XONTEL S20P Manual de usuario
S20P IP HD Camera User Manual
Thank you for purchasing our product. If there is any question or request, please do not hesitate
to contact XonTel.
This Manual explains how to use and manage XonTel S20P IP Camera on your network. Previous
experience of networking will be of use when using the products. Please read this manual carefully
before operation and retain it for future reference.
Copyright Statement
This manual may not be reproduced in any form or by any means to create any derivative such as
translation, transformation, or adaptation without the prior written permission of XonTel.
XonTel reserves the right to change this manual and the specifications without prior notice. The
latest specifications and user documentation for all XonTel products are available on our official
website www.xontel.com
Safety Instruction
These instructions are intended to ensure that user can use the product correctly to avoid danger
or property loss. The precaution measures are divided into “Warnings” and “Cautions”
Warnings: Serious injury or death may be caused if any of these warnings is neglected.
Cautions: Injury or equipment damage may be caused if any of these cautions are neglected.
Warnings: Please follow these safeguards to
prevent injury or death.
Cautions: Please follow these safeguards to
prevent potential injury or material damage.
Warnings
This installation must be conducted by a qualified service person and should strictly
comply with the electrical safety regulations of the local region
To avoid risk of fire and electric shock, do keep the product away from rain and moisture
before installed.
Do not touch components such as heat sinks, power regulators, and processors, which
may be hot
Source with DC 12V or POE
Please make sure the plug is firmly inserted into the power socket
When the product is installed on a wall or ceiling, the device should be firmlyfixed
If the product does not work properly, please contact your dealer. Never attempt to
disassemble the camera by yourself
Cautions
Make sure that the power supply voltage is correct before using the camera
Do not store or install the device in extremely hot or cold temperatures, dusty or damp
locations, and do not expose it to high electromagnetic radiation
Only use components and parts recommended by manufacturer
Do not drop the camera or subject it to physical shock
To prevent heat accumulation, do not block air circulation around the camera
Laser beams may damage image sensors. The surface of image sensors should not be
exposed to where a laser beam equipment is used
Use a blower to remove dust from the lens cover
Use a soft, dry cloth to clean the surface of the camera. Stubborn stains can be removed
using a soft cloth dampened with a small quantity of detergent solution, then wipe dry
Do not use volatile solvents such as alcohol, benzene or thinners as they may damage the
surface finishes
Save the package to ensure availability of shipping containers for future transportation
EU Conformity Statement
2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated collection points. For more information see:
www.recyclethis.info.
2006/66/EC (battery directive): This product contains a battery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentation for specific battery information. The battery is marked with this
symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or
Mercury (Hg). For proper recycling, return the battery to your supplier or to a designated
collection point. For more information see: www.recyclethis.info.
Table of Contents
Chapter I Product Description.............................................................................................................. 6
1.1 Product Overview.................................................................................................................... 6
1.2 Key Features............................................................................................................................ 6
1.3 Hardware Overview ................................................................................................................ 7
1.4 System Requirements.............................................................................................................. 8
Chapter II Network Connection ........................................................................................................... 9
2.1 Setting the Camera over the LAN............................................................................................ 9
2.1.1 Connect the Camera to the PC Directly ........................................................................ 9
2.1.2 Connect via a Switch or a Router.................................................................................. 9
2.2 Dynamic IP Connection ........................................................................................................... 9
Chapter III Accessing the Network Camera........................................................................................ 10
3.1 Assigning An IP Address ........................................................................................................ 10
3.1.1 Assign An IP Address via Browser ............................................................................... 11
3.2 Accessing from the Web Browser ......................................................................................... 13
Chapter IV System Operation Guide.................................................................................................. 16
4.1 Live Video.............................................................................................................................. 16
4.2 Playback ................................................................................................................................ 18
4.3 Basic Settings......................................................................................................................... 20
4.3.1 Video ........................................................................................................................... 20
4.3.2 Image........................................................................................................................... 21
4.3.3 Audio ........................................................................................................................... 25
4.3.4 Network....................................................................................................................... 26
4.3.5 Date&Time .................................................................................................................. 30
4.4 Advanced Settings................................................................................................................. 31
4.4.1 Alarm........................................................................................................................... 31
4.4.2 Storage ........................................................................................................................ 36
4.4.3 Security........................................................................................................................ 40
4.4.4 SIP................................................................................................................................ 42
4.4.5 Logs ............................................................................................................................. 45
4.5 System ........................................................................................................................................ 46
4.6 Maintenance ......................................................................................................................... 47
Chapter V Services.............................................................................................................................. 48
Chapter I Product Description
1.1
Product Overview
XonTel provides a consistent range of cost-effective and reliable network cameras to fully meet
your requirements. Based on embedded Linux operating system, XonTel network cameras could
be easily accessed and managed either locally or remotely with great reliability. With built-in
high-performance DSP video processing modules, the cameras pride on low power consumption
and high stability. They support H.264/MJPEG video compression algorithm and industry-leading
HD dual-stream technology to achieve the highest level of video image quality under the limited
network resources. It is fully functional, supporting for flexible and comprehensive alarm linkage
mechanism, day and night auto switch, smart PTZ control and privacy masking, etc.
