USER GUIDE
BEDIENUNGSANLEITUNG
取扱説明書
S3
English 1
Deutsch 17
33⽇本語
CONTENTS / INHALTSVERZEICHNIS / ⽬録
INTRODUCTION .............................................................................
..................................................................PRODUCT OVERVIEW
.......................................................................GETTING STARTED
INSTALLATION .......................................................................................
NAVIGATION ...................................................................................
.....................................................................................OPERATION
........................................................VIDEO RECORDING MODE
............................................................PHOTO CAPTURE MODE
PLAYBACK MODE ..........................................................................
............................................................................STANDBY MODE
DRIVING SHORTCUTS ..................................................................
PERSONALIZED SETTINGS .........................................................
.............................................................COMMON FUNCTIONS
TECHNICAL SPECIFICATIONS ..................................................
2
2
3
4
5
6
7
8
8
9
9
9
12
15
CONTENTS
1
· Record crystal clear, high-definition video simultaneously via the stealth size front-
view and rear-view HD cameras in 1080P resolution with 150°/150° viewing angle.
Excellent video quality for recording even in low visibility driving conditions. Also
features image capture with 12-megapixel resolution.
· Convenient automatic recording and monitoring features include: automatic ignition,
motion/crash detection and recording, parking mode for monitoring your vehicle via
the highly sensitive built-in G-Sensor and seamless loop video recording.
· Smart features include: Screen auto off, automatic device shutdown after the engine
is turned off, one-button audio recording and one-button emergency video
recording and protection.
· Records up to 1.5 hour simultaneous front cam (1080P) and rear cam (1080P) via
16GB TF/MicroSD card. Seamless loop recording feature ensures efficient use of
storage.
PRODUCT OVERVIEW
Thank you for purchasing the S3 High Definition Car DVR / Camcorder by Z-Edge .
Featuring a stealth size design and dual-lens for recording front and back. Please
read this manual carefully before using this product. We hope you enjoy using this
product.
INTRODUCTION
®
2
GETTING STARTED
1
2
3
4
5
6
7
8
Up
Down
Power
OK/Record
Display Screen
Adhesive Mount Slot
LED Indicator Lights
TF/MicroSD Card Slot
Reset Hole
AV IN (Mini USB Port)
Components
Loudspeaker
ESC/Menu 9
10
11
12
13
14
15
Front-View Lens
Charge/Connect PC (Micro USB Port)
Rear-View Lens
1 2
3
4 5
6
8
9
13
10
11
14
7
12
15
3
1. Insert the TF/MicroSD Card into the
TF/MicroSD Card Slot (component 10)
of the camera.
2. Turn the camera on without removing
the adhesive backing. Whilst looking
at the display screen, find a suitable
location for installing your dashcam on
your windshield. Please note:
a. This position should neither distract the
driver nor block the driver's view while
driving. We recommend locating towards the top of the windshield, behind the
rear-view mirror and positioned slightly closer to the driver’s side. Find a position
that provides an unrestricted and full viewing angle for the camera - you can adjust
the angle the front camera lens points by pushing it up and down within the camera
body.
b. This position should be clean so that the adhesive mount can attach to the surface
firmly. If not, please clean the surface using water if necessary and wait until dry.
c. This position should be close to the cigarette lighter (power) in the car to ensure
charging while recording.
3. Having found a suitable location on your windshield, remove the protective backing
and firmly press the adhesive strip against the windshield until secure. Ensure the
camera is orientated correctly, and level before applying pressure. The camera is now
securely attached to the windshield.
4. For a more organized car environment, the micro USB cable can be routed as indicated
by the green dashed line in the diagram. Plug the car charger into your cigarette
lighter and connect the USB cable.
5. Adhesive mounts are included inside every pack. To swap or replace an adhesive
mount, turn around the mount from horizontal position to vertical position to release
from the slot. Slide the replacement mount inside the slot until it clicks into position.
6. Start the engine of your car. The S3 will automatically turn on and start recording
when connected to a power source.
INSTALLATION
4
NAVIGATION
· Press and hold for 3 seconds to turn device ON/OFF.Manual ON/OFF:
"Power" Button
· Navigate to Lower/Next Item: Press “Down” button to navigate to lower or next item
while browsing the system menu or playback files.
In video recording mode press “Down” button to · Enable/Disable Audio Recording:
enable/disable audio record feature (see “Audio Record” for more details).
In standby mode (device not recording or capturing images), · Switch to Playback Mode:
short press “Down” button to switch to Playback mode.
"Down" Button
7. The device will detect when the engine is switched off, and automatically power off
shortly after the last video clip duration is complete and saved.
Some car models supply power from the cigarette lighter even after the WARNING:
engine is turned off. We recommend you always unplug the USB charger manually
before leaving your car to avoid any unwanted car battery drainage.
