Worcester GreenStar DanesMoor Manual de usuario

GB/IE

USER INSTRUCTIONS

& CUSTOMER CARE GUIDE

8-716-106-255a (03.05)

GREENSTAR DANESMOOR

18-25kW

FLOOR STANDING OIL-FIRED CONDENSING BOILER

CONVENTIONAL FLUE & ROO SEALED FLUE

FOR FULLY PU PED OPEN VENT OR SEALED CENTRAL HEATING SYSTE S AND

DO ESTIC HOT WATER CYLINDERS

THE APPLIANCE IS FOR USE WITH 28 SECOND

KEROSENE ONLY

THE APPLIANCE IS FOR USE WITH 28 SECOND

KEROSENE ONLY

the nation’s favourite for

PLUMBING & HEATING SUPPLIES

SECURE PAYMENTS

shop online with confidence

FREE SHIPPING

on all orders over £100 to mainland UK

FINANCE AVAILABLE

spread the cost with low interest rates

PRICE MATCH

always get the best deals available

Boilers

Radiators

Heating controls



Cylinders

Fires

Renewable energy

Bathroom suites

Kitchen sinks & taps

Showers

Wet rooms

Towel warmers

Bathroom furniture

& much more

HUGE REDUCTIONS

we have

ON THOUSANDS OF ITEMS

0844 800 3460

CALL US ON

visit our website

plumbnation.co.uk

USER INSTRUCTIONS & CUSTO ER

CARE GUIDE

CONTACT INFOR ATION

USER INSTRUCTIONS & CUSTO ER CARE GUIDE

8-716-106-255a (03.05)







THESE INSTRUCTIONS ARE APPLICABLE TO

THE WORCESTER BOSCH APPLIANCE

ODEL(S) STATED ON THE FRONT COVER OF

THIS ANUAL ONLY AND UST NOT BE USED

WITH ANY OTHER AKE OR ODEL OF

APPLIANCE.

IF YOU ARE IN  CONTACT THE

WORCESTER BOSCH TECHNICAL HELPLINE.

PLEASE KEEP THESE INSTRUCTIONS WITH

THE INSTALLATION AND SERVICING

INSTRUCTIONS IN A SAFE PLACE OR WITH

THE APPLIANCE AFTER INSTALLATION OR

SERVICING.





WORCESTER BOSCH:

TEL: FAX:

 !""#$$"%&'(

UK: 08547 256206 757536

SCOTLAND ONLY: 01506 - 441687

EIRE: 01494 0099

&)%*+!!'(

AIN RECEPTION: 01905 754624 754619

TECHNICAL: 08705 266241

SPARES: 01905 752571

LITERATURE: 01905 752556

SALES: 01905 752640

WEBSITE: www.worcester-bosch.co.uk

WATER TREATMENT:

FERNOX 01799 550811

www.fernox.com

SENTINEL 0151 420 9595

www.betzdearborn.com/sentinel

FLUE TERMINAL GUARDS:

WORCESTER BOSCH

OIL FIRING TECHNICAL ASSOCIATION:

OFTEC 0845 6585080

www.oftec.org

ABBREVIATIONS:

Ø Diameter

CH Central Heating

DHW Domestic Hot Water

TRV Thermostatic Radiator Valve

IP Ingress Protection

CF Conventional flue

RS Room sealed flue

N/A Not allowed

PCB Electronic Printed Circuit Board

SEDBUK Seasonal Efficiency for Domestic Boilers

in the United Kingdom

OFTEC Oil Firing Technical Association for the

Petroleum Industry

USER INSTRUCTIONS & CUSTO ER CARE GUIDE

8-716-106-255a (03.05)

 

,



 





