used in this manual:

CAUTION!

Non-observance of the safety notes constitutes

a hazard for the user.

CAUTION!

Dangerous electrical voltage.

CAUTION!

Disconnect the instrument from the line before

opening it!

CAUTION!

Hot surface.

CAUTION!

Non-observance of the safety notes constitutes

the risk of damage to the instrument.

NOTE!

Notes which must be observed when using the

HBO 100 Microscope Illuminating System.

1.2 Regulations concerning

Instrument Safety and

Electromagnetic

Compatibility (EMC)

The HBO 100 Microscope Illuminating System

has been designed, produced and tested in

compliance with EN 61010, Part 1 (VDE 0411).

It was delivered in a technically safe and perfect

state.

The illuminating system meets the requirements

of EC directives 73/23 and 89/336 and the EMC

legislation, as amended on September 18,

1998.

Radio-noise suppression complies with

EN 55011, Class B, noise immunity with

EN 61326.

Compliance with the EC directives mentioned is

documented by the CE certificate.

Microscope Illuminating System Safety

HBO 100 Unpacking, Use Carl Zeiss

B 46-0063 e 03/06 5

1.3 Notes on Unpacking,

Transport and Storage

The lamps may be removed from the package

only if the protection mask (Cat. No. 417009)

and the safety gloves with artery protection

(Cat. No. 417008) are worn.

For safety reasons, a safety holder is inserted in

the microscope illuminator instead of the bulb

during transport.

Both the HBO 100 microscope illuminator and

the HBO 103 lamp must be transported in their

original packaging.

This packaging must be kept for storage and

disposal.

The transport and storage temperatures to be

observed correspond to those of the microscope

stands.

1.4 Hints on Use

− When they are hot, the lamps are under high

internal pressure.

They may only be inserted in the microscope

illuminator if a safety mask and safety gloves

(see chapter 1.3) are worn.

− The HBO 103 lamps are under high pressure

during operation; they must always be

operated in closed lamp housings!

− The light of the HBO 103 short-arc lamps

contains a high amount of UV light:

ÎNever look directly into the lamp or in

reflected light

ÎWear safety glasses (sunglasses) when

operating the lamps

ÎCover inspection openings with filters

− The UV radiation of the lamps produces little

quantities of harmful ozone.

Take care to ventilate the working room with

fresh air.

− Both the HBO 100 microscope illuminator

and the HBO 103 lamps must be protected

from impact and humidity. Always keep the

ventilation slats clear and ensure that no

objects enter the instrument through the

ventilation slats.

− If the lamp bulb has broken, observe the

information provided by the lamp

manufacturer.

Instead of the HBO 103 lamp, its predecessor

HBO 100 can also be used.

Safety Microscope Illuminating System

Carl Zeiss Maintenance, Care, Lamp breakage HBO 100

6 B 46-0063 e 03/06

1.5 Hints on Maintenance and

Care

To ensure perfect function of the microscope

illuminating system, it is necessary to use only

components and spares marketed or approved

by us. When in doubt, please contact our

service staff.

With the exception of the work described in this

manual, the user must not perform any repairs

or changes himself.

We would like to emphasize that all other

changes and repairs must be performed by

specially authorized personnel.

Defective instruments or components may only

be repaired and maintained by our service

department.

− After expiry of the average operating time

(see data sheets from the lamp

manufacturers), the lamps must be

exchanged to avoid the risk of explosion!

The operating time of the HBO 103 can be

checked on the display of operating hour

meter of the relevant transformer.

(Fig. 6)

With increasing service life, dirt will deposit

on the lamp bulb so that homogeneous

illumination of the object field is no longer

ensured.

− The lamps must be exchanged as described

in chapter 3.1.

− Before each lamp exchange, make sure to

allow the HBO 100microscope illuminator to

cool down sufficiently long in order to

reduce the pressure; wait at least for 15

minutes!

− Always disconnect the instrument from the

line before each lamp exchange or any other

work inside the instrument.

− Clean the housing of the microscope

illuminator when it is dirty.

Do not use any solvents.

Soak a cleaning cloth in a mixture of water

and washing-up liquid, remove the dirt and

dry the housing using a clean cloth.

1.6 Advice on lamp breakage

If the HBO lamps have reached their rated

lifetime or their bulbs show advanced

blackening, they should be replaced because of

the increasing risk of explosion.

If lamps are operated properly, lamp explosion

is very unlikely.

For the rare case, that an HBO lamp bursts and

the mercury (Hg) contained in the bulb is

released, we recommend to follow this

procedure:

− First of all, the persons being nearby should

instantly leave the place to avoid inhaling

mercury vapor.

− Air the laboratory thoroughly (for approx.

30 minutes)!

− Every lamp housing of a higher-power lamp

should be equipped with an individual

exhaust device that is not connected to the

domestic air-conditioning system to avoid

that mercury vapor enters this system.

− Once the lamp housing has cooled down,

collect any mercury residues precipitated

inside the lamp housing by using an

adsorbent available from a chemicals

supplier.

