Wolf ICBCI243TF/S Guía

ICB REVISED 4 / 2018

INDUCTION COOKTOP DESIGN GUIDE

TABLE OF CONTENTS

3INDUCTION COOKTOPS

Features and specications are subject to change at any

time without notice.

Throughout this guide, dimensions may vary by ± 3 mm.

English

INDUCTION COOKTOPS

Induction Cooktops

Almost instantaneous temperature response. Practically no

wasted heat. Induction cooking has been popular among

European chefs and homeowners for decades. Now Wolf

leads the way in bringing this remarkable technology to your

kitchen. Its secret is magnetism. Electro-magnetic elements

cause iron and magnetic stainless cook-ware to heat up

instantly and with perfectly distributed heat. Heat generation

stops the instant you turn off the element or remove the

pan. The cooktop’s surface remains cool. Your kitchen stays

cooler too. Transitional models have a brushed stainless

steel trim. Contemporary models can be mounted flush with

the countertop.

The following models have the same stainless steel frame as

our module cooktops for paired installations: ICBCI243TF/S,

ICBCI304TF/S, and ICBCI365TF/S.

ICBCI365C/B

ICBCI365TF/S

ICBCI304C/B

ICBCI243TF/S

INDUCTION COOKTOPS

TRANSITIONAL

CONTEMPORARY

ICBCI243C/B

INDUCTION COOKTOPS

ICBCI365T/S

ICBCI304T/S

ICBCI304TF/S

subzero-wolf.com.au

Induction Cooktops

60 cm TRANSITIONAL

INDUCTION COOKTOPS

914 mm

533

64 mm

CONDUIT

32 mm

91 cm CONTEMPORARY

762 mm

533

64 mm

CONDUIT

32 mm

76 cm CONTEMPORARY

51 mm

CONDUIT

32 mm

600 mm

533

600 mm

533

64 mm

CONDUIT

32 mm

60 cm CONTEMPORARY

INDUCTION COOKTOPS

91 cm TRANSITIONAL

914 mm

533

51 mm

CONDUIT

32 mm

762 mm

533

51 mm

CONDUIT

32 mm

76 cm TRANSITIONAL

English

INDUCTION COOKTOPS

Planning Information

A minimum height clearance of 159 mm is required from the

top of the countertop to any combustible surface directly

below the cooktop.

Contemporary induction cooktops can be mounted ush

with the top of the countertop, or as a frameless standard

installation sitting on top of the countertop surface. If the

cooktop is to be mounted ush with the countertop, a

recessed area surrounding the cooktop cut-out must be

provided. Wolf downdraft systems cannot be used with

contemporary induction cooktops.

IMPORTANT NOTE: Flush mount installations are intended

for granite, solid surface or stone countertop surfaces only.

ELECTRICAL

Installation must comply with all applicable electrical codes

and be properly grounded (earthed).

Locate the electrical supply as shown in the illustrations on

the following pages. A separate circuit, servicing only this

appliance is required.

Performance may be compromised if the electrical supply is

less than 220 volts.

The cooktop is supplied with a single phase and 3-phase

convertible power inlet box.

ELECTRICAL REQUIREMENTS

INDUCTION COOKTOPS SINGLE PHASE 3-PHASE

Required Power Supply 220-240 V AC

50/60 Hz

380-415 V AC

50 Hz

TOTAL AMPS SINGLE PHASE 3-PHASE

60 cm Induction 30 16

76 cm Induction 32 16

91 cm Induction 48 16

INDUCTION COOKTOPS |

Induction Cooktops

ELEMENT RATING

60 cm COOKTOP W

279 mm 2600 | 3150 boost

203 mm 2100 | 3000 boost

203 mm 2100

76 cm COOKTOP W

279 mm 2600 | 3150 boost

203 mm 2100 | 3000 boost

203 mm 2100

152 mm 1400

91 cm COOKTOP W

279 mm 2600 | 3700 boost

(2) 203 mm 2100 | 3000 boost

(2) 203 mm 2100

subzero-wolf.com.au

INDUCTION COOKTOPS

COUNTERTOP CUT-OUT

254 mm

114 mm

89 mm

FRONT VIEW

SIDE

VIEW

NOTE: Shaded area above countertop indicates minimum clearance to combustible surfaces,

combustible materials cannot be located within this area or must be treated.

Electrical supply location only applies to installations with built-in oven.

min 650

330

min457

WIDTH

495

64 mm

914 mm

FLOOR TO

COUNTERTOP

CUT-OUT WIDTH W

60 cm Cooktop 562 mm

76 cm Cooktop 737 mm

91 cm Cooktop 889 mm

60 cm | 76 cm | 91 cm Induction Cooktop

STANDARD INSTALLATION

English

INDUCTION COOKTOPS

60 cm | 76 cm | 91 cm Induction Cooktop

FLUSH INSTALLATION

RECESS

537 mm

RECESS

40 mm min

CUT-OUT WIDTH

COUNTERTOP CUT-OUT

495

64 mm

254 mm

114 mm

89 mm

FRONT VIEW

SIDE

VIEW

NOTE: Shaded area above countertop indicates minimum clearance to combustible surfaces,

combustible materials cannot be located within this area.

Electrical supply location only applies to installations with built-inoven.

Outside corner radius 11 mm.

min 650

330

min 457

8 mm

mm MAX

COUNTERTOP

PROFILE

914 mm

FLOOR TO

COUNTERTOP

CUT-OUT WIDTH W A

60 cm Cooktop 562 mm 603 mm

76 cm Cooktop 737 mm 765 mm

91 cm Cooktop 889 mm 918 mm

INDUCTION COOKTOPS

Wolf Appliance International Limited Warranty

FOR RESIDENTIAL USE

FULL TWO YEAR WARRANTY*

For two years from the date of original installation, this Wolf Appliance product warranty covers all parts

and labor to repair or replace, under normal residential use, any part of the product that proves to be

defective in materials or workmanship. All service provided by Wolf Appliance under the above warranty

must be performed by Wolf factory certied service, unless otherwise specied by Wolf Appliance, Inc.

Service will be provided during normal business hours.

LIMITED THIRD THROUGH FIFTH YEAR WARRANTY

For ve years from the date of original installation, Wolf Appliance will repair or replace the following parts

that prove to be defective in materials or workmanship: gas burners (excluding appearance), electric

heating elements, blower motors (ventilation hoods), electronic control boards, magnetron tubes and

induction generators. The part(s) will be repaired or replaced, free of charge, with the owner paying for

all other costs including labor. All service provided by Wolf Appliance under the above warranty must be

performed by Wolf factory certied service, unless otherwise specied by Wolf Appliance, Inc. Service will

be provided during normal business hours.

For more information regarding your Wolf product warranty, contact your authorized Wolf dealer. Warran-

ties must comply to all country, state, city, local and or ordinance.

*Stainless steel (doors, panels, handles, product frames and interior surfaces) are covered by a limited

60-day parts and labor warranty for cosmetic defects.

SUBZERO-WOLF.COM.AU
