Xtreme Power Conversion XC-14A Manual de usuario
Xtreme Cooling
Portable Air Condioners
Models: XC-14A, XC-22A, XC-30A
User’s & Installaon Manual
Xtreme Power Conversion® (XPC) Corporaon
Table of Contents
IMPORTANT SAFETY INSTRUCTIONS..............................................4
INTRODUCTION......................................................................................6
PRODUCT DESCRIPTION......................................................................6
ASSEMBLY.................................................................................................7
INSTALLATION GUIDE..........................................................................9
Component Parts
Power Cord Holder
Rubber Stoppers
Discharge Ducts / Supply Air Duct
Moving the Unit
Plugging in the Unit
OPERATION...........................................................................................11
Control Panel
MAINTENANCE.....................................................................................12
Filter Cleaning
Spring Replacement
TROUBLESHOOTING..........................................................................15
SPECIFICATIONS..................................................................................18
SHIPPING LIST......................................................................................19
OBTAINING SERVICE..........................................................................20
XTREME POWER CONVERSION® (XPC) CORPORATION
LIMITED WARRANTY.........................................................................21
OPTIONS.................................................................................................23
Alarm Codes
Troubleshoong Chart
Ambient Air Adaptor
Cooling Hose Assembly
Temperature Sensor Line
Remote Control
Pump Kit
XC-14A, XC-22A, XC-30A USER’S MANUAL Portable Air Condioners
Xtreme Power Conversion® (XPC) Corporaon
Page 2
Xtreme Power Conversion® (XPC) Corporaon
XC-14A, XC-22A, XC-30A USER’S MANUAL Portable Air Condioners
Page 3
Thank you for selecng this Xtreme Cooling unit. It provides you
with spot cooling for large areas where cooling of an enre area is
not praccal or possible. Please read this manual before installing
the XC-14A, XC-22A, or XC-30A as it provides important informaon
that should be followed during installaon and maintenance of the
Portable Air Condioner, allowing you to correctly set up your
system for the maximum safety and performance. Included is
informaon on customer support and service, if it is required. If you
experience a problem with the unit, please refer to the
Troubleshoong secon in this manual to correct the problem. If the
problem is not corrected, please collect informaon so that the
Technical Support personnel can more effecvely assist you.
IMPORTANT SAFETY INSTRUCTIONS:
(SAVE THESE INSTRUCTIONS)
Please read this manual carefully for instrucons on correct installaon
and usage. Please read all safety instrucons.
1. Transport and store the unit in an upright posion only. Leave the unit
in an upright posion for at least 3 hours before use.
2. Always place the unit on an even, level surface.
3. Ensure the unit is connected to a grounded ulity of the correct
rang / capacity.
4. The unit will cool when the room temperature is between 64.4°F - 113°
F (18°C - 45°C) depending on the thermostat seng.
5. DO NOT use this unit for funcons other than those described in this
User’s Manual.
6. DO NOT lt the unit.
7. DO NOT cover or obstruct the unit’s inlet and/or outlet grilles.
8. DO NOT use the unit in areas where it will be exposed to rain or water.
9. NEVER unplug the unit while it is operang
10. DO NOT place any foreign objects on the unit.
11. DO NOT operate the unit with wet or damp hands.
12. DO NOT allow chemical substances to come in contact with the unit.
13. DO NOT operate the unit in the presence of flammable substances or
vapors such as alcohols, pescides, gasoline, etc.
14. DO NOT use the plug to start or to stop the unit. Always use the
control panel to start and to stop the unit.
15. Always turn off the unit when it is not in use, and unplug the power
DO NOT use the unit in wet environments, such as a
laundry room, to avoid risk of electrical shock
XC-14A, XC-22A, XC-30A USER’S MANUAL Portable Air Condioners
Xtreme Power Conversion® (XPC) Corporaon
Page 4
WARNING
DO NOT operate the unit in explosive or flammable
environments
WARNING
Xtreme Power Conversion® (XPC) Corporaon
XC-14A, XC-22A, XC-30A USER’S MANUAL Portable Air Condioners
Page 5
plug from the electrical outlet.
16. Always turn the unit off and unplug the main power plug from the
electrical outlet before cleaning, moving, or performing maintenance.
17. AVOID the use of adapter plugs or extension cords. If it is necessary to
use an extension cord or an adapter plug to operate the unit, ensure
that they are correctly rated for the applicaon. Consult local qualified
electrician and all local electrical codes to ensure proper setup. Any
extension cord used with the device must be rated for a minimum of
15A.
18. DO NOT unplug the unit by pulling on the electrical cord. Keep the
electrical cord away from heat sources and always completely unroll
the cord to avoid overheang. If the power cord becomes damaged, a
qualified service agent, qualified electrician, or similarly qualified
person must replace it, in order to avoid a hazard or shock.
19. The filters must be used with the product at all mes. When the filters
are removed for cleaning, always ensure that the unit has been turned
off and unplugged from the electrical outlet.
20. Regularly clean the filters to maintain efficiency. If the filters are not
cleaned regularly, the units output performance and efficiency will
decline and energy consumpon will increase.
21. DO NOT operate the unit with a damaged power cord or plug, aer it
malfuncons, or if the unit has been dropped or damaged.
