York E*BD-(T Guía de inicio rápido

246819-BTG-H-0208

FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE

SPLIT-SYSTEM HEAT PUMPS

13 SEER – R-22

MODELS:

E*BD-F018 THRU 060

(1.5 THRU 5 NOMINAL TONS, 1 PHASE)

E*BD-(T,W)036 THRU 060

(2.5 THRU 5 NOMINAL TONS, 3 PHASE)

Due to continuous product improvement, specifications

are subject to change without notice.

Visit us on the web at www.york.com

Additional rating information can be found at

www.ahridirectory.org

LISTED

ISO 9001

Certified Quality

Management System

TECHNICAL

GUIDE

TECHNICAL

GUIDE

DESCRIPTION

The 13 SEER series heat pumps are designed for use with a

variety of UPG evaporator sections to suit any application

need. A full line of matching Add-On Coils are available for

use with upflow, downflow or horizontal furnaces. Matching

Air Handlers are also available for upflow, downflow or hori-

zontal installation to provide a complete system. Electric heat

may be installed in air handlers. All units are factory charged

to assure easy installation.

WARRANTY

Single Phase Units:

5-year limited parts warranty.

5-year limited compressor warranty.

Three Phase Units:

1-year limited parts warranty.

5-year limited compressor warranty.

FEATURES

•DURABLE CONSTRUCTION - The outdoor unit is con-

structed of pre-painted steel that offers tough protection

against corrosion and resists fading when exposed to sun-

light. Drain holes are incorporated into the base pan to per-

mit free drainage of moisture.

•QUALITY COILS - The coil is constructed of enhanced

copper tube and aluminum fins.

•COIL PROTECTION - Coils are protected from damage by

a polymer mesh applied between the coil face, and a PVC

coated steel coil guard.

•PROTECTED COMPRESSOR - The hermetic compressor

is internally protected against high pressure and tempera-

ture by the simultaneous operation of a high pressure relief

valve and temperature sensors which stop the compressor

if operating temperatures go too high. Both protectors

reset automatically. A discharge line solid core filter drier

further protects the compressor.

•Complete System Control – These heat pumps utilize

the unique microprocessor defrost control system to pro-

vide optimal comfort and to monitor the overall system for

reliable operation. The defrost control system continuously

monitors the space environment to maintain optimum effi-

ciency. It initiates defrost only when necessary to further

reduce heating costs and improve reliability. In the event

improper operating conditions occur, the control will auto-

matically shut the system down to extend the life of the

heat pump. Rapid cycling is prevented by use of an inter-

nal anti-recycle timer.

•LOW OPERATING SOUND LEVEL - The compressor is

mounted on rubber isolators to reduce operating sounds.

The slow moving condenser fan keeps air turbulence and

sound to a low level.

•EASY ACCESS - Removable panel affords accessibility to

the electrical box.

•FULLY CHARGED AND FACTORY WIRED - to simply

installation and reduce labor costs. Only power supply and

control wiring and refrigerant lines must be connected. All

models are sweat connect with reusable service valves.

•Factory tested - to verify system operation and control

functioning before shipment.

•U.L. and C.U.L. listed - approved for outdoor application.

Certified in accordance with the Unitary Small Equipment cer-

tification program, which is based on ARI Standard 210/240.

246819-BTG-H-0208

2Unitary Products Group

All dimensions are in inches. They are subject to change

without notice. Certified dimensions will be provided upon

request.

Physical and Electrical Data - 1 Phase

MODEL EABD-F018S EABD-F024S EABD-F030S EABD-F036S EABD-F042S EABD-F048S EABD-F060S

Unit Supply Voltage 208-230V, 1φ, 60Hz

Normal Voltage Range 1187 to 252

Minimum Circuit Ampacity 9.9 15.0 16.9 19.8 25.0 32.7 37.8

Max. Overcurrent Device Amps 215 25 25 30 40 50 60

Min. Overcurrent Device Amps 315 20 20 20 30 35 40

Compressor Type 4Recip Recip Recip Recip Recip ScrollDScrollD

Compressor

Amps Rated Load 7.5 10.7 12.4 14.6 18.8 25.0 29.1

Locked Rotor 41 44 60 78 78 115 150

Crankcase Heater Yes Yes Yes Yes Yes No No

Fan Motor Amps Rated Load 0.5 1.5 1.5 1.5 1.5 1.5 1.5

Fan Diameter Inches 22 22 22 22 22 24 24

Fan Motor Rated HP 1/15 1/4 1/4 1/4 1/4 1/4 1/4

Nominal RPM 850 850 850 850 850 850 850

Nominal CFM 2,000 3,250 3,450 3,500 3,500 3,400 3,500

Coil Face Area Sq. Ft. 15.72 18.34 20.96 23.58 23.58 24.00 27.00

RowsDeep1111122

Fin / Inches 22 22 22 22 22 18 18

Liquid Line Set OD (Field Installed) 3/8 3/8 3/8 3/8 3/8 3/8 3/8

Vapor Line Set OD (Field Installed) 3/4 3/4 7/8 7/8 7/8 7/8 1-1/8

Unit Charge (Lbs. - Oz.) 57 - 1 6 - 6 8 - 7 8 - 7 8 - 7 12 - 8 16 - 7

Charge Per Foot, Oz. 0.68 0.68 0.70 0.70 0.70 0.70 0.76

Operating Weight Lbs. 172 184 196 208 208 250 294

1. Rated in accordance with ARI Standard 110, utilization range “A”.

2. Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.