Microscope Illuminating System Safety

HBO 100 Disposal, Warranty Carl Zeiss

B 46-0063 e 03/06 7

1.7 Hints on Disposal

Used HBO 103 lamps and defective microscope

illuminators should not be treated like domestic

waste; they should be disposed of in their

original packaging in accordance with the legal

regulations.

When in doubt, please contact the Carl Zeiss

microscopy service.

1.8 Hints on Warranty

The instrument manufacturer is not liable for

damage caused by unauthorized operation,

particularly the removal and exchange of

components, or the use of accessories from

other manufacturers. This forfeits all the claims

against warranty.

Instrument Description Microscope Illuminating System

Carl Zeiss Components, Catalogue Numbers HBO 100

8 B 46-0063 e 03/06

2 Instrument

Description

2.1 Components of the

Microscope Illuminating

System

1 Lamp, top part

2 Line cable 5 Lamp, bottom part

3 Transformer for HBO 100 6 Dovetail

4 Connecting cable 7 Heat-protection filter

Fig. 1 HBO 100 Microscope Illuminating System

(manual adjustment)

1 Lamp, top part

2 Line cable 5 Lamp, bottom part

3 Transformer for HBO 100 6 Dovetail

4 Connecting cable 7 Heat-protection filter

Fig. 2 HBO 100 Microscope Illuminating System,

self-adjusting

The HBO 100 Microscope Illuminating System

is available in a manually and a self-adjusting

version.

The microscope illuminating systems include

the following components (Fig. 1/Fig. 2):

− Illuminator with:

dovetail for attachment to the microscope,

integrated collector,

heat-protection filter

− HBO 103 W/2 mercury vapor short-arc lamp

(Osram)

− Transformer for HBO 100

− line cable with earth-contact plug

line cable with American flat plug

HBO 103

Microscope

Illuminators

HBO 100 illuminator

423010

HBO 100 illuminator, self-adjusting

423011-9901

Lamp

Mercury vapor-

short-arc lamp

HBO 103 W/2

380301-9350-000

Transformer Transformer for HBO 100

432604-9901

Line cable

Line cable with earth-contact plug

380137-6750-000

Line cable with American flat plug

380137-6740-000

Table: Catalogue numbers

Tabla de contenidos

Otros manuales de Microscopio de Zeiss

Zeiss

Zeiss LSM 5 MP Manual de usuario

Zeiss

Zeiss Primostar 3 Manual de usuario

Zeiss

Zeiss Cell Observer spinning disk confocal Manual de usuario

Zeiss

Zeiss Axiocam MR Manual de instalación y funcionamiento

Zeiss

Zeiss Axioscope 5 Manual de usuario

Zeiss

Zeiss OPMI 1 FR pro Manual de instrucciones

Zeiss

Zeiss Primo Star Manual de usuario

Zeiss

Zeiss LSM 880 Manual de usuario

Zeiss

Zeiss LSM 510 Manual de usuario

Zeiss

Zeiss Crossbeam 350 Manual de usuario

Zeiss

Zeiss Primostar 1 Manual de usuario

Zeiss

Zeiss LSM 510 Inverted Manual de usuario

Zeiss

Zeiss Axioscope 5 Manual de usuario

Zeiss

Zeiss LSM 700 Manual de usuario

Zeiss

Zeiss AxioObserver D1 Manual de usuario

Zeiss

Zeiss OPMI 1FR XY Manual de usuario

Zeiss

Zeiss LSM 880 Manual de usuario

Zeiss

Zeiss Axioskop 40 Manual de usuario

Zeiss

Zeiss ELYRA Manual de usuario

Zeiss

Zeiss LSM800-02 Manual del operador

Zeiss

Zeiss JENAVAL Manual de usuario

Zeiss

Zeiss KF 2 ICS Manual de usuario

Zeiss

Zeiss LSM800-2 Manual de usuario

Zeiss

Zeiss SL 800 Manual del operador

Manuales populares de Microscopio de otras marcas

Thermo Scientific

Thermo Scientific Nicolet iN10 Guía

National

National DC3-163 Manual de usuario

KERN Optics

KERN Optics OPE-1 Manual de usuario

OPTIKA MICROSCOPES

OPTIKA MICROSCOPES B-150D Manual de usuario

Prior

Prior Lux POL Manual de usuario

Opitec

Opitec Smartscoop 115615 Manual de usuario

KERN

KERN OPO-1 Manual de usuario

Topcon

Topcon SP-1P Manual de usuario

Motic

Motic PA43 Manual de usuario

Leica

Leica DVM5000 Guía del usuario

MshOt

MshOt MZ62 Manual de usuario

KERN Optics

KERN Optics OZR-5 Manual de usuario

VWR

VWR VisiScope 384 Series Manual de usuario

Nikon

Nikon ECLIPSE E200 POL Manual de usuario

Leica

Leica DI C800 Manual

ThermoFisher Scientific

ThermoFisher Scientific Continuµm Manual de usuario

ThermoFisher Scientific

ThermoFisher Scientific Continuµm Manual de usuario

Olympus

Olympus SZ61 Manual de usuario
