Xtreamer Prodigy Manual de usuario

User Manual

Xtreamer Prodigy Ver.3.0.1.

English

Introduction

Congratulations on your purchase of the Xtreamer Prodigy media player, a state-of-the-art

consumer electronic device that will enrich your home multimedia experience.

Xtreamer Prodigy is a new generation Realtek based media player equipped with

enhanced top quality hardware commonly used in high-end computing and consumer

electronic solution. It has an additional memory, USB 3.0 slave connection for high-speed

data transfer, GB LAN and can be equipped with one 3.5” HDD.

With Xtreamer Prodigy media player you can bring your movies, music and images to your

living room, get rid of that bulky DVD collection, access hundreds of internet feeds and

channels, check your favorite online services and social nets, browse the web, use Android

applications and so on.

This is the first media player that incorporates the full 3D support. Enjoy a full movie

theater experience at home.

In Xtreamer Prodigy we also introduce Android 2.2.1 support opening you to the wide

world of thousands of Android applications.

Due to the rapid development of our product we cannot possibly guarantee that this

Guide will include all its features. So if you have questions please feel free to browse the

Xtreamer Knowledge base or contact our staff.

Please make sure to visit our site www.xtreamer.net for the Xtreamer news, official

announcements and firmware upgrade.

English

Hard-Disk Installation

Open the hard disk cover on the

front panel

Connect the HDD guard to an HDD as shown

on the picture. Fasten the screws.

As shown here, slowly and carefully push the HDD

guard together with the HDD into the main body of

Xtreamer Prodigy.

01.

02.

03.

English

Video & Audio Output Connections

ㆍHDMI cable connection

Connections

ㆍComposite cable connection

Connect HDMI cable to HDMI terminal at the back of product. Connect the remaining cable

terminal to HDMI terminal at the back of a digital TV. Make sure to carefully distinguish

between input and output terminals.

Connect yellow cable for video signal to the terminal located at the back of side of TV. Then,

select external input of TV. Connect the remaining red and white terminal cables to the left/ right

and audio output terminal at the back of the device. Then, connect red and white cables to the

left/ right terminal of DTV input or component audio input located at the back of a digital TV.

English

Connection

ㆍComponent cable connection

Connect the green, blue and red terminal cables to the Xtreamer Prodigy and TV in accordance with

the color scheme; connect white AV cable to L terminal, and red AV cable to R terminal.

(Component cable is an optional item)

English

ㆍOptical cable connection

Connection

You can enjoy high-quality 5.1CH sound when connected to an amplifier or a receiver with

optical cable. Connect optical cable to Optical port on Xtreamer Prodigy as shown above. Then,

connect to an amplifier or a receiver. ( Optical cable is optional )

ㆍCoaxial cable connection

You can enjoy high-quality 5.1CH sound when connected to an amplifier or a receiver with

coaxial output cable. Connect coaxial cable to coaxial port on Xtreamer Prodigy as shown above. Then,

connect to an amplifier or a receiver. ( Coaxial cable is optional )

English

Connect to the Network

ㆍWired and Wireless Network

Connection

Wireless IP Sharing Router

To set up your network connection please check the Settings guide below.

To setup shared folders on your local network, please refer to this online guide.

English

Remote Control Functions

English

General Remote Control Functions

1 POWER Power on / off

Page mode in browser, special functions

Bookmarks,playlist, special functions

5 Address bar input, special functions

Special functions, playlistoperations

9 ADD Add

10 EJECT Eject for DVD

11 DELETE Delete

12 ZOOM

To enlarge and reduce screen/ repeatedly pressing for adjusting

zoomingpercentage/movingto positionof enlarged output by using

directionkeys./ Setup the X,Y positionon screen

13 GOTO To select file in the same title or to execute shortcut to the already

designated chapter position/shortcutto the desired timeposition

14 MENU Opens a list of availablefunctions in Media Libraryand during

playback,allowsaccess to DVD menu.

15 SETUP Function available when playing media file or using menu’s in

VIDEOIN screen to displayvarious setup screens

16 FUNC Opens a list of availablefile functionsin Media Library

17 TVOUT Toggle Video Output Modes and resolution(HDMI, AV) - double

press

18 REFRESH Refreshes the lists

19 PREVIEW To turn on/ off preview screen automaticallydisplayed in mediaplay

filesearch mode

20 BOOKMARK Supportsadding a file to bookmarkand to show bookmarklists

21 INFO To display the current status function availablewhile playback /

Open informationof the movie playing
