X-Micro XBT-DG3X Manual de usuario
Bluetooth Stereo Media Phone
User’s Manual
With additional Operation Instruction
for Skype using IVT software
Version1.0
1
Copyright
Copyright 2005 by X-Micro Technology Corp., All rights reserved. No part of
this publication may be reproduced, transmitted, transcribed, stored in a
retrieval system, or translated into any language or computer language, in
any form or by any means, electronic, mechanical, magnetic, optical,
chemical, manual or otherwise, without the prior written permission of X-Micro
Technology Corp.
Disclaimer
X-Micro Technology Corp. makes no representations or warranties, either
expressed or implied, with respect to the contents hereof and specifically
disclaims any warranties, merchantability or fitness for any particular purpose.
Any software described in this manual is sold or licensed "as is". Should the
programs prove defective following their purchase, the buyer (and not this
company, its distributor, or its dealer) assumes the entire cost of all necessary
servicing, repair, and any incidental or consequential damages resulting from
any defect in the software. Further, X-Micro Technology Corp., reserves the
right to revise this publication and to make changes from time to time in the
contents hereof without obligation to notify any person of such revision or
change.
All brand and product names mentioned in this manual are trademarks and/or
registered trademarks of their respective holders.
2
INFORMATION TO USER
Model Name: XBT-DG7X, XBT-HS3X
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of the following
measures:
* Reorient or relocate the receiving antenna.
* Increase the separation between the equipment and receiver.
* Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
* Consult the dealer or an experienced radio/TV technician for help.
3
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate
this equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
* This equipment complies with FCC radiation exposure limits set forth for
an uncontrolled environment.
This equipment should be installed and operated with minimum distance
20cm between the radiator & your body.
* This transmitter must not be co-located or operating in conjunction with
any other antenna or transmitter.
4
TABLE OF CONTENT
1.Introduction .................................................................................................6
1.1 Bluetooth Stereo Headset
1.2 Package Contents
2. Headset Features ..................................................................................... 6
3. LED Indication .......................................................................................... 7
4. Charge Battery and Reset the Headset ................................................... 7
4.1 Charge Battery
5. Turn On / Off the Headset ........................................................................ 8
5.1 To turn the Headset On
5.2 To turn the Headset Off
6. Connect With PC/Notebook ..................................................................... 8
6.1 Pair with your PC/Notebook
6.2 Play Music with PC and Notebook
6.2.1 Button Functionality Under Music Mode
7. Connect with Skype ……..................................................................... …..13
7.1 Configure Audio Gateway to work with Skype
7.2 Pair Headset with PC
7.3 Establish Link between BTW Software and Skype
7.4 Configure Skype’s Settings
7.5 Basic Operation within Skype Mode
8. Link with Mobile Phone............................................................................. 18
8.1 Pairing
8.2 Connect with Mobile Phone
8.3 Answer & End a Phone Call
5
9. Multiple Links ………………………….................................................. ….23
9.1 Pair both side first
9.2 Switch between Mobile Phone and PC(music)
9.3 Switch between PC(music) and PC(Skype)
9.4 Switch between Mobile phone and PC(Skype)
10. FAQ ..................................................................................................... ..25
11. Support………. ....................................................................................27
6
1 INTRODUCTION
Thank you for your purchasing of our X-Micro Bluetooth Stereo Media
Phone. Bluetooth is a technology which is very popular in short range
wireless communication. It allows wireless connections between Bluetooth
devices such as cellular phones, personal digital assistants (PDA), desktop
and notebook computers, input-output devices (mouse, keyboards,
printers)...etc.
1.1 Bluetooth Stereo Headset
This Bluetooth headset offers the latest innovation in Bluetooth
technology. It features crystal clear stereo sound, which is a remarkable
break through that others do not have. With this Bluetooth stereo headset,
you can connect it wirelessly with other Bluetooth devices such as mobile
phone, desktop or notebook computer, PDA (with audio gateway profile
supported) within a range of 10 meters. (BTW software version 2.0.1.2101
or higher is recommended.)
1.2 Package Content
* Bluetooth stereo headset.
* Detachable stereo earpiece with
microphone.
* USB cable.
* User’s manual.
* 5VDC power adapter (Optional)
2 HEADSET FEATURES
1 Buttons : Increase Volume (V+).
2 Buttons : Decrease Volume (V-).
3LED Indicator
7
4 Play/Talk Button : Answer call, Play music, Pause.
5On/Off Button : Power on/off, End Call,Stop Music, Pairing.
6 Charging Port
7Reverse Button: Reverse, Previous Song Title.
8Forward Button: Forward, Next Song Title.
3 LED Indication and Definition
1. Stand-By Mode - Red LED flash in slow pace.
2. Pairing Mode - Blue and Red LED flash simultaneous.
3. PC Mode - Red LED flash regularly.
4. Mobile Mode - Blue LED flash regularly.
5. Battery Low - Red LED blinks about 2 seconds interval.
6. Charge Mode - Red LED stays solid without blinking.
4 CHARGE BATTERY AND RESET THE HEADSET
The headset comes with a build-in high capacity battery; please let the
battery be fully charged before first time use.
1. Connect the USB charging cable into the headset charging port (Fig.1).
The red LED stays ON continuously without blinking.
The unit will automatically switch to “ON” status regardless its status is
On or Off.
2. Once the battery has been fully charged, the red LED light will start to
blink.
8
5 Turn On / Off the Headset
5.1 To turn on: Press and hold the On/Off button for around 1 second,
Both red and blue light will blink one time
simultaneous to indicate the headset is on.
The headset is now turned on and in stand-by mode.
The red LED light will blink continuously in stand-by
mode.
5.2 To turn off: Press and hold the On/Off button for around 4 seconds.
The red LED light will blink 3 times then turn off.
6 CONNECT WITH PC/NOTEBOOK
6.1 Pair with your PC/Notebook
Pairing process is required before making connection with either PC or
Notebook device.
(1) Make sure your PC or Notebook has been installed Bluetooth driver first,
double click on the
Bluetooth icon at the desktop or the right hand of task bar to enter the
setup window “IVT Corporation BlueSoleil – Main window”.
9
(2) Turn on the headset, press and hold on the On/Off Button briefly for
about 3 seconds.
(3) From “BlueSoleil” select “My Bluetooth” tab and select “Bluetooth
Device Discovery”.
(You may also press F5 for quick device search)
(4) Select and Right Click on “Stereo Headset (VX.XX.XX)” , then select
“Pair Device”.
(5) When “Bluetooth PIN Code Request” window comes up, enter the
default password “ 0000 ” and press OK.
