Xenarc 1029 Manual de usuario

1029 INSTALLATION MANUAL

2│Table of Contents

Features ……………………………………………03

Specifications ……………………………………04

Quick –Start ……………………………………..05

Remote Control ………………………………….07

Capacitive Touch

………………………………..10

Hardware Installation …………………………11

1029CNH / 1029CNV / 1029TNH / 1029TNV Models

Additional Info. …………………………………..15

Owner’s Record. ………………………………….16

3│Features

Model Comparison Chart

1029CNH

1029CNV

1029TNH

1029TNV

VGA ( D-SUB 15 Pin ) Input

VIDEO ( RCA ) Inputs

High Quality Scaling

●

High Quality Anti - Aliasing

●

Auto Power On

●

Touch Screen

Capacitive

5-Wire Resistive

HDMI Input

●

○

●

○

IP grade

IP65

●Standard ○Not Available

Features

●For Marine, In-Car Computing, PC, Server, GPS, POS, and various

HDMI/DVI/VGA Use

●IP65 / NEMA4 rated water and dust resistance

●1,000NIT Sunlight Readable with long life LED backlight

●Projected Capacitive Multi-Touch Touchscreen (USB) (1029CNH /

1029CNV Only)

●5-Wire Resistive Touch Screen (USB) (1029TNH / 1029TNV Only)

●Multi-Monitor Touchscreen Support

●HDMI Input x 1 (1029CNH / 1029TNH Only)

●VGA Input (15 pin D-SUB) x 1 & Video Input x 2

●DVI Input through included DVI to HDMI adaptor (1029CNH / 1029TNH

Only)

●Supports HDCP

●NTSC / PAL Multi-System

●16x9 Aspect Ratio

●Ultra High Resolution - 1024 x 600 Native

●Solid Capacitors for improved durability

●Automatic backlight level adjustment through built-in ambient light

sensor

●High Performance Image and Video Signal Processor

●AISS - Advanced Image-Scaling and Shaping

●Last Input memory

●Last Power setting memory

●IR Remote Control

●Auto power-on upon signal detection

●Automatic display adjustment

●On Screen Display Control

●Mirror Image Flip

●Vertical Image Flip

●Function to disable front button(s)

●Function to disable On Screen Text

●AV2 Auto Switching for backup camera

●U-Shape mounting bracket

●VESA 75mm mounting holes

●26-Pin heavy-duty connector with connector locking

●Anti Reflective Coating

●Brushed aluminum face plate

●Aluminum Casing

●Supports 10V DC ~ 35V DC

●"E" Mark Certified for Automotive use

4│Specification

Specifications

Display Specifications

●Screen Size : Diagonal 10.1”( 16 : 9 )

●Physical Resolution : 1024 ( H ) x 600 ( V )

●Pixel Pitch : 0.2175 ( H ) x 0.2088 ( V ) ( in )

●Dot Resolution : 3072 x 600 = 1,843,200 ( dots )

●Supported Resolution : 640 x 480 ~ 1920 x 1200

●Supported Refresh : 60~75Hz

●LCD Panel Brightness : 1000 cd/m²

●Contrast Ratio : 500 : 1

●Response Time : 5~20ms

●Viewing Angle : Vertical : 140゜/ Horizontal : 110゜

●Colors : 8-bits (16,777,216 colors )

Physical Specifications

●Video Source Input

—RGB analog male connector ( 15-Pin D-SUB ) x 1

—RCA composite video female connector x 2

—HDMI input connector x 1 ( 1029CNH / 1029TNH Only )

●Touch Panel ( Input / Output )

—USB connector x 1

●Power Source Input

—Single 12V DC_IN ( Supports 10V~35V )

●External Buttons Input

—OSD buttons for Power / Select / Menu / Increase / Decrease

—Power button for power switch

●Dimension ( In ) : 10.45 ( L ) x 6.96 ( H ) x 1.33 ( D ) In

●Weight ( lb ) : 3.64 lbs

Electrical Specifications

●Operating Voltage Range : DC 10V ~ 35V

●Power Supply : DC 12V

●Power Consumption :

—Suspended Mode < 2W ( Max )

—Continuous Mode < 10W ( Max )

Other Specifications

●Operating Temperature : -4℉~ 158℉

●Storage Temperature : -22℉~ 176℉

●FCC, CE, E13, Certification

●ROHS Compliant

●IP65 Compliant

●24 Month Warranty

5│Quick - Start

Attach the 26-Pin connector to the monitor

Attach the D-Sub 15-Pin connector to your

computer’s analog VGA output connector

Attach the HDMI connector to your computer’s

HDMI output connector ( CNH / TNH Only )

Attach your “ Video source one “

(e.g. VCR, Video Game Console)

to the Yellow RCA connector marked Video 1

Attach your “ Video source two “

(e.g. Rear View Camera)

to the Yellow RCA connector marked CCD

6│Quick - Start

Attach the USB plug to your USB connector

Touchscreen Installation

Please download and install the Touchscreen driver

for your operating system from our website

WWW.XENARC.COM.

