Xerox®WorkCentre®3215/3225

Quick Use Guide

Xerox WorkCentre 3215/3225

Multifunction Printer

EN Printer Basics ............................................................... 3

EN Copying.........................................................................8

EN Printing......................................................................... 6

Printer Tour...................................................................3

Control Panel................................................................4

Supported Papers........................................................6

Basic Printing .............................................................. 7

Basic Copying..............................................................8

EN Scanning.......................................................................9

EN Faxing..........................................................................14

EN Troubleshooting ........................................................16

Paper Jams.................................................................16

Scanning from a computer using Windows 7.....11

Scanning from a computer using Windows XP..12

Scanning from a computer using

Macintosh 10.5 and later.......................................13

Scanning to a Computer......................................... 10 Basic Faxing............................................................... 15

CentreWare Internet Services...................................5

Xerox Easy Printer Manager......................................5

Contents

Printer Basics

Jam Access

Printer Tour

Main Tray

Manual feed slot

Scanner

Automatic Document Feeder (ADF)

Exit Tray

Toner Cartridge

EN Drum Cartridge

Printer Basics

Arrow buttons scroll up, down, forward, and back through the menus

OK button accepts the menu selection

Back/Return button goes up one level in the menu

Clear a character

Access the address book

Cancel the current job

Select copy, scan, or fax

Enter the system menus

Enter the feature menus

Select scan to email

EN Power On, Off

EN Start a copy, scan, fax, or print job

Power Saver on, off

Manual dial

Redial a fax, or enter a pause

Clear all changed settings

Printer Basics

Ethernet Wi-Fi

Ethernet

USB Wi-Fi

CentreWare Internet Services

EN CentreWare Internet Services enables you to access printer conﬁguration details, paper and supplies status,

job status, and diagnostic functions over a TCP/IP network. You can also manage fax, email, and network

scanning address books. To connect, type the printer's IP address in your computer's web browser. The IP

address is available on the Conﬁguration page.

Xerox Easy Printer Manager

EN You can access printer settings, maintenance, diagnostic features, and the User Guide using the Xerox Easy

Printer Manager. You can also scan from the printer to your computer. You can ﬁnd the Xerox Easy Printer

Manager in Start > All Programs > Xerox Printers in Windows, or on the dock in Mac OSX.

Printing

Windows Macintosh

71–85 g/m2

(20–24 lb. Bond)

164–220 g/m2

(60–80 lb. Cover)

86–120 g/m2

(24–32 lb. Bond)

60–70 g/m2

(16–20 lb. Bond)

121–163 g/m2

(32 lb. Bond–60 lb. cover)

60–163 g/m2

(16 lb. Bond–60 lb. Cover)

Letter............................8.5 x 11 in.

Legal.............................8.5 x 14 in.

Executive.....................7.25 x 10.5 in.

Folio..............................8.5 x 13 in.

Oﬁcio............................8.5 x 13.5 in.

Postcard.......................4.0 x 6.0 in.

A4..................................210 x 297 mm

A5..................................148 x 210 mm

A6..................................105 x 148 mm

B5 ISO..........................176 x 250 mm

B5 JIS ...........................182 x 257 mm

60–220 g/m2

(16 lb. Bond–80 lb. Cover)

Letter............................8.5 x 11 in.

Legal.............................8.5 x 14 in.

Executive.....................7.25 x 10.5 in.

Folio..............................8.5 x 13 in.

Oﬁcio............................8.5 x 13.5 in.

Postcard.......................4.0 x 6.0 in.

A4..................................210 x 297 mm

A5..................................148 x 210 mm

A6..................................105 x 148 mm

B5 ISO..........................176 x 250 mm

B5 JIS ...........................182 x 257 mm

Monarch......................3.9 x 7.5 in.

Commercial #10........4.1 x 9.5 in.

DL ..................................110 x 220 mm

C5 ..................................162 x 229 mm

C6 ..................................114 x 162 mm

2122

W: 105–216 mm (4.1–8.5 in.)

L: 127–356 mm (5–14 inches)

W: 76–216 mm (3–8.5 in.)

L: 127–356 mm (5–14 inches)

1 2 110 v 220 v

Letter A4

Legal

Folio

Oﬁcio

WorkCentre 3225

When loading paper: conﬁrm or select the correct type and size on the control panel

Select printing options in the Xerox®print driver

EN EN

Plain EN

EN Thick Cardstock

Thin Thicker

Supported Papers

Custom

Printing

Letter............................8.5 x 11 in.

Legal.............................8.5 x 14 in.

Folio..............................8.5 x 13 in.

Oﬁcio............................8.5 x 13.5 in.

A4..................................210 x 297 mm

Windows Macintosh

1 2

3 4

Basic Printing

Select paper size and type in the print driver.

Copying

12 3

60–105 g/m2

(16–28 lb. Bond)

X: 148–216 mm (5.8–8.5 in.)

Y: 148–356 mm (5.8–14.0 in.)

EN Load the original

EN Press the Copy button

EN Select the number of copies

EN Navigate the menus to select copying options

EN See: User Guide > Copy

Basic Copying

The Clear All button restores default settings.

EN Press the Start button

Scanning

Ethernet

USB Wi-Fi

60–105 g/m2

(16–28 lb. Bond)

X: 148–216 mm (5.8–8.5 in.)

Y: 148–356 mm (5.8–14.0 in.)

Scanning

Loading the original

When connected with USB, Ethernet, or Wi-Fi you can send scanned ﬁles from the printer control panel to a

connected computer. You can also scan from a connected computer. To set up scanning for your connection,

see the User Guide > Installation and Setup > Scan to PC Setup.

Scanning

Wi-Fi

Ethernet

USB

EN Press the Scan button EN Select Scan to PC, then press OK

EN EN

Scroll to select a destination, then press OK

Scroll to select a proﬁle if desired, then press OK

EN Press the Start button

EN Navigate the menus to select scanning options

Scanning to a Computer

The Clear All button restores default settings.
