Xerox WorkCentre®7328/7335/7345

Quick Scan Features

Setup Guide

This guide includes instructions for:

Scan to Email on page 1

Scan to Mailbox Setup (Optional) on page 4

Network Scanning Setup (Optional) on page 7

Scan to FTP/SMB (Optional) on page 9

Scan to Email

Hard copies can be scanned at the device and sent to remote clients as email attachments in

TIFF/JPEG, Multi-page TIFF, Single-page TIFF, JPEG, and PDF format. SMTP and POP3

mail servers are used to send and receive email respectively.

See also:

System Administrator Guide: Contains detail about Email setup.

InteractiveUser Guide: Contains information on how to send an email and how to set

various Email options.

701P46840

v1.0

Scan to Email

Prerequisites for Scan to Email Setup

Confirm that:

1. An existing operational network using TCP/IP is available.

2. The device must be setup with DNS and the Domain Name settings for the network.

have been correctly setup for the multifunction device.

* Only if the SMTP server requires login and password for authentication.

Procedure for Scan to Email Setup

1. Press Login/Out, then type the Login ID 11111 and press Confirm.

2. Press Machine Status, then touch the Tools tab.

3. Select System Settings, then touch Connectivity and Network Setup.

4. Select Port Settings.

5. On the Port Settings screen, select Send E-mail and then select Change Settings.

6. On the Send E-mail screen, select Port Status and select Change Settings.

7. On the Send E-mail Port Status screen, select Enabled then select Save.

8. Touch Close.

9. On the Port Settings screen, select Receive E-mail, then select Change Settings.

10. On the Receive E-mail screen, select Port Status, then Change Settings.

11. On the Receive E-mail Port Status screen, select Enabled, then Save and Close.

12. On the Port Settings screen, select Mail Notice Service, then select Change Settings.

13. On the Mail Notice Service screen, select Port Status, then Change Settings.

14. On the Mail Notice Service - Port Status screen, select Enabled, then Save.

15. Select Close until the Tools tab screen is displayed.

Data to Setup Email Install Requirement Comments

SMTP mail server Host

Name or IP address

Required If using an external mail

server, your Internet Service

Provider will provide you

with the mail server name or

IP address.

SMTP login/password Required*

WorkCentre Email address Required This email address will fill in

the "From" field on the

emails sent from the device.

Local email addresses Optional A Local Address Book can

be created to store email

addresses.

LDAP server address can

be enabled

LDAP Host Name Displays only email

addresses on the corporate

(LDAP) internal address

book.

Scan to Email

Scan to Email Troubleshooting

For internal corporate mail servers, substitute the word "Corporate" for "ISP" in the

following troubleshooting table.

Symptom Possible Cause Resolution/Validation

SMTP error at

multifunction device

Incorrect Mail Server or

Host Name

Validate that the correct ISP mail

server name has been entered in

the SMTP Host Name field.

Incorrect settings in

Microsoft Outlook Express

Verify that you can access the ISP

mail server from within Microsoft

Outlook Express and that all

settings are correct.

Incorrect multifunction

device email address

entered

Verify that the device is using the

correct email address in the From:

field. The Email address must

match what the ISP's mail server is

expecting.

ISP requires SMTP

authentication to their mail

server

Check with your ISP to determine

if this is a requirement. If so,

enable SMTP authentication for

the multifunction device via

CentreWare Internet Services.

ISP does not allow mail on

the standard port number

Check with your ISP to determine

if this is the problem. Ask if they

can accept mail on another port

number. If so, change the SMTP

port number for the multifunction

device via CentreWare Internet

Services.

ISP requires login to the

email account via Microsoft

Outlook Express before

allowing mail to be sent

Check with your ISP to determine

if this is a requirement. If so, login

to the Microsoft Outlook Express

account, and then try sending the

email. If this is successful, you can

set Outlook Express to check

email every 5 or 10 minutes for the

multifunction device's email

account.

Scan to Mailbox Setup (Optional)

This feature allows documents to be stored in a mailbox for future processing. Scan to

Mailbox can be setup at the machine control panel or at a network computer through the

CentreWare Internet Services webpage. Instructions for each method are shown.

See also:

System Administrator Guide: Contains detail concerning Network Scanning setup.

Interactive User Guide: Contains information on using mailboxes.

