WorkCentre®M35 Copier-Printer WorkCentre®M45 Copier-Printer WorkCentre®M55 Copier-Printer

35 images per minute (ipm) letter 45 images per minute (ipm) letter 55 images per minute (ipm) letter

(8.5 x 11"/216 x 279 mm/A4) (8.5 x 11"/216 x 279 mm/A4) (8.5 x 11"/216 x 279 mm/A4)

25 ipm legal 36 ipm legal 36 ipm legal

(8.5 x 14"/216 x 356 mm) (8.5 x 14"/216 x 356 mm) (8.5 x 14"/216 x 356 mm)

22 ipm ledger 31 ipm ledger 31 ipm ledger

(11 x 17"/279 x 432 mm/A3) (11 x 17"/279 x 432 mm/A3) (11 x 17"/279 x 432 mm/A3)

4.6 seconds 3.4 seconds 3.4 seconds

WorkCentre®M35/M45/M55

Intel®Celeron®433 MHz

64 MB RAM, expandable to 128 MB

Minimum 9.1 GB

PCL®6 (PCL 5e) emulation

PostScript®3 emulation* (optional)

PostScript emulation: 600 x 600 dpi (optional)*

PCL emulation: 600 x 600 dpi

WorkCentre®M35/M45/M55

*Not available at product introduction.

Detailed Specifications

WorkCentre M35 shown with Duplex

Automatic Document Feeder, High-Capacity

Feeder and Offsetting Catch Tray options.

WorkCentre M45 shown with Duplex

Automatic Document Feeder, High-Capacity

Feeder and Office Finisher options.

WorkCentre M55 shown with Duplex

Automatic Document Feeder, High-Capacity

Feeder and Office Finisher options.

OUTPUT SPEED—printing and copying

FIRST-IMAGE-OUT TIME—letter size, from platen to offsetting catch tray

NETWORK PRINTING—SMart Network Controller

Processor

Memory

System Disk

Printer Languages

(auto switching)

NETWORK PRINTING—resolution, printing via CentreWare®software

EDITOR’S

Better Buys

for Business

CHOICE

2003

WorkCentre®M35/M45

NETWORK PRINTING—printing features

PRINT PROTOCOLS AND NETWORKS

Physical

Operating Systems

Network Protocols

WorkCentre®M35/M45/M55 Copier-Printers

Edge-to-edge printing

Booklet creation

Cover selection

Paper selection by attribute

Multi-up

Stapling (single/dual)

Output tray selection

Watermark

Fit to new paper size

Transparency interleave

Banner sheet enable/disable

Hole punching

Image quality

Ethernet 100BaseT/10BaseT, 10Base2, 10Base5 via adapter

Wireless ethernet (IEEE 802.11b) via third-party adapters

Microsoft®Windows®95, 98, Millennium®(Me), NT®4.0, 2000, XP®

Novell®NetWare®4.x, 5.x, 6

Mac OS®8.x, 9.x, OS X—optional*

Solaris®2.5.1, 2.6 and higher

HP-UX®10.2, 11.x

IBM AIX®4.2 and higher

Linux®Intel®

—Red Hat®

—Caldera®

—MandrakeTM (LPRNG printing infrastructure)

—Corel®(i386)

—TurboLinux®(i386)

—SuSE®(i386)

Linux Power PC®

—TurboLinux Server 6.0.2

TCP/IP: Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, NetBIOS, HTTP

Netware: Bindery and NDS IPX/SPX, NDPS®/NEPS (with Server Gateway)

AppleTalk®: EtherTalk® —optional*

Microsoft Windows Networking over IP and NetBEUI

WorkCentre®M35/M45/M55

*Not available at product introduction.

Continued

WorkCentre®M35/M45/M55

*Enhanced: Xerox custom graphical user interface.