3. Dual element fuses or HACR circuit breaker. Minimum recommended overcurrent protection.

4. All scrolls listed with a superscript “D” are Danfoss scrolls. All scrolls listed with a superscript “C” are Copeland scrolls.

5. The Unit Charge is correct for the outdoor unit, matched indoor coil and 15 feet of refrigerant tubing. For tubing lengths other than 15

feet, add or subtract the amount of refrigerant, using the difference in length multiplied by the per foot value.

Unit

Model

Dimensions

(Inches)

Refrigerant

Connection

Service Valve Size

1. Including Fan Guard.

* Adapter fitting required for 1-1/8” line set.

B C Liquid Vapor

018 27 37 27

3/8”

3/4”

024 31 37 27

030 35 37 27

7/8”

036 39 37 27

042 39 37 27

048 34 43 32

060 38 43 32 7/8”*

246819-BTG-H-0208

Unitary Products Group 3

Additional R-22 Charge / Orifice Size for Various Matched Systems - 1 Phase

Outdoor Unit EABD-F018S EABD-F024S EABD-F030S EABD-F036S EABD-F042S EABD-F048S EABD-F060S

Required TXV 1TVM2A1 1TVM2A1 1TVM2A1 1TVM2A1 1TVM2C1 1TVM2C1 1TVM2C1

Factory Charge, lbs-oz 7 - 1 6 - 9 8 - 9 8 - 7 8 - 7 12 - 8 16 - 7

Indoor Coil1,2 Additional Charge, Oz

FC/MC/PC/UC18A2A 0––––––

FC/MC/PC/UC18B2A 0––––––

FC/MC/PC/UC24A2A –0–––––

FC/MC/PC/UC24B2A –0–––––

FC/MC/PC/UC30A2A –0–––––

FC/MC/PC/UC30B2A –0–––––

FC/MC/PC35B2A ––09–––

FC/MC/PC35C2C ––09–––

FC/MC/PC/UC42B2C ––09–––

FC/MC/PC/UC42C2C ––09–––

FC/MC/PC/UC48C2C – – – 9 14 – –

FC/MC/PC/UC48D2C – – – 9 14 – –

FC/PC/UC60C2C –––––77

FC/MC/PC/UC60D2C –––––77

MC61D2C –––––77

HC18A2A 0––––––

HC30A2A –0–––––

HC36B2A ––0––––

HC42C2C –––9–––

HC60C2C –––––77

HD24A2A –0–––––

HD36B2A ––09–––

HD48C2C – – – – 14 – –

HD60D2C –––––77

AHP18B2A 0––––––

AHP24B2A –0–––––

AHP30B2A ––0––––

AHP36C2A –––9–––

AHP42C2C –––9–––

AHP/SHP48D2C – – – – 14 7 –

AHP/SHP60D2C –––––77

AV24B2A 00–––––

AV36C2A ––09–––

AV/SV48D2C – – – – 14 7 –

AV/SV60D2C ––––––7

FC/MC/PC/UC18A3X 0––––––

FC/MC/PC/UC18B3X 0––––––

FC/MC/PC/UC24A3X –0–––––

FC/MC/PC/UC24B3X –0–––––

FC/MC/PC/UC30A3X –0–––––

FC/MC/PC/UC30B3X –0–––––

FC/MC/PC35B3X ––09–––

FC/MC/PC35X3X ––09–––

FC/MC/PC/UC42B3X ––09–––

FC/MC/PC/UC42X3X ––09–––

FC/MC/PC/UC48C3X – – – 9 14 – –

FC/MC/PC/UC48D3X – – – 9 14 – –

FC/PC/UC60C3X –––––77

FC/MC/PC/UC60D3X –––––77

MC61D3X –––––77

HC18A3X 0––––––

HC30A3X –0–––––

HC36B3X ––0––––

HC42C3X –––9–––

HC60C3X –––––77

For Notes See Page 4.

246819-BTG-H-0208

4Unitary Products Group

* This loose coil match does not achieve 13 SEER.

PROCEDURES:

1. Unit factory charge listed on the unit nameplate includes refrigerant for the condenser, the smallest evaporator and 15 feet of inter-

connecting line tubing.

