Mi Smart Projector 2 User Manual
1
Table of Contents
User Notice.......................................................................................................................................................................................................................................... 2
Safety Instructions............................................................................................................................................................................................................................ 2
Exterior.................................................................................................................................................................................................................................................. 4
Connection Ports............................................................................................................................................................................................................................... 5
Remote Control.................................................................................................................................................................................................................................. 6
Auto Focus........................................................................................................................................................................................................................................... 7
Keystone Correction......................................................................................................................................................................................................................... 7
Frequently Used Menu..................................................................................................................................................................................................................... 8
Specifications ..................................................................................................................................................................................................................................... 9
Troubleshooting................................................................................................................................................................................................................................. 10
Regulatory Compliance................................................................................................................................................................................................................... 11
Product Certifications ..................................................................................................................................................................................................................... 12
2
User Notice
Thank you for choosing the Mi Smart Projector 2.
Read this manual carefully before use, and retain it for future reference.
Illustrations of product, accessories, and user interface in the user manual are for reference purposes only. Actual product and
functions may vary due to product enhancements.
Safety Instructions
Before using the product, make sure to carefully read the following safety instructions.
This warning symbol informs the user that this product contains non-insulated voltage sources that can cause an electric
shock. Coming into contact with any internal component may result in an electric shock.
This symbol informs the user about important handling and maintenance related information. Please read this information
carefully to ensure proper use.
This symbol informs the user to be aware of high temperatures.
This symbol informs the user to avoid touching this part.
Transportation Instructions: It is recommended to transport this projector in its original or similar packaging.
3
Preventing Electric Shocks and Fire Hazards:
Safety Precautions:
- Only use the provided genuine power adapter.
- Unplug the projector from the electrical outlet during thunderstorms or when it is not being used for a long time, so as to avoid
damage caused by a power surge or lightning strike.
- Do not place any flammable objects near this projector so as to avoid fire.
- Do not block any of the vents as this may cause heat build-up inside the projector, and possibly result in a fire.
- Do not block the lens when the projector is turned on. Any object placed close to the lens may get very hot and/or deformed, and may
even cause a fire.
-
Do not place this projector on an unstable platform, stand or table so as to prevent it from falling and causing serious damage or personal injury.
- Do not look directly into the lens when the projector is turned on to avoid eye damage.
- Do not attempt to disassemble this projector as it may contain dangerous high voltage components. This projector must only be
maintained and repaired by a qualified or authorized technician.
- Do not expose this projector to rain or moisture (operating humidity is 20%–80%).
- Do not immerse this projector in, nor expose it to water or other liquids. Immediately unplug the projector if any liquid or object got
into its housing, and have it checked by a qualified technician before using it again.
- Do not place this projector in any of the following environments:
• In poorly ventilated or narrow spaces.
• Near devices that produce a strong magnetic field.
• In direct sunlight.
• In extremely hot, cold or humid environments.
• Close to a fire alarm.
4
Projection Lens
On/Off Button
（Press to turn on）Rubber Feet Air Inlet
Caution
Heat Dissipation Vent
1/4'' Female Threaded
Tripod MountConnection Ports
Camera
-
The air vents allow the air to exchange internally and
externally.
Do not place any objects within 20 cm of the
air vents.
-
Do not look directly into the lens to avoid eye damage
as the projector will emit strong light during working.
-
If you plan to mount the projector on a suspended
ceiling, make sure to select the right screws and bracket
for it.
Exterior
5
Connection Ports
- DC in port.- Headphone port. - HDMI input port.- Supports USB 2.0.
12 3 4
1DC IN 3USB2.0 4HDMI
2
6
- Pay attention to the positive and negative poles when installing batteries in the remote control.
- Dispose of, or recycle the battery in accordance with local laws and regulations of the country or region it is used in.
- It is recommended that the distance between the remote control and the projector is no more than 5 meters.
-
The illustration of the remote control is for reference purposes only. Actual products and functions may vary due to the regions they are used in.
Note:
Power Button:
When the projector is off, press to turn on.
When the projector is on, press to open the menu. Then select the right option to turn the projector off.
Remote Control
Google Assistant: Press the Assistant button on your remote to talk to Google Assistant.
Navigation Pad: Move to up, down, left, or right, then press the middle to confirm.
APP: Access the app interface.
Home: Return to the home screen.
Return: Return to the previous menu.
LIVE: Access the Live Channel.
Volume Button: + Increase the volume; - Decrease the volume.
Pairing the Remote Control:
Hold the remote control close to the projector within a distance of 20 cm,
then simultaneously press the app button and the home button to pair.
NETFLIX: Access the Netflix App.
7
Auto Focus Keystone Correction
Go to Settings > Projector > Focus and select Execute Focus, the
screen will focus and once it is finished you can press the left or
right button on the remote control for further fine-tuning.
Go to Settings > Projector > Keystone Correction > Keystone
Correction, and use the up and down buttons to select Quick
Adjustment, Fine Tuning, and Reset, then press the OK button
to enter the correction mode.
If the projector is moved, it will start automatic keystone
correction and the projected image will be adjusted automatically.
Note: Go to Settings > Projector > Keystone Correction, to
configure Auto Keystone. Auto Keystone is enabled by default.
Go to Settings > Projector > Focus and select the Auto
Focus switch, when it is enabled, moving the projector will
automatically trigger the screen to focus.
Quick Adjustment
Fine Tuning
Reset
8
Frequently Used Menu
Open the app, then select Launch Board. The frequently used functions are displayed on this page.
Select the User Manual to see the detailed instructions for the users.
The menu page will be updated from time to time, and the current app version shall prevail.
Common Functions
System Apps
File ManagerExecute Focus
Seings User Manual
Inputs
Keystone Correction Bluetooth Speaker
Note:
9
Specifications
Basic Information
Name Mi Smart Projector 2
Model XMTYY02FMGL
Item Dimensions 115x150x150 mm
Net Weight 1.3 kg
Electrical Specifications Power Consumption Rated Power < 65 W; Standby Power < 0.5 W
Rated Input External Adapter,
Optical Parameters Display Technology LED Light Source with DLP technology
Standard Resolution 1920×1080P
Projection Parameters
Projection ratio (TR) 1.2 : 1
Screen Size 60" to 120"
Lens Focus Auto Focus
Keystone Correction Omni-directional auto-keystone correction
System
Built-in Storage 2 GB DDR3 / 16 GB eMMC
Operating System Android TV
Bluetooth Bluetooth 5.0/BLE
Wireless Connectivity Wi-Fi IEEE 802.11 a/b/g/n/ac 2.4GHz/5GHz
Audio Audio Effects Dolby Audio + DTS-HD
Speaker 2 x 5 W Full-range
Others
Noise Level ≤ 28 dB(A) viewing mode @ ambient temperature of 25 °C
Storage Temperature/Humidity -20 ℃to 55 ℃/ ≤ 90%
Operating Temperature/Humidity 0 ℃to 40 ℃/ 20%–80%