CONTENTS



SAFETY PRECAUTIONS 2

EXCELLENCE CO ES AS STANDARD 3

GENERAL INFOR ATION 4-6



CONTROLS 7

OPERATING THE APPLIANCE

Switching the boiler on/off 8

Setting the heating temperature 8

Controlling central heating 8

Frost protection 9

Fault conditions 10

,

TIPS ON ENERGY SAVING 11-12



AINTAINING YOUR APPLIANCE 13

FAULT FINDING 14

FAULT OR BREAKDOWN 15



GUARANTEE 16

GUARANTEE REGISTRATION 17

USER INSTRUCTIONS & CUSTO ER CARE GUIDE



8-716-106-255a (03.05)

SAFETY PRECAUTIONS



OIL SMELLS, LEAKS OR FUMES FROM THE

APPLIANCE:

Extinguish any naked flames

Open windows and doors

Switch off the appliance electricity supply

Isolate the fuel supply to the boiler

Contact boiler engineer

HEALTH & SAFETY:

The appliance contains no asbestos and no

substances have been used in the construction

process that contravene the COSHH Regulations

(Control of Substances Hazardous to Health

Regulations 1988). Where applicable, the CE

mark indicates compliance with relative EU

Directives.

COMBUSTIBLE AND CORROSIVE

MATERIALS:

Do %-& store or use any combustible materials

(paper, thinners, paints etc.) inside or within the

vicinity of the appliance.

The combustion air must be kept clear of

chemically aggressive substances which can

corrode the appliance and invalidate any warranty.

FITTING & MODIFICATIONS:

Fitting the appliance and any controls to the

appliance may only be carried out by a competent

engineer in accordance with the relevant

Installation Regulations.

Flue systems must not be modified in any way

other than as described in the fitting instructions.

Any misuse or unauthorised modifications to the

appliance, flue or associated components and

systems could invalidate the warranty. The

manufacturer accepts no liability arising from any

such actions, excluding statutory rights.

SERVICING:

The user must have the system regularly serviced

by a competent, qualified OFTEC registered

engineer using approved spares, to help maintain

the economy, safety and reliability of the

appliance.

The appliance should be serviced once each

year after installation unless the installation

conditions and usage demand more frequent

services.

DO NOT OPERATE THE APPLIANCE WHEN:

The appliance, flue or system is incorrectly fitted,

faulty or damaged

The flue terminal outlet fitted on the outside wall

or roof is obstructed or damaged

There are fumes, fuel leaks or fuel smells from

the fuel supply, appliance or flue system

The system is empty or frozen

The condensate pipe is blocked or restricted

The appliance clearances are inadequate

The air supply is restricted or vents damaged.

USER INSTRUCTIONS & CUSTO ER CARE GUIDE



8-716-106-255a (03.05)

Thank you for purchasing a Greenstar oil-fired

condensing boiler from Worcester Bosch. The

company prides itself on manufacturing boilers to

the strictest quality control standards throughout

every stage of production.

Worcester Bosch has led the field in innovative

appliance design and performance for more than

40 years. This heritage means all products are of

exceptional quality and proven reliability.

The condensing range in particular, is extremely

energy efficient, converting more of the fuel

consumed into heat offering you economical running

costs and value for money. It sits in SEBUK band

A, at the top of the energy rated appliances available.

There is also the assurance of our no-nonsense

parts and labour guarantee - backed up by

'Worcester Total Cover', an optional complete

maintenance scheme to keep your boiler operating

at peak condition and efficiency.

To find out more about Worcester Bosch, use the

'Contact Information' shown on the inside front

cover.

EXCELLENCE CO ES AS

STANDARD

EXCELLENCE CO ES AS STANDARD

USER INSTRUCTIONS & CUSTO ER CARE GUIDE



8-716-106-255a (03.05)

GENERAL INFOR ATION

Read these instructions carefully to get the best

from your appliance.

CENTRAL HEATING SYSTEMS:

During the first few hours of operation of the central

heating system, check that all radiators are being

heated at an even rate.

If the top of a radiator is at a lower temperature

than the bottom then it should be vented by releasing

air through the venting screw at the top of the

radiator. Ask your installer to show you how this is

done. Repeated venting will reduce the quantity of

water in the system and this must be replenished

for safe and satisfactory operation of the appliance.