2. Verify the orifice size and the additional charge required for the specific evaporator coil in the system using the above table.

3. Additional charge for the amount of interconnecting line tubing greater than 15 feet at the rate specified in the table above.

4. Permanently mark the unit nameplate with the total system charge. Total System Charge = Base charge (as shipped) + adder for

evaporator + adder for line set.

5. If the orifice in the evaporator was changed, verify the evaporator nameplate has been marked with the correct orifice/TXV size.

HD24A3X –0–––––

HD36B3X ––09–––

HD48C3X – – – – 14 – –

HD60D3X –––––77

AHP18B3X 0––––––

AHP24B3X –0–––––

AHP30B3X ––0––––

AHP36C3X –––9–––

AHP42C3X –––9–––

AHP/SHP48D3X – – – – 14 7 –

AHP/SHP60D3X –––––77

AV24B3X 00–––––

AV36C3X ––09–––

AV/SV48D3X – – – – 14 7 –

AV/SV60D3X – – – – 14 7 7

F*FP024H06T2A 0 – –––––

F*FP030H06T2A – 0 –––––

F*FP040H06T2A – – 09–––

F*FP042H06T2A – – –9–––

F*FV060H06T2C – – –––77

FOOTNOTES:

1. Systems matched with furnace or air handlers not equipped with blower-off delays may require blower Time Delay Kit 2FD06700224.

2. PC coils cannot be used in downflow or horizontal applications. FC coils cannot be used in horizontal applications.

Additional R-22 Charge / Orifice Size for Various Matched Systems - 1 Phase (Continued)

Outdoor Unit EABD-F018S EABD-F024S EABD-F030S EABD-F036S EABD-F042S EABD-F048S EABD-F060S

Required TXV 1TVM2A1 1TVM2A1 1TVM2A1 1TVM2A1 1TVM2C1 1TVM2C1 1TVM2C1

Factory Charge, lbs-oz 7 - 1 6 - 9 8 - 9 8 - 7 8 - 7 12 - 8 16 - 7

Indoor Coil1,2 Additional Charge, Oz

246819-BTG-H-0208

Unitary Products Group 5

All dimensions are in inches. They are subject to change with-

out notice. Certified dimensions will be provided upon request.

Physical and Electrical Data - 3 Phase

MODEL EABD-

T030S EABD-

T036S EABD-

T042S EABD-

T048S EABD-

T060S EABD-

W030S EABD-

W036S EABD-

W042S EABD-

W048S EABD-

W060S

Unit Supply Voltage 208-230V, 3φ, 60Hz 460V, 3φ, 60Hz

Normal Voltage Range 1187 to 252 432 to 532

Minimum Circuit Ampacity 12.1 14.3 14.4 20.2 23.1 5.6 6.9 7.2 9.5 11.2

Max. Overcurrent Device Amps 220 20 20 35 40 15 15 15 15 15

Min. Overcurrent Device Amps 315 15 15 25 25 15 15 15 15 15

Compressor Type Recip Recip Recip Scroll Scroll Recip Recip Recip Scroll Scroll

Compressor Amps Rated Load 8.5 10.2 10.4 15.0 16 3.9 4.9 6.1 6.1 8

Locked Rotor 62 72 71 95 123 30 45 45 45 70

Crankcase Heater Yes Yes Yes No No Yes Yes Yes No No

Fan Motor Amps Rated Load 1.5 1.5 1.5 1.5 1.5 0.7 0.7 0.7 0.7 0.7

Fan Diameter Inches 22 22 22 24 24 22 22 22 24 24

Fan Motor Rated HP 1/4 1/4 1/4 1/4 1/4 1/4 1/4 1/4 1/4 1/4

Nominal RPM 850 850 850 850 850 850 850 850 850 850

Nominal CFM 3450 3500 3500 3400 3500 3450 3500 3500 3400 3500

Coil Face Area Sq. Ft. 20.96 23.58 23.58 24.00 27.00 20.96 23.58 23.58 24.00 27.00

RowsDeep 1112211122

Fin / Inches 22 22 22 18 18 22 22 22 18 18

Liquid Line Set OD (Field Installed) 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8

Vapor Line Set OD (Field Installed) 7/8 7/8 7/8 7/8 1-1/8 7/8 7/8 7/8 7/8 1-1/8

Unit Charge (Lbs. - Oz.) 48 - 7 8 - 7 8 - 7 12 - 8 16 - 7 8 - 7 8 - 7 8 - 7 12 - 8 16 - 7

Charge Per Foot, Oz. 0.70 0.70 0.70 0.70 0.76 0.70 0.70 0.70 0.70 0.78

Operating Weight Lbs. 196 208 208 250 294 196 208 208 250 294

1. Rated in accordance with ARI Standard 110, utilization range “A”.

2. Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.