Prerequisites for Scan to Mailbox Setup

Confirm that:

1. An existing operational network utilizing TCP/IP is available.

Procedure for Scan to Mailbox Setup through the Control Panel

1. Press Login/Out.

2. On the keypad enter 11111 or the current User ID. Touch Confirm when finished.

3. Press the Machine Status button on the Control Panel.

4. Press the Tools tab.

5. Press Setup and Calibration, then touch Setup.

6. Press the Create Mailbox button.

7. Scroll through the list to locate an unassigned Mailbox number.

8. Select an unassigned Mailbox number from the displayed list.

9. Touch the Create/Delete button.

10. When the New Mailbox - Passcode screen displays, use the On and Off buttons to

determine whether or not a passcode will be required to access the Mailbox. If On is

selected, use the numeric keypad to enter a numbered passcode.

11. Press the Save button to save your settings. (To exit the screen, without saving settings,

press the Cancel button.)

12. When the Mailbox Settings screen displays, five setting selections will be displayed on

numbered horizontal lines. The available selections include: Mailbox Name, Check

Passcode, Delete Documents After Retrieval, Delete Documents with Expire Date, and

Link Job Flow Sheet to Mailbox.

13. To assign a name to the Mailbox, press the Mailbox Name selection line.

14. Press the Change Settings button.

15. Use the touch screen keyboard to enter in a name for your Mailbox.

16. When finished entering in a name, press the Save button. (To exit the screen, without

saving changes, press the Cancel button.)

17. On the Mailbox settings screen, press any other selection lines of interest and use the

Change Settings button to access and make setting changes. Then touch Save.

18. To exit the Mailbox settings screen, press the Close button.

19. To exit the screen that lists all assigned and unassigned Mailboxes, touch Close.

Scan to Mailbox Setup (Optional)

Procedure for Scan to Mailbox Setup through CentreWare Internet Services

1. From a workstation, open up a web browser (such as Internet Explorer), and then enter

the device's IP address in the format http://xxx.xxx.xxx.xxx (the xxx's represent the

device's IP address). If connected properly, you should see a CentreWare Internet

Services web page for your device.

2. Click the Scan tab.

3. Select Mailbox in the directory tree.

4. When the numbered list of Mailboxes is shown, locate an unassigned Mailbox number

from the displayed list and click the Reg button for that Mailbox.

5. Type in a name for this Mailbox in the Mailbox Name entry box.

6. Type in a pass code in the Passcode entry box.

7. Confirm the pass code by retyping it in the Re-enter Passcode box.

8. Use the drop-down arrow to set Check Passcode to Always (recommended) to secure

your mailbox.

9. Place a checkmark in the Auto Delete Documents box if you wish to delete documents

from your mailbox after retrieving same.

10. Place a checkmark in the Delete Documents with Expiration Date box to use this

feature in place of, or as an augmentation to, Auto Delete.

11. Click Apply when done.

Note

If prompted to enter a User Name and Password, the default settings are 11111

and x-admin respectively.

Scan to Mailbox Setup (Optional)

Procedure for Scanning to Mailbox

1. From the device's main screen, press the Scan to Mailbox button.

2. When the Scan to Mailbox screen displays, a list of Mailboxes will be shown. Use the

supplied arrow to scroll through the icons to locate your Mailbox.

3. Select your Mailbox by touching its selection line on the touch screen.

4. When the Passcode screen displays, enter your passcode (series of numbers) using the

Control Panel's numeric keypad.

5. Press the Confirm button on the touch screen.

6. Use the displayed controls to set up scanning parameters.

7. Place your document in the document handler and press Start.

8. Press the Services button to return to the device's main screen.

Note

To retrieve the scanned document to a Windows PC, install the scan driver on the

PC or use CentreWare Internet Services. More information can be found on the

CentreWare Utilities CD-ROM and the "CentreWare Internet Services" chapter of

the User Guide.

Network Scanning Setup (Optional)

Network scanning uses FTP or SMB protocols to transfer scanned documents on to a server

or a client. Templates (scanned file properties) and repositories (destination folders) need to

be set up to enable network scanning.

See also:

Interactive User Guide: Contains information on how to perform a network scan, as

well as information on how to set up templates and repositories.

System Administrator Guide: Contains details about Network Scanning setup.