When excessive venting or water leaks are found

in the system you must contact a service engineer

to inspect the installation and rectify any fault.

Only use additives compatible with the appliance

and system. Use of incompatible additives can cause

damage and will invalidate the appliance guarantee.

Sealed eating systems:

Where the appliance is fitted to a sealed heating

system your installer will inform you of the minimum

and maximum pressure which must be indicated

on the pressure gauge.

Regularly check the pressure is maintained and

contact your installer or maintenance engineer if

there is a noticeable, permanent drop in pressure.

If the system loses pressure it should be

repressurised and the cause of the fall investigated.

CONDENSATE:

This is a high efficiency appliance using condensing

technology which will under normal operation

produce a regular discharge of condensate to drain

and at times, give out a plume of water vapour from

the flue terminal.

ROOM THERMOSTAT:

A room temperature controller must be fitted to

control the central heating. Refer to the instructions

supplied with the thermostat for information on

siting and setting.

THERMOSTATIC RADIATOR VALVES:

It is recommended that this type of valve is fitted

to all but one of the radiators (or at least those in

the sleeping accommodation). The remaining

radiator, which must be where the room thermostat

is located, should be un-controlled and must be

left open.

USER INSTRUCTIONS & CUSTO ER CARE GUIDE



8-716-106-255a (03.05)

BOILER LOCATION:

This boiler is only suitable for installing internally

within a property at a suitable location onto a fixed

rigid non-combustible surface at least the same size

as the boiler and capable of supporting the boiler

weight.

The boiler is not suitable for external installation

unless a suitable enclosure is provided.

Roof space installations must fully conform to

BS5410 part 1 section 4.6.9





VENTILATION:

Air vents must be functional at all times and the air

supply must not be restricted or contaminated.

The appliance clearances must meet the minimum

shown opposite for servicing and venting purposes.

* If this clearance is less than 75mm the flue 'knock-

out' panel sections must be removed to improve

air circulation and cooling.

Do not place clothes or objects to hinder the air

circulation required by the appliance.

Conventional flue appliances require an adequate

supply of fresh air which must be delivered to the

boiler for combustion purposes through a permanent

inlet, such as an air brick, into the area where the

boiler is situated.

600mm

300mm

5mm*

380mm

1200mm

1150mm

Conventional flued appliances:

inimum area of air inlet for combustion:

110cm² for 18/25kW appliances.

GENERAL INFOR ATION



USER INSTRUCTIONS & CUSTO ER CARE GUIDE



8-716-106-255a (03.05)

If a cupboard or compartment which is to be used

for storage or airing is built around the appliance

after installation there must be a non-combustible

partition around the boiler. Further information can

be found in BS 5410 which also describes venting

requirements.

Venting compartments:

 Ventilation must be provided for boilers fitted

into compartments as described in BS 5410

 A minimum of 2 air vents must be fitted, one at

low level and another at high level onto the same

wall using the same air for circulation.

Free air must not be taken from a room or internal

space containing a bath or shower and must not

communicate with a protected area such as a

hall, stairway, landing, corridor, lobby, shaft etc.

 Air vents must allow access for clean free air

and must be sited to comply with the flue terminal

position requirements.

 Air ducting runs must not exceed 3m.

 Low level air vents must be less than 450mm

from the floor.

A warning label must be added to the vents with

a statement to the effect: ''Do not block this vent.

Do not use for storage'.

Internal* ventilation

High

Level

Low

Level

External** ventilation

High

Level

Low

Level

18/25 220 330 110 220

18/25 220 220 110 110

Internal* ventilation

High

Level

Low

Level

External** ventilation

High

Level

Low

Level

GENERAL INFOR ATION

*Internal air to and from a space/room inside the building.