Depending on your application, you can choose

to install the included U-Shape bracket onto the

monitor

Please make sure that you install the plastic and

metal washer as shown if you choose to use the

U-Shape bracket.

Insert Power Adapter as shown

7│Remote Control

1. Power Button : Turn the monitor ON or OFF.

2. Mirror Button : Enable or Disable the mirroring of the display.

Continue to press it and choose the mirroring you want.

3. Dimmer Button : Dim the brightness of the display by pressing this key

continuously to set the brightness level of the display.

( Only available when auto sensor is disabled. )

4. Display Button : Display the current input signal on the screen.

5. Sleep Button : Enable or Disable the sleep timer. Press this button to

select and set the time to turn off the monitor automatically.

6. Picture Button : Enable or select the picture mode you prefer.

Press this button and then you can select standard, user, bright,

or soft.

7. PC auto Button : Enable to adjust the picture automatically, only

available in VGA mode.

8. Menu Button : Enable the OSD menu.Press this button again to exit.

9. Source Button : Enable to switch to different source input.

10. Up / Down Button ( ▲ / ▼ ) : Navigate Up or Down in OSD menu.

11. Left / Right Button ( ◄ / ► ) : Navigate Left or Right in OSD menu, as

well as decreasing or increasing the value of setting in OSD.

12. Enter Button : Confirm the setting or selection.

8│Remote Control

Instructions for remote control shortcuts

1. Dimmer ( Adjust the brightness )

By pressing the Dimmer button, it will adjust the brightness level from 0,

20, 40, 60, 80 and 100.

Default is 100 ( Only available when auto sensor is disabled )

2. Sleep ( Set the sleep time out )

Select the time to automatically turn off the monitor.

The minimum is 15 minutes and the maximum is 120 minutes.

3. Picture ( Set the modes of the picture )

Enable to select the picture modes you prefer.

Press this button and then you can select standard, user, bright, or soft.

4. PC AUTO ( Auto adjust, only on VGA )

By pressing PC AUTO, it will auto adjust the image.

5. Source ( Select the source )

Press this button to select the input signal to display.

If one of these modes is disabled in OSD menu, please setup under

( Function →Source Enable )

9│Remote Control

6. Mirror ( Image mirror )

Enable or Disable the mirroring of the display. Continue to press it and

choose the mirroring mode you wish to display.

7. Display ( Display mode )

Display the current input signal on the screen.

10 │Capacitive Touch

( 1029CNH / 1029CNV Only )

1. Supports plug and play

2. Supports below operating systems

Touch Function

WINDOWS

Available for multi-touch

Only supports single mouse point

VISTA

Only supports single mouse point

MAC

OS9

Only supports single mouse point

Available for multi-touch

Linux

Kernel 2.6.24 Upwards

Available for multi-touch if kernel version is 2.6.36

above. If kernel version below 2.6.35, it will only

support single point.

Kernel 2.6.23 Downward

Only supports single mouse point

Kernel 2.4.X

Only supports single mouse point

3. Touch Calibration is not required.

4. Operation

Touch & type

To select or activate something, touch it.

To type something, such as a name, password, or search terms, just touch

where you want to type. A keyboard pops up that lets you type into the

field.

Other common gestures include:

• Touch & hold. Touch & hold an item on the screen by touching it and not

lifting your finger until an action occurs.

• Drag. Touch & hold an item for a moment and then, without lifting your

finger, move your finger on the screen until you reach the target

position. For example, you can move object or icon around on the Home

screen.

• Swipe or slide. Quickly move your finger across the surface of the screen,

without pausing when you first touch (so you don’t drag something

instead). For example, you can slide a Home screen left or right to view

the other Home screens.

• Double-tap. Tap quickly twice on a webpage, map, or other screen to

zoom. For example, double-tap a picture in Chrome to zoom in, and

double-tap again to zoom out.(This function depends on Win7 or Win8

function)

• Pinch. In some apps (such as Maps, Chrome, and Gallery), you can zoom

in and out by placing two fingers on the screen at once and pinching

them together (to zoom out) or spreading them apart (to zoom in). (This

function depends on Win7 or Win8 function)
