◆Symmetrical circuitry using independent left and right power supply

circuits and a twin DAC structure for fully independent left and right

channels

◆Separate power-transformer windings for digital and analog circuitry

◆Exclusive Yamaha loading mechanism with superior quietness

◆PURE DIRECT

◆Super sound from Super Audio CDs

◆Newly developed heavyweight feet to suppress vibrations

■Supplied accessories

Please check that you have received all of the following parts.

• Power cable

• Remote control

• Batteries (AA, R6, UM-3) (×2)

• Audio pin cable

• Safety brochure

■About this manual

•yindicates a tip for your operation.

• This manual is printed prior to production. Design and specifications are subject to change in part as a result of improvements, etc. In

case of differences between the manual and the product, the product has priority.

• The color of images in this manual may vary from the original.

• Read the “Safety brochure” before using this unit.

Contents

Controls and functions.......................................................................................................................................... 6

Connections.......................................................................................................................................................... 14

Specifications ....................................................................................................................................................... 18

Playable disc format............................................................................................................................................ 19

Troubleshooting................................................................................................................................................... 21

01EN_CD-S1000_G.book Page 4 Wednesday, February 4, 2009 9:25 AM

Black process 45.0° 240.0 LPI

CONTROLS AND FUNCTIONS

5En

Controls and functions

In this chapter, you will learn the controls and functions of CD-S1000.

6En

Controls and functions

■Front panel

1POWER

Press upward or downward to turn on or off this unit.

• The POWER indicator above lights up when this unit is turned

on.

• Playback starts automatically if the power is turned on while a

disc is set in the disc tray.

2Remote control sensor

Receives signals from the remote control.

3SA-CD/CD

Switches the playback layer of a hybrid SA-CD between

SA-CD and CD (see page 19).

• The SA-CD/CD indicator above lights up when the SA-CD

layer is selected.

• This setting is retained even if you turn off this unit.

• Audio signals are only output from the ANALOG OUT jacks

while the Super Audio CD layer is selected.

• Audio signals recorded in DSD multi-channel format cannot be

played on this unit.

4PURE DIRECT

Turns on the PURE DIRECT mode to improve audio

quality.

When this unit is in the PURE DIRECT mode:

• The PURE DIRECT indicator above lights up.

• Audio signals are not output at the OPTICAL

DIGITAL OUT jack and the COAXIAL DIGITAL

OUT jack (see page 8).

• The front panel display is turned off and only the

minimum required indicators and messages are

displayed.

• Press again to turn off the PURE DIRECT mode.

• This setting is retained even if you turn off this unit.

5Disc tray

Loads a disc.

POWER

OFF

SA-CD/CD PURE DIRECT

312 4 5

Notes

7En

6(Open/Close)

Opens or closes the disc tray.

You can also close the disc tray by:

• pressing (Play) on the front panel or on the remote control

or by pushing the front edge of the disc tray gently.

• pressing a numeric button on the remote control.

7(Skip/Search backward),

(Skip/Search forward)

: Skips to the next track.

: Skips back to the beginning of the current track.

(twice): Skips to the previous track.

Press and hold or to search backward/

forward.

Each time you press and hold or , the search

speed increases by 4 levels.

8(Play)

Starts playback.

9(Pause)

Pauses playback. Press or to resume playback.

0(Stop)

Stops playback.

APlayback status indicator

Lights up when this unit is in the play or pause mode.

BDisc type indicator

Indicates the type of disc set in the disc tray.

CTime display mode indicator

See “DISPLAY” (page 11) for details.

DPlayback mode indicator

See “REPEAT” (page 10), “RANDOM” (page 11), and

“PROGRAM” (page 11) for details.

EMulti-information display

ALLOFFRANDOM

REMAINTOTALTRACK

SREPPROGWMAMP3SA-CD

9876

AB C D E

See pages 20 for more information on MP3/WMA

playback.

English

8En

Controls and functions

■Rear panel

1ANALOG OUT jacks

2OPTICAL DIGITAL OUT jack

3COAXIAL DIGITAL OUT jack

The audio signals are only output from the ANALOG OUT jacks

while the Super Audio CD layer is selected or when the PURE

DIRECT mode is on.

COAXIALOPTICAL

OUTPUT

ANALOG OUT

DIGITAL OUT

See page 14 for connection information.

Note

9En

4VOLTAGE SELECTOR

(Asia and General models only)

The VOLTAGE SELECTOR on the rear panel of this unit

must be set for your local main voltage BEFORE plugging

the power cable into the AC wall outlet.

See page 15 for further information.

