Zebex Z-6070 Series Manual de usuario

P/N: MUL-53249-01

User ' s Manual

Z-6070 Series Hand Free

Laser Scanner

Importance

This equipment generates, uses and can radiate radio frequency

energy. If not installed and used in accordance with the instructions

in this manual, it may cause interference to radio communications.

The equipment has been tested and found to comply with the limits

for a Class A computing device pursuant to EN55022 and 47

CFR,part2 and Part 15 of FCC Rules. These specifications are

designed to provide reasonable protection against interference when

operated in a commercial environment.

For CE-countries:

- The Z-6070 is in conformity with the CE standards. Please note

that a ZEBEX CE-Marked power supply unit should be used to

conform to these standards.

Radio and television interference

Operation of this equipment in a residential area can cause

interference to radio or television reception. This can be determined

by turning the equipment off and on. The user is encouraged to try

to correct the interference by one or more of the following measures:

Re-orientate the receiving antenna

Relocate the device with respect to the receiver

Move the device away from the receiver

Plug the device into a different outlet so that the

device and the receiver are on different branch

circuits

If necessary, the user should consult the manufacturer, an authorized

dealer or experienced radio/television technician for additional

suggestion. The user may find the following booklet prepared by the

Federal Communications Commission helpful:

“How to ldentify and Resolve Radio-TV Interference Problems”.

This booklet is available from the U.S. Government Printing Office,

Washington, DC 20402, Stock No. 004000003454.

Important Notice

ZEBEX INDUSTRIES INC. MAKES NO WARRANTY OF

ANY KIND WITH REGARD TO THIS MATERIAL,

INCLUDING, BUT NOT LIMITED TO, THE IMPLIED

WARRANTIES OF MERCHANT ABILITY AND FITNESS

FOR A PARTICULAR PROPOSE. ZEBEX INDUSTRIES

INC. SHALL NOT BE LIABLE FOR ERRORS CONTAINED

HEREIN OF FOR INCIDENTAL CONSEQUENTIAL

DAMAGES IN CONNECTION WITH THE FURISHING,

PERFORMANCE, OR USE OF THESE MATERIALS.

ZEBEX INDUSTRIES INC.

All other registered trademarks are registered companies’

property. ZEBEX is a registered trademark of ZEBEX

INDUSTRIES INC.

portion of its contents is not allowed without the specific

written consent of ZEBEX INDUSTRIES INC.

Printed In May, 2004

TABLE OF CONTENTS

Introduction ......................................................................... 1

Unpacking........................................................................... 2

Scanner Outline and Indicator............................................. 4

Power Connection............................................................... 6

Verify the Scanning Operation............................................. 7

Template Installation (if required) ........................................ 8

Connecting the Scanner.................................................... 10

RS-232 interface...................................................... 10

Keyboard wedge.......................................................11

USB Interface.......................................................... 12

Wand emulation....................................................... 13

Replacing the Interface Cable........................................... 14

How to Scan...................................................................... 15

Scanning Operation

Multi-line mode ........................................................ 15

Fixed mode scanning..................................... 16

Hand held mode............................................. 18

Single line mode...................................................... 19

Sleep Mode....................................................................... 20

LED & Beeper Indications................................................. 21

Changing Beeper Volume Using Push Button................... 23

Maintaining the Scanner.................................................... 24

Controlling Scanner from the POS System....................... 25

Laser Safety...................................................................... 26

Appendixes

Appendix A: Connector & Pin Out............................ 29

Appendix B: Specifications ...................................... 30

Appendix C: Trouble Shooting................................. 32

iii

Introduction

Z-6070 is the first dual-laser presentation scanner in the

world with numerous record-breaking key features. Its

pioneered application of dual laser diodes drastically

enhance scanning power by doubling up scan lines,

broadening scan angle and intensifying scan pattern across

scan field. With this state-of-art technology, Z-6070 is able to

deliver the most comprehensive 32-line scan pattern

empowering 2400 scans per second, In addition, Z-6070 is

equipped with Z-SCAN technology, which is an innovative

ASIC hardware decode technology to provide real-time

decode capability to effectively shorten customer transaction

time.

Z-6070’s broad scan field could effectively facilitate scanning

barcodes on products in all kinds of shapes. Moreover, it is

designed for both hands-free and handheld applications. To

scan large merchandise that cannot be placed on the counter,

sales clerks could easily pick up Z-6070 from its stand to

perform the product scan. While scanning multiple barcodes

on one object, sales clerks could switch it to single line scan

option simply by pressing one button. The adjustable stand

design grants users the flexibility to set the easiest angle of

scan. Furthermore, Z-6070 is programmed with multiple

beeper tones and barcode data edition function for different

applications.

Unpacking

When you open the Z-6070 containing box, please check to

make sure everything you ordered is present and check if

there is any damage during shipment. If you find any

damages or missing components, please report immediately

to your sales representative.

Open the box, in it should contain:

G G

Figure 1

Item Part n. Description

A Z67-93390-US Z-6070 hand free scanner

B Z67-93390-US Adjustable stand (optional)

Communication and power link Cable (According to

order)

CAB-53122-DM

CAB-50114-CA

Keyboard wedge cable for

PC/AT/PS2

CAB-53129-RP DB-9 female connector RS232 cable

DTE pin-out

CAB-53130-R9 DB-9 female connector RS232 cable

DCE pin-out

CAB-53131-UB Low speed USB cable

AC to DC power adaptor---Regulate 5V@600mA

(Optional by order)

PWO-90810-US 120V United States

PWO-90811-EU 230V Continental European

PWO-52215-US 100~240V United States,Applied

Regions:North America, Japan

PWO-52212-EU

100~240V Continental European

Applied Regions:

Europe, Middle East, South

East,Asia, South America

PWO-52213-UK

100~240V United Kingdom Applied

Regions:

Hong Kong, Malaysia, Singapore,

UAE, UK

PWO-52214-AU 100~240V Applied Regions:New

Zealand, Australia

For special power requirement, please contact your dealer,

distributor or directly contact ZEBEX

E MUL-53249-xx Reference manual

F MUL-53243-xx Programming Guide

G MET-01531-FP base template /Screw(optional)

Scanner Outline and Indicator

Figure 2

Wake up scanner When the scanner enters into the

sleep mode, pressing this switch can

wake the scanner up. The sleep

mode feature can be programmed

using the menu labels from the

Programming Guide.

NOTE: The default value for the

sleep mode time-out is set to 10

minutes after laser sleep, 30

minutes after motor sleep. When

the scanner is in sleep mode, the

LED is intermittently flashing red.

Button

Single -line pattern Pick up the scanner, press and

release the trigger will active single

line scan mode

Beeper tone

selection When the scanner is sitting in the

adjustable stand, press down this

button for a duration of time (5 sec),

it will automatically change the

beeper volume.

LED A red LED indicates the scanner is ready to read a

barcode while a green LED indicates a good read.

Good

Read

Buzzer

If the data is captured correctly, the buzzer will be heard.

Both the volume and frequency are programmable using

the menu labels from the Programming Guide.

Adjustable

stand This stand allows you to direct the scan pattern in a way

that is the best for your application by adjusting the

scanner window forward, backward.

Power

Link

interface

cable

Connect the external AC/DC power adaptor into

the power jack on the power link cable. And the

interface connector provides the communication

the scanner and host terminal