3. Dual element fuses or HACR circuit breaker. Minimum recommended overcurrent protection.

4. The Unit Charge is correct for the outdoor unit, matched indoor coil and 15 feet of refrigerant tubing. For tubing lengths other than

15 feet, add or subtract the amount of refrigerant, using the difference in length multiplied by the per foot value. If line exceeds 25

feet, you may refer to publications software 036-68001-001 for proper line sizing.

DIMENSIONS

Unit

Model

Dimensions

(Inches) Refrigerant Connection

Service Valve Size

1. Including Fan Guard.

* Adapter fitting required for 1-1/8” line set.

B C Liquid Vapor

030 35 37 27

3/8” 7/8”

036 39 37 27

042 39 37 27

048 34 43 32

060 38 43 32 7/8”*

246819-BTG-H-0208

6Unitary Products Group

PROCEDURES:

1. Unit factory charge listed on the unit nameplate includes refrigerant for the condenser, the smallest evaporator and 15 feet of inter-con-

necting line tubing.

2. Verify the TXV and additional charge required for specific evaporator coil in the system using the above table.

3. Additional charge for the amount of interconnecting line tubing greater than 15 feet at the rate specified in the table above.

4. Permanently mark the unit nameplate with the total system charge. Total System Charge = Base Charge (as shipped) + adder for

evaporator + adder for line set.

Additional R-22 Charge / Orifice Size for Various Matched Systems - 3 Phase

Outdoor Unit EABD-(T,W)030S EABD-(T,W)036S EABD-(T,W)042S EABD-(T,W)048S EABD-(T,W)060S

Required TXV 1TVM2A1 1TVM2A1 1TVM2C1 1TVM2C1 1TVM2C1

Factory Charge, lbs-oz 8 - 9 8 - 7 8 - 7 12 - 8 16 - 9

Indoor Coil1Additional Charge, Oz

FC/MC/PC/UC35B2C09–––

FC/MC/PC/UC35C2C09–––

FC/MC/PC/UC42B2C09–––

FC/MC/PC/UC42C2C09–––

FC/MC/PC/UC48C2C – 9 14 – –

FC/MC/PC/UC48D2C – 9 14 – –

FC/PC/UC60C2C –––75

FC/MC/PC/UC60D2C–––75

MC61D2C –––75

HC36B2A 0––––

HC42C2C –9–––

HC60C2C –––75

HD36B2A 09–––

HD48C2C – – 14 – –

HD60D2C –––75

AHP30B2A 0––––

AHP36C2A –9–––

AHP42C2C –9–––

AHP/SHP48D2C – – 14 7 –

AHP/SHP60D2C –––75

FC/MC/PC/UC42B3X09–––

FC/MC/PC/UC42X3X09–––

FC/MC/PC/UC48C3X – 9 14 – –

FC/MC/PC/UC48D3X – 9 14 – –

FC/PC/UC60C3X –––75

FC/MC/PC/UC60D3X–––75

MC61D3X –––75

HC36B3X 0––––

HC42C3X –9–––

HC60C3X –––75

HD36B3X 09–––

HD48C3X – – 14 – –

HD60D3X –––75

AHP30B3X 0––––

AHP36C3X –9–––

AHP42C3X –9–––

AHP/SHP48D3X – – 14 7 –

AHP/SHP60D3X –––75

F*FP040H06T2A 09–––

F*FP042H06T2A –9–––

FOOTNOTES:

1. Systems matched with furnace or air handlers not equipped with blower-off delays may require blower Time Delay Kit 2FD06700224.

246819-BTG-H-0208

Unitary Products Group 7

COOLING CAPACITY - With Air Handler Coils

UNIT

MODEL

AIR HANDLER

COIL MODEL1COOLING

MODEL W RATED

CFM NET MBH SEER EER

TOTAL SENS.

