ZANUSSI

P R O F E S S I O N A L

ELECTRIC HOBS

N 900

200226

Supply voltage 400 V, 3N, 50/60

Net weight - kg. 60

Electrical power - kW 7

Working temperature - min/max - °C 80, 450

depth 715

width 360

Cooking surface dimensions - mm

Thermostatic l

material Mild Steel

type Smooth

Cooking surface

height 250

depth 900

width 400

External dimensions - mm

Power supply Electric

NTRE400

200226

CHARACTERISTICS MODELS

TECHNICAL DATA

RANGE

COMPOSITION

N 900: a range of over 150 models

for the professional caterer designed

to guarantee the highest level of

performance, reliability, energy

saving, safety standards and

ergonomic operation. These

concepts are reflected in the total

modularity of the range that ensures

innumerable configurations, either

free-standing, bridged or cantilever.

N900 demonstrates how advanced

technology can satisfy the needs of

the professional caterer.

The model detailed on this sheet is a

top electric versions ideal for uniform

cooking using pots and pans, even

large size ones.

FUNCTIONAL AND

CONSTRUCTION

FEATURES

� Worktop in 20/10 stainless steel.

Front and side panels in stainless

steel with Scotch-Brite finish.

� This model has right-angled side

edges to allow flush fitting joins

between units, eliminating gaps and

possible dirt traps.

� 2 indipendently controlled cooking

zones.

� Cooking hob in smooth-surfaced

carbon steel, guaranteeing

temperature uniformity for low

temperature cooking, enabling either

uniform temperature across the

whole hob, 2 different temperature

zones on the same hob or heating of

only one section of the hob.

� Removable hob plate.

� The special design of the control

knob system guarantees against

water infiltration.

� Main connections can be via the

base or the rear of the unit.

� This model can be easily mounted

on the refrigerated base, open base

cupboards, bridging supports or

cantilever systems.

� IPX5 water protection.

BACH2 2009-06-19 The Company reserves the right to alter technical specifications without prior notice.

www.zanussiprofessional.com

ZANUSSI

P R O F E S S I O N A L

WATER COLUMN WITH SWIVEL ARM 206288

WATER COLUMN EXTENSION FOR 900 LINE 206290

SIDE HANDRAIL-RIGHT/LEFT HAND 206165

REAR FLUE UPSTAND FOR SMALL CHIMNEY 206159

PAIR OF COVERING STRIPS FOR END ELEMENTS 206234

LARGE HANDRAIL(PORTIONING SHELF)800 MM 206186

LARGE HANDRAIL(PORTIONING SHELF)400 MM 206185

JUNCTION SEALING KIT 206086

FRONTAL HANDRAIL 800 MM 206167

FRONTAL HANDRAIL 400 MM 206166

FRONTAL HANDRAIL 1600 MM 206192

FRONTAL HANDRAIL 1200 MM 206191

FLUE CONDENSER FOR 1/2 MOD. DIAM.120MM 206155

DRAUGHT DIVERTER WITH 120 MM DIAMETER 206126

CHIMNEY UPSTAND 400MM 206303

2 SIDE COVERING PANELS FOR TOP-D=900MM 206278

NTRE400

200226

ACCESSORIES MODELS

OPTIONAL ACCESSORIES

I - Electrical connection 400 V, 3N, 50/60

NTRE400

200226

LEGEND

200226
