Xerox B210 Manual de usuario

An interactive

guide to setting up

your Xerox B210

Printer for printing.

Get Started

Last updated March 28, 2022

Back to Previous Page

This package will step you through the setup process

of installing the software and drivers you need to print

and scan, and connect the printer to the network.

You will be asked questions along the way to identify

the appropriate process steps to follow.

After performing the step or to answer the question,

click on the red arrows to proceed onto the next

step. To go back, click on the gray arrow on the

top right of the page.

Follow the hyperlinks to read instructional articles,

watch videos, or obtain file downloads from

support.xerox.com

Before you start!

Back to Start

Back to Previous Page

Terminology You Need to Know

Network: A system of linked devices that share resources, such as Internet access and printers, connected through a

common wireless (Wi-Fi) or wired (supported by Ethernet cords) network router.

Wi-Fi Direct: This is a feature on your printer/MFP that when enabled, emits a wireless signal that Wi-Fi capable

devices (e.g. phones, computers) can directly connect to for printing. You can connect your device to the printer’s

wireless signal just like you would connect to an Internet router’s Wi-Fi signal.

Computer’s Operating System (OS): This is the software version that your computer is running. Your operating

system determines which print drivers and Xerox applications you will use for printing and scanning.

Utility, or Utility Pack: This is a set of files, software and tools that must be downloaded to your computer to setup

your printer. After being downloaded, the files may need to be installed manually on your PC, or will be automatically

installed with the help of an imbedded “wizard” or executable file. The package contents vary based on your PC’s OS,

but they generally contain drivers for printing, scanning and faxing as well as Wi-Fi setup assistant. They may contain

applications that allow you to fax, scan, or access your printer’s advanced settings from your desktop.

CentreWare Internet Services (CWIS): This is your printer’s web interface where you can manage advanced settings.

You access it by entering your printer’s IP address in your web browser. Your printer must be on the network or have

Wi-Fi direct enabled in order to access CWIS. Next

Back to Start

Back to Previous Page

Perform the following steps:

1) Unpack the box and locate the installation

poster and USB cord

2) Remove all the internal packaging and tape

3) Plug the printer into an outlet and power on

4) Load the paper

➢Click here to view a video about unboxing

your printer.

Unpacking and Powering On

Back to Start

Back to Previous Page

Select the type of device you are setting up

to print from.

If you will be printing from multiple devices, setup to

print from your computer first.

Choose Your Device

Windows Computer

Macintosh Computer

Android or iOS Mobile device

Other

Back to Start

Back to Previous Page

How do you want to connect the printer to the

Windows computer?

Directly with a USB cord

This method directly connects your

printer to your computer using a USB

cord. Your printer must be located

within the cord’s reach of the

computer. The USB cord was shipped

with your printer.

This method is not recommended if

you plan to print from mobile devices.

Through the network with an

Ethernet cord

This method connects your printer to

your network using a cable. Any

computer or device that is also on the

network can print to it. The Ethernet

cord is not provided.

If you do not have a wireless network

router, you can use Wi-Fi direct to

print from devices that are not on the

network. The networked printer can be

configured to emit a signal that

devices can directly connect to.

Through the network via Wi-Fi

This method wirelessly connects your

printer to your home office network.

Any computer or device that is also on

the network can print to it. You must

have a wireless router and a good Wi-

Fi signal.

You can also enable Wi-Fi direct to

print from devices that are not on the

network. The networked printer can be

configured to emit a signal that

devices can directly connect to.

Back to Start

Back to Previous Page

Perform these steps at your PC:

1. Connect the printer and the computer using the provided USB cable

2. Install the software by either installing the CD that was shipped

with your printer or downloading the utility file

Xerox_B210_Windows_PrintDriver_Utilities_Signed.zip from here.

3. Run the executable (.exe) file

The program will connect to the printer, walk you through

adding the printer to the network, install the Easy Printer

Manager software and drivers, and print a test page.

➢To view a video about using the utility, click here.

➢Note: to manually add the printer to the network using WPS, refer

to the KB articles for Wi-Fi and wired setups.

Prepare for Driver Installation and Connection Setup

Back to Start

Back to Previous Page

Enable Wi-Fi Direct from the “Easy Printer

Manager” application on your computer.

Wi-Fi Direct can be used as a backup connection, to

support wireless printing from non-networked

devices, and to access advanced settings in CWIS.

1. Open Easy Printer Manager > Select Advanced Settings >

hover over Device Settings, then select Network Settings.

For Wi-Fi Direct, select On to enable the feature.

2. Make note of the IP Address displayed. It will be used later to

access the printer's web interface (CentreWare Internet Services).

3. For Network Key, enter a password that contains at least 8

characters. This password will be used later to connect to the

printer's Wi-Fi Direct signal.

4. Click Save to save the settings.

Setup Wi-Fi Direct

Back to Start

Back to Previous Page

If you need to enable or disable the banner

page from printing with each print job, this

can be configured in CWIS.

The banner page is a cover page that contains

information identifying the user and job name.

➢Click here to read the knowledge base instructions.

Enable or Disable the Banner Page

Back to Start

Back to Previous Page

You have completed the setup and install

process for this device.

Choose what you would like to do next.

You are all done!

Setup another device

Done

Back to Start
