Worx MakerX WX743.9 Manual de instalación

WX743

WX743.X

20V Cordless Mini Heat

Gun

SAFETY AND OPERATING MANUAL

ORIGINAL INSTRUCTIONS

PRODUCT SAFETY

GENERAL SAFETY WARNINGS

WARNING: Read all safety warnings and

instructions.

Failure to follow all instructions

listed below may result in electric shock, fire and/

or serious injury.

Save all warnings and instructions for future

reference.

This appliance can be used by children aged from

8 years and above and persons with reduced

physical, sensory or mental capabilities or lack

of experience and knowledge if they have been

given supervision or instruction concerning use

of the appliance in a safe way and understand the

hazards involved. Children shall not play with the

appliance. Cleaning and user maintenance shall

not be made by children without supervision.

WARNING: For the purposes of recharging the

battery, only use the detachable supply unit

provided with this appliance.

ADDITIONAL SAFETY RULES FOR HEAT GUNS

WARNING: This tool must be placed on its stand

when not in use.

A fire may result if the appliance is not used with

care, therefore

– be careful when using the appliance in places

where there are combustible materials;

– do not apply to the same place for a long time;

– do not use in presence of an explosive

atmosphere;

– be aware that heat may be conducted to

combustible materials that are out of sight;

– place the appliance on its stand after use and

allow it to cool down before storage;

– do not leave the appliance unattended when it

is switched on.

SAFETY WARNINGS FOR BATTERY PACK

a) Do not dismantle, open or shred cells or

battery pack.

b) Do not short-circuit a battery pack. Do

not store battery packs haphazardly in

a box or drawer where they may short-

circuit each other or be short-circuited

by conductive materials. When battery

pack is not in use, keep it away from other

metal objects, like paper clips, coins, keys,

nails, screws or other small metal objects, that

can make a connection from one terminal

to another. Shorting the battery terminals

together may cause burns or a fire.

c) Do not expose battery pack to heat or fire.

Avoid storage in direct sunlight.

d) Do not subject battery pack to mechanical

shock.

e) In the event of battery leaking, do not

allow the liquid to come into contact with

the skin or eyes. If contact has been made,

wash the affected area with copious

amounts of water and seek medical

advice.

f) Seek medical advice immediately if a cell

or battery pack has been swallowed.

g) Keep battery pack clean and dry.

h) Wipe the battery pack terminals with a

clean dry cloth if they become dirty.

i) Battery pack needs to be charged before

use. Always refer to this instruction and

use the correct charging procedure.

j) Do not maintain battery pack on charge

when not in use.

k) After extended periods of storage, it may

be necessary to charge and discharge

the battery pack several times to obtain

maximum performance.

l) Recharge only with the charger specified

by Worx. Do not use any charger other

than that specifically provided for use

with the equipment.

m)Do not use any battery pack which is not

designed for use with the equipment.

n) Keep battery pack out of the reach of

children.

o) Retain the original product literature for

future reference.

p) Remove the battery from the equipment

when not in use.

q) Dispose of properly.

r) Do not mix cells of different manufacture,

capacity, size or type within a device.

s) Do not remove battery pack from its

original packaging until required for use.

t) Observe the plus (+) and minus (–) marks

on the battery and ensure correct use.

SYMBOLS

Read operator’s manual

Warning

Wear eye protection

Wear protective gloves

Do not burn

Batteries may enter water cycle if disposed improperly, which can be

hazardous for ecosystem. Do not dispose of waste batteries as unsorted

municipal waste.

Li-I on

Li-Ion battery. This product has been marked with a symbol relating

to ‘separate collection’ for all battery packs and battery pack. It will

then be recycled or dismantled in order to reduce the impact on the

environment. Battery packs can be hazardous for the environment and

for human health since they contain hazardous substances.

Waste electrical products must not be disposed of with household

waste. Please recycle where facilities exist. Check with your local

authorities or retailer for recycling advice

COMPONENT LISTS

1. TRESTLE

2. NOZZLE

Not all the accessories illustrated or described are included in standard

delivery.

TECHNICAL DATA

WX743 WX743.X*

Rated voltage 20 V Max

Power input 200 W

Max temperature 260 oC

Battery type Lithium battery

Machine weight (bare tool) 210 g

X=1-99, A-Z, M1-M9 there are only used for different customers, there are no safe

relevant changes between these models.

**Voltage measured without workload. Initial battery voltage reaches maximum of 20

volts. Nominal voltage is 18 volts.

Category Model Capacity

20V Hub/HubX

WA7160 Input: 20 V 10 A Max.

Output: 20 V 10 A Max.

WA7161 Input: 20 V 10 A Max.

Output: 20 V 10 A Max.

Or Output: 5 V 2 A (USB port)

We recommend that you purchase your accessories from the same store that sold you

the tool. Refer to the accessory packaging for further details. Store personnel can assist

you and offer advice.

MakerX series tools and 20V Hub/HubX are specially designed to work together, so do

not attempt to use any other devices.

A B

C D
