Thank you for choosing a Yamaha out-
board motor. This Owner’s manual con-
tains information needed for proper oper-
ation, maintenance and care. A thorough
understanding of these simple instruc-
tions will help you obtain maximum
enjoyment from your new Yamaha. If you
have any question about the operation or
maintenance of your outboard motor,
please consult a Yamaha dealer.
In this Owner’s Manual particularly
important information is distinguished in
the following ways.
QThe Safety Alert Symbol means
ATTENTION! BECOME ALERT!
YOUR SAFETY IS INVOLVED!
w
Failure to follow WARNING instructions
could result in severe injury or death to
the machine operator, a bystander, or a
person inspecting or repairing the out-
board motor.
cC
A CAUTION indicates special precautions
that must be taken to avoid damage to
the outboard motor.
NOTE:
A NOTE provides key information to make
procedures easier or clearer.
* Yamaha continually seeks advance-
ments in product design and quality.
Therefore, while this manual contains
the most current product information
available at the time of printing, there
may be minor discrepancies between
your machine and this manual. If there
is any question concerning this manual,
please consult your Yamaha dealer.
NOTE:
The F15MH, F15PR and their standard
accessories are used as a base for the
explanations and illustrations in this man-
ual. Therefore, some items may not apply
to every model.
EMU01449
TO THE OWNER
EMU01446
F15A
OWNER'S MANUAL
©2001 by Yamaha Motor Corporation, USA
1st Edition, April 2001
All rights reserved.
Any reprinting or unauthorized use
without the written permission of
Yamaha Motor Corporation, USA
is expressly prohibited.
Printed in Japan
P/N LIT-18626-04-69
66M-9-15-1 5/10/01 9:39 AM Page 1
66M-9-15-1 5/10/01 9:39 AM Page 2
E
GENERAL INFORMATION
BASIC COMPONENTS
OPERATION
MAINTENANCE
TROUBLE RECOVERY
INDEX
READ THIS OWNER’S MANUAL CAREFULLY
BEFORE OPERATING YOUR OUTBOARD MOTOR.
1
2
3
4
5
6
EMA20010
CONTENTS
66M-9-15-1 5/10/01 9:39 AM Page 3
66M-9-15-1 5/10/01 9:39 AM Page 4
EMB00010
Chapter 1
GENERAL
INFORMATION
IDENTIFICATION NUMBERS RECORD ..1-1
Outboard motor serial number ...........1-1
EMISSION CONTROL INFORMATION...1-2
Star labels ..............................................1-3
SAFETY INFORMATION..........................1-4
IMPORTANT LABELS ..............................1-6
BASIC BOATING RULES ........................1-7
FUELING INSTRUCTIONS.....................1-11
Gasoline (petrol) .................................1-12
ENGINE OIL ............................................1-13
BATTERY REQUIREMENT ....................1-14
PROPELLER SELECTION .......................1-14
START-IN-GEAR PROTECTION ............1-16
1
2
3
4
5
6
E
66M-9-15-1 5/10/01 9:39 AM Page 5
1-1
EMB10011
IDENTIFICATION NUMBERS
RECORD
EMB10210
OUTBOARD MOTOR SERIAL
NUMBER
The outboard motor serial number is
stamped on the label attached to the port
side of the clamp-bracket.
Record your outboard motor serial num-
ber in the spaces provided to assist you in
ordering spare parts from your Yamaha
dealer or for reference in case your out-
board motor is stolen.
1Outboard motor serial number
E
1
401012
YAMAHA MOTOR CO., LTD.
MADE IN JAPAN
PAYS D'ORIGINE JAPON
66M-9-15-1 5/10/01 9:39 AM Page 6
1-2
E
504**2
q
w
EMU01385
EMISSION CONTROL
INFORMATION
EMU01387
NORTH AMERICAN MODELS
This engine conforms to U.S.
Environmental Protection Agency (EPA)
regulations for marine SI engines. See the
label affixed to your engine for details.
Approval label of Emission control
certificate
This label is attached to the bottom cowl-
ing.
1Emission control information label
New Technology ; (4-stroke) EM
Manufactured date label
This label is attached to the clamp brack-
et.
2Manufactured date label
EMISSION CONTROL INFORMATION
ENGINE FAMILY :
THIS ENGINE CONFORMS TO 2001 U.S. EPA REGULATIONS FOR MARINE SI ENGINES.
THIS ENGINE CONFORMS TO 2001 CALIFORNIA EMISSION REGULATIONS FOR SI MARINE ENGINES.
REFER TO THE OWNERS MANUAL FOR MAINTENANCE SPECIFICATIONS AND ADJUSTMENTS.
FELs :
SPARK PLUG :
DISPLACEMENT :
ADVERTISED POWER :
IDLE SPEED :
SPARK PLUG GAP (mm) :
FUEL : GASOLINE
VALVE LASH (mm) : IN EX
cm
kw
g/kw-hr rpm IN NEUTRAL
3
EM
Manufactured:
66M-9-15-1 5/10/01 9:39 AM Page 7
1-3
E
EMU01389
STAR LABELS
Your outboard motor is labeled with a
California Air Resources Board (CARB)
star label. See below for a description of
your particular label.
1Star label
One Star - Low Emission
The one-star label identifies engines that
meet the Air Resources Board’s 2001
exhaust emission standards. Engines
meeting these standards have 75% lower
emissions than conventional carbureted
two-stroke engines. These engines are
equivalent to the U.S. EPA’s 2006 stan-
dards for marine engines.
Two Stars - Very Low Emission
The two-star label identifies engines that
meet the Air Resources Board’s 2004
exhaust emission standards. Engines
meeting these standards have 20% lower
emissions than One Star-Low-Emission
engines.
Three Stars - Ultra Low Emission
The three-star label identifies engines that
meet the Air Resources Board’s 2008
exhaust emission standards. Engines
meeting these standards have 65% lower
emissions than One Star-Low-Emission
engines.
000851
q
66M-9-15-1 5/10/01 9:39 AM Page 8
