Yealink Technical White Paper 802.1X Authentication
2
Table of Contents
About 802.1X....................................................................................................................................... 3
Yealink IP Phones Compatible with 802.1X ..................................................................................... 3
Configuring 802.1X Settings.............................................................................................................. 5
Configuring 802.1X Using Configuration Files ............................................................................ 6
Configuring 802.1X via Web User Interface............................................................................... 12
Configuring 802.1X via Phone User Interface............................................................................ 17
802.1X Authentication Process ....................................................................................................... 19
Sample Screenshots –Identity .................................................................................................... 21
Sample Screenshots - Anonymous Identity............................................................................... 24
Troubleshooting ............................................................................................................................... 27
Why doesn’t the IP phone pass 802.1X authentication?.......................................................... 27
Appendix A: Glossary ....................................................................................................................... 28
Appendix B: 802.1X Authentication Process ................................................................................. 29
A Successful Authentication Using EAP-MD5 Protocol............................................................ 29
A Successful Authentication Using EAP-TLS Protocol .............................................................. 30
A Successful Authentication Using EAP-PEAP/MSCHAPv2 Protocol...................................... 32
A Successful Authentication Using EAP-TTLS/EAP-MSCHAPv2 Protocol .............................. 34
A Successful Authentication Using EAP-PEAP/GTC Protocol .................................................. 34
A Successful Authentication Using EAP-TTLS/EAP-GTC Protocol........................................... 34
A Successful Authentication Using EAP-FAST Protocol ........................................................... 34
Yealink Technical White Paper 802.1X Authentication
3
About 802.1X
The IEEE 802.1X standard defines a Port-based Network Access Control (PNAC) and
authentication protocol that restricts unauthorized clients from connecting to a LAN. The IEEE
802.1X defines the encapsulation of the Extensible Authentication Protocol (EAP) defined in
RFC3748 which is known as “EAP over LAN” or EAPOL.
802.1X authentication involves three parties: a supplicant, an authenticator and an
authentication server. The supplicant is a client device (such as an IP phone) that wishes to
attach to the network. The authenticator is a network device, such as an Ethernet switch. And the
authentication server is typically a host running software supporting the RADIUS and EAP
protocols.
The authenticator acts like a security guard to a protected network. The supplicant is not
allowed access through the authenticator to the protected side of the network until the
supplicant’s identity has been validated and authorized. An analogy to this is like providing a
valid visa at the airport's arrival immigration before being allowed to enter the country. With
802.1X port-based authentication, the supplicant provides credentials, such as user name,
password or digital certificate for the authenticator, and the authenticator forwards the
credentials to the authentication server for verification. If the authentication server determines
the credentials are valid, the supplicant is allowed to access resources located on the protected
side of the network.
Yealink IP Phones Compatible with 802.1X
802.1X is the most widely accepted form of port-based network access control in use and is
available on Yealink IP phones. Yealink IP phones support 802.1X authentication based on
EAP-MD5, EAP-TLS, EAP-PEAP/MSCHAPv2, EAP-TTLS/EAP-MSCHAPv2, EAP-PEAP/GTC,
EAP-TTLS/EAP-GTC and EAP-FAST protocols.
The table below lists the protocols supported by Yealink SIP IP phones with different versions.