5Foot

If this unit is unstable, you can adjust the foot height by

rotating it.

6AC IN

Use this inlet to plug in the supplied power cable.

See page 15 for connection information.

AC IN

VOLTAGE

SELECTOR

54 6

(Asia and General models)

English

10 En

Controls and functions

■Remote control 1Infrared signal transmitter

Sends infrared signals to this unit.

2SA-CD/CD

Switches the playback layer of a hybrid SA-CD between

SA-CD and CD (see page 19).

• The SA-CD/CD indicator on the front panel lights up when the

SA-CD layer is selected.

• This setting is retained even if you turn off this unit.

• Audio signals are only output from the ANALOG OUT jacks

while the Super Audio CD layer is playing.

• Audio signals recorded in DSD multi-channel format cannot be

played on this unit.

3DIMMER

Selects brightness level for the front panel display. Each

time you press DIMMER, the brightness level changes in

the following order.

This setting is retained even if you turn off this unit.

4Numeric buttons

Use to select a track directly.

This operation is ineffective for MP3 or WMA discs.

5REPEAT

Repeats playback of a single track or all tracks. Each time

you press REPEAT during playback, the repeat playback

mode changes as follows:

• REP S (single repeat playback): On reaching the end of

the current track, playback repeats from the beginning

of the current track.

• REP ALL (all repeat playback): On reaching the end of

the last track, playback repeats from the beginning of

the first track.

This operation is ineffective for MP3 or WMA discs.

654

321

RANDOMREPEAT PROGRAM

CLEARENTER

DISPLAYDIMMER

OPEN/CLOSEPURE DIRECTSA-CD/CD

Notes

Note

→Brightest →Bright (default)

Darkest ←Dark ←

Otros manuales para CDS1000 - SACD Player

Tabla de contenidos

Idiomas:

Otros manuales de Reproductor de CD de Yamaha

Yamaha

Yamaha DV-C6480 - Progressive-Scan DVD Player Manual de usuario

Yamaha

Yamaha CDX-390 Manual de usuario

Yamaha

Yamaha CD-2 Manual de usuario

Yamaha

Yamaha CDX-97 Manual de usuario

Yamaha

Yamaha CDX-397 Manual de usuario

Yamaha

Yamaha CDX- 590 Manual de usuario

Yamaha

Yamaha C6860 - DV DVD Changer Manual de usuario

Yamaha

Yamaha CDV-1200K Manual de usuario

Yamaha

Yamaha CDV-1200K Manual de usuario

Yamaha

Yamaha CD-S300 Manual de usuario

Yamaha

Yamaha MCS-1330 Manual de usuario

Yamaha

Yamaha CDC-755 Manual de usuario

Yamaha

Yamaha CDC-745 Manual de usuario

Yamaha

Yamaha CD-X1 Manual de usuario

Yamaha

Yamaha CDC-697 Manual de usuario

Yamaha

Yamaha CD-450 Manual de usuario

Yamaha

Yamaha CDX-420 Manual de usuario

Yamaha

Yamaha CD-S303BL Manual de usuario

Yamaha

Yamaha EMX-120CD Manual de usuario

Yamaha

Yamaha DVD-S1700 Manual de usuario

Yamaha

Yamaha CDC-645 Manual de usuario

Yamaha

Yamaha CD-S3000 Manual de usuario

Yamaha

Yamaha CDS1000 - SACD Player Manual de usuario

Yamaha

Yamaha CDC-755 Manual de usuario

Manuales populares de Reproductor de CD de otras marcas

RCA

RCA RP-7923 Manual de usuario

Pioneer

Pioneer DEH-P3550MP XM Manual de usuario

Philips

Philips AZ1207 Manual de usuario

Philips

Philips CD582 Manual de usuario

Philips

Philips AZ 6821 Manual de usuario

Lasonic

Lasonic MSU-2020 Manual de usuario

THOMSON

THOMSON RCD150 Manual de usuario

Denon

Denon DCD-1420 Manual de usuario

Panasonic

Panasonic SJ-MR100 Manual de usuario

Onkyo

Onkyo DX-7210 Manual de usuario

Sony

Sony MZ-R3 Manual de usuario

Denon

Denon DVM-4800 Manual de usuario

JBL

JBL MR-32 Manual de usuario

RCA

RCA RCD152 Manual de usuario

Technics

Technics SL-PS770A Manual de usuario

Clarion

Clarion compact disc Manual de usuario

Sony

Sony MZ-M10 Manual de usuario

Philips

Philips Expanium AZ 1538 Manual de usuario