1 & 3 PH 13 SEER HP WITH MA

EABD-F018S MA08B 17 FC/MC18B 600 18.0 12.4 13.00 11.00

EABD-F024S MA08B 17 FC/MC24B 800 23.2 16.8 13.00 11.00

MA08B 17 FC/MC30B 800 23.2 16.8 13.00 11.00

EABD-F030S MA12B 17 FC/MC35B 1000 28.4 20.3 13.00 11.00

MA12B 17 FC/MC42B 1000 28.4 20.3 13.00 11.00

EABD-(T,W)030S MA12B 17 FC/MC35B 1000 28.0 20.0 13.00 11.00

MA12B 17 FC/MC42B 1000 28.0 20.0 13.00 11.00

EABD-F036S MA12B 17 FC/MC35B 1200 34.6 25.3 13.00 11.00

MA12B 17 FC/MC42B 1200 34.6 25.3 13.00 11.00

MA14D 24 FC/MC48D 1200 35.0 25.6 13.00 11.00

EABD-(T,W)036S MA12B 17 FC/MC35B 1200 34.0 24.8 13.00 11.00

MA12B 17 FC/MC42B 1200 34.0 24.8 13.00 11.00

MA14D 24 FC/MC48D 1200 34.4 25.1 13.00 11.00

EABD-F042S MA16C 21 FC/MC48C 1400 41.0 30.8 13.00 11.00

MA14D 24 FC/MC48D 1400 41.0 30.8 13.00 11.00

EABD-(T,W)042S MA16C 21 FC/MC48C 1400 40.0 30.0 13.00 11.00

MA14D 24 FC/MC48D 1400 40.0 30.0 13.00 11.00

EABD-F048S MA16C 21 FC60C 1600 46.0 35.4 13.00 11.00

MA20D 21 FC/MC60D 1600 46.0 35.4 13.00 11.00

MA20D 24 MC61D 1600 46.0 35.5 13.00 11.00

EABD-(T,W)048S MA16C 21 FC60C 1600 45.0 34.6 13.00 11.00

MA20D 21 FC/MC60D 1600 45.0 34.6 13.00 11.00

MA20D 24 MC61D 1600 45.0 34.7 13.00 11.00

EABD-F060S MA20D 24 FC/MC60D 1800 55.0 40.7 13.00 11.00

MA20D 24 MC61D 1800 55.5 41.0 13.00 11.00

EABD-(T,W)060S MA20D 24 FC/MC60D 1800 54.5 40.3 13.00 11.00

MA20D 24 MC61D 1800 55.0 40.6 13.00 11.00

1 PH 13 SEER HP WITH MV - VARIABLE SPEED

EABD-F018S MV12B 17 FC/MC18B 600 18.0 12.6 14.00 12.00

EABD-F024S MV12B 17 FC/MC24B 800 23.6 16.7 14.00 12.00

MV12B 17 FC/MC30B 800 23.6 16.7 14.00 12.00

EABD-F030S

MV12B 17 FC/MC35B 1000 29.0 20.1 14.00 12.00

MV16C 21 FC/MC35C 1000 29.0 20.1 14.00 12.00

MV12B 17 FC/MC42B 1000 29.0 20.1 14.00 12.00

MV16C 21 FC/MC42C 1000 29.0 20.1 14.00 12.00

EABD-F036S

MV12B 21 FC/MC35C 1200 35.2 25.0 13.50 11.00

MV16C 21 FC/MC35C 1200 35.2 25.0 14.00 12.00

MV16C 21 FC/MC42C 1200 35.4 25.2 14.00 12.00

MV16C 21 FC/MC48C 1200 35.4 25.2 14.00 12.00

MV20D 24 FC/MC48D 1200 35.4 25.2 14.00 12.00

EABD-F042S MV16C 21 FC/MC48C 1400 41.0 30.3 13.75 11.00

EABD-F048S MV20D 24 FC/MC60D 1600 46.0 34.6 13.50 11.00

MV20D 24 MC61D 1600 46.5 34.8 13.75 11.00

EABD-F060S MV20D 24 FC/MC60D 1800 54.0 39.7 13.25 11.00

MV20D 24 MC61D 1800 55.0 39.9 13.25 11.00

For Notes See Page 8

246819-BTG-H-0208

8Unitary Products Group

— = Not Applicable.

Go to www.ari.org/aridirectory for the latest additional matches.