· Press “Up” button to navigate to upper or previous Navigate to Upper/Previous Item:
item while browsing the system menu or playback files.
· In standby mode (device not recording or capturing Switch to Photo Capture Mode:
images), short press “Up” button to switch to Photo Capture mode.
· In photo capture mode press “Up” button to capture a photo.Photo Capture:
· In Playback mode press “Up” button to capture a photo.Delete Files:
"Up" Button
· While browsing press “OK” button to select or confirm highlighted item.Select/Confirm:
· In video recording mode press “OK” button to start/Enable/Disable Video Recording:
stop video recording.
· In playback mode press “OK” button to start/stop video playback. Video Playback:
“OK" Button
5
OPERATION
Powering ON/OFF
· When device is connected via the USB car charger, it will Automatic:
automatically detect engine ignition and turn on.
· Press and hold the “Power” button for 3 seconds to power on/off device.Manual:
Indicator Lights
· Recording videoFlashing Red:
· ChargingBlue Light:
Recorded Video Files
Videos are recorded and saved to the memory card as multiple video clips. Once
the memory card is full, the “Loop Recording” feature automatically overwrites
the earliest unprotected saved file. This prevents long duration video clips from
being lost in a single overwrite. Video clip duration can be set to 1, 3 or 5 minutes
inside the “Menu Setting” menu. Video clips can be played directly on the display
screen, or copied/stored and played on a computer.
· Access General Settings Menu: In standby mode (device not recording or capturing
images) pressing the “Menu” button twice will highlight the “Menu Settings” menu.
Use the “Up” and “Down” buttons to navigate. Press “OK” button to confirm. Short
press “Menu” button while in the menu to exit.
· Press “Menu” button to return in system menu.Return:
· In the event of an emergency, it is important to save Emergency Video Protection:
and protect recorded video files so that they are not erased by the “Loop Recording”
feature. With “Crash Detection” feature enabled, this device automatically protects
video files when a significant vibration has been detected. However you can manually
protect any video clip by pressing the “Menu” button during a video recording. This
will protect the saved clip/file from being automatically deleted in the future. A warning
icon appears on screen to signify the file has been successfully protected. Press the
“Menu” button again to remove protection.
"Menu" Button
6
Parking Mode
When “Parking Mode” is enabled, the device continues to monitor the vehicle
while it is turned off and parked. If any motion or vibration is detected by the
device, it will automatically turn on and begin recording. Approximately 30
seconds after the motion or vibration has finished, the device will automatically
turn off and return to monitoring mode.
In “Parking Mode” the device is powered by the internal rechargeable battery,
and the LCD display screen is automatically set to power save to conserve battery
power. This feature can be set to Off or On inside the menu: Feature Setting ->
Parking Mode.
VIDEO RECORDING MODE
Motion Detection
With “Motion Detection” enabled, video recording is automatically paused
when no movement is detected by the front view camera or G-Sensor. Video
recording will automatically start again when movement is detected. This
feature can be disabled or enabled with Off/On options inside the menu: Feature
Setting -> Motion Detection.
Loop Recording
Videos are recorded and saved to the memory card as multiple video clips.
Once the memory card is full, the “Loop Recording” feature automatically
overwrites the earliest unprotected saved file. This prevents long duration video
clips from being lost in a single overwrite. Video clip duration can be set to 1, 3
or 5 minutes inside the menu: Menu Setting -> Loop Recording.
Crash Detection
In the event of a collision the “Crash Detection” feature, triggered by the highly
sensitive built-in G-Sensor, will automatically turn video recording on and
protect the saved file. The sensitivity of the G-Sensor can be set to Off, Low,
Normal or High inside the menu: Feature Setting -> G-Sensor Sensitivity.
7
Emergency Video Protection
In addition to automatic video file protection, any video can be protected
manually by pressing the “Menu” button during a video recording. A warning
icon appears on screen to signify the file has been successfully protected. Press
the “Menu” button again to remove protection.
From standby mode short press “Up” button to switch to photo capture mode.
Capture a photo by pressing the “Up” button.
Audio Record
With audio record feature enabled the device will record audio for the current
video clip via the integrated microphone. This feature can be enabled/disabled
inside the menu: Menu Setting -> .Audio Record
Automatically turn off the LCD display screen after 1 or 3 minutes. This feature
is useful if the display screen proves a driving distraction for the driver. Feature
can be set to Off, 1 Minute or 3 Minutes inside the menu: Menu Setting -> LCD
Auto Off. Turn on the display screen again by pressing any button.
PHOTO CAPTURE MODE
From standby mode short press “Down” button to switch to playback mode.
Browse video and image files by pressing the “Up” and “Down” buttons. Play/
Pause highlighted video files by pressing “OK” button.
PLAYBACK MODE
LCD Auto Off
8