Authentication Protocol
IP Phone Models
Firmware Version
EAP-MD5
All IP phones
All Versions
EAP-TLS
T46G, T42G, T41P, CP860
Firmware version 71 or later
T48G
Firmware version 72 or later
Yealink Technical White Paper 802.1X Authentication
4
Authentication Protocol
IP Phone Models
Firmware Version
T58V/A, T56A, T49G,
T40P, T29G, T27P,
T23P/G, T21(P) E2, T19(P)
E2, W56P
Firmware version 80 or later
T54S, T52S, T48S, T46S,
T42S, T41S, T40G, T27G,
W52P
Firmware version 81 or later
T46G,T42G, T41P, CP860
Firmware version 71 or later
T48G
Firmware version 72 or later
T58V/A, T56A, T49G,
T40P, T29G, T27P,
T23P/G, T21(P) E2, T19(P)
E2, W56P
Firmware version 80 or later
T54S, T52, T48S, T46S,
T42S, T41S, T40G, T27G,
W52P
Firmware version 81 or later
EAP-TTLS/EAP-MSCHAPv2
T46G, T42G, T41P, CP860
Firmware version 71 or later
T48G
Firmware version 72 or later
T58V/A, T56A, T49G,
T40P, T29G, T27P,
T23P/G, T21(P) E2, T19(P)
E2, W56P
Firmware version 80 or later
T54S, T52S, T48S, T46S,
T42S, T41S, T40G, T27G,
W52P
Firmware version 81 or later
EAP-PEAP/GTC
T48G, T46G, T42G, T41P
Firmware version 73 or later
T58V/A, T56A, T49G,
T40P, T29G, T27P,
T23P/G, T21(P) E2, T19(P)
E2, CP860, W56P
Firmware version 80 or later
T54S, T52S, T48S, T46S,
T42S, T41S, T40G, T27G,
Firmware version 81 or later
Yealink Technical White Paper 802.1X Authentication
5
Authentication Protocol
IP Phone Models
Firmware Version
W52P
EAP-TTLS/EAP-GTC
T48G, T46G, T42G, T41P
Firmware version 73 or later
T58V/A, T56A, T49G,
T40P, T29G, T27P,
T23P/G, T21(P) E2, T19(P)
E2, CP860, W56P
Firmware version 80 or later
T54S, T52S, T48S, T46S,
T42S, T41S, T40G, T27G,
W52P
Firmware version 81 or later
EAP-FAST
T58V/A, T56A, T29G,
T27P, T23P/G, T21(P) E2,
T19(P) E2, T49G, T48G,
T46G, T42G, T41P, T40P,
CP860, W56P
Firmware version 80 or later
T54S, T52S, T48S, T46S,
T42S, T41S, T40G, T27G,
W52P
Firmware version 81 or later
Yealink IP phones support 802.1X as a supplicant, both Pass-thru Mode and Pass-thru Mode
with Proxy Logoff. When the device connected to the phone disconnects from the PC port, the
Yealink IP phone can provide additional security by sending an EAPOL Logoff message to the
Ethernet switch. This functionality, also known as proxy logoff, prevents another device from
using the port without first authenticating via 802.1X. The Pass-thru Mode is available on Yealink
IP phones running specified firmware version. You can ask your system administrator or contact
Yealink Field Application Engineer (FAE) for more information.
Configuring 802.1X Settings
The 802.1X authentication on Yealink IP phones is disabled by default. You can configure the
802.1X authentication in one of the following three ways:
Configuring 802.1X Using Configuration Files
Configuring 802.1X via Web User Interface
Configuring 802.1X via Phone User Interface
For detailed descriptions of the authentication parameters in configuration files, you can refer to
Configuring 802.1X Using Configuration Files on page 6. When setting up a large number of IP
phones, Yealink recommends using the boot file (for new auto provisioning mechanism) and
configuration files. If you are provisioning a few phones, you can use the web user interface or
phone user interface to configure 802.1X feature.
If the EAP-TLS, EAP-PEAP/MSCHAPv2, EAP-TTLS/EAP-MSCHAPv2, EAP-PEAP/GTC,
Yealink Technical White Paper 802.1X Authentication
6
EAP-TTLS/EAP-GTC or EAP-FAST protocol is preferred in your 802.1X environment, make sure
that the firmware running on your new phone supports the protocol.
The followings provide system administrator with the procedures to successfully configure
Yealink IP phones in a secure 802.1X environment.
