WORMS SILENTSTAR 6000D M YN Manual de usuario
INSTRUCTIONS FOR USE
GENERATORS
EN
MODELS
SILENTSTAR
6000D M YN
6500D T YN
Édition : 20190903
MU_02GE_SILENTSTAR_6000D_6500D_EN
2
Thank you for purchasing a Worms Entreprises generator.
This manual covers operation and maintenance of the Worms Entreprises generators. All information
in this publication is based on the latest production information available at the time of approval for
printing.
Pay special attention to statements preceded by the following words:
Indicates an impending dangerous situation. If this one is not prevented, it can cause death or severe
injuries for the user..
Indicates a strong possibility of severe personal injury, loss of life and equipment damage if instructions
are not followed.
CAUTION
Indicates a possibility of personal injury or equipment damage if instructions are not followed.
NOTE
Gives helpful information.
If a problem should arise, or if you have any questions about the generator, consult an authorized dealer
or service shop.
The generator is designed to give safe and dependable service if operated
according to instructions.
Do not operate the generator before you have read and understood the
instructions. Failure to do so could result in death, personal injury or
equipment damage.
3
SUMMARY
1. SYMBOLS AND MEANINGS...................................................................................................................................... PAGE 4
2. SAFETY PRECAUTIONS............................................................................................................................................. PAGE 6
3. SPECIFICATIONS ............................................................................................................................................................ PAGE 8
4. CONTROL PANEL ........................................................................................................................................................... PAGE 9
5. PRE-OPERATION CHECK....................................................................................................................................... PAGE 10
6. OPERATING PROCEDURES.................................................................................................................................. PAGE 13
7. STOPPING THE GENERATOR.............................................................................................................................. PAGE 15
8. OIL SENSOR.................................................................................................................................................................... PAGE 16
9. WATTAGE INFORMATION....................................................................................................................................... PAGE 16
10. MAINTENANCE SCHEDULE ............................................................................................................................... PAGE 17
11. ‘‘HOW TO’’ MAINTENANCE.................................................................................................................................. PAGE 18
12. PREPARATION FOR STORAGE........................................................................................................................ PAGE 20
13. TROUBLESHOOTING.............................................................................................................................................. PAGE 21
4
1. SYMBOLS AND MEANINGS
In accordance with the ISO standard, the specified symbols as shown in the following table are used
for the products and this instruction manual.
Read the operator’s instruction manual.
Stay clear of the hot surface.
Exhaust gas is poisonous.
Do not operate in an unventilated room.
Stop the engine before refueling.
Fire, naked flame and smoking prohibited.
Caution, risk of electric shock.
Do not connect the generator to the commercial power lines.
5
ON (Switch Engine) Pr Rated power (kW)
OFF (Switch Engine) ƒr Rated frequency (Hz)
Alternating current H max Maximum site altitude above
sea-level (m)
Direct current COP Continuous power (kW)
Plus : positive polarity U rRated voltage (V)
Minus : negative polarity Tmax Maximum ambient tempera-
ture (°C)
STOP-position of a bistable push control COS ϕRated power factor
ON-position of a bistable push control Ir Rated current (A)
Protective earth (ground) mMass (kg)
Fuse
Engine oil
Add oil
Battery charging condition
Choke (cold starting aid)
Engine start (Electric start)
Engine stop (Electric start)
Fuel
Fast
Slow
6
2. SAFETY PRECAUTIONS
Do not operate the generator near gasoline or gaseous fuel because of the potential
danger of explosion or fire.
Do not fill the fuel tank with fuel while the engine is running. Do not smoke
or use a naked flame near the fuel tank. Be careful not to spill fuel during
refueling. If fuel is spilt, wipe it off and let dry before starting the engine.
Do not place inflammable near the generator. Be careful not to place fuel, matches, gunpowder,
oily cloths, straw, trash, or any other in flammables near the generator.
Do not operate the generator inside a room, cave, tunnel, or other insufficiently ventilated area.
Always operate it in a well-ventilated area, otherwise the engine may
become overheated, and the poisonous carbon monoxide gas contained
in the exhaust gases will endanger human lives. Keep the generator at
least 1 meter (3 feet) away from any structure or building during use. If
the generator must be used indoors, the area must be well-ventilated and
extreme caution must be taken regarding the discharge of exhaust gases. Failure to follow the
correct procedures can be fatal.
Do not enclose the generator nor cover it with a box. The generator has a built-in forced air cooling
system, and may become overheated if it is enclosed. If generator has been covered to protect it
from the weather during non use, be sure to remove it and keep it well away from the area during
generator use.
Operate the generator on a level surface. It is not necessary to prepare a special foundation for
the generator. However, the generator will vibrate on an irregular surface, so choose a level place
without surface irregularities. If the generator is tilted or moved during operation, fuel may spill
and/ or the generator may tip over, causing a hazardous situation. Proper lubrication cannot be
expected if the generator is operated on a steep incline or slope. In such a case, piston seizure
may occur even if the oil level is above the minimum level.