Prerequisites for Network Scanning Setup

Confirm that:

1. An existing operational network utilizing TCP/IP is available.

2. A repository (folder) exists on the FTP or SMB server to hold the scanned documents.

A user account for the device must be created on the server that allows access to the

repository folder.

Procedures for Configuring a Template

You need to create at least one template for users to select to scan their documents to the pre-

configured repository. This template is often referred to as the Default Template. The

template can be created with either Internet Services or SMARTsend software running on a

remote template pool server. To create and configure this template with Internet Services,

perform the following steps.

1. At your workstation, open your Web browser and enter the IP address of the machine in

the Address or Location field. Then press Enter.

2. Click the Properties tab.

3. Click the Network Scanning file folder.

4. Select the Default Template link.

5. Click Edit for File Destinations.

6. Select a filing policy from the drop-down list. Note that you can simply accept the

default policy (Rename New File).

7. For File Destination, note that the displayed destination should match the information

previously entered when you configured your Scan Filing Repository. If you have more

than one repository, the drop-down list allows you to choose your repository.

8. Click Apply to save any changes, or Undo to exit without saving changes. If you

clicked Apply, be prepared to enter the administrator User Name (default of 11111) and

Password (default of x-admin), if prompted.

Network Scanning Setup (Optional)

9. Enter any Document Management Field information (optional).

Note that if this box contains listings, you can make individual selections, then click

Edit instead. This information is filed with your scanned document in the Job Log. The

Job Log can then be accessed by third party software and the information retrieved and

associated with the scanned file.

a. Click Add.

b. Refer to the displayed descriptions to set your parameters as desired.

c. Click Apply when done.

10. To set parameters for the default template, select Edit for any of the available

categories of settings. These include: Network Scanning, Advanced Settings, Layout

Adjustment, Filing Options, Report Options, and Compression Capability.

11. Click Apply to save your settings.

Note

Select MRC Compression, if available, to use Mixed Raster Content (MRC)

compression. MRC is used to divide the scanned image based on content, and

then compress each area in the optimal manner for that image area. This option

allows for smaller output files with better image quality.

Note

Note regarding Searchable XPS: If this option is available, the Searchable

Format provides a second layer of data with the text of the scanned document.

The second layer is converted to an optical character readable format, enabling

the text of the document to be searched on, copied, and pasted, as desired.

Procedure for Network Scanning

1. At the device select All Services and Network Scanning.

2. Select a template from the list. You can also change any other value from the control

panel without impacting the template configuration; only the current job will be

affected.

3. Load a sample document into the document feeder.

4. Press the green Start button. The job is sent to the server using FTP or SMB protocol

as defined within the template.

5. From a workstation, log on to the FTP or SMB Server. Navigate to the repository

(destination) that was specified earlier. Your scanned document is located in that folder.

Note

If remote authentication has been enabled, a separate login screen appears when

the Network Scanning feature is selected. Documents are not scanned unless the

remote authentication server authenticates user access.

Scan to FTP/SMB (Optional)

Files can be scanned on the multifunction device and routed to a server or a client using FTP

or SMB protocols. Directory structures (repositories) need to be created on the server to hold

the scanned documents.

See also:

System Administrator Guide: Contains more detail concerning Scan to FTP/SMB setup.

Interactive User Guide: Contains information on how to scan to FTP/SMB.

Prerequisites for Scan to FTP

When using FTP transmission, one of the following FTP servers, with an account on that

server (login name and password), is required.

Microsoft Windows Server 2003

FTP service of Microsoft Internet Information Server 6.0

Microsoft Windows NT Server 4.0, Microsoft Windows 2000 Server, Microsoft

Windows NT Workstation 4.0, Microsoft Windows 2000 Professional, or Microsoft

Windows XP

FTP service of Microsoft Internet Information Server 3.0 or later

Mac OS X

FTP service of Mac OS X 10.1.5/10.2.x/10.3.8/10.3.9/10.4.2

Novell NetWare

FTP service of NetWare 5.11 or 5.12

Refer to the manual provided with the software for how to configure the FTP service.

Prerequisites for Scan to SMB

When using SMB transmission, a computer running one of the following Operating Systems,

which includes a shared folder, is required.

Microsoft Windows 98

Microsoft Windows Me

Microsoft Windows NT 4.0

Microsoft Windows 2000

Microsoft Windows Server 2003

Microsoft Windows XP

Scan to FTP/SMB (Optional)

Procedure for Setup of Scan to FTP/SMB

To use Scan to PC (FTP/SMB) you need to enable the applicable Ports (SMB or FTP client)

on the Device, and make sure that an IP address has been set on the machine.

