Xerox Phaser 4500 Manual de usuario
laser printer
Phaser™4500
Reference
Quick
Guide
Copyright © 2004 Xerox Corporation. All rights reserved. 001-1551-00 Rev A
RU
CZ
PO
HU
EL
Tray 1-4
A6 105 x 148 mm
A5 148 x 210 mm
A4 210 x 297 mm
ISO B5 176 x 250 mm
B5 JIS 182 x 257 mm
Index Card 3x5in. Tray 1 2
-
4
Statement 5.5 x 8.5 in.
Executive 7.25 x 10.5 in.
Letter 8.5 x 11.0 in.
US Folio 8.5 x 13.0 in.
Legal 8.5 x 14.0 in.
DL 110 x 220 mm
C5 162 x 229 mm
B5 176 x 250 mm
#10 Commercial 4.12 x 9.5 in.
Monarch 3.87 x 7.5 in.
Custom (W) x (H)
60 – 216 g/m2
(16 lb. Bond – 80 lb. Cover)
1
2
3
4
H+
H
W
H+
H>297 mm / 11.7 in.
2-4
≤550
1
≤150
Supported Papers
Print the "Paper Tips Page"
for a complete listing.
Go to Reference/Printing/
Supported Papers.
(RU)
(CZ)
(PO)
(HU)
(EL)
3
4
1
2
12
4
3
H>297 mm / 11.7 in.
5
1.1
1.2
5
H+
Custom
US Folio
Legal
Basic Printing
Confirm Tray nPaper
OK: Letter (8.5 x 11 in.) Plain Paper
Change Paper Size...
Change Paper Type...
5OK: Letter (8.5 x 11.0 in.) Plain
Paper
Change Paper Size...
Change Paper Type...
Exit
OK: Letter (8.5 x 11.0 in.) Plain
Paper
Change Paper Size...
Change Paper Type...
Exit
Confirm Tray NPaper
6
Auto-Sensed sizesAuto-Sensed sizes
A5 148 x 210 mm
A4 210 x 297 mm
B5 JIS 182 x 257 mm
Executive 7.25 x 10.5 in.
Letter 8.5 x 11.0 in.
US Folio 8.5 x 13.0 in.
Legal 8.5 x 14.0 in.
User-Selected sizesUser-Selected sizes
Mac
PC
Change Paper Size
Auto-Sensed
A6 (105 x 148 mm)
ISO B5 (176 x 250 mm)
DL Envelope (110 x 220 mm)
C5 Envelope (162 x 229 mm)
B5 Envelope (176 x 250 mm)
Custom
Index Card (3.0 x 5.0 in.)
Statement (5.5 x 8.5 in.)
#10Commercial Envelope (4.12 x 9.5 in.)
Monarch Envelope (3.87 x 7.5 in.)
Confirm or change settings.Confirm or change settings.
Select properties. Use the Xerox printer driver.Select properties. Use the Xerox printer driver.
76 – 216 mm
3.0 – 8.5 in.
127 – 356 mm
5.0 – 14.0 in.
90 – 216 mm
3.5 – 8.5 in.
140 – 356 mm
5.5 – 14.0 in.
W
H
W
H
Custom
Envelope
H
W
Letterhead
H
W
Labels
Tray 2-4
Tray 1
98 – 216 mm
3.9 – 8.5 in.
98 – 216 mm
3.9 – 8.5 in.
148 – 356 mm
5.8 – 14.0 in.
148 – 356 mm
5.8 – 14.0 in.
2-4
≤49 mm
≤1.92 in.
1
≤17 mm
≤0.66 in.
Troubleshoot Ja
m
Information
Walk-Up Feature
s
Printer Setup
Troubleshoot Ja
m
Information
Walk-Up Feature
s
Printer Setup
JAM AT TRAY; OPEN
CLEAR PAPER
PRESS
JAM AT TRAY; OPEN
CLEAR PAPER
PRESS
Jam at Tray 1
Jam at Tray 1
Press i-Button
for jam clearing procedures.
View PrintingScout message (PC only)
or go to Reference/
Troubleshooting/Paper Jams.
Press i-Button
for jam clearing procedures.
View PrintingScout message (PC only)
or go to Reference/
Troubleshooting/Paper Jams.
Paper Jams
(RU)
(CZ)
(PO)
(HU)
(EL)
Information
Walk-Up Features
Printer Setup
Troubleshooting
Information
Walk-Up Features
Printer Setup
Troubleshooting
READY TO PRINT.READY TO PRINT.
www.xerox.com/office/4500supplies
READY TO PRINT
Information
Walk-Up Features
Printer Setup
Troubleshooting
Information
Menu Map
Printer Identification
Information Pages
Sample Pages
Supplies Info
For Supplies Information:
See the Supplies Info menu
and print the "Supplies Usage Page".
Contact your local reseller or visit
the Xerox Phaser Supplies web site.
For Supplies Information:
See the Supplies Info menu
and print the "Supplies Usage Page".
Contact your local reseller or visit
the Xerox Phaser Supplies web site.
Supplies Info
(RU)
(CZ)
(PO)
(HU)
(EL)
www.xerox.com/office/4500support
Information Button–
Press at any time to display
additional information about
the message or menu.
Information Button–
Press at any time to display
additional information about
the message or menu.
InformationInformation
Front Panel Buttons
Information Button -
Press at any time to display
additional information about
the message or menu.
Information Button -
Press at any time to display
additional information about
the message or menu.
Up ArrowUp Arrow
OKOK
Down ArrowDown Arrow
CancelCancel
BackBack InformationInformation
(RU)
(CZ)
(PO)
(HU)
(EL)
Information
Walk-Up Features
Printer Setup
Troubleshooting
Information
Walk-Up Features
Printer Setup
Troubleshooting
READY TO PRINT.READY TO PRINT.
1
READY TO PRINT
Information
Walk-Up Features
Printer Setup
Troubleshooting
Shutdown
Information
Menu Map
Printer Identification
Information Pages
Sample Pages
Supplies Info
Information
Menu Map
Printer Identification
Information Pages
Sample Pages
Supplies Info
2
Information Pages
= Prints an information page.= Prints an information page.= Prints an information page.= Prints an information page.
www.xerox.com/office/4500support
Visit the Support web site
for software and drivers,
troubleshooting, and documentation.
See the User Documentation CD-ROM
for manuals, videos,
and networking information.
Note: Some resources may not
be available in your language.
Visit the Support web site
for software and drivers,
troubleshooting, and documentation.
See the User Documentation CD-ROM
for manuals, videos,
and networking information.
Note: Some resources may not
be available in your language.
Information
(RU)
(CZ)
(PO)
(HU)
(EL)
