Set List Organizer Owner’s Manual 1
Set List Organizer Owner’s Manual
• Copying of the commercially available music sequence data and/or digital audio files is strictly
prohibited except for your personal use.
• The software and this owner’s manual are exclusive copyrights of Yamaha Corporation.
• Copying of the software or reproduction of this manual in whole or in part by any means is expressly
forbidden without the written consent of the manufacturer.
• Yamaha makes no representations or warranties with regard to the use of the software and
documentation and cannot be held responsible for the results of the use of this manual and the
software.
• The screen displays as illustrated in this Owner’s Manual are for instructional purposes, and may
appear somewhat different from the screens which appear on your devicer.
• Apple, iPad are trademarks of Apple Inc., registered in the U.S. and other countries.
• The company names and product names in this Owner’s Manual are the trademarks or registered
trademarks of their respective companies.
© 2011 Yamaha Corporation. All rights reserved.
What is Set List Organizer?
This application lets you memorize the Program Change settings for respective Songs and transmit them to the MIDI instrument from your iPad. By creating a Set List, you
can easily control the Program Change settings of the MIDI instrument, to correspond to the songs in your live performance.
Set List Organizer
iPad
iMX-1
MIDI OUT MIDI IN
MIDI IN MIDI OUT
Utility window
Text Edit display Set List Edit window Program Change Edit
window
Main display For controlling the Program
Change settings of the MIDI
instrument.
MIDI instrument
By using MIDI cables and a Yamaha
i-MX1, connect the instrument to an iPad
Transmit the Program Change messages
according to the current Song.
NOTE
For information about the MIDI settings of the
instruments, refer to the respective manuals.
Set List Organizer Owner’s Manual 2
Creating a Set List
1. Create a new empty Set List.
On the Main display, tap the Set List name to call up the Set List table. On this table,
add the new empty Set List. For details, refer to the Main display.
2. On the Main display, select the Set List created in Step 1
3. Add a Song to the Set List selected in Step 2.
Tap [LIST EDIT] to call up the Set List Edit window. Add the Song to this table. For
details, refer to the Set List Edit window.
4.
Make the Program Change settings for the Song added in Step 3.
Tap [PGM] of the selected Song to call up the Program Change Edit window, then
make the desired settings. For details, refer to the Program Change Edit window.
Set List Organizer Owner’s Manual 3
Controlling the Program Change settings of the MIDI instrument
1. Select the desired Set.
On the Main display, select the Set List created in the previous page.
2. Control the Program Change settings from the iPad during
your Performance.
On the Main display, tap the desired Program Change button of the corresponding
Song to change the Voice of the MIDI instrument.
NOTE
You can also conveniently make notes to help you remember which Voices were assigned to the
Program Change buttons.
To do this, select a Song on the Main display, and tap [TEXT EDIT] to call up the Text Edit display. For
details, refer to the Text Edit display.
Set List Organizer Owner’s Manual 4
Title bar and Utility window
Each lamp flashes according to the MIDI in/out
messages.
Tapping this opens or closes the Utility window.
Lets you transmit/receive the Set List data to/from
another Set List Organizer which is running on a
neighboring iPad.
Tap this button on both iPads.
Tapping here initializes all the settings.
Tapping this calls up the Owner’s Manual
Indicates the program version.
Title bar
Utility window
Set List Organizer Owner’s Manual 5
Main display
The Main display lets you control the Program Change settings of the MIDI instrument. This display features two view types: Song List view and Song Text view.
Tapping [-] or [+] selects the Set List.
Tapping the Set List name calls up the Set List
table described on the next page.
Song List view
Indicates that this number is selected.
You can change the Song by tapping
any number.
Calls up the Text Edit display which
lets you input or edit text for the
currently selected Song.
Song Number and Song Name
Calls up the Set List Edit window
which lets you change the Song
name and order, as well as add/
delete Songs to/from the current
Set List.
Song List view
Calls up the Song Text view of
the currently selected Song.
Indicates that this button was the last
one tapped.
Tapping one of the Program Change
buttons transmits the memorized
Program Change number to the
instrument. Tapping the gray colored
button transmits nothing.
Calls up the Program Change Edit
window of the corresponding Song.
On that window, you can assign the
desired Program Change number to
each number button.
Changes the Song.
Set List Organizer Owner’s Manual 6
Song List view
Set List table
Song Text view
Tapping the Set List Name calls
up the Set List table.
Calls up the Song Text view of
the currently selected Song.
Adds the Set List to the table.
Deletes each of
the Set Lists.
Calls up the
Rename window.
Sliding here changes
the order of the Set List.
Closes the table.
Shows your text memo input
on the Text Edit display.
Returns to the Song List view.
Set List Organizer Owner’s Manual 7
Text Edit display
This display is called up via [TEXT EDIT], letting you input or edit text memos for information about the currently selected Song.
Selects the font type, size and color.
Selects the background picture.
Changes the bar.
This on-screen keyboard lets you
input or edit text.
Closes the display.
Shows characters you input via the
on-screen keyboard.
Set List Organizer Owner’s Manual 8
Set List Edit window
This window lets you change the Song name and order, as well as add/delete Songs to/from the current Set List.
Adds Songs to the Set List.
Up to thirty Songs can be added.
Deletes each of the Songs in
response to the confirmation
window.
Closes the window.
Sliding here changes the order
of the Song. The order set here is
applied to the Song List view.
Calls up the Rename window with
on-screen keyboard.
Set List Organizer Owner’s Manual 9
Program Change Edit window
This window lets you assign the Program Change setting including MIDI channel, Bank Select and the volume value to each Program Change button.
U.R.G., Digital Musical Instruments Division
© 2011 Yamaha Corporation
106MW-A0
Closes the window.
Equivalent to the Program Change button
number on the Main display.
Program Change ON/OFF button
When set to ON, the corresponding
Program Change button becomes
available. When set to OFF, the
corresponding Program Change
button becomes gray, indicating it is
unavailable.
Indicates the MIDI channel, Bank
Select MSB, Bank Select LSB and
Program Change. Tapping this area
calls up the window for setting the
value.
If you want to make the settings simply
and quickly, this [LEARN] button is
useful. Tap [LEARN] (the button starts
flashing), then transmit the Program
Change messages from the MIDI
instrument. The received MIDI messages
will be assigned to the corresponding
Program Change button. Tapping this
While flashing cancels the Learn status.
Adjusts the volume of the Voice
specified via the Program Change. The
volume can be adjusted by operating the
knob, or by tapping the value to call up
the slider for changing the value.
Volume ON/OFF button
When set to ON, tapping the Program
Change button transmits the volume
value, and doesn’t transmit when set to
OFF.
