DTX-MULTI 12 Firmware Update Guide 1

DTX-MULTI 12

Firmware Update Guide

Thank you for choosing a Yamaha product.

This document explains how to update the firmware of the DTX-MULTI 12 and the update history.

For details of the major new functions and operations, refer to DTX-MULTI 12-related documents on the

following website:

http://download.yamaha.com

■Special Notices

・ When you execute this update program, any settings you have made such as Trigger Setups and pad

types will be overwritten with the corresponding defaults.

・ Please save your important data onto the USB storage device before updating the firmware of the

DTX-MULTI 12.

・ This updater is to be used at the user’s own risk.

・ DO NOT power off or disconnect the cable from the product during the updating process. The DTX-

MULTI 12 may be damaged.

・ DO NOT remove the USB storage device from the product during the updating process. The DTX-

MULTI 12 and the USB storage device may become inoperable.

・ If the update fails, and the DTX-MULTI 12 still does not operate correctly even after you execute the

update once again, please contact your Yamaha dealer.

・ This software and documentation are the exclusive copyrights of Yamaha Corporation.

・ Reproducing or modifying all or parts of this software or its documentation without permission is strictly

prohibited.

・ The company names and product names in this document are the trademarks or registered trademarks

of their respective companies.

DTX-MULTI 12 Firmware Update Guide 2

Included Files

This folder contains the following files:

・dtx_m12_en_update_guide_v***.pdf This document (PDF file)

・the "***.PGM" file The update program

Required Items

・USB storage device formatted on the DTX-MULTI 12

For details of compatible USB Devices, please visit the following website:

http://download.yamaha.com

Confirming the Current Version

Hold down the [SHIFT] button and then turn the power on by pressing the Standby/On switch.

"Firm Ver : *.**" indicates the current version of the firmware.

NOTE

If the message above does not appear, turn the power off by pressing the Standby/On switch and try again.

DTX-MULTI 12 Firmware Update Guide 3

Updating Procedure

NOTICE

Please save your important data onto the USB storage device before updating the firmware of the DTX-

MULTI 12.

1. After downloading, decompress the archived file, and then find the "***.PGM" file. Copy the

"***.PGM" file to the root of the USB storage device.

2. Make sure to turn the power off (the Standby/On switch is set to the Standby position,) and then

connect the USB storage device to the [USB TO DEVICE] terminal on the side panel.

3. Hold down the [▽△] button, and then turn the power on by pressing the Standby/On switch.

4. Press the [ENTER] button to start the update process. This process takes a few minutes.

5. When the update process is completed, the message “Completed. Reboot MULTI 12” will appear,

and you can turn the power off (the Standby/On switch is set to the Standby position.)

6. Confirm the version of the firmware as described in “Confirming the Current Version.”

This completes the update process.

Manual Development Group

Published 07/2016 YJ-A0

DTX-MULTI 12 Firmware Update Guide 4

Main Enhancements

【V1.03 → V1.10】

・ Added new pad types for the DT50S/DT50K and KP100. (101 page of Owner’s Manual)

・ Added the new trigger parameter “NoiseFilterTable.”

・ Added the new trigger parameter “2P Balance.”

・ Added new setting values “14&15” and “16&17” for Copy Trigger parameters “Pad to copy” and “Pad

to replace.” (104 page of Owner’s Manual)

■Version History

【V1.02 → V1.03】

・ Added “ph2” setting for ClkOutSel (Click-track output selection) parameter. (84 page of Owner’s

Manual) This setting is used to output the click-track via the PHONES jack only, and all other sound

via the OUTPUT (L/MONO and R) jacks only.

・ Added new pad types as follows. (101 page of Owner’s Manual)

KU100, TP70S Snare, TP70S Tom, TP70S HiHat, TP70, PCY100, PCY90, XP80 Snare, XP80Tom,

XP70

・ Expanded the input gain setting range. (101 page of Owner’s Manual)

【V1.01 → V1.02】

・ Fixed a bug where, when two HH65 Hi-hat Controllers connected to the FOOT SW and HH CTRL

jacks were simultaneously operated, a sound would be produced only for one of them.

【V1.00 → V1.01】

・ Added new pad types for external pads as follows.

New Pad Type Model

KP125W/125 KP125W/125

XP120/100Sn XP120SD/100SD

XP120/100Tm XP120T/100T

・ Fixed a problem in which the DTX-MULTI 12 may freeze along with the loss of currently recorded data,

when the recording operation uses up the full memory for User patterns.

・ Solved some minor errors.