Pay attention to the wiring or extension cords from the generator to the connected
device. If the wire is under the generator or in contact with a vibrating part, it may
break and possibly cause a fire, generator burnout, or electric shock hazard.
Replace damaged or worn cords immediately.
Do not operate in rain, in wet or damp conditions, or with wet hands. The operator may suffer
severe electric shock if the generator is wet due to rain or snow.
If the generator is wet, wipe and dry it before starting. Do not pour water directly over
the generator, never wash it with water.
7
Be extremely careful that all necessary electrical grounding procedures are followed during each
and every use. Failure to do so can be fatal.
Do not contact the generator to a commercial power line. Connection to a commercial
power line may short circuit the generator and ruin it or cause electric shock hazard.
Use the transfer switch for connecting to domestic circuit. In the special case
where the generator will be connected as stand by to the commercial network, the
installation must be carried out by a qualified electrician taking into account the
technical specifications of the generator and the commercial network.
No smoking while handling the battery. The battery emits flammable hydrogen gas,
which can explode if exposed to electric arcing or a naked flame. Keep the area well-
ventilated and keep naked flames/sparks away when handling the battery.
Engine becomes extremely hot during and for some time after operation.
Keep combustible materials well away from generator area. Be very careful
not to touch any parts of the hot engine especially the muffler area or
serious burns may result.
Keep children and all bystanders at a safe distance from work areas.
It is absolutely essential that you know the safe and proper use of the
power tool or appliance that you intend to use. All operators must read,
understand and follow the tool/appliance owners manual. Tool and appliance
applications and limitations must be understood. Follow all directions given
on labels and warnings. Keep all instruction manuals and literature in a safe
place for future reference.
Use only «Homologated» extension cords according to CEI 245-4. When a tool or appliance is
used outdoors, use only extension cords marked «For Outdoor Use». Extension cords, when not
in use should be stored in a dry and well ventilated area.
Always switch off generator’s circuit breaker and disconnect tools or appliances when not in use,
before servicing, adjusting, or installing accessories and attachments.
8
3. SPECIFICATIONS
SILENTSTAR
6000D M YN
SILENTSTAR
6500D T YN
LTP Power 230V (cosϕ=1) 5200 W 3600 W
COP Power 230V (cosϕ=1) 4400 W 3600 W
LTP Power 400V (cosϕ=0,8) -5200 W / 6500 VA
COP Power 400 V (cosϕ=0,8) -4400 W / 5500 VA
Noise Power Level (Lwa) 97 dB
ALTERNATOR
Nominal Voltage 230 V single phase 400 V three phases
Type Brushless, 2 poles
Voltage Regulation Condenser
Frequency 50 Hz
Single socket 230 V - 10/16 A SCHUKO 1 1
Single socket 230V IP44 - 16 A 1 1
Single socket 230V - 32A (CEE) 1 -
Three socket 400V - 3P+T+N 16A - 1
Voltmeter Serial
Frequencymeter Serial
Hourmeter Serial
ENGINE
Engine Model L100AE - YANMAR
Engine Type 4 stroke DIESEL
Cooling System Air cooled
Maximum Output 8,8 HP - 3000 rpm
Piston Displacement 435 cm3
Fuel Diesel
Fuel Tank Capacity 22 L
Autonomy at 3/4 Load 14 h 20
Starting System Electric
Electronic Oil Sensor Serial
Frame Sound proof canopy - Double layer panels
Dimensions LxlxH (mm) 860 x 560 x 720 mm
Packaging Dimensions LxlxH (mm) 1130 x 630 x 930 mm
Dry Weight 175 kg 180 kg
Gross Weight 190 kg 195 kg
9
4. CONTROL PANEL
1
7 8 9 1011
234
56
1Current leakage protection and circuit
breaker 7Single phase socket 230 V - 10/16 A
SCHUKO
2Voltmeter 8Single phase socket 230 V - 16 A CEE
3Hourmeter 9Single phase socket 230 V - 32 A - CEE
or Three phase socket 400 V - 3P+T+N 16 A
4Frequencymeter 10 Earth connection
5Emergency Stop 11 Connection for additional options
6Key Switch
10
5. PRE-OPERATION CHECK
CHECK ENGINE OIL
Before checking or refilling oil, be sure generator is located on stable and level surface with engine
stopped.
•
Remove oil filler cap (a) and check the engine oil level.
•
If oil level is below the lower level line (c), refill with suitable oil (see table) to upper level line (b). Do
not screw in the oil filler cap when checking oil level.
Oil Capacity Upper Level
SILENTSTAR 6000D MYN 1,6 L
SILENTSTAR 6000D TYN 1,6 L
•
Change oil if contaminated. (See «How-To» Maintenance.)
RECOMMENDED ENGINE OIL:
Use class SE (API classification) oil or a higher grade oil according to the table below. SAE 10W-30
is recommended for general, all temperature use. If single viscosity oil is used, select the appropriate
viscosity for the average temperature in your area.
Do not remove the fuel tank cap while the engine is running. Do not refuel
while smoking or near naked flame or other such potential fire hazards.
Otherwise fire accident may occur.
