Zanussi ZWT 71401 WA Manual de usuario

User Manual 2

Manual de instrucciones 27

ZWT 71401 WA

Washer Dryer

Lavadora-secadora

Contents

Safety information 2

Safety Instructions 4

Product description 5

Control panel 6

Programmes 7

Consumption values 9

Options 10

Settings 10

Before first use 11

Daily Use - Washing only 11

Daily use - Drying 13

Daily use - Washing & Drying 14

Hints and tips 15

Care and cleaning 17

Troubleshooting 19

Installation 21

Building in 23

Technical Data 25

Subject to change without notice.

Safety information

Before the installation and use of the appliance, carefully read the

supplied instructions. The manufacturer is not responsible if an

incorrect installation and use causes injuries and damages.

Always keep the instructions with the appliance for future

reference.

Children and vulnerable people safety

WARNING!

Risk of suffocation, injury or permanent disability.

•This appliance can be used by children aged from 8 years and

above and persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have

been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved.

•Do not let children play with the appliance.

•Children of less than 3 years should be kept away unless

continuously supervised.

•Keep all packaging away from children.

•Keep all detergents away from children.

•Keep children and pets away from the appliance door when it is

open.

•If the appliance has a child safety device, we recommend you

activate it.

•Cleaning and user maintenance shall not be made by children

without supervision.

2 www.zanussi.com

General Safety

•Do not change the specification of this appliance.

•The appliance can be installed as freestanding or below the

kitchen counter with correct space.

•Do not install the appliance behind a lockable door, a sliding

door or a door with a hinge on the opposite side, where the

appliance door can not be fully opened.

•Connect the mains plug to the mains socket only at the end of

the installation. Make sure that there is access to the mains

plug after the installation.

•The ventilation openings in the base (if applicable) must not be

obstructed by a carpet.

•Ensure you have good ventilation in the installation room to

avoid the back flow of gases into the room from appliances

burning other fuels, including open fires.

•Exhaust air must not be discharged into a flue which is used for

exhausting fumes from appliances burning gas or other fuels (if

applicable).

•The operating water pressure (minimum and maximum) must be

between 0,5 bar (0,05 MPa) and 8 bar (0,8 MPa).

•Obey the maximum load volume of 7 kg (refer to the

“Programme chart” chapter).

•The appliance is to be connected to the water mains using the

new supplied hose-sets. Old hose sets must not be reused.

•If the supply cord is damaged, it must be replaced by the

manufacturer, its Authorised Service Centre or similarly

qualified persons in order to avoid a hazard.

•Wipe away lint that has accumulated around the appliance.

•Items that have been soiled with substances such as cooking

oil, acetone, alcohol, petrol, kerosene, spot removers,

turpentine, waxes and wax removers should be washed in hot

water with an extra amount of detergent before being dried in

the wash dryer.

•Do not use the appliance if industrial chemicals have been used

for cleaning.

•Do not dry unwashed items in the wash dryer.

www.zanussi.com 3

•Items such as foam rubber (latex foam), shower caps,

waterproof textiles, rubber backed articles and clothes or

pillows fitted with foam rubber pads should not be dried in the

wash dryer.

•Fabric softeners, or similar products, should be used as

specified by the fabric softener instructions.

•Remove all objects from pockets such as lighters and matches.

•Never stop the wash dryer before the end of the drying cycle

unless all items are quickly removed and spread out so that the

heat is dissipated.

•The final part of a wash dryer cycle occurs without heat (cool

down cycle) to ensure that the items are left at a temperature

that ensures that the items will not be damaged.

•Do not use water spray and steam to clean the appliance.

•Clean the appliance with a moist soft cloth. Only use neutral

detergents. Do not use abrasive products, abrasive cleaning

pads, solvents or metal objects.

•Before maintenance, deactivate the appliance and disconnect

the mains plug from the mains socket.

Safety Instructions

Installation

• Remove all the packaging and the transit

bolts.

• Keep the transit bolts. When you move the

appliance again you must block the drum.

• Always be careful when you move the

appliance because it is heavy. Always wear

safety gloves.

• Do not install or use a damaged appliance.

• Obey the installation instruction supplied

with the appliance.

• Do not install or use the appliance where the

temperature is less than 0 °C or where it is

exposed to the weather.

• Make sure that the floor where you install the

appliance is flat, stable, heat resistant and

clean.

• Do not install the appliance where the

appliance door can not be fully opened.

• Always move the appliance vertically.

• The rear surface of the appliance must be

put against the wall.

• Make sure that there is air circulation

between the appliance and the floor.

• Adjust the feet to have the necessary space

between the appliance and the carpet.

• When the appliance is put in its permanent

position, check if it is fully level with the aid

of a spirit level. If it is not, adjust the feet until

it is.

