Zebronics ZEB-PLUTO 2 Manual de usuario

www.zebronics.com

User Manual

PLUTO

2.1 Speaker

ZEB

Thank you for purchasing the ZEB-PLUTO 2

2.1 Speaker. Please read the user manual

carefully before usage & save it for future

reference.

Note:

Features

2.1 channel speaker

BT v5.0/AUX/FM/USB /mSD

RGB LED Lights

7.62cm (3") subwoofer

Volume controller

6 LED modes +1 oﬀ mode

Speciﬁcations

Output Power (RMS)

Subwoofer : 9 watts

Satellites : 2 x 3 watts

Total : 15 watts

Drivers

Subwoofer : 7.62 cm (3")

Satellites : 5.2 cm x 2

https://zebronics.com/pages/warranty-policy

Impedance

Subwoofer : 3 ohm

Satellite : 4 ohm

Frequency response : 80Hz - 15kHz

S/N Ratio : ≥ 65dB

Separation : ≥ 60dB

File format support

(USB/mSD) : Mp3

Line input : 3.5mm

Max supported USB/

mSD memory size : 32GB

FM frequency range : 87.5 MHz -108MHz

BT name : ZEB - PLUTO 2

BT versionv : 5.0

Product Dimension (W x D x H)

Subwoofer : 13.4 x 13.7 x 13.8 cm

Satellite : 8 x 8 x 10 cm

Net.Weight : 860g

Package Content

Speaker : 1 U

QR Code Guide : 1 U

Control Panel Description

1.Volume knob with power on /oﬀ switch

2. Mode / LED Button.

3.Previous button / Volume -

4.Play/Pause button

5.Next / Volume + button

6. USB Port

7.mSD Slot

8.LED indicator

General Instructions

BT Mode:

Turn on the speaker, press "LED/M"

button to switch to BT Mode. Switch ON BT on

your phone or tablet and search for nearby BT

devices, Search for the BT name " ZEB PLUTO 2 "

and tap to connect it.

678

USB Mode & mSD mode:

The speaker automatically switches to

USB input mode when a USB ﬂash drive is

inserted into the speaker. The songs from the

USB audio source can be heard through the

speaker (this mode isn't selectable on the

speaker unless a mSD/ USB ﬂash drive is

connected). Single Press The PREV to switch to

previous audio track and Single Press the NEXT

button to switch to next audio track.

FM Radio:

Press the LED/M button to select FM mode.

Long press Play pause button to initiate FM

Scanning process. Once the scanning process is

done, the Speaker automatically plays the First

channel of the FM. Press Prev to switch to

previous FM channel and Press Next to switch

to next FM channel.

AUX-IN:

Press the "LED/M" button to select AUX mode.

The speaker can be connected to an audio

source using the inbuilt USB 3.5mm cable. Plug

the USB connector to the Rated 5V Power

source and connect the 3.5 mm Aux connector

to an audio source. The songs from the audio

source can be heard through the speaker.

LED LIGHTS Control

Using the integrated LED/Mode button. Press

and hold the LED/Mode button. To switch the

LED mode of the speaker. There are 6 LED

Modes + One oﬀ mode available in the speaker.

ISO 9001:2015 Certified Company

www.zebronics.com