**External air to and from directl outside the building.

Conventional flue:

Room Sealed flue:

MINIMUM AIR VENT AREA (cm²) FOR

APPLIANCES INSTALLED IN A COMPARTMENT:

USER INSTRUCTIONS & CUSTO ER CARE GUIDE





8-716-106-255a (03.05) CONTROLS

CONTROLS

A Central heating temperature control

B Lock-out indicator

C Heating demand indicator

D Optional internal programmer (see instructions

supplied with programmer for details)

E Reset button - burner lock-out (behind front

panel)

F Reset button - boiler overheat thermostat (behind

front panel)

G Reset button - flue overheat thermostat (behind

front panel)

H Holder for User Guide

J Front panel

OFF

TIMED

ONCE

OFF

TIMED

ONCE

HOT WATER CENTRAL HEATING

ADVANCE SET ? ADVANCE

SELECT SELECTYES

HJG

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Caldera de Worcester

Worcester

Worcester 12/18 Manual de usuario

Worcester

Worcester 24Si II series Guía del usuario

Worcester

Worcester GB162-50 V2 Guía del usuario

Worcester

Worcester danesmoor 50/70 Guía del usuario

Worcester

Worcester GREENSTAR II HE OIL 12/22 Guía del usuario

Worcester

Worcester Greenstar CDi Compact Series Manual de usuario

Worcester

Worcester Greenstar Danesmoor 25kW Manual de usuario

Worcester

Worcester Greenstar CDi Manual de usuario

Worcester

Worcester GB162 Manual de usuario

Worcester

Worcester Greenstar CDi Manual de usuario

Worcester

Worcester GREENSTAR CAMRAY KITCHEN Manual de usuario

Worcester

Worcester 28i RSF Guía del usuario

Worcester

Worcester 29CDi GC 47-406-34 Guía del usuario

Worcester

Worcester ZWBR 7-30 R 30 HE PLUS COMBI Manual de instalación y operación

Worcester

Worcester danesmoor 50/70 Manual de usuario

Worcester

Worcester Greenstar Heatslave II External 12/18 Manual de usuario

Worcester

Worcester Greenstar i System Compact ErP Series Manual de usuario

Worcester

Worcester GREENSTAR HEATSLAVE12/18 Manual de usuario

Worcester

Worcester 26CDi Xtra Guía del usuario

Worcester

Worcester Highflow 400 BF Guía del usuario

Worcester

Worcester Greenstar 8000 Style Series Manual de usuario

Worcester

Worcester GREENSTAR 24i junior Manual de usuario

Worcester

Worcester GREENSTAR 30CDi Classic System ErP 41-406-37 Manual de usuario

Worcester

Worcester OIL HEATSLAVE 12/14 Guía del usuario

Manuales populares de Caldera de otras marcas

Vaillant

Vaillant uniSTOR VIH SW GB 500 BES Manual de usuario

Radijator

Radijator BIO max 23.1 Manual de usuario

Brunner

Brunner BSV 20 Manual de usuario

Buderus

Buderus Logamax GB062-24 KDE H V2 Manual de usuario

Potterton

Potterton 50e Hoja de datos

UTICA BOILERS

UTICA BOILERS TriFire Manual de usuario

Joannes

Joannes LADY Series Manual

ECR International

ECR International UB90-125 Manual de instrucciones

Froling

Froling FHG Turbo 3000 Manual de usuario

Froling

Froling P4 Pellet 8 - 105 Manual de usuario

U.S. Boiler Company

U.S. Boiler Company K2 Manual de usuario

Henrad

Henrad C95 FF Manual de usuario

NeOvo

NeOvo EcoNox EF 36 Manual de usuario

Potterton

Potterton PROMAX SL 12 Manual de usuario

Eco Hometec

Eco Hometec EC 25 COMPACT Manual de usuario

Viessmann

Viessmann VITODENS 200 Guía

Baxi

Baxi Prime 1.24 Manual de usuario

REXNOVA

REXNOVA ISA 20 BITHERMAL Manual de usuario