Electrical Connection

WARNING!

Risk of fire and electrical shock.

• The appliance must be earthed.

• Always use a correctly installed shockproof

socket.

• Do not use multi-plug adapters and

extension cables.

• Do not pull the mains cable to disconnect

the appliance. Always pull the mains plug.

• Do not touch the mains cable or the mains

plug with wet hands.

• Only for UK and Ireland: The appliance has a

13 amp mains plug. If it is necessary to

change the fuse in the mains plug, use a 13

amp ASTA (BS 1362) fuse.

4 www.zanussi.com

• This appliance complies with the E.E.C.

Directives.

Water Connection

• Make sure not to cause damage to the water

hoses.

• Before you connect the appliance to new

pipes or pipes not used for a long time, let

the water flow until it is clean.

• The first time you use the appliance, make

sure that there is no leakage.

Use

WARNING!

Risk of injury, electrical shock, fire,

burns or damage to the appliance.

• Use this appliance in a household only.

• Do not change the specification of this

appliance.

• Do not put flammable products or items that

are wet with flammable products in, near or

on the appliance.

• Do not touch the glass of the door while a

programme operates. The glass can be hot.

• Do not dry the damaged items which contain

padding or fillings.

• If you have washed your laundry with a stain

remover start an extra rinse cycle before you

start the dryer.

• Make sure that you remove all metal objects

from the laundry.

• Only dry fabrics which are applicable to dry

in the tumble dryer. Follow the instructions

on the fabric label.

• Plastic items are not heat resistant.

– If you use a detergent ball, remove it

before you set the drying programme.

– Do not use a detergent ball when you

set a non-stop programme.

WARNING!

Risk of injury or damage to the

appliance.

• Do not sit or stand on the open door.

• Do not dry dripping wet clothes in the

appliance.

Disposal

• Disconnect the appliance from the mains

supply.

• Cut off the mains cable and discard it.

• Remove the door catch to prevent children

and pets to get closed in the appliance.

Product description

Appliance overview

1 2

1Detergent dispenser

2Control panel

3Door handle

4Rating plate

5Drain pump filter

6Feet for the appliance level

www.zanussi.com 5

Child safety

This device prevents children or pets to be

closed in the drum.

• Turn the device

clockwise, until the

groove is horizontal.

You cannot close the

door.

• To close the door,

turn the device

anticlockwise until the

groove is vertical.

Fixing plate kit (4055171146)

Available from your authorized dealer.

If you install the appliance on a plinth, secure

the appliance in the fixing plates.

Read carefully the instructions supplied with the

kit.

Control panel

Control panel description

1400

1200

900

700

Eco

Centrifugar

Opciones/

Opção Fácil

Aclarado/

Enxag. Extra

Tiempo/

Tempo de sec.

Inicio/Pausa

Puerta/Porta

Inicio

Diferido

Agua

en cuba/

Cuba cheia

Super

Rapido

23 24

2 3 4

5678910

1Programme knob and On/Off position

2Display

3Delay start button (Inicio Diferido)

4Door locked indicator

5Start/Pause button (Inicio/Pausa)

6Easy Iron button (Fácil)

7Drying time button (Tiempo/Tempo de sec.)

8Extra rinse button (Aclarado/Enxag.Extra)

9Options button (Opciones/Opção)

10 Spin reduction button (Centrifugar)

Display

The display shows:

A) Child lock indicator

This device permits you to leave the

appliance unattended during it's functioning

(see «Child Safety Lock» paragraph).

The indicator comes when the related

option is set.

B) This area shows:

6 www.zanussi.com

•Programme time

After the programme selection, the

duration is displayed in hours and

minutes (for example 2.10).

The duration is calculated automatically

on the basis of the maximum

recommended load for each type of

fabric.

After the programme start, the time

remaining is updated every minute

•Selected drying time

After selecting a drying programme, the

drying time is displayed in minutes or in

hours and minutes (e.g. 130 mins =

2.10).

After the programme start, the time

remaining is updated every minute.

•End of programme

When the programme has finished three

flashing zeros are displayed.

•Delay start

When you press the delay start button,

the display shows the delay start time.

After the programme start, the set delay

appears for few seconds, then the

duration of the set programme is

displayed again.

•Alarm codes

If the appliance has a malfunction, the

display shows the alarm codes. Refer to

the chapter 'Troubleshooting' .

•Incorrect option selection

The display shows the message

for some seconds and the Start/Pause

indicator button flashes if :

– You set a option that is not suitable

for the programme.

– You change the programme while it

operates.

Programmes

Programme Chart

Programme

Temperature

range

Maximum

load

Maximum

spin speed

Programme description

(Type of load and soil level)

Washing programmes

1 - 5 Algod. 1)

90°C - 60°C -

40°C - 30°C - Frio

7 kg

1400 rpm

White cotton and coloured cotton. Normal

soil and light soil.