In practical applications, XonTel network cameras could either work independently in the LAN, or
be networked to form a powerful safety monitoring system. It is widely used in fields such as
finance, education, industrial production, civil defense, health care for security’s sake.
1.2
Key Features
Based on Linux OS with high reliability
H.264/MJPEG video compression capability
Support POE
Support Video Content Analysis
ICR filter with auto switch, true day/night
Built-in WEB server, support IE/ Firefox/ Chrome/ Safari browser
UPnP protocol for the easy management of IPC
Support DDNS
Motion Detection, Privacy Masking and Network Fault Detection
FTP upload, SMTP upload, SD card record and SIP phone
G.711/AAC audio compression capability
Alarm I/O(built-in for pro bullet and box cameras, optional for dome cameras)
Real-time video electronic amplification
Three-privilege levels of users for flexible management
Micro SD card local storage support, expand the edge storage
1.3
Hardware Overview
Lens Ethernet Port (PoE)
Error LED Indicator
Power LED Indicator
Micro SD/SDHC/SDXC Card Slot
Figure 1-3-1 S20P Network Camera
Note:
1) Error LED Indicator: Error LED Indicator is on when the device starts up or runserror.
2) Reset Button: Press “Reset” button for 5 seconds, then the device will be restored to factory
default.
3) Only PoE is available for power supply.
Press Button
Reset
1.4
System Requirements
Operating System: Windows XP/Vista/7/8/10/Server 2000/Server 2008
CPU: 1.66GHz or higher
RAM: 1G or higher
Graphic memory: 128MB or more
Internet protocol: TCP/IP (IPv4/IPv6)
Web Browsers: Internet Explorer 8.0 and above version, Mozilla Firefox, Google Chrome and Safari.
Chapter II Network Connection
2.1
Setting the Camera over the LAN
Connecting the camera to a switch or a router is the most common connection method. The
camera must be assigned an IP address that is compatible with its LAN.
2.1.1 Connect the Camera to the PC Directly
In this method, only the computer connected to the camera will be able to view the camera. The
camera must be assigned a compatible IP address to the computer.
2.1.2 Connect via a Switch or a Router
In this method, the IP network camera will connect the network over the LAN via the switch or router.
2.2
Dynamic IP Connection
Connecting the network camera via a router
Step1: Connect the network camera to a router;
Step2: On the camera, assign a LAN IP address, the Subnet mask and the Gateway;
Step3: On the router, set port forwarding. E.g. 80, 8000 and 554 ports. The steps for port
forwarding vary depending on different routers. Please look up the router's user manual for
assistance with port forwarding;
Step4: Apply a domain name from a domain name provider;
Step5: Configure the DDNS settings in the setting interface of the router;
Step6: Visit the camera via the domain name.
Chapter III Accessing the Network Camera
The camera must be assigned an IP address to be accessible.
3.1
Assigning an IP Address
The Network Camera must be assigned an IP address to be accessible. The default IP address of
S20P Network Camera is 192.168.5.190. The default user name is “admin”, and password is
“xontel”.
You can change the IP address of the camera via browser. Please connect the camera in the same
LAN of your computer.