**Standard: Driver based on Microsoft tree-structure user interface (includes Xerox features and functionality).

***Not available at product introduction.

WorkCentre®M35/M45/M55 Copier-Printers

DHCP, BOOTP, SNMP, WINS, DDNS, SLP®v2, HTTP, RARP, DHCP Autonet

PCL: 80 scalable fonts, line printer bitmap format line printer fonts

PostScript 3: 136 PostScript standard fonts (optional)***

Font management utility for downloading additional fonts

Environment PCL5e PCL 6 PostScript (optional)***

Windows 95/98/Me Bidirectional enhanced* Bidirectional enhanced* Bidirectional enhanced*

Windows NT 4.0 Bidirectional with user Bidirectional enhanced Bidirectional with user

selectable interface selectable interface

(standard** and enhanced) (standard** and enhanced)

Windows 2000/XP Bidirectional Bidirectional Bidirectional

(Microsoft Certified) with user-selectable with user-selectable with user-selectable

interface (standard interface (standard interface (standard

and enhanced) and enhanced) and enhanced)

Macintosh®System N/A N/A Generic PPD

8.x, 9.x, OS X***

Macintosh System N/A N/A Bidirectional via AppleTalk

9.x***

Web server embedded on SMart network controller

—Tray status/contents

—Consumables status

Complete job print queue management—hold, release, promote and delete

Print-ready files PCL, PS (optional)***

Output feature selection

Allows simple, remote installation setting of configuration options and management of the device

Windows XP, 2000/NT 4.0/Me/98/95: Netscape Navigator®6.x, Microsoft Internet Explorer 5.x/6.x

Macintosh 9.x/OS X: Netscape Navigator 6.x

Linux: Netscape®6.x

PRINT PROTOCOLS AND NETWORKS

Continued

Administration Protocols

Fonts

Print Drivers

CENTREWARE®INTERNET SERVICES—integrated device Web page

Device Status

Print Queue Viewing

Job Submission

Device Administration

Browsers

WorkCentre®M35/M45/M55

WorkCentre®M35/M45/M55 Copier-Printers

Direct document e-mail from device

Manual address entry via touchscreen keyboard (ad hoc)

600 x 600 dpi

300 x 300 dpi

200 x 200 dpi

11.7 x 17”/297 x 432 mm/A3

SMTP, MIME encoded

TIFF 6.0 with G3 MH or G4 MMR compression (single page or multiple pages)

PDF with G3 MH or G4 MMR compression (image only)

Duplex Automatic Document Feeder (optional) with 75-sheet capacity

1:1, 1:2, 2:2 and 2:1

1 to 9,999

600 x 600 dpi x 8 bit

Concurrent scanning and printing

AutoIQ automatic digital image quality control

Auto rotation 180° or 270° when needed

Image shift

Edge erase

Edge-to-edge copying

Auto centering

Original type selection (normal, text, halftone, photo)

Lighter/darker

Background suppression

Contrast

Sharpness

Screening

128 MB, expandable to 512 MB

Variable zoom from 25% to 400% in 1% increments

Anamorphic zoom

Six user-programmable percentages

Continued

E-MAIL (optional)

Capability

Resolutions

Maximum Scan Area

Network Protocol

File Formats

COPYING

Document Scanner

Sides (input:output)

Quantity

Resolution

Concurrency

Digital Imaging

Copy Pre-collation Memory

Reduction/Enlargement

WorkCentre®M35/M45/M55 Copier-Printers

Auto paper select

Auto reduction/enlargement to fit selected paper size

Auto registration

Auto tray switching

Automatic job recovery

Booklet creation

N-up—up to six columns by six rows

Transparency dividers (blank or printed)

Negative image

Mirror image

Covers insertion (front only, front and back, back only; blank or printed)

Build Job

Page programming of tabs or paper inserts

Store and recall job programming

Job interrupt

Bound document copying (produce multiple sets from stored job segments)

Sample set

Mixed-size originals

Context-sensitive help screens

Interface to third-party access control devices, coin machines, card readers

Supports a variety of vending stations available through the Xerox Custom Application Service

PC interface for upload/download of internal auditron data and customer device administration/software upgrade

Xerox Copier AssistantTM Software provides a PC-based alternative to the user interface touchscreen. Used in conjunction

with a customer-supplied PC attached via the USB port, this software provides text-to-speech, screen magnification

and easy PC keyboard access to basic and advanced copy features.

SNMP Version 1 and SNMP Version 2c trap

MIB access (IETF-MIB II RFC 1213), host resources

MIB RFC 2790, Printer MIB RFC v. 2

Device Discovery wizard (downloadable from xerox.com)

Device Administration wizard (downloadable from xerox.com)

Font management utility

A Web-based server application for network administrators that permits Web browser-based

device management from any workstation

Works with any SNMP-managed printer from any manufacturer

Requires Windows XP or 2000 (Professional or Advanced Server) and Internet Explorer 5.01 or higher

WorkCentre®M35/M45/M55

Continued

COPYING

Continued

Special Features

Foreign Device Interface

(optional)

USB Port

(copier function only)

Accessibility Option

DEVICE MANAGEMENT

Management Support

CentreWare Network

Services

Xerox CentreWare Web

WorkCentre®M35/M45/M55 Copier-Printers

Server gateway application: centralized management tool.