6 - 8 Algod. + Prelava.

90°C - 40°C

7 kg

1400 rpm

White cotton and coloured cotton. Heavy

soil and normal soil.

9 - 12 Sintéticos

60°C - 40°C -

30°C - Frio

3.5 kg

900 rpm

Synthetic items or mixed fabric items.

Normal soil.

13 - 15 Delicados

40°C - 30°C - Frio

3.5 kg

700 rpm

Delicate fabrics as acrylics, viscose, poly-

ester items. Normal soil.

16 Jeans

40°C

3.5 kg

1200 rpm

Items in denim and jersey. Also for dark

coloured items.

17 - 19 Lav.mano/mão

40°C - 30°C - Frio

2 kg

900 rpm

Machine washable wool, hand washable

wool and delicate fabrics with «hand wash-

ing» care symbol. 2)

Drying

www.zanussi.com 7

Programme

Temperature

range

Maximum

load

Maximum

spin speed

Programme description

(Type of load and soil level)

20 Algod. 3 kg Drying programme for cotton items.

21 Sintéticos 2 kg Drying programme for synthetic items.

Extra

22 Aclarados/

Enxag.

7 kg

1400 rpm

To rinse and spin the laundry. All fabrics.

23 Descarga 7 kg To drain the water after programme with the

optionAgua en cuba/Cuba cheia set.

24 Centrifugar 7 kg

1400 rpm

To spin and drain the water after programme

with the option Agua en cuba/Cuba cheia set.

Set the spin speed according to the fabric to

be spun.

1) «The programme Algod. at 60°C with a load of 7 kg, with the option Eco set , is the '«Cottons Energy Saving Programme», reference pro-

gramme for the data entered in the energy label in compliance with EEC 92/75 standards.

2) During this cycle the drum rotates slowly to ensure a gentle washing. It can seem that the drum doesn't rotate or doesn't rotate properly.

Consider this as a normal functioning of the appliance.

Programme options compatibility

Programme

Centri-

fugar

Agua en

cuba/

Cuba

cheia

Eco

Su-

per

Rapi-

Fácil

Aclara-

do/

En-

xag.Ex-

tra

Algod. ■■■■■■

Algod. + Prelava. ■■■■■■

Sintéticos ■■■■■■

Delicados ■■ ■

Jeans ■■ ■

Lav.mano/mão ■■

Aclarados/Enxag. ■■ ■■

Descarga ■

Centrifugar

8 www.zanussi.com

Programmes for timed drying

1) In compliance with EC directive EN 50229, the cotton reference programme for the data entered in the Energy Label must be tested

dividing the maximum washing load by two equal parts and drying with DRYING TIME each of them .

Consumption values

The data of this table are approximate. Different causes can change the data: the

quantity and type of laundry, the water and ambient temperature.

Programmes Load

(kg)

Energy

con-

sumption

(kWh)

Water con-

sumption

(litre)

Approximate pro-

gramme duration

(minutes)

Cottons 60 °C 7 1.35 67 150

Cotton Energy Saving Pro-

gramme 60 °C 1) 7 1.05 49 180

Cottons 40 °C 7 0.85 67 140

Synthetics 40 °C 3.5 0.55 42 90

Delicates 40 °C 3.5 0.55 63 65

Wool/Handwash 30 °C 2 0.25 55 60

1) «Cotton Energy Saving programme » at 60°C with a load of 7 kg is the reference programme for the data entered in the energy label, in

compliance with EEC 92/75 standards.

www.zanussi.com 9

Dryness Level Type of fabric Load

(kg)

Spin

speed

(rpm)

Suggested

duration

(mins)

Extra Dry

For towelling materials

Cottons and Linen

(bathrobes, bath towels, etc)

4 1400 215 - 220

3 1400 160 - 180

1.5 1400 95 - 105

Cottons and Linen

(bathrobes, bath towels, etc)

4 1400 205 - 210

3 1400 150 - 170

1.5 1400 85 - 95

Synthetics and mixed fab-

rics

(jumpers, blouses, underwear,

household linen)

2 900 90 - 100

1 900 55 - 65

Cottons and Linen

(sheets, tablecloths, shirts, etc)

4 1400 140 - 150

3 1400 90 - 100

1.5 1400 60 - 70

Cupboard Dry1)

For items to put away

Cupboard Dry

For items to put away

Iron Dry

Suitable for ironing

1) In compliance with EC directive EN 50229, the cotton reference programme for the data entered in the Energy Label must be tested

dividing the maximum washing load by two equal parts and drying with DRYING TIME each of them .

Options

Centrifugar

With this option you can change the default

spin speed.

The indicator of the set speed comes on.