1 PH 13 SEER AC WITH AV / SV - VARIABLE SPEED

EABD-F018S AV24 17 – 600 18.0 12.6 14.00 12.00

EABD-F024S AV24 17 – 800 23.8 16.7 14.00 12.00

EABD-F030S AV36 17 – 1000 29.2 20.1 14.00 12.00

EABD-F036S AV36 21 – 1200 35.0 25.2 14.00 12.00

EABD-F042S AV/SV48 21 – 1400 41.5 30.3 14.00 12.00

EABD-F048S AV/SV48 24 – 1600 46.5 34.8 13.75 11.00

EABD-F060S AV/SV60 24 – 1800 55.0 39.9 13.25 11.00

1 & 3 PH 13 SEER HP WITH AHP / F*FP / F*FV

EABD-F018S F*FP024 17 – 600 18.0 11.4 13.00 11.00

AHP18 17 – 600 18.0 11.4 13.00 11.00

EABD-F024S F*FP030 17 – 800 23.2 16.4 13.00 11.00

AHP24 17 – 800 23.0 16.4 13.00 11.00

EABD-F030S F*FP040 21 – 1000 28.0 19.5 13.00 11.00

AHP30 17 – 1000 28.4 19.5 13.00 11.00

EABD-(T,W)030S F*FP040 21 – 1000 27.6 19.2 13.00 11.00

AHP30 17 – 1000 28.0 19.2 13.00 11.00

EABD-F036S

F*FP040 21 – 1200 34.6 25.4 13.00 11.00

F*FP042 21 – 1200 34.6 25.4 13.00 11.00

AHP36 21 – 1200 34.4 25.4 13.00 11.00

AHP42 21 – 1200 34.6 25.3 13.00 11.00

EABD-(T,W)036S

F*FP040 21 – 1200 34.0 24.9 13.00 11.00

F*FP042 21 – 1200 34.0 24.9 13.00 11.00

AHP36 21 – 1200 33.8 24.9 13.00 11.00

AHP42 21 – 1200 34.0 24.8 13.00 11.00

EABD-F042S AHP/SHP48 24 – 1400 41.0 30.7 13.00 11.00

EABD-(T,W)042S AHP/SHP48 24 – 1400 40.0 29.9 13.00 11.00

EABD-F048S F*FV060 24 – 1600 46.0 34.6 13.50 11.00

AHP/SHP48 24 – 1600 46.0 35.3 13.00 11.00

AHP/SHP60 24 – 1600 46.0 34.6 13.25 11.00

EABD-(T,W)048S F*FV060 24 – 1600 45.0 33.8 13.50 11.00

AHP/SHP48 24 – 1600 45.0 34.5 13.00 11.00

AHP/SHP60 24 – 1600 45.0 33.8 13.25 11.00

EABD-F060S F*FV060 24 – 1800 54.0 39.7 13.25 11.00

AHP/SHP60 24 – 1800 55.0 39.7 13.00 11.00

EABD-(T,W)060S F*FV060 24 – 1800 53.5 39.3 13.25 11.00

AHP/SHP60 24 – 1800 54.5 39.3 13.00 11.00

Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ARI Standards 210/240.

Cooling MBH based on 80°F entering air temperature, 50% RH, and rated air flow.

EER (Energy Efficiency Ratio) is the total cooling output in BTU’s at a 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.

SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTU’s during a normal annual usage period for cooling divided by the total electric power

input in watt-hours during the same period.

1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.

COOLING CAPACITY - With Air Handler Coils (Continued)

UNIT

MODEL

AIR HANDLER

COIL MODEL1COOLING

MODEL W RATED

CFM NET MBH SEER EER

TOTAL SENS.

246819-BTG-H-0208

Unitary Products Group 9

COOLING CAPACITY - Upflow, Downflow, and Horizontal Furnaces and Coils

UNIT MODEL

FURNACE** COIL

MODEL

COOLING

CFM RANGE

(MIN.-MAX.) WRATED

CFM NET MBH SEER1EER

TOTAL SENS.