Provides added identification to the general discovery performed by Unicenter TNG and the ability to

see the WorkCentre under a Unicenter TNG Business Process View.

Provides for the identification of Xerox N-Series printers and WorkCentre multifunction devices

in the general discovery performed by Tivoli NetView.

CentreWare MC Snap-in supports printer discovery and management.

Provides for the identification of Xerox N-Series printers and WorkCentre multifunction devices in the general

discovery performed by OpenView.

Provides traps and message updates to the OpenView alarm browser and the ability to launch CentreWare Internet

Services for device management directly from OpenView.

Plug and Print 2000 (PnP2000) is an administrative service program that simplifies enterprise-wide printer installs and

relocations for Windows 2000 environments. The product discovers devices, automatically installs devices, enables

sharing printers to users and provides install reports—all through a user-friendly interface.

Simplifies printing in SAP R/3 environments by providing users of SAP R/3 v4.6C, 4.x and 3.x ERP applications with

enhanced WorkCentre printing functionality. (PostScript and PCL):

—Simplex or duplex printing

—Finishing—single or dual stapling

—Tray pull location from any tray

—Print security via PIN ID capability at the WorkCentre

Provides built-in process intelligence that allows the printing of barcodes on any appropriately configured PostScript

printer on the SAP R/3 4.x (or higher) network. Used in conjunction with Xerox Device Types for SAP R/3 Environment

and Xerox Font Center Barcode Fonts. Utility automatically calculates checksum, placement of start/stop characters and

encoding of data string.

75 sheets

35 ipm (M35), 45 ipm (M45), 55 ipm (M55)—8.5 x 11"/216 x 279 mm long edge feed (LEF)

Statement/5.5 x 8.5"/140 x 216 mm/A5 LEF or short edge feed (SEF)

Letter/8.5 x 11"/216 x 279 mm/A4 LEF or SEF

Legal/8.5 x 14"/216 x 356 mm SEF

Ledger/11 x 17"/279 x 432 mm/A3 SEF

13 lb to 32 lb bond/50 to 120 gsm

WorkCentre®M35/M45/M55

*Paper capacities are based on 20 lb bond/75 gsm stock; capacities will vary with different weight stocks.

DEVICE MANAGEMENT

Continued

Novell NDPS/NEPS

(gateway for

WorkCentre)

Xerox CentreWare®for

Unicenter TNG®

Xerox CentreWare®for

Tivoli®NetView®

Xerox CentreWare®MC for

Microsoft Management

Console (MMC)

Xerox CentreWare®for

HP®OpenView®

Xerox Plug and

Print 2000

Xerox Device Types for

SAP R/3 Environment

Xerox SAP R/3

Intelligent Barcode

Utility

PAPER HANDLING—Duplex Automatic Document Feeder (optional)

Capacity*

Speed

Paper Sizes Sensed

Weights

WorkCentre®M35/M45/M55 Copier-Printers

Two

550 sheets each

User adjustable from 5.5 x 8.5"/140 x 216 mm/A5 to 11 x 17"/279 x 432 mm/A3

16 lb bond to 110 lb index/60 to 200 gsm

Letterhead

Bond

Preprinted forms

Plain

Tab stock

Envelopes (optional, Tray 2 only)

Hole-punched

Heavyweight

Recycled paper

100 sheets

4.13 x 5.83"/105 x 148 mm to 11.7 x 17"/297 x 432 mm

16 lb bond to 80 lb cover/60 to 216 gsm

Letterhead

Bond

Preprinted forms

Plain

Tab stock

Envelopes

Hole-punched

Heavyweight

Recycled paper

Label stock

Transparencies

Two trays: 1,600 and 2,000 sheets

Letter/8.5 x 11"/216 x 279 mm/A4 LEF

16 lb bond to 110 lb index/60 to 200 gsm

4,800 sheets (with Bypass and Front-Loading Paper Trays)

300 sheets (Letter/8.5 x 11"/216 x 279 mm/A4)

4.25 x 5.5"/A6 to 11 x 17"/A3

WorkCentre®M35/M45/M55

*Paper capacities are based on 20 lb bond/75 gsm stock; capacities will vary with different weight stocks.

