Zanussi OZ Manual de usuario

user instructions

Oz completo GB 19-05-1999 15:54 Pagina 3

The formation of frost and/or water droplets on the

back wall of the compartment is quite normal and

occurs in all refrigerators; it is due to the presence of

the rear-mounted evaporator.

In OZ, the phenomenon is more obvious because

of the aquamarine colour of the compartment and

because of the light shining down it from the interior

light fitted vertically on the left-hand side.

Thisphenomenondoes not,however,in anyway affect

normal operation of the appliance.

Important

22210-5301 1577*

Oz foglio aggiuntivo ING 19-05-1999 16:00 Pagina 1

Congratulations!

By buying

, you have chosen a top quality product,

designed to make your home life easier and more

comfortable.

is covered by a guarantee: the guarantee certifica-

te is attached. If it is missing, ask your retailer for it.

Oz completo GB 19-05-1999 15:54 Pagina 5

invites you to read this instruction booklet carefully and

to keep it in a safe place so that it is easily available for futu-

re reference, if required.

If, one day, you unfortunately have to part with , make

sure that you give this booklet to the new owner, so that he

has all the information needed for the operation and mainte-

nance of the appliance.

The warnings you are about to read have been prepared to

ensure your safety and that of others: please read them very

carefully before installing and using the appliance.

Important recommendations and advice

Oz completo GB 19-05-1999 15:54 Pagina 2

If OZ is replacing a refrigerator with a mechanical

locking catch, make sure that this device is rendered

inoperable before discarding the appliance: this is to

avoid the possibility of children accidentally shutting

themselves in the appliance and thus endangering

their lives.

OZ has been designed to be operated by adults. Do

not allow children to tamper or play with it.

When moving OZ, take great care not to damage the

refrigerant circuit and avoid any leakage of fluid.

OZmust not be located near to radiators or cookers.

Also avoid exposure to direct sunlight for prolonged

periods.

After installing OZ, make sure that the power supply

cable is not trapped .

Air must be able to circulate freely round the back of

OZ and care must be taken to avoid any damage to

the refrigerant circuit.

Never place electrical appliances (for example ice

cream makers) inside OZunless expressly approved

by the manufacturer.

Always remember to remove the plug from the power

socket before cleaning OZor carrying out any mainte-

nancework(evenif onlyreplacingtheinterior lightbulb).

It is dangerous to modify or try to modify the charac-

teristics of OZ.

If any electrical work is required to install OZ, this must only be carried out by a

qualified electrician.

In the event of a breakdown or damage to the power supply cable, never attempt

to repair OZ yourself. Repairs carried out by inexperienced persons may cause

serious damage. Contact your nearest local Service Centre and always insist on

genuine spare parts.

Never use any mechanical devices or other artificial means to speed up the defro-

sting process: carefully follow the instructions in the “Defrosting” section.

General safety

Service and repairs

Oz completo GB 19-05-1999 15:54 Pagina 3

Like all domestic refrigerators, OZis designed solely

for the storage and freezing of foodstuffs.

OZ’s refrigerant circuit contains R 600 A isobutane

hydrocarbon: maintenance work and any topping up

must be carried out only by authorised personnel.

In all refrigerators and freezers, some surfaces beco-

me covered with frost. Before trying to remove this

frost, check the defrosting instructions in this manual.

Never use metal objects to clean the appliance: they

could seriously damage the paintwork and surfaces.

Never use sharp tools to remove the frost from OZ.

Use the special plastic scraper supplied with the

appliance.

Never place hot liquids or food inside OZ, or contai-

ners fitted with a lid and filled to the brim.

Never place fizzy drinks in the freezer compartment:

the containers could explode.

During operation, the condenser and compressor located at the back of OZ become

hot. Make sure that the appliance has been installed in accordance with the instructions

containedin this booklet:inadequate ventilationcan causedamage tothe appliance and

cause it to malfunction

Warning:The OZsigns on the back of the appliance are ventilation ope-

nings and must always be kept clear of obstructions.

If OZ is transported in a horizontal position, the oil contained in the compressor can

flow into the refrigerant circuit.To allow the oil to flow back into the compressor, stand

OZupright and wait for at least 2 hours before switching the appliance on.

Use

Installation

Oz completo GB 19-05-1999 15:54 Pagina 4

In its refrigerant circuit and insulation layer, OZuses only R 600 A natural

isobutane gas, which is totally free of CFC (Chloro Fluoro Carbons).

Do not dispose of OZ at normal urban refuse or scrap disposal sites.

Contact your local authorities for information on collection centres for pro-

per disposal of refrigerators.

During disposal, ensure that the refrigerant circuit is not damaged, espe-

cially at the back of the appliance.

All materials marked with the symbol , used to manufacture OZ,

can be recycled.

Environmental protection

Oz completo GB 19-05-1999 15:54 Pagina 5

Oz completo GB 19-05-1999 15:54 Pagina 6

Index

Installation

• Moving 9

• Positioning 10

• Cleaning the inside 12

• Electrical connections 13

Technical characteristics

• Rating plate 14

• EEC directives 15

Use and operation

• Operation and temperature adjustment 17

• Refrigerating food and drinks 18

• Movable shelves 19

• Movable baskets 19

• Freezing fresh food 20

• Storing deep-frozen food 22

•Thawing 24

• Ice cubes 24

• Defrosting 24

Maintenance

• Periodic cleaning 27

• Periods out of use 28

• Interior light 29

Service

•Technical service 30

• Spare parts 31

Oz completo GB 19-05-1999 15:54 Pagina 7

Installation

Oz completo GB 19-05-1999 15:54 Pagina 8