EABD-F018S 450

750 14,17 FC/MC/PC/UC18 600 18.0 12.4 13.00 11.00

14 HC18 600 17.8 12.1 13.00 11.00

EABD-F024S 600

1000

14,17 FC/MC/PC/UC24 800 23.2 16.7 13.00 11.00

14,17 FC/MC/PC/UC30 800 23.2 16.7 13.00 11.00

14 HC30 760 23.4 16.6 13.00 11.00

– HD24 800 23.2 16.7 13.00 11.00

EABD-F030S 800

1200

17,21 FC/MC/PC35 1000 28.4 20.3 13.00 11.00

17,21 FC/MC/PC/UC42 1000 28.4 20.3 13.00 11.00

17 HC36 950 28.0 19.6 13.00 11.00

– HD36 1000 28.6 20.3 13.00 11.00

EABD-(T,W)030S 800

1200

17,21 FC/MC/PC35 1000 28.0 20.0 13.00 11.00

17,21 FC/MC/PC/UC42 1000 28.0 20.0 13.00 11.00

17 HC36 950 27.6 19.3 13.00 11.00

– HD36 1000 28.2 20.0 13.00 11.00

EABD-F036S 1000

1400

17,21 FC/MC/PC35 1200 34.6 25.3 13.00 11.00

17,21 FC/MC/PC/UC42 1200 34.6 25.3 13.00 11.00

21,24 FC/MC/PC/UC48 1200 35.0 25.6 13.00 11.00

21 HC42 1140 34.4 24.5 13.00 11.00

– HD36 1200 34.4 25.2 13.00 11.00

EABD-(T,W)036S 1000

1400

17,21 FC/MC/PC35 1200 34.0 24.8 13.00 11.00

17,21 FC/MC/PC/UC42 1200 34.0 24.8 13.00 11.00

21,24 FC/MC/PC/UC48 1200 34.4 25.1 13.00 11.00

21 HC42 1140 33.8 24.0 13.00 11.00

– HD36 1200 33.8 24.7 13.00 11.00

EABD-F042S 1200

1000 21,24 FC/MC/PC/UC48 1400 41.0 30.8 13.00 11.00

– HD48 1400 40.5 30.3 13.00 11.00

EABD-(T,W)042S 1200

1600 21,24 FC/MC/PC/UC48 1400 40.0 30.0 13.00 11.00

– HD48 1400 39.5 29.5 13.00 11.00

EABD-F048S 1400

1800

21,24 FC/MC/PC/UC60 1600 45.0 35.4 13.00 11.00

24 MC61 1600 46.0 35.5 13.00 11.00

24 HC60 1520 45.5 34.3 13.00 11.00

– HD60 1600 45.0 34.7 13.00 11.00

EABD-(T,W)048S 1400

1800

21,24 FC/MC/PC/UC60 1600 44.0 34.6 13.00 11.00

24 MC61 1600 45.0 34.7 13.00 11.00

24 HC60 1520 44.5 33.5 13.00 11.00

– HD60 1600 44.0 33.9 13.00 11.00

EABD-F060S 1600

2000

21,24 FC/MC/PC/UC60 1800 55.0 40.7 13.00 11.00

24 MC61 1800 55.5 41.0 13.00 11.00

24 HC60 1710 54.5 39.7 13.00 11.00

– HD60 1800 54.0 39.9 13.00 11.00

EABD-(T,W)060S 1600

2000

21,24 FC/MC/PC/UC60 1800 54.5 40.3 13.00 11.00

24 MC61 1800 55.0 40.6 13.00 11.00

24 HC60 1710 54.0 39.3 13.00 11.00

– HD60 1800 53.5 39.5 13.00 11.00

1. Requires a 2FD06700224 Blower Time Delay unless a standard furnace is equipped with one.

** Refer to Quick Selection Chart for specific furnace match-up.

246819-BTG-H-0208

10 Unitary Products Group

COOLING CAPACITY - With Variable Speed Furnaces

UNIT MODEL VARIABLE SPEED

FURNACE MODEL COIL

MODEL1WCOOLING

RATED

CFM NET MBH SEER EER

TOTAL SENS.

