ZANUSSI

P R O F E S S I O N A L

RACK TYPE DISHWASHERS

CORNER DRYER FOR RTM

864512 864513

Supply voltage 400 V, 3N, 50/60 400 V, 3N, 50/60

Net weight - kg. 70 70

installed-electric 8.5 8.5

Power - kW

height 895 895

depth 706 706

width 850 850

External dimensions - mm

Power supply Electric Electric

ADTERC90MD

864512

ADTELC90MD

864513

CHARACTERISTICS MODELS

TECHNICAL DATA

RANGE

COMPOSITION



The Zanussi Dishwashing

range is produced for

customers with the highest

conceivable demands in

efficient, economic and

ergonomic dishwashing

operations. The product

range is comprised of

glasswashers, undercounter

dishwashers, hood type

dishwashers, rack type

dishwashers and pot and pan

washers. The Corner Dryers

complete the rack type

dishwashing range.

FUNCTIONAL AND

CONSTRUCTION

FEATURES

� It is designed to be placed

on a 90° or 180° dishwashing

driven curve, immediately

after a modular rack type

dishwasher. The dryer must

always be ordered with a 90°

or 180° dishwashing driven

curve.

� The feeding system from

the dishwasher and the curve

will automatically move the

racks through the dryer.

� The drying zone removes

every trace of water from the

crockery, through a high

powered fan that extracts dry

air from outside with

minimum temperature loss

and steam escape.

� Electronically controlled to

optimize the drying results.

� The hygienic design

provides easy cleaning.

� The dryer is constructed in

304 AISI stainless steel.

� Developed and produced in

an ISO 9001 and ISO 14001

certified factory.

� CFC free packaging.

� For further specifications

and accessories, please see

overleaf.

RACK TYPE DISHWASHERS

CORNER DRYER FOR RTM

EBCE20 2010-05-28 The Company reserves the right to alter technical specifications without prior notice.

www.zanussiprofessional.com

ZANUSSI

P R O F E S S I O N A L

RACK TYPE DISHWASHERS

CORNER DRYER FOR RTM

EBCE20 2010-05-28 The Company reserves the right to alter technical specifications without prior notice.

www.zanussiprofessional.com

ZANUSSI

P R O F E S S I O N A L

EI - Electrical connection 400 V, 3N, 50/60

ADTERC90MD

864512

LEGEND

864512

RACK TYPE DISHWASHERS

CORNER DRYER FOR RTM

EBCE20 2010-05-28 The Company reserves the right to alter technical specifications without prior notice.

www.zanussiprofessional.com

ZANUSSI

P R O F E S S I O N A L

EI - Electrical connection 400 V, 3N, 50/60

ADTELC90MD

864513

LEGEND

864513