Agua en cuba/Cuba cheia

• Set this option to prevent the laundry

creases.

• The related indicator comes on.

• There is a water in the drum when the

programme is completed.

• The drum turns regularly to prevent the

laundry creases.

• The door stays locked. You must drain the

water to unlock the door.

To drain the water refer to ‘At the

end of the programme’.

Opciones/Opção

Press this button to set one of the following

options:

The related indicator comes on.

•Eco

Use this option if you want to wash laundry

saving energy.

The time is prolonged while the temperature

is reduced.

Only for cottons and synthetic items with

normal or light soil at a temperature of 40°C

or higher.

•Super Rapido

Press this button to decrease the

programme duration.

Set this option for items with light soil or

items to refresh.

Aclarado/Enxag.Extra

With this option you can add some rinses to a

washing programme.

Use this option for persons allergic to

detergents and in areas where the water is soft.

The related indicator comes on.

Inicio Diferido

With this option you can delay the start of a

programme from 30 minutes to 20 hours.

The display shows the related indicator.

Tiempo/Tempo de sec.

With this option you can set the time for the

fabrics you have to dry (cottons or synthetics) .

The display shows the set value.

Each time you press this button the time value

increases by 5 minutes.

For Cottons you can set a drying time from 10

minutes to 250 minutes (4.10), for synthetics

from 10 minutes to 130 minutes (2.10).

You cannot set all time values for

different types of fabrics.

Fácil

The laundry is gently washed and spun to avoid

any creasing. In this way ironing is easier.

Furthermore, the appliance will perform some

additional rinses in some programmes.

On cotton programmes the maximum spin

speed is reduced automatically.

Door locked indicator

With this option you can delay the start of a

programme from 30 minutes to 20 hours.

The indicator shows when the door can be

opened:

• The indicator is on: the door cannot be

opened.

• The indicator flashes: the door is opening in

some minutes.

• The indicator is off: the door can be opened.

Settings

Child Lock

With this option you can prevent that the

children play with the control panel.

• To activate/deactivate this option, press

Centrifugar and Opciones/Opção at the

10 www.zanussi.com

Otros manuales para ZWT 71401 WA

Tabla de contenidos

Idiomas:

Otros manuales de Secadora de Zanussi

Zanussi

Zanussi TD 100 Instrucciones de montaje

Zanussi

Zanussi ZTE7101PZ Manual de usuario

Zanussi

Zanussi TD 4100 W Manual de usuario

Zanussi

Zanussi ZDH7332PZ Manual de usuario

Zanussi

Zanussi TC 482 W Manual de usuario

Zanussi

Zanussi TD4100 Manual de usuario

Zanussi

Zanussi ZTAB 250 Manual de usuario

Zanussi

Zanussi ZTE7101PZ Manual de usuario

Zanussi

Zanussi TD 201/A Instrucciones de funcionamiento y seguridad

Zanussi

Zanussi TD184 Manual de usuario

Zanussi

Zanussi ZTE170 Manual de usuario

Zanussi

Zanussi ZTK 120 Manual de usuario

Zanussi

Zanussi TCE 7276 W Manual de usuario

Zanussi

Zanussi ZTK123 Manual de usuario

Zanussi

Zanussi TC7103W Manual de usuario

Zanussi

Zanussi ZI 935 Instrucciones de funcionamiento y seguridad

Zanussi

Zanussi ZTE278 Manual de usuario

Zanussi

Zanussi TDS372TW Manual de usuario

Zanussi

Zanussi ZI 930 Instrucciones de montaje

Zanussi

Zanussi ZDE 36150W Manual de usuario

Zanussi

Zanussi TD 524 Manual de usuario

Zanussi

Zanussi TC7102S Manual de usuario

Zanussi

Zanussi ZDEB 47209W Manual de usuario

Zanussi

Zanussi Z930 Instrucciones de funcionamiento y seguridad

Manuales populares de Secadora de otras marcas

Bosch

Bosch WTA79200GB Manual de usuario

Amana

Amana W10233410A Manual de usuario

Miele

Miele TWH 780 WP Manual de usuario

Asko

Asko T760 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manual de usuario

Bosch

Bosch Logixx 10 WTB76556GB Hoja de especificaciones

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Manual de instrucciones

Electrolux

Electrolux EW2H328R2 Manual de usuario

Beko

Beko DS8433RX1M Manual de usuario

Dawlance

Dawlance Spinner DS 6000 C Manual de usuario

Electrolux

Electrolux TP5080TW Manual de usuario

AEG

AEG TR838P4OB Manual de usuario

Indesit

Indesit IDV 75 Manual de usuario

Infiniton

Infiniton SD-DG85C Manual de usuario

BOMANN

BOMANN WT 5019 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manual de usuario

Asko

Asko T793C Manual de usuario

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manual de usuario