PAPER HANDLING—Front-Loading Paper Trays

Number

Capacity*

Sizes

Weights

Types

PAPER HANDLING—Bypass Tray

Capacity*

Sizes

Weights

Types

PAPER HANDLING—High-Capacity Feeder Option

Capacity*

Paper Size

Weights

Total Capacity*

OUTPUT OPTION—Offsetting Catch Tray Option

Capacity*

Sizes

WorkCentre®M35/M45/M55 Copier-Printers

Capacity:* 250 sheets

Capacity:* 2,000 sheets

4.25 x 5.5"/A6 to 11 x 17"/A3

16 lb bond to 80 lb cover/60 to 216 gsm

Single (any corner) and dual

Auto stapling (50 sheets maximum)

Offline stapling (40 sheets maximum)

Statement, letter, legal, tabloid, A5, A4, A3 sizes supported

Two** and three hole (N. America); two or four hole (Europe)

ITU (CCITT) Group 3 quality/resolution of 600 x 600, 400 x 400, 300 x 300, 200 x 200, 200 x 100 dpi

One or two V.34 modems: 33,600 bps. Less than four seconds per page transmission time. ISDN via third-party adapter.

MMR, MR, MH

Auto fax transmission reduction

Page-by-page job status at the machine

Fax from platen

Delay start

Automatic memory resend

Automatic cover sheets

Priority send

Broadcast

One- or two-sided printing, stapled or unstapled

Reduction at reception to fit available paper

Junk fax prevention

Activity report

Broadcasting/Multipoll

Dial directory

Transmission confirmation

Pending fax

Mailbox

Up to 200 password-protected mailboxes

Total of 200 speed dials (single-line option) or 1,000 speed dials (dual-line option)

Up to 100 dial groups with up to 200 recipients per group (single-line option)

Up to 200 dial groups with up to 400 recipients per group (dual-line option)

Auto redial

Batch send

WorkCentre®M35/M45/M55

*Paper capacities are based on 20 lb bond/75 gsm stock; capacities will vary with different weight stocks.

**Not available at product introduction.

OUTPUT OPTION—Office Finisher Option

Top Tray

Stacking Tray

Sizes

Weights

Stapling

Hole Punching

(optional)

FAX (optional)

Compatibility

Speed/Modem (s)

Speed/Compression

Fax Send Features

Fax Receive Features

Fax Reports

Fax Receive Mailboxes

Auto Dialing

WorkCentre®M35/M45/M55 Copier-Printers

Tracks copy usage

Supports up to 2,150 user accounts, 5,925 general accounts and 256 group accounts

Auditron report printout

Ability to upload/download account and usage data via direct connection using Windows-based software.

WorkCentre®M35 WorkCentre®M45 WorkCentre®M55

Up to 100,000 Up to 150,000 Up to 200,000

WorkCentre®M35/M45/M55

Network Copier-Printer with network controller and High-Capacity Feeder

Network Copier-Printer with network controller and Stand

Notes: Platen Cover is available with Stand configurations on selected models only.

Duplex Automatic Document Feeder is available with all configurations.

One-line fax option

Two-line fax option

Office Finisher

Offsetting Catch Tray

Foreign Device Interface

Two-hole legal punch option (N. America)**

Three-hole punch option (N. America)

Two-hole punch option (Europe)

Four-hole punch option (Europe)

Copy Pre-collation RAM Upgrade (256 MB)

Image Overwrite Security

Scan to E-mail

110–140 Volt Nominal, 60 Hz, 15A or

220–240 Volt Nominal, 50 Hz, 10A

WorkCentre®M35/M45/M55

*Features, configurations and options may vary by location.

