Hand-HeldComputer�
SVersion
QuickStartGuide
June6,2007PN:8000136-001.A
Contents of the box:
The WORKABOUT PRO
This Guide
Additional documentation
(dependent on order)
Features: Front
Speaker Stylus
Microphone Port
Scan Bar
LED
Indicator
Tether Port
Beeper Port
DC Input LIF Port
LED
Indicator
Stylus
Microphone
Port
Battery Cover
Back Cover
Endcap
Features: Back and Keyboard
Features: Typical Variants
Version without
scanner or
GSM radio
Version with GSM
radio and scanner
in endcap
Version with serial
port in endcap
Version with scanner
in pod
Version with pistol grip
SIM Card Slot
(if present)
SD Card Slot
Note: The SIM Card slot
may be covered on your unit
Battery Contacts
FCC Labels
On/Off Switch
Battery Cover
Battery Fasteners
On/Off Switch
Features: The Battery Compartment Getting Started
Switch the hardware on.
Insert the battery.
Close and lock
the battery cover.
Over
1
2
3
ON
Battery Fasteners
Turn the fasteners towards
the centre of the unit
to lock the battery cover.
4Charge the battery. The power adaptor may
be plugged directly into the WORKABOUT PRO.
The WORKABOUT PRO may also be charged
in a Docking Station.
Note: Use only the
universal AC power
adaptor appoved by
Psion Teklogix for the
WORKABOUT PRO.
Allow the WORKABOUT PRO to charge
for 6 hours.
Note: Full battery performance is
only reached after the rst few full
charge/discharge cycles.
5 - 40°C
41 - 104°F 6h
5Turn the unit on. Press the Enter key
for a few seconds.
Orange FN Key
Blue FN Key
Enter Key
6Connect the WORKABOUT PRO to the
host computer. Connect using a Tether Port to
USB cable, or through a Docking Station.
7
8Congure ActiveSync. Follow the onscreen
instructions provided by ActiveSync to establish
a connection between the host computer and the
WORKABOUT PRO.
To turn the WORKABOUT PRO off, do one
of the following:
Press and release the Blue FN key, then press and•
release the Enter key.
Select• Shut down from the Start menu.
Resetting the unit
Important: Resetting may result in data loss.
To cold-reset the WORKABOUT PRO:
Press the Blue FN key, the Orange FN key, and the Enter key•
simultaneously for a few seconds. The WORKABOUT PRO
cold-resets.
During a cold reset, running programs are halted and RAM
memory is cleared. The contents of ash memory and the
registry are preserved. The operating system is reloaded.
To warm-reset the WORKABOUT PRO:
Press the Blue FN key and the Enter key simultaneously for a•
few seconds. The WORKABOUT PRO warm-resets.
During a warm reset, running programs are halted. The
contents of RAM, ash memory and the registry are preserved.
8000136-001
Rev. B
*8000136-001*
July 14, 2009 PN: 8000136-001.B
ISO 9001 Certied
Quality Management System
Hand-Held Computer
S Version
Quick Start Guide
Install ActiveSync®.
Go to http://go.microsoft.com/fwlink/?LinkId=147001 and
follow the instructions to download and install
ActiveSync 4.5 or higher.
Note: ActiveSync is not needed when connecting
to a host computer that uses the Windows®Mobile
Device Center (such as Microsoft®Windows Vista®).