Configuring 802.1X Using Configuration Files
The following IP phones use the new auto provisioning mechanism:
SIP-T58V/T58A/T56A IP phones running firmware version 80 or later
SIP-T54S/T52S/T48G/T48S/T46G/T46S/T42G/T42S/T41P/T41S/T40P/T40G/T29G/T27P/T2
7G/T23P/T23G/T21(P) E2/T19(P) E2, CP860, W52P and W56P IP phones running firmware
version 81 or later
Other IP phones or the IP phones listed above running old firmware version use the old auto
provisioning mechanism.
For Old Auto Provisioning Mechanism
1. Add/Edit 802.1X authentication parameters in the configuration file.
The following table shows the information of parameters:
Parameters
Permitted Values
Default
network.802_1x.mode
0, 1, 2, 3, 4, 5, 6 or 7
0
Description:
Configures the 802.1x authentication method.
0-Disabled
1-EAP-MD5
2-EAP-TLS
3-EAP-PEAP/MSCHAPv2
4-EAP-TTLS/EAP-MSCHAPv2
5-EAP-PEAP/GTC
6-EAP-TTLS/EAP-GTC
7-EAP-FAST
Note: If you change this parameter, the IP phone will reboot to make the change take
effect.
Web User Interface:
Network->Advanced->802.1x->802.1x Mode
Phone User Interface:
Menu->Settings->Advanced Settings (default password: admin) ->Network->802.1x
Settings->802.1x Mode
Yealink Technical White Paper 802.1X Authentication
7
Parameters
Permitted Values
Default
network.802_1x.identity
String within 32
characters
Blank
Description:
Configures the user name for 802.1x authentication.
Note: It works only if the value of the parameter “network.802_1x.mode” is set to 1, 2, 3, 4,
5, 6 or 7. If you change this parameter, the IP phone will reboot to make the change take
effect.
Web User Interface:
Network->Advanced->802.1x->Identity
Phone User Interface:
Menu->Settings->Advanced Settings (default password: admin) ->Network->802.1x
Settings->Identity
network.802_1x.md5_password
String within 32
characters
Blank
Description:
Configures the password for 802.1x authentication.
Note: It works only if the value of the parameter “network.802_1x.mode” is set to 1, 3, 4, 5,
6 or 7. If you change this parameter, the IP phone will reboot to make the change take
effect.
Web User Interface:
Network->Advanced->802.1x->MD5 Password
Phone User Interface:
Menu->Settings->Advanced Settings (default password: admin) ->Network->802.1x
Settings->MD5 Password
network.802_1x.root_cert_url
URL within 511
characters
Blank
Description:
Configures the access URL of the CA certificate.
Note: It works only if the value of the parameter “network.802_1x.mode” is set to 2, 3, 4, 5,
6 or 7. The format of the certificate must be *.pem, *.crt, *.cer or *.der.
Web User Interface:
Network->Advanced->802.1x->CA Certificates
Phone User Interface:
None
network.802_1x.client_cert_url
URL within 511
Blank
Yealink Technical White Paper 802.1X Authentication
8
Parameters
Permitted Values
Default
characters
Description:
Configures the access URL of the device certificate.
Note: It works only if the value of the parameter “network.802_1x.mode” is set to 2
(EAP-TLS). The format of the certificate must be *.pem.
Web User Interface:
Network->Advanced->802.1x->Device Certificates
Phone User Interface:
None
The following shows an example of the EAP-TLS protocol for 802.1X authentication in
configuration files:
network.802_1x.mode = 2
network.802_1x.identity = yealink
network.802_1x.root_cert_url = http://192.168.1.8:8080/ca.crt
network.802_1x.client_cert_url = http://192.168.1.8:8080/client.pem
2. Upload the configuration files, CA certificate and client certificate to the root directory of
the provisioning server.
Applying the Configuration Files to Your Phone
Once you have edited and configuration file (e.g., y0000000000xx.cfg) using the parameters
introduced above, you need to do the following to apply the files to your phone:
1. Connect your phone to a network that is not 802.1X-enabled.
2. Perform the auto provisioning process to apply the configuration files to the phone.
Then the IP phone will reboot to make the settings effective.