**Not available at product introduction.

ACCOUNTING

Internal Auditron

MONTHLY DUTY CYCLE

BASIC CONFIGURATIONS*

ACCESSORY OPTIONS

ELECTRICAL REQUIREMENTS

WorkCentre®M35 Copier-Printer WorkCentre®M45 Copier-Printer WorkCentre®M55 Copier-Printer

< 1151 watts < 1247 watts < 1247 watts

< 255 watts < 284 watts < 284 watts

< 184 watts < 223 watts < 223 watts

< 75 watts < 75 watts < 75 watts

99 seconds (maximum) 105 seconds (maximum) 105 seconds (maximum)

30 seconds (maximum) 30 seconds (maximum) 30 seconds (maximum)

WorkCentre®C35/C45/C55

50° to 90° F (10° to 32° C)

10% to 85%

Width Depth Height Weight

58.7"/1,490 mm 28.3"/720 mm 43.9"/1,115 mm 399 lbs/181 kg

Width Depth Height

88.25"/2,245 mm 67"/1,700 mm 78"/1,981 mm

FCC Class A Compliant (U.S.), DOC Class A Compliant (Canada)

89/336/EEC (Europe)

UL Listed (UL 1950, Third Edition)

CB Certified (IEC 60950/EN 60950)

73/23/EEC (Europe)

Novell®Tested and Approved

Windows Hardware Quality Labs

99/5/EEC (Europe)

WorkCentre®M35/M45/M55

POWER CONSUMPTION

Running

Standby

Low Power Mode

Sleep Mode

Warm-up

Low-Power Recovery

ENVIRONMENTAL CONSIDERATIONS

Required Temperature

Range

Required Relative

Humidity

DIMENSIONS AND WEIGHT

Fully Configured With

Office Finisher

SPACE REQUIREMENT

Fully Configured With

Office Finisher—

Movable Surface

CERTIFICATIONS

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Impresora todo en uno de Xerox

Xerox

Xerox WORKCENTRE 7425 Manual de usuario

Xerox

Xerox 3210 - workcentre b/w laser Manual de usuario

Xerox

Xerox 4150 - WorkCentre B/W Laser Manual de usuario

Xerox

Xerox WorkCentre 7525 Manual de usuario

Xerox

Xerox WorkCentre 3550 Manual de usuario

Xerox

Xerox 4150 - WorkCentre B/W Laser Manual

Xerox

Xerox WorkCentre 7132 Manual de usuario

Xerox

Xerox WorkCentre Pro 657 Manual de usuario

Xerox

Xerox WorkCentre 6025 Manual de usuario

Xerox

Xerox Phaser 3610 Manual de usuario

Xerox

Xerox WorkCentre 7830 Manual de usuario

Xerox

Xerox ColorQube 9302 Manual de usuario

Xerox

Xerox WorkCentre 6400V/S Manual de usuario

Xerox

Xerox Phaser 6115 MFP Manual de usuario

Xerox

Xerox versalink C7020 Manual de usuario

Xerox

Xerox WorkCentre 6655i/X Manual de usuario

Xerox

Xerox WorkCentre PE16 Manual de usuario

Xerox

Xerox WorkCentre 7300 Series Manual de funcionamiento

Xerox

Xerox WorkCentre Pro 657 Manual de usuario

Xerox

Xerox ColorQube 8700 Guía de inicio rápido

Xerox

Xerox WorkCentre 4265 Manual de funcionamiento

Xerox

Xerox WorkCentre 6025 Manual de funcionamiento

Xerox

Xerox WorkCentre 7228 Manual de usuario

Xerox

Xerox WORKCENTRE 7425 Manual de instrucciones

Manuales populares de Impresora todo en uno de otras marcas

Triumph Adler

Triumph Adler DC 2016 Manual

Epson

Epson WorkForce WF-2510 Guía del usuario

Epson

Epson Stylus Scan 2000 Manual de instalación y operación

Epson

Epson PictureMate Snap PM 240 Manual de instrucciones

Konica Minolta

Konica Minolta bizhub C35 Manual de usuario

Brother

Brother MFC-J430w Manual de usuario

Konica Minolta

Konica Minolta BIZHUB 558 Manual de usuario

Lexmark

Lexmark MX710 Series Manual

Brother

Brother MFC-9760 Manual de usuario

Lexmark

Lexmark XC8155 Manual de usuario

Lexmark

Lexmark X642E Manual de usuario

Sharp

Sharp MX-2310U Guía

Aficio

Aficio 200 Manual de usuario

Canon

Canon ImageCLASS 2300 Manual

Ricoh

Ricoh Pro C900 Manual de usuario

Lexmark

Lexmark X925 Manual de usuario

Brother

Brother Business Smart MFC-J4510dw Manual de usuario

Epson

Epson Stylus CX8400 Series Manual de usuario