22. Only use the unit in the upright posion on a even, flat surface. Unit
must be posioned at least 24 inches (60 cm) from the nearest object
in any direcon.
23. Stop operaon immediately if abnormal noise or odor is noced.
Contact local service center.
DO NOT operate a unit with a damaged power cord
WARNING
INTRODUCTION
The informaon provided in this manual covers 13,200 – 29,000
BTU/HR Xtreme Cooling units, their basic funcons, operang
procedures, opons available and emergency situaons. It also
includes informaon on how to ship, store, handle, and install the
equipment. Only detailed requirements of the Cooling units are
described herein, and installaon must be carried out in accordance
with this manual. Electrical installaon must also carefully follow
local legislaon and regulaons. Only qualified personnel should
conduct these installaons as failure to acknowledge electrical
hazards could prove to be fatal.
XC-14A, XC-22A, XC-30A USER’S MANUAL Portable Air Condioners
Xtreme Power Conversion® (XPC) Corporaon
Page 6
PRODUCT DESCRIPTION
Xtreme Cooling Portable Air Condioners feature spot cooling for
large areas where cooling of the enre area is not praccal or
possible. A dedicated spot cooling thermostat controls the unit in
this applicaon. These air condioners can also be used in smaller
areas for room cooling.
A control panel provides ease of use and contains self-diagnosc
funcons and displays, showing operang modes, room and set
temperatures, and faults. If an abnormal operaon occurs, a visual
display of the fault is shown.
Caster wheels are included for ease of portability.
Suitable applicaons include: factory or work place, industrial
kitchen, computer room, emergency cooling, outdoor event, etc.
Xtreme Power Conversion® (XPC) Corporaon
XC-14A, XC-22A, XC-30A USER’S MANUAL Portable Air Condioners
Page 7
ASSEMBLY
Component Parts
Cool air outlet hose
Figure 1 – Front and Right Side View
Figure 2 – Rear and Le Side View
Display / Control board
Top fan wire grille
Evaporator / filter
Guide bar for condensate water tank
Condensate water tank
(Water level is sensed, and the unit operaon is stopped
when tank is full. An alarm will be displayed. Empty
the tank and replace to resume operaon)
Side handles
Rubber stoppers
Condenser / filter
Power cord holder
Casters
Electrical access panel
XC-14A, XC-22A, XC-30A USER’S MANUAL Portable Air Condioners
Xtreme Power Conversion® (XPC) Corporaon
Page 8
1. Remove the Power Cord Holder
from the accessory box
2. Place the Power Cord Holder on
the rear of the unit as
shown in Figure 3
3. Use screws to install the Power
Cord Holder to the rear of the unit
(screws inside the accessory box)
1. Remove the Rubber Stoppers
from the accessory box
2. Place the Rubber Stoppers on
the rear of the unit as shown in
Figure 4
3. Use screws to install the
Rubber Stoppers to the rear of
the unit (screws inside the
accessory box)
Power Cord Holder
Rubber Stoppers
Figure 3 – Power Cord Holder aachment
Figure 4 – Rubber Stopper aachment
Xtreme Power Conversion® (XPC) Corporaon
XC-14A, XC-22A, XC-30A USER’S MANUAL Portable Air Condioners
Page 9
Figure 5 – Cool Air Outlet
aachment
Discharge Ducts / Supply Air
Duct
1. Remove the Cool Air Outlet Hose(s)
from the box
2. Place the Cool Air Outlet Hose(s) on
the front top of the unit as shown in
Figure 5
3. Use screws to install the Cool Air Outlet
Hose(s) to the front of the unit
(screws inside the accessory box)
WARNINGS REGARDING PROPER LOCATION FOR INSTALLATION
INSTALLATION GUIDE
DO NOT use the unit in explosive environments or in
areas where flammable gas leakage may occur
WARNING
DO NOT use the unit in areas where it will be
exposed to rain or water
WARNING
DO NOT install the unit on uneven or sloping surface.
The unit may roll or topple over even if casters are
set in the locked posion
WARNING
DO NOT use the unit in a corrosive atmosphere
WARNING
DO NOT use the unit above 113 F (45 C)
o o
WARNING
XC-14A, XC-22A, XC-30A USER’S MANUAL Portable Air Condioners
Xtreme Power Conversion® (XPC) Corporaon
Page 10
Unlock the casters and push the unit using the side handles to a flat,
level surface and set the cater brakes to the locked posion.
Moving the Unit
Check the prongs and surface of the power cord plug for dust/dirt. If
dust and/or dirt are present, wipe off with a clean, dry cloth.
Check the power cord, plug, and prongs for damage or excess play.
If any damage or excess play is found, contact a qualified repair
technician or a qualified electrician to perform replacement of repair
of the power cord, plug, or prongs.
NOTE: Make sure the AC outlet is free of dirt, dust, oil, water, or any
other foreign material.
The unit is equipped with an approved NEMA plug configuraon (XC-
14A = 5-15P; XC-22A = 6-15P; XC-30A = 6-20P). The appropriate
outlet must be used for each plug type.
Plugging in the Unit
If the power cord or plug are damaged, repair should
only be performed by qualified electrician.
WARNING
DO NOT connect / disconnect the power cord or
aempt to operate buons with wet hands. This
could result in electrical shock.
WARNING