For more information on auto provisioning, refer to
Yealink_SIP-T2 Series_T19(P)
E2_T4_Series_CP860_W56P_IP_Phones_Auto_Provisioning_Guide
.
3. Connect the phone to the 802.1X-enabled network and reboot the phone.
You can make a phone call to verify whether the phone is authenticated.
For New Auto Provisioning Mechanism
1. Add/Edit 802.1X authentication parameters in the configuration file (e.g., static.cfg).
The following table shows the information of parameters:
Parameters
Permitted Values
Default
static.network.802_1x.mode
0, 1, 2, 3, 4, 5, 6 or 7
0
Yealink Technical White Paper 802.1X Authentication
9
Parameters
Permitted Values
Default
Description:
Configures the 802.1x authentication method.
0-EAP-None
1-EAP-MD5
2-EAP-TLS
3-EAP-PEAP/MSCHAPv2
4-EAP-TTLS/EAP-MSCHAPv2
5-EAP-PEAP/GTC
6-EAP-TTLS/EAP-GTC
7-EAP-FAST
If it is set to 0 (EAP-None), 802.1x authentication is not required.
Note: If you change this parameter, the IP phone will reboot to make the change take
effect.
Web User Interface:
Network->Advanced->802.1x->802.1x Mode
Phone User Interface:
Menu->Settings->Advanced Settings (default password: admin)
->Network->802.1x->802.1x Mode
static.network.802_1x.eap_fast_provision_mode
0 or 1
0
Description:
Configures the EAP In-Band provisioning method for EAP-FAST.
0-Unauthenticated Provisioning
1-Authenticated Provisioning
If it is set to 0 (Unauthenticated Provisioning), EAP In-Band provisioning is enabled by
server unauthenticated PAC (Protected Access Credential) provisioning using anonymous
Diffie-Hellman key exchange.
If it is set to 1 (Authenticated Provisioning), EAP In-Band provisioning is enabled by server
authenticated PAC provisioning using certificate based server authentication.
Note: It works only if the value of the parameter “static.network.802_1x.mode” is set to 7
(EAP-FAST). If you change this parameter, the IP phone will reboot to make the change
take effect.
Web User Interface:
Network->Advanced->802.1x->Provisioning Mode
Phone User Interface:
Yealink Technical White Paper 802.1X Authentication
10
Parameters
Permitted Values
Default
None
static.network.802_1x.anonymous_identity
String within 512
characters
Blank
Description:
Configures the anonymous identity (user name) for 802.1X authentication.
It is used for constructing a secure tunnel for 802.1X authentication.
Note: It works only if the value of the parameter “static.network.802_1x.mode” is set to 2,
3, 4, 5, 6 or 7. If you change this parameter, the IP phone will reboot to make the change
take effect.
Web User Interface:
Network->Advanced->802.1x->Anonymous Identity
Phone User Interface:
None
static.network.802_1x.identity
String within 32
characters
Blank
Description:
Configures the user name for 802.1x authentication.
Note: It works only if the value of the parameter “static.network.802_1x.mode” is set to 1,
2, 3, 4, 5, 6 or 7. If you change this parameter, the IP phone will reboot to make the change
take effect.
Web User Interface:
Network->Advanced->802.1x->Identity
Phone User Interface:
Menu->Settings->Advanced Settings (default password: admin)
->Network->802.1x->Identity
static.network.802_1x.md5_password
String within 32
characters
Blank
Description:
Configures the password for 802.1x authentication.
Note: It works only if the value of the parameter “static.network.802_1x.mode” is set to 1,
3, 4, 5, 6 or 7. If you change this parameter, the IP phone will reboot to make the change
take effect.
Web User Interface:
Network->Advanced->802.1x->MD5 Password
Tabla de contenidos