Note

The configuration can also be performed using CentreWare Internet Services. For

information on how to use CentreWare Internet Services, refer to the Internet

Services section of this guide.

1. Display the System Administrator Menu screen.

a. Press the Log In/Out button.

b. Enter the Login ID (11111) with the numeric keypad or the keyboard displayed

on screen, then touch Confirm.

c. Press the Machine Status button on the Control Panel.

d. Touch the Tools tab.

2. When using the SMB protocol, enable the SMB port.

a. Select System Settings.

b. Touch Connectivity and Network Setup.

c. Select Port Settings.

d. Select SMB and then select Change Settings.

e. Select Port Status and then select Change Settings.

f. Select Enabled then select Save.

g. Select Close until the Port Settings screen is displayed.

3. When using the FTP protocol, enable the FTP client port.

a. Select System Settings.

b. Touch Connectivity and Network Setup.

c. Select Port Settings.

d. From the Tools tab screen, select Network Settings, then Port Settings.

e. From the Port Settings screen, select FTP Client and then select Change

Settings.

f. Select Port Status and then select Change Settings.

g. Select Enabled then select Save.

h. Select Close repeatedly until the Tools tab screen is displayed.

Otros manuales para WorkCentre 7328

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Impresora todo en uno de Xerox

Xerox

Xerox WorkCentre 7970 Manual de usuario

Xerox

Xerox Phaser 6115 MFP Manual de usuario

Xerox

Xerox WorkCentre Pro 555 Manual de usuario

Xerox

Xerox WorkCentre 7525 Manual del propietario

Xerox

Xerox 4150 - WorkCentre B/W Laser Manual de usuario

Xerox

Xerox WorkCentre M24 Color Manual de usuario

Xerox

Xerox WorkCentre Xi70c Manual de usuario

Xerox

Xerox CopyCentre C20 Manual de usuario

Xerox

Xerox WorkCentre 7655 Manual de operación y mantenimiento

Xerox

Xerox DOCUCOLOR 12 Manual de lista de piezas

Xerox

Xerox VersaLink B7025 Manual de funcionamiento

Xerox

Xerox WorkCentre 6605DN Manual de usuario

Xerox

Xerox AltaLink C81 Series Manual de usuario

Xerox

Xerox WorkCentre 7132 Manual de usuario

Xerox

Xerox 2218 - FaxCentre B/W Laser Manual de usuario

Xerox

Xerox 4250 - WorkCentre - Copier Manual de instrucciones

Xerox

Xerox WorkCentre 3119 Manual de usuario

Xerox

Xerox WorkCentre Pro 275 Manual de usuario

Xerox

Xerox Phaser 6110MFP Manual de usuario

Xerox

Xerox B1022 Manual de usuario

Xerox

Xerox Phaser 6180MFP Manual de usuario

Xerox

Xerox Document WorkCentre 480cx Manual técnico

Xerox

Xerox ColorQube 9300 series Manual de usuario

Xerox

Xerox DocuColor 5750 Manual de servicio

Manuales populares de Impresora todo en uno de otras marcas

Triumph Adler

Triumph Adler DC 2016 Manual

Epson

Epson WorkForce WF-2510 Guía del usuario

Epson

Epson Stylus Scan 2000 Manual de instalación y operación

Epson

Epson PictureMate Snap PM 240 Manual de instrucciones

Konica Minolta

Konica Minolta bizhub C35 Manual de usuario

Brother

Brother MFC-J430w Manual de usuario

Konica Minolta

Konica Minolta BIZHUB 558 Manual de usuario

Lexmark

Lexmark MX710 Series Manual

Brother

Brother MFC-9760 Manual de usuario

Lexmark

Lexmark XC8155 Manual de usuario

Lexmark

Lexmark X642E Manual de usuario

Sharp

Sharp MX-2310U Guía

Aficio

Aficio 200 Manual de usuario

Canon

Canon ImageCLASS 2300 Manual

Ricoh

Ricoh Pro C900 Manual de usuario

Lexmark

Lexmark X925 Manual de usuario

Brother

Brother Business Smart MFC-J4510dw Manual de usuario

Epson

Epson Stylus CX8400 Series Manual de usuario