1 PH 13 SEER HP WITH VARIABLE SPEED FURNACES2

EABD-F018S

(F,L)L8VA12 FC/MC/PC18A 14 600 18.0 12.5 14.00 12.00

FL9VA12 FC/MC/PC18A 14 600 18.0 12.5 14.00 12.00

FL9(C,V)B12 FC/MC/PC18B 17 600 18.0 12.6 14.00 12.00

(F,L)L8VA12 HC18 14 600 18.0 12.5 14.00 12.00

FL9VA12 HC18 14 600 18.0 12.5 14.00 12.00

EABD-F024S

(F,L)L8VA12 FC/MC/PC24A 14 800 23.2 16.7 14.00 12.00

FL9VA12 FC/MC/PC24A 14 800 23.2 16.7 14.00 12.00

FL9(C,V)B12 FC/MC/PC24B 17 800 23.2 16.6 14.00 12.00

(F,L)L8VA12 FC/MC/PC30A 14 800 23.2 16.7 14.00 12.00

FL9VA12 FC/MC/PC30A 14 800 23.2 16.7 14.00 12.00

FL9(C,V)B12 FC/MC/PC30B 17 800 23.2 17.2 14.00 12.00

(F,L)L8VA12 HC30 14 800 23.2 17.2 14.00 12.00

FL9VA12 HC30 14 800 23.2 16.9 14.00 12.00

(F,L)L8VA12 HD30 – 800 23.2 16.9 14.00 12.00

FL9VA12 HD30 – 800 23.2 16.9 14.00 12.00

EABD-F030S

(F,L)L8VB16 FC/MC/PC35B 17 1000 29.0 20.4 14.00 12.00

FL9(C,V)B12 FC/MC/PC35B 17 1000 29.0 20.4 14.00 12.00

(F,L)L8VC16 FC/MC/PC35C 21 1000 29.0 20.3 14.00 12.00

FL9(C,V)C16 FC/MC/PC35C 21 1000 29.0 20.4 14.00 12.00

(F,L)L8VB16 FC/MC/PC42B 17 1000 29.0 20.4 14.00 12.00

FL9(C,V)B12 FC/MC/PC42B 17 1000 29.0 20.4 14.00 12.00

(F,L)L8VC16 FC/MC/PC42C 21 1000 29.0 20.3 14.00 12.00

FL9(C,V)C16 FC/MC/PC42C 21 1000 29.0 20.4 14.00 12.00

(F,L)L8VB16 HC36 17 1000 29.0 20.4 14.00 12.00

FL9(C,V)B12 HC36 17 1000 29.0 20.4 14.00 12.00

(F,L)L8VB16 HD36 – 1000 29.0 20.4 14.00 12.00

FL9(C,V)B12 HD36 – 1000 29.0 20.4 14.00 12.00

EABD-F036S

(F,L)L8VB16 FC/MC/PC42B 17 1200 35.2 25.7 13.50 11.00

FL9(C,V)B12 FC/MC/PC42B 17 1200 35.2 25.7 13.25 11.00

(F,L)L8VC16 FC/MC/PC42C 21 1200 35.2 25.6 13.75 11.00

(F,L)L8VC20 FC/MC/PC42C 21 1200 35.2 25.6 14.00 12.00

FL9(C,V)C16 FC/MC/PC42C 21 1200 35.0 25.5 13.25 11.00

FL9(C,V)C20 FC/MC/PC42C 21 1200 35.0 25.4 13.50 11.00

(F,L)L8VC20 FC/MC/PC48C 21 1200 35.4 25.7 14.00 12.00

FL9(C,V)C16 FC/MC/PC48C 21 1200 35.4 25.7 14.00 12.00

FL9(C,V)C20 FC/MC/PC48C 21 1200 35.4 25.4 14.00 12.00

FL9(C,V)D20 FC/MC/PC48D 24 1200 35.4 25.6 14.00 12.00

(F,L)L8VC20 HC42 21 1200 35.2 25.4 14.00 12.00

FL9(C,V)C16 HC42 21 1200 35.0 25.6 13.25 11.00

FL9(C,V)C20 HC42 21 1200 35.0 25.6 13.50 11.00

(F,L)L8VC20 HD36 – 1200 35.2 25.8 14.00 12.00

FL9(C,V)C16 HD36 – 1200 35.0 25.5 13.25 11.00

FL9(C,V)C20 HD36 – 1200 35.0 25.6 13.50 11.00

EABD-F042S

(F,L)L8VC20 FC/MC/PC48C 21 1400 41.0 30.9 13.50 11.00

FL9(C,V)C16 FC/MC/PC48C 21 1400 41.0 30.9 13.50 11.00

FL9(C,V)C20 FC/MC/PC48C 21 1400 41.0 30.9 13.50 11.00

FL9(C,V)D20 FC/MC/PC48D 24 1400 41.0 30.9 13.50 11.00

(F,L)L8VC20 HD48 – 1400 40.0 30.2 13.50 11.00

FL9(C,V)C16 HD48 – 1400 40.5 30.6 13.25 11.00

FL9(C,V)C20 HD48 – 1400 40.0 30.1 13.25 11.00

For Notes See Page 11

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Bomba de calor de York

York

York E9FD018 Series Manual de usuario

York

York Sunline 2000 BCH 036 Manual de usuario

York

York SINGLE PACKAGE DUAL FUEL HEAT PUMP Manual de usuario

York

York YZB018 THRU 060 Guía de inicio rápido

York

York YHJD24S41S7 Guía de inicio rápido

York

York SUNLINE 2000 B2CH180 Manual de usuario

York

York E4TS030 Guía de inicio rápido

York

York YLCD Series Manual de usuario

York

York PHG6A24 Guía de inicio rápido

York

York YZF Manual de usuario

York

York YHE24B21S Guía de inicio rápido

York

York YLCA 40 Manual de usuario

York

York EKKC-18 DS Manual de usuario

York

York YCUL0016 Manual de usuario

York

York SINGLE PACKAGE HEAT PUMP UNITS Instrucciones de funcionamiento e instalación

York

York YHE Series Manual de usuario

York

York BUZ024 Manual de usuario

York

York YLCA Manual de usuario

York

York YMA024 Guía de inicio rápido

York

York YMB018 THRU 060 Guía de inicio rápido

York

York FC Guía de inicio rápido

York

York SUNLINE 2000 48 Guía de inicio rápido

York

York FCHP090 Manual de usuario

York

York YK145.00-EG4 Guía de inicio rápido

Manuales populares de Bomba de calor de otras marcas

MICROWELL

MICROWELL HP 1000 GREEN Manual de usuario

Sanyo

Sanyo SAP120FCH Manual de usuario

Daikin

Daikin EHYHBH05AA Manual de usuario

Panasonic

Panasonic WH-SDF03E3E5 Guía

Bryant

Bryant 544B Manual de usuario

Airxcel

Airxcel 45000 Series Manual

Mitsubishi Electric

Mitsubishi Electric PUZ-SWM60VAA Manual de usuario

Dimplex

Dimplex LI 16I-TUR Guía del usuario

Carrier

Carrier WSHP Open v3 Guía de configuración rápida

TGM

TGM CTV14CN018A Manual de usuario

Carrier

Carrier 38MGQ Series Manual de usuario

Kokido

Kokido K2O K880BX/EU Guía de solución de problemas

Viessmann

Viessmann VITOCAL 300-G PRO Type BW 2150 Guía rápida

Carrier

Carrier 48EZN Manual de usuario

Viessmann

Viessmann KWT Vitocal 350-G Pro Series Instrucciones de funcionamiento

Ariston

Ariston NIMBUS Manual de usuario

Weishaupt

Weishaupt WWP L 7 Guía del usuario

GE Zoneline AZ85H09EAC Manual de usuario
